Thunder TDR11010 12/24V Roof Lights Rocker Switch
A 12/24V roof lights rocker switch from Thunder, the TDR11010 features a 20A rating, blue backlit icon, and off-on SPDT function for controlling roof light operation.
Product overview
Thunder's range of illuminated switches will make sure you turn on the right equipment when you need it. Each with a 20A, 12/24V draw, all rocker switches offer a twin action and blue backlit icons for easy identification.
Thunder panels, sockets, and gauges are designed to work hand in hand, providing a simple information display solution customised to your needs. Just select the mount you need, flush or surface, pick up the sockets and gauges you need, and install them into your vehicle.
Features and benefits
12/24V compatibility: Suits both standard 12V passenger vehicles and 24V commercial vehicles and equipment.
20 amp rating at 12V: Provides sufficient current capacity for roof light control applications.
Off-On SPDT function: Provides simple on and off control for connected roof lights.
Blue LED backlit icon: Clearly identifies the switch function for easy operation, even in low light conditions.
5 terminal, single pole, 2 position design: Provides the wiring configuration required for roof light control.
Part of the Thunder panel and socket range: Designed to work alongside Thunder's broader range of panels, sockets, and gauges for a customised in-vehicle setup.
Technical specs
| Specification |
Detail |
| SKU |
TDR11010 |
| Brand |
Thunder |
| Type |
Roof Lights Rocker Switch |
| Voltage |
12/24V |
| Amp Rating |
20A @ 12V |
| Mounting Hole |
21mm x 37mm |
| Poles |
1 |
| Positions |
2 |
| Terminals |
5 |
| Function |
Off-On, SPDT |
| Display |
Blue LED |
Compatible with
The TDR11010 is compatible with 12V and 24V roof light systems requiring an off-on control switch, and Thunder's range of panels, sockets, and gauges.
Frequently asked questions
What is the TDR11010 used for?
The TDR11010 is a rocker switch designed for controlling roof light operation, using an off-on function to switch roof lights on and off.
What voltage does the TDR11010 support?
The TDR11010 supports both 12V and 24V systems.
What amperage is the TDR11010 rated to?
The TDR11010 is rated to 20A at 12V.
Does the TDR11010 illuminate?
Yes. The TDR11010 features a blue LED backlit icon for easy identification.
How many terminals does the TDR11010 have?
The TDR11010 has 5 terminals, with a single pole and 2 position SPDT function.
