250 watts per channel. 500 watts bridged. Punch EQ2 tone control and real-time output monitoring. Product Overview The Rockford Fosgate P500X2 is a 2-channel Class A/B stereo amplifier from the Punch series, delivering 250W RMS per channel into 2-ohm loads or 150W per channel at 4 ohms. When bridged, it combines both channels into a single 500W RMS mono output at 4 ohms, making it a capable driver for a pair of 8-ohm SVC subwoofers in parallel, or a quad configuration of 2-ohm DVC subwoofers. Total rated output is 500W RMS, CEA-2006 verified. Where the P500X2 stands apart within the Punch 2-channel range is its Punch EQ2 tone control system a dual-band EQ offering up to +18dB of bass boost at 45Hz and up to +12dB of treble lift at 12kHz, with the active EQ function varying depending on the amplifier's LP/AP/HP crossover switch position. Combined with a tri-colour output clip LED that displays real-time THD levels, an independent input clip LED, and thermal protection monitoring, the P500X2 gives the installer and listener more visibility into amplifier performance than any other unit in the Punch stereo range. Wide input sensitivity (150mV–12V) supports a broad range of source units, and Captive C-Clamp connectors on both power and speaker terminals provide a secure, vibration-resistant connection. Key Specifications Channels: 2 Rated power @ 4 ohms: 150W RMS x 2 Rated power @ 2 ohms: 250W RMS x 2 Rated power bridged @ 4 ohms: 500W RMS x 1 Total rated power: 500W RMS (CEA-2006) Dynamic power @ 4 ohms: 223W x 2 (PowerCube) Dynamic power @ 2 ohms: 365W x 2 (PowerCube) Bridgeable: Yes — 500W x 1 @ 4 ohms Circuit topology: Class A/B Efficiency (average): 73% @ 4 ohms Frequency response: 20Hz – 20kHz (+/-1dB) Input sensitivity: 150mV – 12V THD+Noise: <1.0% @ 4 ohms / <1.0% @ 2 ohms Punch EQ2 Bass: 0dB to +18dB @ 45Hz Punch EQ2 Treble: 0dB to +12dB @ 12kHz Crossover: 12dB/octave Butterworth — LP / AP / HP switch Signal input: Hi/Low level, 1 x RCA pair Signal output: 1 x RCA pair (pass-through) Remote control: Optional PLC2 (not included — sold separately) Visual indicators: Power / Protect / Thermal LED, Input Clip LED, Output Clip LED (tri-colour THD) Power wire gauge: 4 AWG Power input connector: Captive C-Clamp Speaker wire gauge: 8 AWG – 18 AWG Speaker output connector: Captive C-Clamp Cooling: Convection Operating voltage: 9–16V DC Recommended fuse: 80A (not included) Average current draw: 40A @ 13.8V (music) Max current draw: 80A @ 13.8V (sinewave) Suggested alternator: 75A minimum Dimensions (H x W x D): 6.05 x 19.71 x 33.73 cm Shipping weight: 5.57 kg Compliance: CEA-2006 Features & Benefits 250W Per Channel @ 2Ω | 500W Bridged @ 4Ω — Full Flexibility — Run in stereo at 250W per channel for a pair of speakers, or bridge to a single 500W mono output for a subwoofer configuration. The P500X2 covers both use cases from one chassis — useful for systems that may evolve from a speaker-focused build to one incorporating a dedicated subwoofer without requiring a second amplifier purchase. Punch EQ2 — Dual-Band Bass and Treble Control — Unlike the single-band Punch EQ found on other amplifiers in the range, the Punch EQ2 includes both a bass control (0dB to +18dB @ 45Hz) and a treble control (0dB to +12dB @ 12kHz). The active EQ band changes depending on the crossover switch position — in Low-Pass mode the bass EQ is operative, in High-Pass mode the treble EQ is operative, and in All-Pass (bypass) mode both bands can be used simultaneously. This allows frequency-appropriate tuning regardless of how the amplifier is deployed in the system. Tri-Colour Output Clip LED — Real-Time THD Monitoring — The output clip LED displays three distinct states based on measured distortion at the output stage: blue indicates clean output below 0.5% THD, violet indicates approaching 1% THD, and red signals 10% or greater THD — a level that causes audible distortion and risks speaker damage. This real-time feedback allows gain calibration confirmation after installation and ongoing monitoring during use. It is one of the most practical diagnostic tools available on an amplifier at this price point. Independent Input Clip LED — A separate LED monitors the incoming signal for clipping before it enters the amplifier. Combined with the output clip LED, this allows the installer to distinguish between clipping at the source (head unit or preamp) and clipping generated within the amplifier itself — essential for accurate gain structure setup. C.L.E.A.N. Setup System — The on-board C.L.E.A.N. calibration system works alongside the clip LEDs to guide precise gain matching between the source unit and the P500X2. Together, these tools eliminate the guesswork that causes premature speaker failure from miscalibrated gain settings. Wide Input Sensitivity (150mV – 12V) — An unusually broad input sensitivity range accommodates everything from low-output factory head units to high-output aftermarket preamps without requiring external level adjustment. This extends compatibility across a wide range of source units in new and factory-retained head unit configurations. High-Level Input with Auto Turn-On — Accepts speaker-level signal from factory head units and powers on automatically when signal is detected — no remote turn-on wire required. The wide 150mV–12V sensitivity range further simplifies integration with both OEM and aftermarket systems. Optional PLC2 Remote Level Control — The P500X2 is wired and ready for the Rockford Fosgate PLC2 (sold separately), adding driver-accessible output adjustment and activating the input clip indicator for front-seat gain monitoring. Not included — sold separately. Captive C-Clamp Connectors — Power input and speaker output terminals use Captive C-Clamp connectors rather than standard screw terminals. The C-Clamp design applies distributed clamping pressure across a wider contact area, providing a more vibration-resistant and mechanically secure connection — particularly beneficial in vehicles subject to road vibration, off-road use, or high-power current demands. RCA Pass-Through Output — Signal chains cleanly to a second amplifier via the RCA pass-through — useful in systems running the P500X2 on speakers alongside a separate Punch mono amplifier handling subwoofer duty. LP / AP / HP Crossover Switch — The three-position crossover switch configures the P500X2 as a low-pass filtered amplifier (sub channel), all-pass (full-range), or high-pass filtered (speaker channel in a crossed-over system), each mode also governing which EQ band of the Punch EQ2 is active. Crossover frequency range is not specified in the provided data — confirm with Rockford Fosgate. Thermal LED + Full Protection — A dedicated thermal LED provides visual warning of elevated operating temperatures before the protection circuit activates. Over-current and short-circuit protection are active across both channels, and muted turn-on prevents power-up thumps that can stress tweeters. Technical Specs Specification Detail Channels 2 Rated power @ 4Ω 150W RMS x 2 Rated power @ 2Ω 250W RMS x 2 Rated power — bridged @ 4Ω 500W RMS x 1 Total rated power 500W RMS Dynamic power @ 4Ω 223W x 2 (PowerCube) Dynamic power @ 2Ω 365W x 2 (PowerCube) Bridgeable Yes Circuit topology Class A/B Efficiency (average) 73% @ 4Ω Frequency response 20Hz – 20kHz (+/-1dB) Input sensitivity 150mV – 12V THD+Noise <1.0% @ 4Ω / <1.0% @ 2Ω Punch EQ2 Bass 0dB to +18dB @ 45Hz Punch EQ2 Treble 0dB to +12dB @ 12kHz Crossover LP / AP / HP switch — 12dB/octave Butterworth Crossover frequency range Not specified Signal input Hi/Low level, 1 x RCA pair Signal output 1 x RCA pair (pass-through) Remote control Optional PLC2 (sold separately) Output clip LED Tri-colour: Blue (<0.5% THD) / Violet (1% THD) / Red (10%+ THD) Input clip LED Yes Thermal LED Yes Power / Protect LED Yes Power wire gauge 4 AWG Power input connector Captive C-Clamp Speaker wire gauge 8 AWG – 18 AWG Speaker output connector Captive C-Clamp Cooling Convection Operating voltage 9–16V DC Recommended fuse 80A (not included) Average current draw 40A @ 13.8V (music) Max current draw 80A @ 13.8V (sinewave) Suggested alternator 75A minimum Dimensions (H x W x D) 6.05 x 19.71 x 33.73 cm Shipping weight 5.57 kg Compliance CEA-2006 Compatible With / Goes Well With Stereo speaker mode: 4-ohm coaxial or component speakers — 150W RMS per channel 2-ohm coaxial or component speakers — 250W RMS per channel Component speaker sets with passive crossovers (crossovers not supplied) Factory and aftermarket head units (150mV–12V input sensitivity) Bridged mono mode (500W @ 4Ω): Pair of 8-ohm SVC subwoofers wired in parallel (combined 4Ω load — confirmed by manufacturer) Quad configuration of 2-ohm DVC subwoofers wired to a combined 4Ω load (confirmed by manufacturer — specific wiring required; professional installation strongly recommended) Goes well with: Rockford Fosgate Punch series speakers (matched to 150W or 250W per channel) Rockford Fosgate P300X1 or Punch mono amplifier (via RCA pass-through for a full two-amp system) Rockford Fosgate PLC2 Remote Punch Level Control (optional — sold separately) Aftermarket head units with RCA preamp outputs (150mV–12V sensitivity compatible) Frequently Asked Questions What subwoofer configurations can the P500X2 drive when bridged? Bridged at 4 ohms, the P500X2 produces 500W RMS. The manufacturer confirms two configurations: a pair of 8-ohm SVC subwoofers wired in parallel, or a quad of 2-ohm DVC subwoofers in a specific series/parallel arrangement — both presenting a 4Ω load. Do not bridge below 4 ohms. What is Punch EQ2 and how does it differ from standard Punch EQ? Punch EQ2 is a dual-band tone control offering both bass boost (up to +18dB @ 45Hz) and treble boost (up to +12dB @ 12kHz). The active band changes depending on the LP/AP/HP crossover switch position — bass EQ in Low-Pass mode, treble EQ in High-Pass mode, and both available in All-Pass mode. What does the tri-colour output clip LED indicate? The output clip LED changes colour based on measured THD at the amplifier's output: blue indicates clean output below 0.5% THD, violet signals approximately 1% THD, and red indicates 10% or greater THD — audible distortion that risks speaker damage. It allows real-time gain monitoring without test equipment. Is the Punch Level Control included with the P500X2? No. The PLC2 remote Punch Level Control is an optional accessory sold separately. The P500X2 is fully wired to accept it, and when connected the PLC2 adds driver-accessible output adjustment and activates the input clip indicator for front-seat monitoring. What does CEA-2006 compliance mean for the P500X2? CEA-2006 requires power ratings to be measured simultaneously across all channels under defined conditions. The 250W x 2 and 500W bridged figures are verified, real-world specifications — not single-channel burst or inflated peak ratings. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Two channels. BRT efficiency. Built for motorcycles, ATVs, and stealth installs. Product Overview The Rockford Fosgate PBR300X2 is a 2-channel amplifier from the Punch series, delivering 300W total using Rockford Fosgate's patented BRT (Boosted Rail Technology). Unlike conventional 2-channel amplifiers that rely on a switching power supply to generate their output, BRT achieves rated power through an ultra-efficient design that eliminates the switching stage entirely resulting in a chassis significantly smaller than a traditional amplifier of equivalent output. Total power is 300W across two channels; power per channel and impedance breakdown are not specified in supplier-provided data. The PBR300X2 is positioned for installations where space and electrical draw are primary constraints. Motorcycles requiring stereo speaker output, ATVs, and recreational vehicles with limited mounting real estate are the target use cases along with stealth car and marine builds where a standard amplifier chassis simply won't fit. The variable 4–6V hi-level DC offset turn-on circuit allows direct integration with OEM speaker outputs in systems that don't provide a dedicated remote turn-on wire, while high-level inputs eliminate the need for an aftermarket head unit or RCA outputs. A 12dB/octave Butterworth crossover and MOSFET output stage complete a practical, installation-friendly feature set. Key Specifications Channels: 2 Total output power: 300W (power per channel and impedance breakdown — not specified) Power supply technology: BRT (Boosted Rail Technology — no switching power supply) Output stage: MOSFET Crossover: 12dB/octave Butterworth (frequency range — not specified) Signal input: High level Turn-on method: Variable hi-level DC offset (4–6V) Chassis: Ultra-compact Bridgeable: Not specified Frequency response: Not specified Input sensitivity: Not specified Nominal impedance: Not specified CEA compliance: Not specified in provided data Power wire gauge: Not specified Speaker wire gauge: Not specified Operating voltage: Not specified Recommended fuse: Not specified Dimensions: Not specified Features & Benefits BRT (Boosted Rail Technology) — No Switching Power Supply — The PBR300X2 uses Rockford Fosgate's patented BRT architecture to produce rated power without a conventional switching power supply. This reduces current draw, minimises electrical noise, and shrinks the chassis to a fraction of the size of a traditional 2-channel amplifier — making it viable for vehicle types and install locations that would otherwise rule out amplification entirely. Ultra-Compact Chassis — Stereo Power in a Stealth Footprint — Where the PBR300X1 delivers mono output for a single driver, the PBR300X2 provides two independent channels from the same compact BRT platform. This makes it the logical choice for motorcycle stereo builds — left and right speaker channels from a single unit that installs in a saddlebag, underseat compartment, or within a fairing. Exact dimensions are not specified in supplier data — confirm with Rockford Fosgate before planning a space-critical install. Variable Hi-Level DC Offset Turn-On (4–6V) — Motorcycles, ATVs, and many OEM car audio systems either lack a dedicated remote turn-on output or carry a DC offset on their speaker outputs. The PBR300X2's variable DC offset circuit detects a 4–6V signal on the speaker inputs and uses it to power the amplifier — removing the need to source and run a remote wire in installations where doing so is difficult or impossible. High-Level Inputs — Accepts signal directly from the speaker outputs of a factory head unit, OEM radio, or handlebar-mounted controller. No line output converter or aftermarket head unit is required, keeping the installation simple and the component count low — particularly relevant for motorcycle and recreational vehicle builds where simplicity and reliability matter. MOSFET Output Stage — The MOSFET output stage contributes to the compact, efficient character of the PBR300X2 and handles the variable voltage and vibration conditions common in motorcycle and off-road vehicle environments more reliably than earlier output stage designs. It also supports the BRT architecture's low-heat operating profile. 12dB/Octave Butterworth Crossover — The on-board Butterworth crossover allows the two output channels to be filtered, directing appropriate frequency ranges to different speakers in a system. The crossover frequency range is not specified in supplier data — confirm with Rockford Fosgate before planning a multi-speaker install. Technical Specs Specification Detail Channels 2 Total output power 300W Power per channel Not specified Power by impedance Not specified Power supply BRT — no switching power supply Output stage MOSFET Circuit topology Not specified Frequency response Not specified Input sensitivity Not specified THD+Noise Not specified Nominal impedance Not specified Bridgeable Not specified Crossover type 12dB/octave Butterworth Crossover frequency range Not specified Signal input High level Turn-on method Variable hi-level DC offset, 4–6V CEA compliance Not specified Power wire gauge Not specified Speaker wire gauge Not specified Operating voltage Not specified Recommended fuse Not specified Dimensions Not specified Weight 4.3 kg Compatible With / Goes Well With The PBR300X2 is confirmed by the manufacturer for use in the following applications: Motorcycles requiring 2-channel (stereo) speaker amplification ATVs and off-road recreational vehicles Smaller stealth car, marine, or custom installations with limited space OEM/factory audio systems (via variable hi-level DC offset turn-on) Goes well with: Compact 2-channel speakers suited to motorcycle, ATV, or stealth car audio builds Factory head units and OEM audio systems (high-level input compatible) Marine or weatherproof speaker enclosures for recreational vehicle applications Frequently Asked Questions What is BRT (Boosted Rail Technology) and why does it matter for a 2-channel amp? BRT is Rockford Fosgate's patented amplifier architecture that generates rated power without a switching power supply. The result is a significantly smaller and more efficient chassis than a conventional 2-channel amplifier — making stereo amplification viable in motorcycles, ATVs, and stealth builds where space and current draw are limited. How much power does each channel produce? Total power is 300W across both channels. The per-channel power rating and impedance breakdown are not specified in supplier-provided data. Contact Rockford Fosgate or your authorised dealer to confirm per-channel output before matching to speakers. Will the PBR300X2 work on a motorcycle or ATV? Yes. The PBR300X2 is specifically designed for motorcycles, ATVs, and recreational vehicles. The BRT architecture's low current draw and ultra-compact chassis make it practical for these applications, and the variable DC offset turn-on circuit supports OEM systems that lack a standard remote turn-on output. What is the variable DC offset turn-on circuit? Many motorcycle and OEM systems output a 4–6V DC offset on their speaker lines rather than a dedicated remote turn-on signal. The PBR300X2 detects this voltage and uses it to power the amplifier automatically — eliminating the need to wire a separate remote turn-on lead in most factory and recreational vehicle installations. Can the PBR300X2 be used in a standard car or truck installation? Yes, though it is engineered primarily for space-constrained and stealth applications. It suits any car or truck installation where a compact chassis, low current draw, and factory head unit compatibility are priorities. Standard amplifier features such as RCA inputs, Punch EQ, and remote level control are not confirmed in supplier data — verify the full feature set with Rockford Fosgate if these are required. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate P1000X2 1000 Watts, Two Channels, Zero Trunk Compromise Product Overview The Rockford Fosgate P1000X2 is a Punch Series 2-channel stereo amplifier built for car audio enthusiasts who demand serious output without sacrificing boot space. Rated at 500 watts RMS per channel at 2 ohms or bridged to deliver the full 1000 watts into a single mono load this amplifier is equally at home powering full-range and component speaker systems as it is driving a dedicated subwoofer configuration. Where the P1000X2 earns its place in a serious build is in its flexibility. It's optimally matched to a pair of 8-ohm SVC subwoofers or four 2-ohm DVC subwoofers when bridged, and its onboard Punch EQ with +18dB boost at 45Hz means you can dial in the low-end punch you're after without reaching for an external processor. The stealth top-mounted control panel keeps the setup clean, and the cast aluminium heatsink handles the heat critical in Australian climates where cabin temperatures can push gear hard on a summer run. Key Specifications Total RMS Output: 1000 watts Per-Channel Output: 500W x 2 at 2 ohms Channels: 2 (stereo or bridged mono) Bridgeable: Yes — 1000W mono Crossover: 12dB/octave Butterworth Onboard EQ: Punch EQ — +18dB boost at 45Hz Inputs: High-level (speaker-level) and RCA RCA Pass-Thru Outputs: Yes Auto Turn-On: Yes — via high-level input detection Remote Control: Optional PLC2 Punch Level Control (with input clip indicator) Turn-On Behaviour: Muted (no thump on startup) Heatsink: Cast aluminium Control Panel Position: Stealth top-mounted Protection: Short circuit and over-current Features & Benefits High-Level Input with Auto Turn-On — Connects directly to your factory head unit's speaker outputs, no RCA cables required. Ideal for OEM upgrades where aftermarket decks aren't an option. RCA Pass-Thru Outputs — Daisy-chain a second amplifier for subs or additional channels without signal loss back at the head unit. Keeps your wiring tidy in multi-amp builds. C.L.E.A.N. Setup (Clip Level Elimination Audio Notify) — Rockford Fosgate's built-in gain-setting tool takes the guesswork out of calibration, helping you maximise output without introducing distortion. Especially useful if you're setting up without a multimeter or test tone. Optional PLC2 Remote Punch Level Control — Mount a dash-accessible remote volume control for the amp's output. The input clip indicator lights up to show when you're pushing the signal too hard — real-time feedback without looking at the amp. 12dB/Octave Butterworth Crossover — Clean roll-off characteristics let you configure the amp for full-range, high-pass, or low-pass duties depending on your system layout, without phase issues at the crossover point. Onboard Punch EQ (+18dB @ 45Hz) — Targets the sub-bass frequencies that give music its physical impact. Tune the low-end to taste directly on the amp — no separate bass processor needed for most builds. Muted Turn-On — Eliminates the pop and thump on startup that can stress tweeters and give away a sloppy install. A small detail that separates a clean build from an amateur one. Stealth Top-Mounted Control Panel — All controls sit on top of the amp for easy access during setup and tuning, while keeping the side profile clean for tight mounting locations. Cast Aluminium Heatsink — Dissipates heat efficiently during extended listening sessions. In Australian conditions — long highway runs, hot car parks, summer road trips — thermal management matters more than most spec sheets suggest. Short Circuit & Over-Current Protection — Onboard protection circuits guard both the amplifier and your speakers against wiring faults or load mismatches. Technical Specs Specification Detail Total RMS Power 1000W Per-Channel RMS (2Ω) 500W x 2 Number of Channels 2 Bridged Mono Output 1000W Crossover Type Butterworth Crossover Slope 12dB/octave Onboard EQ +18dB boost at 45Hz Input Type High-level (speaker-level) + RCA RCA Pass-Thru Yes Auto Turn-On Yes (via high-level input) Remote Punch Level Control Optional (PLC2, sold separately) Input Clip Indicator Yes (via PLC2) Turn-On Mode Muted Heatsink Material Cast aluminium Control Panel Location Top-mounted (stealth) Short Circuit Protection Yes Over-Current Protection Yes Dimensions Not specified Signal-to-Noise Ratio Not specified THD Not specified Frequency Response Not specified Input Sensitivity Not specified Compatible With / Goes Well With Speaker Configurations: Full-range speaker systems (2-channel stereo) Component speaker systems (2-channel stereo) Pair of 8-ohm SVC subwoofers (bridged mono) Four 2-ohm DVC subwoofers (bridged mono) Accessories: Rockford Fosgate PLC2 Remote Punch Level Control (optional, sold separately) Recommended: use manufacturer-specified power and speaker cables to optimise power delivery (cable spec not provided — confirm with supplier) Head Unit Compatibility: Factory/OEM head units (via high-level input) Aftermarket head units with RCA pre-outs Frequently Asked Questions How much power does the P1000X2 actually produce per channel? In stereo mode, the P1000X2 delivers 500 watts RMS into each channel at 2 ohms — 1000 watts total. Always match speaker RMS ratings accordingly. Can the P1000X2 be bridged to run a single subwoofer? Yes. Bridged, the P1000X2 outputs 1000 watts mono. It's best matched to a pair of 8-ohm SVC subs or four 2-ohm DVC subwoofers in this configuration. Does the P1000X2 work with a factory head unit that has no RCA outputs? Yes. The high-level input allows direct connection to speaker-level outputs from an OEM or factory head unit, and the Auto Turn-On circuit eliminates the need for a remote turn-on wire. What does C.L.E.A.N. setup mean and do I need extra equipment to use it? C.L.E.A.N. (Clip Level Elimination Audio Notify) is Rockford Fosgate's onboard gain-calibration system. No additional tools are required — it guides you to the correct gain level without a multimeter or test equipment. Is the PLC2 remote punch level control included in the box? No. The PLC2 is an optional accessory sold separately. It adds a dash-mountable remote volume knob and a real-time input clip indicator — useful for daily-driver builds where you adjust bass on the fly. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Value-Packed And Purpose-Built For Quality Audio Amplification On The Water The FUSION AM Series marine amplifiers are purpose-built for the marine environment. Boasting some of the most impressive environmental protection available, they deliver performance on the water like never before. With 2 channels and a 400 Watt peak power output, the MS-AM402 will drive up to two subwoofers, an extra pair of speakers, or even 4 speakers (2 speakers in parallel each channel at 2 Ohms) to spread the sound around your vessel. Incorporating heat-tempered and conformal coated PCBs for maximum product life, and gold-plated connectors for improved signal flow, the MS-AM402 reproduces clean and powerful audio with enough power to rock the boat. Features: 400W peak power output to power up to four speakers Class-AB amplifier – power efficient with less cross-over distortion Conformal coated PCBs – water resistant protection from salt air and moisture FUTRANZ heat sink technology – transfers heat more efficiently and provides more thermal stability with maximum component reliability F.R.A.T (Fusion Regulated Amplifier Technology) – provides enormous power output at low voltage. F.I.S.T (Fusion Intercooled Semi-Conductor Technology) – clamps down internal power switching to rapidly remove heat from all associated semi-conductors 1 year limited Consumer Warranty Specifications: Amplifier Class Class-AB Rated Power (2 Ohms) 100 Watts RMS x 2 @ 14.4V - 2 Ohms 1% THD Rated Power (4 Ohms Bridged) 200 Watts RMS x 1 @ 14.4V - 4 Ohms Bridged 1% THD Frequency Response 5Hz - 38kHz +/- 3dB Peak Power 400 Watts Rated Power (4 Ohms) 65 Watts RMS x 2 @ 14.4V - 4 Ohms 1% THD Depth 229mm [9"] Height 53mm [2-1/16"] Length 296mm [11-/2/3"] Legendary Products & Support From Authorized Dealers When you choose Fusion, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Fusion dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Fusion's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Fusion dealer today!

Read more less

Rockford Fosgate M2-200X2 M2 Series 200 Watt 2-Channel Full-Range Class-D Element Ready Marine Amplifier A marine grade 200W 2-channel full-range Class-D amplifier delivering 100W x 2 at 2-ohm or 200W x 1 at 4-ohm bridged (CTA-2006 rated). Features C.L.E.A.N. gain calibration, P.O.W.E.R. supply, fully adjustable high-pass and low-pass crossovers, variable infrasonic filter, RCA pass-thru outputs, NOMAD speaker protection, MEHSA4 heat management, and conformal coated circuit board. Backed by a 2 year warranty. Product Overview The Rockford Fosgate M2-200X2 is a 200W 2-channel full-range Class-D marine amplifier from the M2 Element Ready series, purpose-built for powering marine speakers across the full audio spectrum. Full-Range Class-D topology delivers high-efficiency power delivery across a 20Hz-20kHz frequency response while reducing current demand on the vessel's electrical system. Rated continuous power is 50W x 2 at 4-ohm, 100W x 2 at 2-ohm, or 200W x 1 at 4-ohm bridged to mono (CTA-2006, less than 1.0% THD+N). Dynamic power via PowerCube reaches 60W x 2 at 4-ohm, 107W x 2 at 2-ohm, and 215W x 1 at 4-ohm bridged. The circuit board is conformal coated to protect electronics from dust and water, and the UV stable powder coated cast aluminium heatsink provides protection against the marine environment. Zinc nickel-plated marine grade brass connection terminals resist corrosion at the connection points. Fully adjustable 12dB/octave Butterworth high-pass and low-pass crossovers are included, along with an all-pass mode and variable infrasonic filter. RCA pass-thru outputs allow downstream amplifier chaining. Auto-Sense turn-on via high-level input removes the need for a dedicated remote wire, with a bypass switch available for vessels with Retained Accessory Power (RAP) systems. RATS tested for quality and performance and optimised using the AudioGraph PowerCube measurement tool. Features & Benefits Full-Range Class-D - Efficient 2-Channel Marine Amplification: Full-Range Class-D topology delivers high-efficiency power across the complete 20Hz-20kHz audio spectrum, reducing current demand on the vessel's electrical system compared to traditional Class-A/B designs while powering marine speakers with clean, accurate output. Bridgeable to 200W Mono: The M2-200X2 can be bridged to a single mono channel delivering 200W x 1 at 4-ohm (215W dynamic), making it usable as a subwoofer amplifier in smaller builds or as a dedicated mono driver for a single full-range speaker pair in more compact marine audio systems. C.L.E.A.N. Technology - Precision Gain Calibration: C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is a patented circuit with dedicated input and output clip indicator LEDs, enabling precise gain calibration at setup to maximise output while minimising distortion. Fully Adjustable Crossovers with All-Pass Mode: Both high-pass and low-pass crossovers are fully adjustable from 50Hz to 250Hz at 12dB/octave Butterworth, with an all-pass mode for full-bandwidth output when no crossover filtering is needed. A variable infrasonic filter from 50Hz to 250Hz is also available for additional low-frequency protection. RCA Pass-Thru Outputs for Downstream Chaining: RCA pass-thru outputs are active with both RCA and high-level input, allowing the signal to be passed to an additional amplifier - such as the M2-500X1 subwoofer amplifier - without signal degradation. Auto-Sense Turn-On with RAP Bypass: Auto-Sense activates the amplifier automatically when a high-level input signal is detected, removing the need for a dedicated remote turn-on wire. A bypass switch is included for vessels with Retained Accessory Power (RAP) systems to prevent the amplifier from remaining on after the ignition is switched off. NOMAD, MEHSA4, and Conformal Coated Circuit Board: NOMAD provides real-time protection against shorted speaker wires and dangerously low impedances. MEHSA4 (Maximum Efficiency Heat Sink Application) reduces MOSFET temperatures, lowers distortion, and extends output device life. The conformal coated circuit board protects the electronics against dust and water ingress at the PCB level. Technical Specs Specification Detail SKU M2-200X2 Number of Channels 2 Total Power 200W Rated Power - 4-ohm (CTA-2006, less than 1.0% THD+N) 50W x 2 Rated Power - 2-ohm (CTA-2006, less than 1.0% THD+N) 100W x 2 Rated Power - 4-ohm Bridged (CTA-2006) 200W x 1 Dynamic Power - 4-ohm (PowerCube) 60W x 2 Dynamic Power - 2-ohm (PowerCube) 107W x 2 Dynamic Power - 4-ohm Bridged (PowerCube) 215W x 1 Circuit Topology Full-Range Class-D Bridgeable Yes Frequency Response 20 Hz - 20 kHz THD + Noise Less than 1.0% at 4-ohm and 2-ohm Input Sensitivity Low-Level: 150mV - 4V / High-Level: 450mV - 12V Signal Input Low-Level: 2 x RCA / High-Level: 4-Pin Molex Signal Output 2 x RCA Pass-Thru (active with RCA or High-Level input) Tone Controls None High-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth Low-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth All-Pass Yes Infrasonic Filter Variable Remote Controls None Auto-Sense Turn-On Yes (with RAP bypass switch) Power Wire Gauge 4 AWG Power Input Connector Compression Terminal Block Speaker Wire Gauge 8 AWG Speaker Output Connector Compression Terminal Block Terminals Zinc Nickel-Plated Marine Grade Brass Cooling Convection Heatsink UV Stable Powder Coated Cast Aluminium (Focused Mass) Circuit Board Protection Conformal Coated Operating Voltage 9 - 16 VDC Recommended Fuse (not included) 30A Max Current Draw at 13.8V Sinewave 18A Visual Indicators Power/Protect / C.L.E.A.N. In / C.L.E.A.N. Out Dimensions (H x W x D) 49 x 173 x 205mm (1.9 x 6.8 x 8.1 inch) CTA-2006 Compliant Yes Quality Testing RATS (Rockford Automated Testing System) Warranty 2 Years Compatible With / Goes Well With The M2-200X2 suits marine watercraft and powersports applications requiring a compact, efficient 2-channel full-range amplifier for speaker pairs. At 18A maximum current draw and a 30A fuse requirement, it places minimal demand on the vessel's electrical system. It pairs naturally with the M2-500X1 mono subwoofer amplifier for a complete M2 series speaker and subwoofer system using the RCA pass-thru to chain the two amplifiers. Goes Well With: M2-500X1 - Companion M2 series 500W mono subwoofer amplifier, chainable via the M2-200X2's RCA pass-thru outputs for a complete M2 series system M2-8H - Rockford Fosgate M2 series 8 inch 2-way horn marine speakers, a matched pairing with the M2-200X2 for in-hull or in-dash mounting M2WL-8 / M2WL-8B - M2 series 8 inch wake tower speakers powered by the M2-200X2's stereo channels M5-800X4 - Higher output M5 series 4-channel marine amplifier for builds requiring more power than the M2-200X2 can provide per channel RFW4R / RFW4B - Rockford Fosgate 4 AWG amplifier wiring kits (red or black) matched to the M2-200X2's 4 AWG power wire requirement Frequently Asked Questions What is the difference between the M2-200X2 and the M5-800X4? The M2-200X2 is a 2-channel full-range Class-D marine amplifier rated at 100W x 2 at 2-ohm from the M2 Element Ready series, designed for accessible, space-efficient marine speaker amplification. The M5-800X4 is a 4-channel Class-AD marine amplifier rated at 100W x 4 at 2-ohm from the premium M5 series, adding two additional channels, IPX6 water intrusion rating, Punch EQ2, the PRESET feature, and significantly more installation flexibility. Choose the M2-200X2 for a compact, economical 2-channel solution; choose the M5-800X4 for a 4-channel build with premium marine protection. Can the M2-200X2 be used to power a subwoofer? Yes, when bridged to mono. In bridged mode the M2-200X2 delivers 200W x 1 at 4-ohm (215W dynamic), which is sufficient to drive a single 4-ohm marine subwoofer at moderate output levels. For dedicated subwoofer amplification with more power and a tunable Punch EQ, the M2-500X1 is the recommended companion amplifier. The M2-200X2's RCA pass-thru outputs allow it to chain directly to the M2-500X1 in a two-amplifier system. Does the M2-200X2 need a dedicated remote turn-on wire? Not necessarily. The Auto-Sense feature activates the amplifier automatically when it detects a high-level (speaker) input signal from the source unit, removing the need for a separate remote wire. A RAP bypass switch is also included for vessels where the source unit continues to output a speaker signal after the ignition is switched off, preventing the amplifier from remaining on unintentionally. What crossover options are available on the M2-200X2? The M2-200X2 offers a fully adjustable high-pass crossover, a fully adjustable low-pass crossover, and an all-pass mode, all using 12dB/octave Butterworth slopes adjustable from 50Hz to 250Hz. A variable infrasonic filter is also available. This makes it suitable for use as a speaker amplifier in all-pass mode, a high-passed mid-range amplifier, or in bridged mono as a low-passed subwoofer amplifier, depending on the system configuration. What fuse does the M2-200X2 require and is it included? The M2-200X2 requires a 30A fuse. The fuse is not included in the box and must be sourced separately. Install the fuse as close to the battery as possible in the 4 AWG power supply line. Note that the 30A fuse requirement is significantly lower than the 80A required by the M2-500X1, reflecting the M2-200X2's lower current draw of 18A maximum.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Full-Range Class FD AmplifierGet Pure Sound using Pioneer PRS AmplifiersThe goal of a good amplifier is to cleanly amplify the music signal, free of distortion or added color. The Premier PRS-D2100T is a new generation of Class FD (Full-Range Class D) amplifiers that clearly achieves this goal. Using an exclusing designed ICEpower circuit, music comes through clear, crisp and detailed.Energy Saving DesignA huge benefit is the Class FD design, which consumes far less current than traditional amplifier designs. This results in less draw on your vehicle's alternator, and could actually improve fuel mileage in many cases. It also allows for a compact chassis (heatsink) that takes up less space and provides more installation flexibility.Variable Crossover (40~500Hz, HPF/LPF)For added flexibility, the variable crossover lets you optimize your system's efficiency and delivers the best possible sound quality. You can adjust it continuously between 40 to 500Hz, as well as selecting from either High-Pass Filter (use for your main speakers) or Low-Pass Filter (use for your subwoofers), giving you the ultimate flexibility in setting up your system.Selectable Bass Boost with Wired Bass RemoteSo you're in the driver's seat going 65mph and you want to fine-tune the bass boost. But the amp's out of reach, way in the back. What are you supposed to do — pull over, get out, and run around to the trunk? That's why the PRS-D2100T comes with a wired bass remote. It's set at 50Hz, ideal for tuning in some more thump from your subwoofers. And because this is selectable bass boost, you can set the level at 0dB, 6dB, or 12dB, whichever sounds best to you.Speaker Level InputsWhat, you DON'T own a Pioneer headunit? Well, we won't hold it against you. In fact we'll even help you build onto your system. The PRS-D2100T's speaker level inputs allow you to connect your OEM unit (or any unit that doesn't have the typical RCA-type inputs) without having to buy add-on adapters.Premier® Two-Year WarrantyThe warranty on this model is two years — double the warranty period of typical models currently on the market.Features: 1200 Watts Max. Music Power Selectable Bass Boost with Wired Bass Remote ICEpower Full-Range Class FD Design Specifications:General Peak Music Power 1200 Watts Number of Channels 2 Load Impedance Capability 2~8 Ohm (Stereo), 4~8 Ohm (Stereo) Continuous Power (4 W) 150 Watts x 2 Continuous Power (2 W) 300 Watts x 2 Continuous Power Bridged (4 W) 600 Watts x 1 Frequency Response 10Hz ~ 40kHz Total Harmonic Distortion 0.005% Signal-to-Noise Ratio 100 dB Dimensions 11-15/16 x 2-3 / x 7-11/16 (304 mm x 56 mm x 195 mm) Bridgeable Y Channel # Capability 2/1 Class-D Design Y MOSFET Output Section Y Compression-Type Speaker Terminals Y Balanced Isolator Input Circuit Y RCA Inputs 2 Channel (Gold Plated) RCA Outputs (Pass Thru) Y Speaker Level Input Yes Input Level Control Hi-Volt (400mV~6.5V) Built-in Crossover 2ch. HPF/LPF Crossover Frequency Range 40~500Hz, -12dB/Oct. Bass Level Control 50Hz, 0/6/9/12dB, with Remote CEA 2006 Specifications Output Power (4 W Bridged, <=1% THD) 600 Watts x 1 Output Power (2 W, <=1% THD) 300 Watts x 2 Signal to Noise (1 Watt into 4 W) 80 dBA Output Power (4 W, <=1% THD) 150 Watts x 2 Legendary Products & Support From Authorized Dealers When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Pioneer dealer today!

Read more less

Performance You Expect From Infinity - Power and Efficiency! Kappa mono and full-range, multi-channel amplifiers deliver the efficiency and power you expect from Class D amps—and the performance you expect from Infinity.. Each model in the lineup will accept both high-level or low-level inputs, allowing the JBL Stadium amplifiers to be added to virtually any car audio system, including factory installed systems. The 2-, 4- and 5-channel amplifiers offer Bluetooth® audio streaming, exclusive Clari-Fi™ music restoration technology that analyzes and improves the audio quality of compressed files in real time, a multi-pairing Party Mode that lets anyone in the car stream music, and a cabin-mounted control panel. Kappa amplifiers give you the power to shape your car audio experience in new ways. Bluetooth® Audio Streaming and Telephony Support The three full-range, multi-channel Kappa amplifiers (K2, K4 and K5 models) feature Bluetooth® connectivity for wireless audio streaming from phones and other devices. You can receive phone calls through your car audio system, just by touching a button on an included control panel. Clari-Fi™ Audio Restoration Technology Clari-Fi™, a proprietary DSP technology is incorporated in the K2, K4 and K5 amplifiers, analyzes music files and improves highly compressed digital music files in real time. A predictive algorithm restores audio content that is discarded in the compression process. Clari-Fi™ works with all playback devices and audio sources. It extends high-frequency bandwidth, restores the natural warmth of vocals and widens the sound stage. In short, Clari-Fi™ gives your digital music back its soul. Party Mode Wireless Pairing The K2, K4 and K5 amplifiers offer Party Mode, a multi-pairing capability that enables Bluetooth® devices to stream audio individually. When Party Mode is selected from the cabin-mounted control panel, anyone in the car can drive the music. Cabin-Mounted Control Panel The K2, K4 and K5 multi-channel amps come with a wired control panel that incorporates an omni-directional microphone and puts a range of functions at your fingertips. You can activate Bluetooth® pairings, accept and end phone calls, select Party Mode and cancel Clari-Fi™. Class-D Amplification Every Kappa amplifier, including the full-range models, is a Class D. These high-efficiency, low-heat amps generate a lot of power without drawing much current, and feature small footprints. Full-Range Line Outputs The full-range Kappa amplifiers (K2, K4 and K5) include full-range line outputs. This enables them to pass the audio signal to additional amps that power subwoofers, increasing your system configuration options. Upgradable Firmware Kappa amplifiers incorporate a mini-USB port that enables you to easily upgrade firmware. ADAS Input Four-channel, priority inputs on the full-range Kappa amplifiers override the playing source when a signal is detected from Advanced Driver Assistance Systems. DBO™ (Dynamic Bass Optimizer) Kappa amps feature a subsonic filter in with variable frequency and Q. For sealed enclosures, set the Frequency Control to 35Hz, and then adjust the Boost Control to your preference. For vented enclosures, set the Frequency Control to 10Hz below the port tuning, then adjust the Boost control to your preference. Sleek Design Sometimes, an amp can be as stylish as it powerful. With brushed steel and screwdriver access concealed by a magnetically attached panel, Kappa amplifiers have a clean, streamlined industrial design. Legendary Products & Support From Authorized Dealers When you choose Infinity, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Infinity dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Infinity's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Infinity dealer today!

Read more less
