MotoBatt 12V 22Ah 220CCA AGM Motorcycle Battery With QuadFlex Technology: A Motobatt Battery Is a Battery You Can Rely On! Motorcycle Battery With Quadflex Technology Motobatt Quadflex batteries, the first and unique 4 terminal system, propose the best balance between CCA and Amp hour capacity. By utilizing the wasted space inside a standard battery case, Motobatt maximizes the dimensions of the plates internally. Additionally, the plate grids are made thicker, and that with the additional density of the pasting improves the Amp Hour capacity, durability, and Cold-cranking Amps. Motobatt has completely changed the Powersport market by improving an old design. MotoBatt MB51814 Features: 20% More Amp Hour Capacity* 20% More Cold Cranking Amps* Heavy Duty Pure Lead Calcium Cast Grids for high-strength More Surface Area per Plate for Superior Performance and Longevity Military Grade Absorbed Glass Matt Separators, Vibration Resistant Multi Terminal Design, Easy to Add Accessories Factory Activated, No Acid to Fill, Simply Check Charge & Go! Extremely Low Self Discharge Rate MotoBatt MB51814 Specifications: Voltage: 12 Capacity (10HR): 22Ah Weight: 6.75kg / 14.88Ibs Dimensions (in / mm): L: 7.2(183) W: 3.15(80) H: 6.69(170) Assembly Figure Terminal Locations: 4 Terminals: 2, M6x2.5 (Part#MPT2) Screws: 4, M6X7 (Part#2xMPS2) Allen Wrench: 1, 4x4 (Part#MPAK2) Terminal Caps: 4, 12x5.5 (Part#2XMPC2) Vehicle Compatibility: BMW R50/5 (70-73) - 500CC BMW R60/5 (70-73) - 600CC BMW R65LS (78-84) - 650CC BMW R75/5 (70-73) - 750CC BMW K75C, S (85-95) - 750CC BMW R80GS, R80ST (80-96) - 800CC BMW R850R (95-97) - 850CC BMW K1100LT/RS (90-95) - 1100CC BMW R1100R (94-00) - 1100CC BMW R1100S (99-00) - 1100CC BMW R1100GS (94-00) - 1100CC BMW R1100RS, RT (93-00) - 1100CC BMW R1150GS, R (00-05) - 1150CC BMW K1200LT, GT, RS, S (99-05) - 1200CC BMW R1200C (98-05) - 1200CC BMW K1200LT, GT (05-09) - 1200CC BMW R1200RT (05-12) - 1200CC BMW K1200RS (97-05) - 1200CC BMW K1300GT (09-11) - 1300CC BMW K1600GT, GTL (11-12) - 1600CC
Legendary Products & Support From Authorized Dealers
When you choose MotoBatt, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized MotoBatt dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by MotoBatt's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized MotoBatt dealer today!
Our Best Value Fuses, Great Quality At Great Prices. Product Features: Rating: 15 Amps Colour: Blue Dimensions: 16mm H x 10mm W x 3mm Spade Width. Pack Size: 10 Per Pack Packaging: Sliding Blister & Card With Hang Hole.
Legendary Products & Support From Authorized Dealers
When you choose DNA, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized DNA dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by DNA's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized DNA dealer today!
Blue Sea Systems Monitor M2 OLED Bilge Monitor: Digital Bilge Meter from Blue SeaBlue Sea Systems BS-1842B Features: The M2 Organic LED Digital Monitor measures essential electrical system parameters with adjustable alarms and an auto-dimming display. The M2 Monitors include a MOSFET External Circuit Relay (ECR) which can be used to control external circuits based on any value measured by the M2. Auto-dimming, bright Organic LED display is easy to read 80dB alarm on all models Isolated 500mA MOSFET relay Bilge float switch not included
Legendary Products & Support From Authorized Dealers
When you choose Blue Sea Systems, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Blue Sea Systems dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Blue Sea Systems's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Blue Sea Systems dealer today!
Rev Plus ST12B-4 Motorcycle Battery - High-Performance AGM Battery
Looking for a reliable, high-quality battery for your motorcycle? The Rev Plus STX4L-BS Motorcycle Battery delivers exceptional performance and durability to keep you on the road without a hitch. Designed for a wide range of motorcycles, this battery ensures you have dependable starting power and long-lasting service life.
Key Features:
AGM Technology: Advanced Absorbent Glass Mat (AGM) technology offers a spill-proof design with no maintenance needed. Just install it and enjoy a hassle-free battery experience!
Enhanced Starting Power: Designed for high cranking amps to provide powerful starting power, even in cold weather. Ideal for riders who need reliable performance in all conditions.
Long-Lasting Durability: The Rev Plus ST12B-4 is built for durability, standing up to vibrations and heavy use over time. Perfect for daily rides, long trips, and tough terrains.
Compact Design: Lightweight and compact for easy installation, with the perfect fit for a range of motorcycle makes and models.
Ready to Use: Activated & charged upon order. New terminal bolts included!
Specifications:
Battery Type: ST12B-4
Voltage: 12V
Capacity: 10AH
CCA: 175
Dimensions: 150 x 69 x 130mm
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Victron Energy 12V to 24V 10A DC to DC Converters: The Orion Converters From Victron Energy Have Been Designed to Be a True World-wide Product
An ever-increasing amount of electric equipment is being used on vehicles and boats. Because most low-voltage equipment, such as navigation and radio equipment, mobile telephones or car hi-fi systems, is designed for 12 Volts, Victron Energy supplies DC/DC converters which deliver a stable 12 Volt supply from a 24 Volt system.
These products are also distinguished by high efficiency, together with absolute safety. An inferior supply can cause irreparable damage to your 12 Volt system, but the use of an Orion voltage converter prevents problems of that type. Next to converters from 24 V to 12 V, a wide range of other models is available.
Victron Energy ORI122410020 Specifications:
Input voltage range: 15-40VDC
Under voltage shutdown: 13V
Under voltage restart: 14V
No load current at 24V: 20mA
DC output voltage: 12V +/- 3%
Maximum continuous output current: 10A
Efficiency: 93%
Ripple & Noise: 75mV pp
Operating temperature range (derate 3% per °C above 40°C): -20 to +70°C (full rated output up to 40°C)
Overload protection: Hiccup mode, recovers automatically after the fault condition is removed
Short circuit proof: Yes
Protection against reverse polarity: Connection With external fuse or circuit breaker (not included)
Legendary Products & Support From Authorized Dealers
When you choose Victron Energy, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Victron Energy dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Victron Energy's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Victron Energy dealer today!
Victron Energy 12V to 24V 8A DC to DC Converters: The Orion Converters From Victron Energy Have Been Designed to Be a True World-wide Product
An ever-increasing amount of electric equipment is being used on vehicles and boats. Because most low-voltage equipment, such as navigation and radio equipment, mobile telephones or car hi-fi systems, is designed for 12 Volts, Victron Energy supplies DC/DC converters which deliver a stable 12 Volt supply from a 24 Volt system. These products are also distinguished by high efficiency, together with absolute safety. An inferior supply can cause irreparable damage to your 12 Volt system, but the use of an Orion voltage converter prevents problems of that type. Next to converters from 24 V to 12 V, a wide range of other models is available.
Victron Energy ORI122420020 Specifications:
Input voltage range (V): 9-18
Under voltage shutdown (V): 8
Under voltage restart (V): 10
Output voltage adjustable with potentiometer: no
Output voltage (V): Adjustable 20-30 V
Efficiency (%): 93
Suitable to buffer-charge a battery: yes
Can be connected in parallel: yes
Continuous output current (A): 20
Max. Output current (A): 30
Fan assisted cooling (temp. controlled): yes
Galvanic isolation: no
Off load current: < 30mA
Remote on-off: yes
Operating temperature range (derate 3% per °C above 40°C): -20 to +55°C
DC connection: M6 bolts
Weight: 0.9kg
Dimensions hxwxd in mm: 65x88x195
Legendary Products & Support From Authorized Dealers
When you choose Victron Energy, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Victron Energy dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Victron Energy's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Victron Energy dealer today!
Makes Connecting to Vehicle Fitted Fuse Distribution Blocks an Absolute Breeze!
Standard Blade Fuse Tap - 10AThunder workshop accessories provide you with reliable and hard-wearing products to ensure a perfect connection in your system. Plug into existing mini blade fuse port, fit fuses, and connect the cable to accessory, job done.
Features:
10A per Circuit (2 Circuits)
Auxiliary power feed for second fuse
150mm 16 AWG cable outputs to an insulated joiner
Specifications:
Type: Fuse Tap
Amp Rating: 10A
Fuse Type: Standard Blade Fuse
Legendary Products & Support From Authorized Dealers
When you choose Thunder, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Thunder dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Thunder's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Thunder dealer today!
Victron Energy Orion-Tr 24/12-30A 360W Isolated DC-DC Converter
Heavy-duty 24V to 12V conversion serious output for serious 12V loads in any 24V system
The Victron Energy Orion-Tr 24/12-30A (ORI241240110) is a high-current isolated DC-DC converter built for installations that demand real 12V power from a 24V source. Delivering 30A continuous output with burst capacity to 45A and rated at 360W at 40°C, it's designed for the kind of sustained, high-draw applications that lightweight converters simply can't handle: heavy 12V accessory loads in 24V trucks and buses, 12V hotel loads in commercial vehicles, or secondary 12V battery charging in large off-grid and marine systems.
Part of Victron's globally trusted Orion-Tr isolated range, this unit brings full galvanic isolation between input, output, and case keeping your 12V circuits clean, quiet, and protected from whatever is happening on the 24V side. The adjustable output (10–15V) means it doubles as a precision 12V battery charger, letting you set the correct charge voltage for your secondary battery chemistry without a separate dedicated unit. Engineered to operate from −20°C to +55°C with thermal derating rather than hard shutdown, it's well suited to the demanding heat and corrugated-road conditions of Australian commercial, 4WD, and off-grid use.
Key Specifications
Input voltage range: 20–35V DC
Under voltage shutdown: 14V
Under voltage restart: 15V
Nominal output voltage: 12.2V (adjustable 10–15V)
Continuous output current: 30A at 25°C
Maximum output current (10s burst): 45A
Short circuit output current: 60A
Continuous output power at 40°C: 360W
Continuous output power at 25°C: 430W
Efficiency: 88%
Galvanic isolation: 200V DC between input, output, and case
Output voltage tolerance: ±0.2V
Output noise: 2mV rms
Off-load current draw: less than 100mA
Operating temperature: −20°C to +55°C (derate 3% per °C above 40°C)
IP43 protection rating (terminals oriented downwards)
DC connection: Screw terminals, max cable cross-section 16mm²
Features & Benefits
Remote on/off input: Route a simple low-power signal from a cabin switch, BMS, or engine run/stop output to control the converter without running heavy input wiring through a high-current switch. Cleaner installs, less voltage drop, and no oversized switch gear on the 24V input side.
Adjustable output voltage (10–15V): Tune the output to the precise charge or supply voltage your 12V system needs. Set it to 14.4V for AGM absorption charging, 13.6V for float, or dial it to suit LiFePO4 making the Orion-Tr a flexible, all-chemistry 12V battery charger as well as a load supply.
30A continuous 45A burst: At 30A continuous and 45A for 10-second peaks, this is one of the highest-output single-unit isolated converters in the Orion-Tr range. It comfortably powers heavy 12V loads fridges, inverters, lighting, communications gear, winch control circuits without tripping into derating under normal conditions.
Doubles as a 12V battery charger: In 24V trucks, buses, coaches, or commercial vehicles with a secondary 12V starter or accessory battery, the Orion-Tr replaces a standalone charger entirely. One unit handles both supply and charging duties, reducing system complexity and component count.
200V DC galvanic isolation: Complete electrical separation between the 24V input, 12V output, and chassis eliminates ground loops and conducted noise across the voltage boundary. Essential in vehicles and vessels where 12V and 24V circuits share physical proximity but must remain electrically independent.
Unlimited parallel operation: Need more than 30A at 12V? Stack additional ORI241240110 units in parallel no current-sharing hardware required. Each unit adds its full 30A rated output to the bus, with no practical upper limit on the number of paralleled units.
Short circuit proof output: Output faults won't destroy the unit. It recovers automatically once the short is cleared, minimising downtime in remote and commercial installations where replacement lead times matter.
Thermal derating not hard cutoff: Above 40°C, output current reduces at 3% per degree rather than tripping offline. In a hot engine bay, a sun-baked trailer, or a sealed commercial vehicle body, that means the system keeps delivering usable power rather than going dark at the worst possible moment.
IP43 rated enclosure: Dust and splash protection with terminals oriented downward. Suitable for under-bonnet, under-chassis, and enclosed cabinet installations in vehicles and marine applications where exposure to moisture and dust is part of daily operation.
Screw terminals, 16mm² capacity: Heavy-gauge 16mm² cable support matches the wiring demands of a 30A+ installation. Standard screw terminals mean no crimping tools or proprietary connectors fast, solid connections that can be serviced in the field.
Non-replaceable input fuse included: The 24V input model includes an internal non-replaceable input fuse for added circuit protection. Note: this fuse is not user-serviceable; if it fails, the unit requires replacement or warranty assessment.
Technical Specs
Specification
Detail
SKU
ORI241240110
Brand
Victron Energy
Model
Orion-Tr 24/12-30A
Input Voltage Range
20–35V DC
Under Voltage Shutdown
14V
Under Voltage Restart
15V
Nominal Output Voltage
12.2V
Output Voltage Adjust Range
10–15V
Output Voltage Tolerance
±0.2V
Output Noise
2mV rms
Continuous Output Current (25°C)
30A
Maximum Output Current (10s)
45A
Short Circuit Output Current
60A
Continuous Output Power (25°C)
430W
Continuous Output Power (40°C)
360W
Efficiency
88%
Off-Load Current Draw
<100mA
Galvanic Isolation
200V DC (input, output & case)
Operating Temperature Range
−20°C to +55°C
Thermal Derating
3% per °C above 40°C
Humidity
Max 95% non-condensing
DC Connection
Screw terminals
Maximum Cable Cross-Section
16mm²
IP Rating
IP43 (terminals down)
Input Fuse
Internal non-replaceable fuse included (24V input model)
Compatible With
24V commercial vehicles (trucks, buses, coaches, plant equipment) with 12V accessory or starter battery loads
24V off-grid solar systems requiring a 12V secondary load or battery circuit
24V marine systems with 12V navigation, communications, or hotel loads
4WD and expedition vehicles with 24V primary systems and 12V accessory circuits
Victron SmartSolar MPPT charge controllers operating on 24V systems
Victron BMV battery monitors and Cerbo GX / Venus GX devices (system-level monitoring)
Victron Lynx distribution busbars and fusing systems (for clean, fused 24V integration)
Parallel arrays of additional ORI241240110 units (unlimited parallel operation supported)
Frequently Asked Questions
Can I use this to charge a 12V battery from my 24V truck or bus system?
Yes. The adjustable output (10–15V) lets you set an appropriate charge voltage for your 12V battery chemistry AGM, gel, or LiFePO4 making the Orion-Tr a fully functional isolated 12V battery charger in any 24V vehicle.
What is the maximum continuous output current this unit can deliver?
The ORI241240110 delivers 30A continuous at 25°C and up to 45A for 10-second bursts. At 40°C ambient, continuous output power is rated at 360W sufficient for heavy 12V accessory loads in commercial and 4WD applications.
Does galvanic isolation matter if both batteries share the same vehicle chassis?
Yes. Even with a shared chassis ground, galvanic isolation prevents ground loops, eliminates conducted noise between the 24V and 12V circuits, and protects sensitive 12V electronics from transients and interference generated on the 24V side.
How do I get more than 30A output at 12V from this unit?
Connect additional ORI241240110 units in parallel. Victron supports unlimited parallel operation with no current-sharing hardware each unit adds 30A to the output, so two units deliver 60A, three deliver 90A, and so on.
What happens if the internal input fuse opens?
The internal input fuse on 24V input models is non-replaceable. If it opens due to a fault condition, the unit will need to be assessed under warranty or replaced. Always install appropriate external overcurrent protection on the input wiring to reduce the risk of nuisance fuse events.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Stinger Shoc-Krome 80 AMP ANL Fuse: Can Be Used With Any Of Stingers ANL Fuse Holders ANL 80 Amp Fuse Chrome The Stinger SPF5280 is a high quality 80 amp ANL style fuse that can be used with any stinger ANL style fuse. Its platinum nickel finish ensures maximum power transfer and premium construction and quality. Stinger SPF5280 Features: Ultimate Circuit Protection High Conductivity Shoc-Krome Plating Maximum Current Transfer High Quality 80 Amp ANL Style Fuse Stinger SPF5280 Specifications: Fuse Amperage: 80 Fuse Type: ANL
Legendary Products & Support From Authorized Dealers
When you choose Stinger, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Stinger dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Stinger's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Stinger dealer today!
Stinger 1 Pack Shoc-Krome 250 AMP ANL Fuse: Can Be Used With Any Of Stingers ANL Fuse Holders.
Legendary Products & Support From Authorized Dealers
When you choose Stinger, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Stinger dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Stinger's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Stinger dealer today!
Stinger 1 Pack Shoc-Krome 150 AMP ANL Fuse: Can Be Used With Any Of Stingers ANL Fuse Holders Stinger SPF52150 Features: Ultimate Circuit Protection High Conductivity Shoc-Krome Plating Maximum Current Transfer ANL Style
Legendary Products & Support From Authorized Dealers
When you choose Stinger, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Stinger dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Stinger's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Stinger dealer today!
Victron 120W 48/24-5A Orion-Tr Isolated DC-DC Converter: Designed to Be a True World-wide Product
Remote on-off
The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual). Adjustable output voltage: can also be used as a battery charger For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system. All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel. High temperature protected The output current will reduce at high ambient temperature. IP43 protection When installed with the screw terminals oriented downwards.
Screw terminals
No special tools needed for installation.
Input fuse (not replaceable)
On 12V and 24V input models only
Victron ORI482410110 Specifications:
Input voltage range: 32-70V
Under voltage shut down: 28V
Under voltage restart: 30V
Nominal output voltage: 24,2V
Output voltage adjust range: 20-30V
Output voltage tolerance: +/- 0,2V
Output noise: 2mV rms
Cont. output current at nominal output voltage and 25°C: 5A
Maximum output current (10 s) at nominal output voltage: 6,3A
Short circuit output current: 25A
Cont. output power at 25°C: 120W
Cont. output power at 40°C: 100W
Efficiency: 86%
Off load current: < 60mA
Galvanic isolation: 200V dc between input, output and case
Operating temperature range: -20 to +55°C (derate 3% per °C above 40°C)
Humidity: Max. 95% non-condensing
DC connection: Screw terminals
Maximum cable cross-section: 6 mm² AWG10
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
