Configure Your Perfect Audio SetupFeel the DifferenceFrom dramatic distinction to dramatic design, Pioneer's new GM-Series amplifiers are thrillers in every sense, pushing the limits of flexibility and functionality.The 2-channel GM-A3602 delivers 400 watts max in a compact design - plenty of juice to power your speakers. It's also got built-in high-pass crossover, speaker level inputs for easy connection to an OEM headunit, and oversized power terminals.CEA2006 Specifications Power Output: 60 Watts RMS x 2 Channels (4 ohms ≤ 1% THD+N) Signal-to-Noise Ratio: 95 dBA (Reference: 1 Watt into 4 ohms) Inspired By ExcellencePioneer is constantly finding ways to make amplifier technology better. Our new and improved GM-Series prove how you can add cutting edge technology and more power to your system without breaking the bank. Like all Pioneer products, these amps are fully tested to ensure that each is designed and built for performance.Higher PowerHaving more power isn't just about LOUD. It's also about CLEAN, getting the most out of your speakers and your music. Constant road noise makes it hard for the music to be heard clearly. But with 400 watts max. power, you'll get to hear all the words and all the notes.High Capacity Switching Power SupplyTo suppress power supply loss, GM-Series amplifiers incorporate a large toroidal transformer and are driven using a high-speed switching MOSFET. This stabilization of power supply maintains stable playback of all types of music.Gain ControlWhat is power without control? To accommodate the varying range of signal levels coming from today's factory and aftermarket radios, all of Pioneer's GM-series amplifiers feature adjustable gain controls. This means that no matter what kind of radio is connected to this amplifier, the appropriate gain control adjustment can be made to ensure loud, clear, distortion-free music. And even if the gain control level is set improperly, Pioneer's Gain Control Caution feature will automatically reduce the amplifier's output until the headunit volume is decreased to acceptable levels. This added layer of protection helps to prevent damage from occurring to the amplifier and the speakers connected to it due to improper gain control adjustments.Bringing the System TogetherWhat, you DON'T own a Pioneer headunit? Well, we won't hold it against you. In fact we'll even help you build onto your system. The GM-A3602's speaker level inputs allow you to connect your OEM unit (or any unit that doesn't have the typical RCA-type inputs) without having to buy add-on adapters. SO, the install goes faster, you save money, and you've got a Pioneer amp in your vehicle.Features: Amplifier Class: AB Load Impedance Allowance (W): 2 to 8 Bridgeable: Yes RCA Inputs: 2-Ch. Speaker Level Input: Yes Speaker Line Input Turn-On Sensor: Yes Hi-Volt Input Level Control: 200 mV to 6.5 V Terminal Type: Screw-Type Crossover Type: LPF Crossover Frequency: 80 Hz Crossover Slope: -12 dB/oct. Specifications: Number of Channels: 2/1 Maximum Power Output: 400 W Continuous Power Output (2Ω, ≤ 1% THD+N): 90 W x 2 Continuous Power Output (4Ω, ≤ 1% THD+N): 60 W x 2 Continuous Power Output Bridged (4Ω): 180 W x 1 Frequency Response: 10 Hz to 70 kHz Total Harmonic Distortion (4Ω): < 0.05% (1 kHz) Signal-to-Noise Ratio (IHF-A Weighted, at 1 kHz): > 95 dB Dimensions (WxHxD): 9-1/2" x 2-1/2" x 7"
Legendary Products & Support From Authorized Dealers
When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Pioneer dealer today!
600W Max, 2-Channel Amplifier
Orion Cobalt 2-channel class A/B car amplifier.
Specifications:
RMS Power Rating: 4 ohms: 100 watts x 2 chan. / 2 ohms: 155 watts x 2 chan. / Bridged, 4 ohms: 310 watts x 1 chan.
Max power output: 600 watts
MOSFET power supply
Tri-mode and bridgeable operation
LED power and protect indicators
Illuminated blue LED stripe design
Selectable bass boost (0, 6, 12 dB)
2/1 channel operation
High-level inputs (signal sensing for automatic turn on)
3-Way system protection circuitry (thermal, short circuit, and overload)
Heavy duty aluminum alloy convection heatsink
Chrome-plated RCA level input
Chrome-plated screw terminals
Input sensitivity (175mV-8V)
Damping factor (>100)
Continuously variable high-pass filter (50-500 Hz)
Continuously variable low-pass filter (50-500 Hz, 2nd order 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 20-30,000 Hz
Dimensions: 11-7/16"L x 8-1/8"W x 2-1/8"H
4-gauge power and ground wiring is required for installation
Legendary Products & Support From Authorized Dealers
When you choose Orion, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Orion dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Orion's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Orion dealer today!
Offers More Power, More Quality and More Bang for Your Buck!
Cobalt series 2-channel class A/B car amplifier.
Specifications:
RMS Power Rating: 4 ohms: 60 watts x 2 chan. / 2 ohms: 80 watts x 2 chan. / Bridged, 4 ohms: 160 watts x 1 chan.
Max power output: 300 watts
MOSFET power supply
Tri-mode and bridgeable operation
LED power and protect indicators
Illuminated blue LED stripe design
Selectable bass boost (0, 6, 12 dB)
2/1 channel operation
High-level inputs (signal sensing for automatic turn on)
3-Way system protection circuitry (thermal, short circuit, and overload)
Heavy duty aluminum alloy convection heatsink
Chrome-plated RCA level input
Chrome-plated screw terminals
Input sensitivity (175mV-8V)
Damping factor (>100)
Continuously variable high-pass filter (50-500 Hz)
Continuously variable low-pass filter (50-500 Hz, 2nd order 12 dB/octave)
CEA-2006 compliant amplifier
Frequency response: 20-30,000 Hz
Dimensions: 7-15/16"L x 8-1/8"W x 2-1/8"H
8-gauge power and ground wiring is required for installation
Legendary Products & Support From Authorized Dealers
When you choose Orion, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Orion dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Orion's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Orion dealer today!
Stinger SPX350X2 2-Channel 350W Class D Powersports Amplifier with IPX-4/5 Weather Resistance
Built for the elements a compact, weather-resistant Class D powersports amplifier delivering 350W bridged into boats, ATVs, UTVs, motorcycles, and 4x4s where standard car amplifiers won't survive.
Product Overview
The Stinger SPX350X2 is a 2-channel Class D powersports amplifier engineered for use in harsh environments where conventional car amplifiers fall short. With an IPX-4/5 weather-resistant design, weather-resistant PCB, and D-Class MOSFETs, it is built to handle the moisture, dust, vibration, and wide voltage swings encountered in marine, off-road, ATV, UTV, motorcycle, and 4x4 applications.
The unregulated power supply design operates across a wide voltage range (8–16V), making it suitable for applications with non-standard battery systems. An AUX RCA pass-through output allows multiple SPX350X2 units to be daisy-chained from a single audio source, and an included remote volume control knob with mute function provides easy level adjustment.
Features & Benefits
IPX-4/5 weather-resistant design — moisture, splash, and dust resistant
Weather-resistant PCB for long-term durability in harsh environments
Full range Class D amplifier with D-Class MOSFETs
Unregulated power supply — operates across 8V to 16V
AUX RCA pass-through output for linking multiple amplifiers from one source
Included remote volume control knob with mute function
12dB/octave Linkwitz-Riley crossover, adjustable 40Hz–400Hz
Balanced 2-channel RCA input (200mV–12Vrms)
Diecast endcaps with removable mounting feet
Compact, low-profile footprint
Suitable for motorcycles, ATVs, UTVs, boats, marine, and mobile applications
Technical Specs
Specification
Detail
SKU / Part Number
SPX350X2
Brand
Stinger
Channels
2-Channel
Class
Class D (Full Range)
RMS Power @ 4Ω (Stereo)
125W RMS x 2
RMS Power @ 2Ω (Stereo)
175W RMS x 2
RMS Power @ 4Ω (Bridged)
350W RMS
Rated Voltage
14.4V
Operating Voltage Range
8V – 16V (Unregulated)
Preamp Input
2-Channel Balanced RCA
Input Voltage Range
200mV – 12Vrms (Balanced)
Preamp Output
2-Channel AUX RCA Pass-Through
Frequency Response
20Hz – 20kHz
Signal to Noise Ratio
>110dB (CEA Standard)
THD+N
<1%
Crossover
12dB/Octave Linkwitz-Riley, 40Hz–400Hz
Power / Ground Wire Gauge
8 AWG
Weather Rating
IPX-4/5
Endcaps
Diecast with removable mounting feet
What's in the Box
Amplifier, Volume Control Knob, Amplifier Fly Lead Harness, Manual
Compatible With / Goes Well With
Direct Vehicle Fit:
Universal — motorcycles, ATVs, UTVs, boats, marine vessels, 4x4 and off-road vehicles
Goes Well With:
Marine-grade speakers and powersports speakers
Additional SPX350X2 units (daisy-chainable via AUX RCA output)
Marine head units with RCA pre-outs
8 AWG power and ground wiring kits
Stinger powersports wiring accessories
Frequently Asked Questions
What does IPX-4/5 weather resistance mean for this amplifier?
IPX-4 provides protection against water splashing from any direction. IPX-5 adds protection against water jets. For a powersports amplifier, this means it can handle rain, spray, splashing water, and wet environments — though it is not fully waterproof and should not be submerged.
Can I run this amplifier in bridged mono mode?
Yes. The SPX350X2 delivers 350W RMS bridged into 4Ω, making it suitable for driving a single subwoofer or full-range speaker in high-output mono applications.
Can I link multiple SPX350X2 amplifiers from one audio source?
Yes. The AUX RCA pass-through output allows you to connect a second (or further) SPX350X2 amplifier directly from the output of the first, distributing a single audio source to multiple amplifiers without additional signal splitting equipment.
Why does this amplifier use an unregulated power supply?
Unregulated power supplies are better suited to applications with non-standard or fluctuating voltage — common in boats, ATVs, and motorcycles where charging systems and battery capacities vary. The SPX350X2 is designed to operate reliably across 8V to 16V.
What wire gauge do I need to install this amplifier?
Stinger specifies 8 AWG power and ground wiring for the SPX350X2. Using undersized wiring will limit power delivery and may cause overheating — always match or exceed the recommended gauge.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Ultra-Compact 400W Stereo Amplifier Class-AD Constant Power, C.L.E.A.N. Clip Detection, High-Level Inputs. Built for Cars, UTVs, and Motorcycles.
Product Overview
The Rockford Fosgate Power T400X2AD is a 400W 2-channel amplifier built on Rockford Fosgate's proprietary Class-AD technology a high-efficiency, ultra-compact design purpose-built for space-constrained vehicle applications including hybrid and electric vehicles, small cars, motorcycles, and side-by-side UTVs where conventional full-size amplifiers cannot be fitted.
Unlike the mono Class-BD amplifiers in the Power series, the T400X2AD is a stereo amplifier and introduces several integration-focused features not found in the larger mono models. A multi-impedance Constant Power configuration maintains the same output at both 4Ω and 2Ω a specific and measurable claim, rather than a generalised "all impedances" statement. High-level inputs with auto turn-on allow direct connection to a factory head unit without a remote turn-on wire, and the Remote-Out feature enables downstream accessories to be triggered when the amplifier engages via high-level input. C.L.E.A.N. clip detection with LED indicators provides real-time feedback of input and output clipping during gain structure setup a genuine installer aid. Dual fan forced induction, dual extruded heat sinks, and real-time thermal sensing manage temperature in the compact chassis.
Key Specifications
Power output: 400W total (2-channel — rated power per channel at specific impedance not confirmed — see Red-flags)
Amplifier class: Class-AD (Rockford Fosgate proprietary)
Configuration: 2-channel stereo
Constant Power: Yes — same output at 4Ω and 2Ω (multi-impedance)
Bridged operation: Yes — 4Ω bridged capable
High-level inputs: Yes — with auto turn-on
Low-level inputs: Yes (RCA)
Remote-Out: Yes — when using high-level inputs
C.L.E.A.N. input/output clip detection: Yes — with LED indicators
Crossover: Built-in (type/slope not specified — confirm with Rockford Fosgate)
Cooling: Dual fan forced induction + dual extruded heat sinks + real-time thermal sensing
Controls: Top mounted
Power/ground connectors: 8 AWG
RCA connectors: Upgraded
PLC2 remote: 2013 PLC2 remote ready
3-stage thermal lock extrusion: Yes
Discrete surface mount technology: Yes
Signal-to-noise ratio: Not specified — confirm with Rockford Fosgate
THD: Not specified — confirm with Rockford Fosgate
Frequency response: Not specified — confirm with Rockford Fosgate
Dimensions: Not specified — confirm with Rockford Fosgate
Weight: Not specified — confirm with Rockford Fosgate
Warranty: Not specified — confirm with Rockford Fosgate
Features & Benefits
Class-AD Technology — Ultra-Compact High Efficiency — Rockford Fosgate's proprietary Class-AD topology delivers high efficiency in a substantially reduced physical footprint compared to traditional Class-AB amplifiers of similar output — enabling fitment in the constrained installation spaces of hybrid and electric vehicles, motorcycles, UTVs, and small cars where a full-size amplifier physically cannot be mounted.
Constant Power at 4Ω and 2Ω — Same Output at Both Impedances — Unlike a standard amplifier that produces significantly more power into 2Ω than 4Ω, the T400X2AD's multi-impedance Constant Power delivers the same output at both 4Ω and 2Ω. This provides consistent performance regardless of whether 4Ω or 2Ω speakers are connected — a particularly useful characteristic in vehicle applications where speaker impedance combinations can be mixed across the two channels.
High-Level Inputs with Auto Turn-On — Direct connection to a factory head unit's speaker outputs without requiring a low-level RCA output or a dedicated remote turn-on wire. The amplifier automatically activates when signal is detected — essential for hybrid and electric vehicles, and modern OEM systems that do not expose a traditional remote output.
Remote-Out Feature via High-Level Input — When the T400X2AD is activated via high-level auto turn-on, its Remote-Out output provides a 12V trigger signal to power downstream accessories — maintaining the ability to control a subwoofer amplifier or other 12V accessories without a direct remote wire from the head unit.
C.L.E.A.N. Input/Output Clip Detection with LED Indicators — Rockford Fosgate's Circuit Level Evaluation And Normalisation (C.L.E.A.N.) system monitors both the input and output stages for clipping, with separate LED indicators for each. This allows precise gain setting during installation — removing guesswork from a process that is the most common cause of speaker and amplifier damage in car audio systems.
Top Mounted Controls — All adjustment controls are accessible from the top of the amplifier chassis — gain, crossover, and C.L.E.A.N. indicators are accessible without removing the amplifier from its mounting position, simplifying setup and fine-tuning in confined installations.
Dual Fan Forced Induction Cooling — Active cooling via dual fans allows the compact chassis to manage the heat generated by sustained 400W output — preventing thermal throttling in confined or poorly ventilated installation locations common in small vehicles and UTVs.
Dual Extruded Heat Sinks with Real-Time Thermal Sensing — Passive heat sinking combined with real-time thermal monitoring provides a staged thermal management approach. The 3-stage thermal lock extrusion protects the amplifier from sustained overload rather than simply shutting down, maximising uptime in demanding installations.
4Ω Bridged Capable — The two channels can be bridged to drive a single 4Ω subwoofer or full-range speaker at higher combined output — adding subwoofer integration capability to the compact amplifier's application range.
2013 PLC2 Remote Ready — Compatible with Rockford Fosgate's PLC2 remote level control, enabling a dash-mounted remote bass level adjustment without accessing the amplifier directly.
Discrete Surface Mount Technology — Internal construction using discrete SMT components rather than integrated modules contributes to the compact physical size while maintaining high-quality signal path components.
Technical Specs
Specification
Detail
Brand
Rockford Fosgate
Part Number
T400X2AD
Series
Power
Power Output
400W (2-channel total)
Amplifier Class
Class-AD (Rockford Fosgate proprietary)
Configuration
2-Channel Stereo
Constant Power
Yes — same output at 4Ω and 2Ω
Bridged Operation
Yes — 4Ω bridged capable
High-Level Inputs
Yes — with auto turn-on
Low-Level Inputs
Yes (RCA)
Remote-Out
Yes (when using high-level inputs)
C.L.E.A.N. Clip Detection
Input and output — with LED indicators
Crossover
Built-in — type/slope not specified
Cooling
Dual fan + dual extruded heat sinks + real-time thermal sensing
Controls
Top Mounted
Power/Ground Connectors
8 AWG
RCA Connectors
Upgraded
PLC2 Remote
2013 PLC2 Remote Ready
Construction
Discrete Surface Mount Technology
Rated Power per Channel
Not specified — confirm with Rockford Fosgate
Frequency Response
Not specified
Signal-to-Noise Ratio
Not specified
THD
Not specified
Dimensions
Not specified
Weight
Not specified
Warranty
Not specified — confirm with Rockford Fosgate
Compatible With / Goes Well With
Suitable vehicle applications:
Hybrid and electric vehicles (high-level input auto turn-on eliminates dependency on remote wire)
Small cars and hatchbacks with limited installation space
Motorcycles and touring bikes with compact battery and mounting constraints
Side-by-side UTVs (Polaris RZR, Can-Am Maverick, and similar)
Trucks and SUVs requiring a compact stereo amplifier solution
Suitable speaker configurations:
2-channel 4Ω or 2Ω stereo speaker configuration
Bridged mono to single 4Ω subwoofer or full-range speaker
Factory speaker upgrade using high-level input connection
Pairs well with:
Aftermarket door speakers (4Ω or 2Ω) for a direct factory integration upgrade
A dedicated mono subwoofer amplifier powered via Remote-Out
Rockford Fosgate PLC2 remote level control (2013 compatible)
8 AWG amplifier wiring kits
Frequently Asked Questions
What does Class-AD mean and how does it differ from Class-AB or Class-D?
Class-AD is Rockford Fosgate's proprietary amplifier topology, engineered for high efficiency in a compact physical footprint. It is distinct from both Class-AB (which is thermally demanding and physically large) and standard Class-D (which can have audio quality trade-offs). The specific efficiency and distortion characteristics of Class-AD should be confirmed from the Rockford Fosgate T400X2AD datasheet.
How does the high-level auto turn-on work with a factory head unit?
The high-level inputs accept signal directly from the factory head unit's speaker outputs. When the head unit produces audio signal, the amplifier detects this and activates automatically — no dedicated remote turn-on wire from the head unit is required. The Remote-Out feature then provides a 12V output to trigger downstream accessories.
What does C.L.E.A.N. clip detection do during amplifier setup?
C.L.E.A.N. (Circuit Level Evaluation And Normalisation) monitors both the input and output stages of the amplifier for clipping. During gain setting, the LED indicators illuminate when the input or output clips — allowing the installer to set the gain at the highest level before clipping occurs, maximising output without inducing distortion. This removes the guesswork from a critical step that directly affects sound quality and component life.
Can the T400X2AD be bridged to run a subwoofer?
Yes. Both channels can be bridged to drive a single 4Ω subwoofer or full-range speaker. Confirm the bridged power output at 4Ω with Rockford Fosgate or the official datasheet before specifying for a specific subwoofer.
Is the T400X2AD suitable for a UTV or motorcycle?
Yes. The ultra-compact Class-AD chassis, dual fan cooling for confined spaces, and high-level auto turn-on for non-standard electrical systems make the T400X2AD specifically suited to UTV and motorcycle audio applications. Confirm physical dimensions with Rockford Fosgate to verify fitment in your specific UTV or motorcycle audio enclosure before purchasing.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Highlights: What's In The Box: Similar Products Polk Audio PA880 800W 1-Channel Amplifier $499.00 Polk Audio PA D1000.1 1200W PA D Series Monoblock $659.00 Polk Audio PA D2000.2 PA D Series 2-Channel Class $449.00 Polk Audio PA D4000.4 4-Channel Car Amplifier $659.00 Polk Audio PA D5000.5 PA D Series 5-Channel Class $825.00 Highlights: 2-CHANNEL CAR AMPLIFIER 125 WATTS RMS X 2 AT 4 OHMS (250 WATTS RMS X 2 AT 2 OHMS) 500 WATTS RMS X 1 IN BRIDGED MODE (4-OHM STABLE IN BRIDGED MODE) VARIABLE HIGH-PASS FILTER (20-4000 HZ, 12 DB PER OCTAVE) VARIABLE LOW-PASS FILTER (50-5000 HZ, 12 DB PER OCTAVE) PREAMP INPUTS AND OUTPUTS FUSE RATING: 25A X 2 4-GAUGE POWER AND GROUND LEADS RECOMMENDED — WIRING AND HARDWARE NOT INCLUDED WITH AMPLIFIER 9"W X 1-13/16"H X 6-3/4"D
Legendary Products & Support From Authorized Dealers
When you choose Polk Audio, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Polk Audio dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Polk Audio's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Polk Audio dealer today!
Designed to Be a True Worldwide Product! Orion 500W max 2-channel XTR series amplifier with crossover. Specifications: RMS Power Rating: ¢ 4 ohms: 70 watts x 2 chan. ¢ 2 ohms: 140 watts x 2 chan. ¢ Bridged, 4 ohms: 250 watts x 1 chan. Max power output: 500 watts MOSFET Power supply and output stage Power and protection LED Indicators Low-level RCA Inputs Accepts high-level speaker inputs from an OEM stereo Thermal, DC offset, short protection and under-voltage protection X-Over (crossover) activates the low-pass, FLAT and high-pass crossovers X-Over frequency control adjusts the frequency for the high- and low-pass filters Silver-plated RCA level inputs Silver-plated screw terminals Variable high-pass filter (50-2,000 Hz, 12 dB/octave) Variable Low-pass filter (50-2,000 Hz, 12 dB/octave) Subsonic Filter (12 dB at 24 Hz) Frequency response: 20-20,000 Hz CEA-2006 compliant amplifier Dimensions: 9-1/4"L x 8-3/4"W x 2-1/2"H 4-gauge power and ground wiring is required for installation
Legendary Products & Support From Authorized Dealers
When you choose Orion, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Orion dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Orion's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Orion dealer today!
The Reference In Car Audio Amplification Get Pure Sound Using Pioneer PRS Amplifiers The goal of a good amplifier is to cleanly amplify the music signal, free of distortion or added color. The Premier PRS-D2200T is a new generation of Class FD (Full-Range Class D) amplifiers that clearly achieves this goal. Using an exclusing designed ICEpower circuit, music comes through clear, crisp and detailed. Class-FD ICEpower Amplifier Class-FD (Full Range Class-D) ICEpower amplifiers combine ultra-efficient Class-D circuitry and ICEpower digital amplifier technology for cleaner, truer sound quality featuring tight bass with minimal lag effect; crisp, airy mids and highs; and unsurpassed specifications. The key to superior full range performance is Controlled Oscillation Modulation (COM) and Multivariable Enhanced Cascade Control (MECC). Superior Channel Separation PRS amplifiers feature Left and Right independent signal circuitry that eliminates signal interference between the channels and achieves excellent channel separation throughout a wider frequency range. Full Custom-Made Power Supply Capacitor Bank In the quest for optimal bass, Pioneer focused on the PRS amplifier's power handling. With a high-capacity, custom-made capacitor bank adapted to the power supply section, this amp supplies power with rock-solid stability, and does an excellent job of reproducing low-frequency sound. Linear Technology Operational Amplifier The PRS amplifier features this Linear Technology Corporation operational amplifier (OP AMP) used in high-end home audio amplifiers for its precise gain and sound linearity characteristics. The PRS-D1200M includes the OP AMP in its bass boost circuitry to prevent sound quality deterioration. Energy Saving Design A huge benefit is the Class FD design, which consumes far less current than traditional amplifier designs. This results in less draw on your vehicle's alternator, and could actually improve fuel mileage in many cases. It also allows for a compact chassis (heatsink) that takes up less space and provides more installation flexibility. Variable Crossover (40~500Hz, HPF/LPF) For added flexibility, the variable crossover lets you optimize your system's efficiency and delivers the best possible sound quality. You can adjust it continuously between 40 to 500Hz, as well as selecting from either High-Pass Filter (use for your main speakers) or Low-Pass Filter (use for your subwoofers), giving you the ultimate flexibility in setting up your system. Selectable Bass Boost with Wired Bass Remote So you're in the driver's seat going 65mph and you want to fine-tune the bass boost. But the amp's out of reach, way in the back. What are you supposed to do — pull over, get out, and run around to the trunk? That's why the PRS-D2200T comes with a wired bass remote. It's set at 50Hz, ideal for tuning in some more thump from your subwoofers. And because this is selectable bass boost, you can set the level at 0dB, 6dB, or 12dB, whichever sounds best to you. Speaker Level Inputs What, you DON'T own a Pioneer headunit? Well, we won't hold it against you. In fact we'll even help you build onto your system. The PRS-D2200T's speaker level inputs allow you to connect your OEM unit (or any unit that doesn't have the typical RCA-type inputs) without having to buy add-on adapters. Premier® Two-Year Warranty The warranty on this model is two years — double the warranty period of typical models currently on the market. Features: Bridegeable 1/2-Channel Capability Bass Boost Remote Variable LPF/HPF (40 Hz to 500 Hz, -12 dB/oct) Input level control (400 mV to 6.5 V) Low load impedance capability (4 ohm, 2 to 8 ohm allowable) Gold-Plated RCA input & output terminals, speaker terminals, and power/ground terminals Speaker level input (1.6 V to 26 V) Speaker line turn on sensor High-performance balanced isolator input circuit High-Efficiency MOSFET output section TVC (Total Vibration Control) Technology CEA2006 Specifications: 150 Watts x 2, at 4 ohms <= 1% THD+N 600 Watts x 1, at 4 ohms BRIDGE <= 1% THD+N 80 dBA Signal-to-Noise Ratio (Reference: 1 Watt Output) Specifications: Peak Music Power: 1200 Watts Number of Channels: 20 Load Impedance Capability: 2~8 Ohm (Stereo), 4~8 Ohm (Bridged) Continuous Power (4 Ohms): 150W x 2 Continuous Power (2 Ohms): 300W x 2 Continuous Power Bridged (4 Ohms): 600W x 1 Frequency Response: 10Hz ~ 40kHz Total Harmonic Distortion: 0.005% Signal-to-Noise Ratio: 100 dB Dimensions: 12 x 2-1/4 x 8 Input Level Control: Hi-Volt (400mV ~ 6.5V) Built-in Crossover: 2ch. HPF/LPF Crossover Frequency Range: 40~120Hz, -12dB/Oct. Bass Level Control: 50Hz, 0/6/9/12dB, with Remote
Legendary Products & Support From Authorized Dealers
When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Pioneer dealer today!
Two channels. BRT efficiency. Built for motorcycles, ATVs, and stealth installs.
Product Overview
The Rockford Fosgate PBR300X2 is a 2-channel amplifier from the Punch series, delivering 300W total using Rockford Fosgate's patented BRT (Boosted Rail Technology). Unlike conventional 2-channel amplifiers that rely on a switching power supply to generate their output, BRT achieves rated power through an ultra-efficient design that eliminates the switching stage entirely resulting in a chassis significantly smaller than a traditional amplifier of equivalent output. Total power is 300W across two channels; power per channel and impedance breakdown are not specified in supplier-provided data.
The PBR300X2 is positioned for installations where space and electrical draw are primary constraints. Motorcycles requiring stereo speaker output, ATVs, and recreational vehicles with limited mounting real estate are the target use cases along with stealth car and marine builds where a standard amplifier chassis simply won't fit. The variable 4–6V hi-level DC offset turn-on circuit allows direct integration with OEM speaker outputs in systems that don't provide a dedicated remote turn-on wire, while high-level inputs eliminate the need for an aftermarket head unit or RCA outputs. A 12dB/octave Butterworth crossover and MOSFET output stage complete a practical, installation-friendly feature set.
Key Specifications
Channels: 2
Total output power: 300W (power per channel and impedance breakdown — not specified)
Power supply technology: BRT (Boosted Rail Technology — no switching power supply)
Output stage: MOSFET
Crossover: 12dB/octave Butterworth (frequency range — not specified)
Signal input: High level
Turn-on method: Variable hi-level DC offset (4–6V)
Chassis: Ultra-compact
Bridgeable: Not specified
Frequency response: Not specified
Input sensitivity: Not specified
Nominal impedance: Not specified
CEA compliance: Not specified in provided data
Power wire gauge: Not specified
Speaker wire gauge: Not specified
Operating voltage: Not specified
Recommended fuse: Not specified
Dimensions: Not specified
Features & Benefits
BRT (Boosted Rail Technology) — No Switching Power Supply — The PBR300X2 uses Rockford Fosgate's patented BRT architecture to produce rated power without a conventional switching power supply. This reduces current draw, minimises electrical noise, and shrinks the chassis to a fraction of the size of a traditional 2-channel amplifier — making it viable for vehicle types and install locations that would otherwise rule out amplification entirely.
Ultra-Compact Chassis — Stereo Power in a Stealth Footprint — Where the PBR300X1 delivers mono output for a single driver, the PBR300X2 provides two independent channels from the same compact BRT platform. This makes it the logical choice for motorcycle stereo builds — left and right speaker channels from a single unit that installs in a saddlebag, underseat compartment, or within a fairing. Exact dimensions are not specified in supplier data — confirm with Rockford Fosgate before planning a space-critical install.
Variable Hi-Level DC Offset Turn-On (4–6V) — Motorcycles, ATVs, and many OEM car audio systems either lack a dedicated remote turn-on output or carry a DC offset on their speaker outputs. The PBR300X2's variable DC offset circuit detects a 4–6V signal on the speaker inputs and uses it to power the amplifier — removing the need to source and run a remote wire in installations where doing so is difficult or impossible.
High-Level Inputs — Accepts signal directly from the speaker outputs of a factory head unit, OEM radio, or handlebar-mounted controller. No line output converter or aftermarket head unit is required, keeping the installation simple and the component count low — particularly relevant for motorcycle and recreational vehicle builds where simplicity and reliability matter.
MOSFET Output Stage — The MOSFET output stage contributes to the compact, efficient character of the PBR300X2 and handles the variable voltage and vibration conditions common in motorcycle and off-road vehicle environments more reliably than earlier output stage designs. It also supports the BRT architecture's low-heat operating profile.
12dB/Octave Butterworth Crossover — The on-board Butterworth crossover allows the two output channels to be filtered, directing appropriate frequency ranges to different speakers in a system. The crossover frequency range is not specified in supplier data — confirm with Rockford Fosgate before planning a multi-speaker install.
Technical Specs
Specification
Detail
Channels
2
Total output power
300W
Power per channel
Not specified
Power by impedance
Not specified
Power supply
BRT — no switching power supply
Output stage
MOSFET
Circuit topology
Not specified
Frequency response
Not specified
Input sensitivity
Not specified
THD+Noise
Not specified
Nominal impedance
Not specified
Bridgeable
Not specified
Crossover type
12dB/octave Butterworth
Crossover frequency range
Not specified
Signal input
High level
Turn-on method
Variable hi-level DC offset, 4–6V
CEA compliance
Not specified
Power wire gauge
Not specified
Speaker wire gauge
Not specified
Operating voltage
Not specified
Recommended fuse
Not specified
Dimensions
Not specified
Weight
1.27 kg
Compatible With / Goes Well With
The PBR300X2 is confirmed by the manufacturer for use in the following applications:
Motorcycles requiring 2-channel (stereo) speaker amplification
ATVs and off-road recreational vehicles
Smaller stealth car, marine, or custom installations with limited space
OEM/factory audio systems (via variable hi-level DC offset turn-on)
Goes well with:
Compact 2-channel speakers suited to motorcycle, ATV, or stealth car audio builds
Factory head units and OEM audio systems (high-level input compatible)
Marine or weatherproof speaker enclosures for recreational vehicle applications
Frequently Asked Questions
What is BRT (Boosted Rail Technology) and why does it matter for a 2-channel amp?
BRT is Rockford Fosgate's patented amplifier architecture that generates rated power without a switching power supply. The result is a significantly smaller and more efficient chassis than a conventional 2-channel amplifier — making stereo amplification viable in motorcycles, ATVs, and stealth builds where space and current draw are limited.
How much power does each channel produce?
Total power is 300W across both channels. The per-channel power rating and impedance breakdown are not specified in supplier-provided data. Contact Rockford Fosgate or your authorised dealer to confirm per-channel output before matching to speakers.
Will the PBR300X2 work on a motorcycle or ATV?
Yes. The PBR300X2 is specifically designed for motorcycles, ATVs, and recreational vehicles. The BRT architecture's low current draw and ultra-compact chassis make it practical for these applications, and the variable DC offset turn-on circuit supports OEM systems that lack a standard remote turn-on output.
What is the variable DC offset turn-on circuit?
Many motorcycle and OEM systems output a 4–6V DC offset on their speaker lines rather than a dedicated remote turn-on signal. The PBR300X2 detects this voltage and uses it to power the amplifier automatically — eliminating the need to wire a separate remote turn-on lead in most factory and recreational vehicle installations.
Can the PBR300X2 be used in a standard car or truck installation?
Yes, though it is engineered primarily for space-constrained and stealth applications. It suits any car or truck installation where a compact chassis, low current draw, and factory head unit compatibility are priorities. Standard amplifier features such as RCA inputs, Punch EQ, and remote level control are not confirmed in supplier data — verify the full feature set with Rockford Fosgate if these are required.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
250 watts per channel. 500 watts bridged. Punch EQ2 tone control and real-time output monitoring.
Product Overview
The Rockford Fosgate P500X2 is a 2-channel Class A/B stereo amplifier from the Punch series, delivering 250W RMS per channel into 2-ohm loads or 150W per channel at 4 ohms. When bridged, it combines both channels into a single 500W RMS mono output at 4 ohms, making it a capable driver for a pair of 8-ohm SVC subwoofers in parallel, or a quad configuration of 2-ohm DVC subwoofers. Total rated output is 500W RMS, CEA-2006 verified.
Where the P500X2 stands apart within the Punch 2-channel range is its Punch EQ2 tone control system a dual-band EQ offering up to +18dB of bass boost at 45Hz and up to +12dB of treble lift at 12kHz, with the active EQ function varying depending on the amplifier's LP/AP/HP crossover switch position. Combined with a tri-colour output clip LED that displays real-time THD levels, an independent input clip LED, and thermal protection monitoring, the P500X2 gives the installer and listener more visibility into amplifier performance than any other unit in the Punch stereo range. Wide input sensitivity (150mV–12V) supports a broad range of source units, and Captive C-Clamp connectors on both power and speaker terminals provide a secure, vibration-resistant connection.
Key Specifications
Channels: 2
Rated power @ 4 ohms: 150W RMS x 2
Rated power @ 2 ohms: 250W RMS x 2
Rated power bridged @ 4 ohms: 500W RMS x 1
Total rated power: 500W RMS (CEA-2006)
Dynamic power @ 4 ohms: 223W x 2 (PowerCube)
Dynamic power @ 2 ohms: 365W x 2 (PowerCube)
Bridgeable: Yes — 500W x 1 @ 4 ohms
Circuit topology: Class A/B
Efficiency (average): 73% @ 4 ohms
Frequency response: 20Hz – 20kHz (+/-1dB)
Input sensitivity: 150mV – 12V
THD+Noise: <1.0% @ 4 ohms / <1.0% @ 2 ohms
Punch EQ2 Bass: 0dB to +18dB @ 45Hz
Punch EQ2 Treble: 0dB to +12dB @ 12kHz
Crossover: 12dB/octave Butterworth — LP / AP / HP switch
Signal input: Hi/Low level, 1 x RCA pair
Signal output: 1 x RCA pair (pass-through)
Remote control: Optional PLC2 (not included — sold separately)
Visual indicators: Power / Protect / Thermal LED, Input Clip LED, Output Clip LED (tri-colour THD)
Power wire gauge: 4 AWG
Power input connector: Captive C-Clamp
Speaker wire gauge: 8 AWG – 18 AWG
Speaker output connector: Captive C-Clamp
Cooling: Convection
Operating voltage: 9–16V DC
Recommended fuse: 80A (not included)
Average current draw: 40A @ 13.8V (music)
Max current draw: 80A @ 13.8V (sinewave)
Suggested alternator: 75A minimum
Dimensions (H x W x D): 6.05 x 19.71 x 33.73 cm
Shipping weight: 5.57 kg
Compliance: CEA-2006
Features & Benefits
250W Per Channel @ 2Ω | 500W Bridged @ 4Ω — Full Flexibility — Run in stereo at 250W per channel for a pair of speakers, or bridge to a single 500W mono output for a subwoofer configuration. The P500X2 covers both use cases from one chassis — useful for systems that may evolve from a speaker-focused build to one incorporating a dedicated subwoofer without requiring a second amplifier purchase.
Punch EQ2 — Dual-Band Bass and Treble Control — Unlike the single-band Punch EQ found on other amplifiers in the range, the Punch EQ2 includes both a bass control (0dB to +18dB @ 45Hz) and a treble control (0dB to +12dB @ 12kHz). The active EQ band changes depending on the crossover switch position — in Low-Pass mode the bass EQ is operative, in High-Pass mode the treble EQ is operative, and in All-Pass (bypass) mode both bands can be used simultaneously. This allows frequency-appropriate tuning regardless of how the amplifier is deployed in the system.
Tri-Colour Output Clip LED — Real-Time THD Monitoring — The output clip LED displays three distinct states based on measured distortion at the output stage: blue indicates clean output below 0.5% THD, violet indicates approaching 1% THD, and red signals 10% or greater THD — a level that causes audible distortion and risks speaker damage. This real-time feedback allows gain calibration confirmation after installation and ongoing monitoring during use. It is one of the most practical diagnostic tools available on an amplifier at this price point.
Independent Input Clip LED — A separate LED monitors the incoming signal for clipping before it enters the amplifier. Combined with the output clip LED, this allows the installer to distinguish between clipping at the source (head unit or preamp) and clipping generated within the amplifier itself — essential for accurate gain structure setup.
C.L.E.A.N. Setup System — The on-board C.L.E.A.N. calibration system works alongside the clip LEDs to guide precise gain matching between the source unit and the P500X2. Together, these tools eliminate the guesswork that causes premature speaker failure from miscalibrated gain settings.
Wide Input Sensitivity (150mV – 12V) — An unusually broad input sensitivity range accommodates everything from low-output factory head units to high-output aftermarket preamps without requiring external level adjustment. This extends compatibility across a wide range of source units in new and factory-retained head unit configurations.
High-Level Input with Auto Turn-On — Accepts speaker-level signal from factory head units and powers on automatically when signal is detected — no remote turn-on wire required. The wide 150mV–12V sensitivity range further simplifies integration with both OEM and aftermarket systems.
Optional PLC2 Remote Level Control — The P500X2 is wired and ready for the Rockford Fosgate PLC2 (sold separately), adding driver-accessible output adjustment and activating the input clip indicator for front-seat gain monitoring. Not included — sold separately.
Captive C-Clamp Connectors — Power input and speaker output terminals use Captive C-Clamp connectors rather than standard screw terminals. The C-Clamp design applies distributed clamping pressure across a wider contact area, providing a more vibration-resistant and mechanically secure connection — particularly beneficial in vehicles subject to road vibration, off-road use, or high-power current demands.
RCA Pass-Through Output — Signal chains cleanly to a second amplifier via the RCA pass-through — useful in systems running the P500X2 on speakers alongside a separate Punch mono amplifier handling subwoofer duty.
LP / AP / HP Crossover Switch — The three-position crossover switch configures the P500X2 as a low-pass filtered amplifier (sub channel), all-pass (full-range), or high-pass filtered (speaker channel in a crossed-over system), each mode also governing which EQ band of the Punch EQ2 is active. Crossover frequency range is not specified in the provided data — confirm with Rockford Fosgate.
Thermal LED + Full Protection — A dedicated thermal LED provides visual warning of elevated operating temperatures before the protection circuit activates. Over-current and short-circuit protection are active across both channels, and muted turn-on prevents power-up thumps that can stress tweeters.
Technical Specs
Specification
Detail
Channels
2
Rated power @ 4Ω
150W RMS x 2
Rated power @ 2Ω
250W RMS x 2
Rated power — bridged @ 4Ω
500W RMS x 1
Total rated power
500W RMS
Dynamic power @ 4Ω
223W x 2 (PowerCube)
Dynamic power @ 2Ω
365W x 2 (PowerCube)
Bridgeable
Yes
Circuit topology
Class A/B
Efficiency (average)
73% @ 4Ω
Frequency response
20Hz – 20kHz (+/-1dB)
Input sensitivity
150mV – 12V
THD+Noise
<1.0% @ 4Ω / <1.0% @ 2Ω
Punch EQ2 Bass
0dB to +18dB @ 45Hz
Punch EQ2 Treble
0dB to +12dB @ 12kHz
Crossover
LP / AP / HP switch — 12dB/octave Butterworth
Crossover frequency range
Not specified
Signal input
Hi/Low level, 1 x RCA pair
Signal output
1 x RCA pair (pass-through)
Remote control
Optional PLC2 (sold separately)
Output clip LED
Tri-colour: Blue (<0.5% THD) / Violet (1% THD) / Red (10%+ THD)
Input clip LED
Yes
Thermal LED
Yes
Power / Protect LED
Yes
Power wire gauge
4 AWG
Power input connector
Captive C-Clamp
Speaker wire gauge
8 AWG – 18 AWG
Speaker output connector
Captive C-Clamp
Cooling
Convection
Operating voltage
9–16V DC
Recommended fuse
80A (not included)
Average current draw
40A @ 13.8V (music)
Max current draw
80A @ 13.8V (sinewave)
Suggested alternator
75A minimum
Dimensions (H x W x D)
6.05 x 19.71 x 33.73 cm
Shipping weight
5.57 kg
Compliance
CEA-2006
Compatible With / Goes Well With
Stereo speaker mode:
4-ohm coaxial or component speakers — 150W RMS per channel
2-ohm coaxial or component speakers — 250W RMS per channel
Component speaker sets with passive crossovers (crossovers not supplied)
Factory and aftermarket head units (150mV–12V input sensitivity)
Bridged mono mode (500W @ 4Ω):
Pair of 8-ohm SVC subwoofers wired in parallel (combined 4Ω load — confirmed by manufacturer)
Quad configuration of 2-ohm DVC subwoofers wired to a combined 4Ω load (confirmed by manufacturer — specific wiring required; professional installation strongly recommended)
Goes well with:
Rockford Fosgate Punch series speakers (matched to 150W or 250W per channel)
Rockford Fosgate P300X1 or Punch mono amplifier (via RCA pass-through for a full two-amp system)
Rockford Fosgate PLC2 Remote Punch Level Control (optional — sold separately)
Aftermarket head units with RCA preamp outputs (150mV–12V sensitivity compatible)
Frequently Asked Questions
What subwoofer configurations can the P500X2 drive when bridged?
Bridged at 4 ohms, the P500X2 produces 500W RMS. The manufacturer confirms two configurations: a pair of 8-ohm SVC subwoofers wired in parallel, or a quad of 2-ohm DVC subwoofers in a specific series/parallel arrangement — both presenting a 4Ω load. Do not bridge below 4 ohms.
What is Punch EQ2 and how does it differ from standard Punch EQ?
Punch EQ2 is a dual-band tone control offering both bass boost (up to +18dB @ 45Hz) and treble boost (up to +12dB @ 12kHz). The active band changes depending on the LP/AP/HP crossover switch position — bass EQ in Low-Pass mode, treble EQ in High-Pass mode, and both available in All-Pass mode.
What does the tri-colour output clip LED indicate?
The output clip LED changes colour based on measured THD at the amplifier's output: blue indicates clean output below 0.5% THD, violet signals approximately 1% THD, and red indicates 10% or greater THD — audible distortion that risks speaker damage. It allows real-time gain monitoring without test equipment.
Is the Punch Level Control included with the P500X2?
No. The PLC2 remote Punch Level Control is an optional accessory sold separately. The P500X2 is fully wired to accept it, and when connected the PLC2 adds driver-accessible output adjustment and activates the input clip indicator for front-seat monitoring.
What does CEA-2006 compliance mean for the P500X2?
CEA-2006 requires power ratings to be measured simultaneously across all channels under defined conditions. The 250W x 2 and 500W bridged figures are verified, real-world specifications — not single-channel burst or inflated peak ratings.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Two channels. BRT efficiency. Built for motorcycles, ATVs, and stealth installs.
Product Overview
The Rockford Fosgate PBR300X2 is a 2-channel amplifier from the Punch series, delivering 300W total using Rockford Fosgate's patented BRT (Boosted Rail Technology). Unlike conventional 2-channel amplifiers that rely on a switching power supply to generate their output, BRT achieves rated power through an ultra-efficient design that eliminates the switching stage entirely resulting in a chassis significantly smaller than a traditional amplifier of equivalent output. Total power is 300W across two channels; power per channel and impedance breakdown are not specified in supplier-provided data.
The PBR300X2 is positioned for installations where space and electrical draw are primary constraints. Motorcycles requiring stereo speaker output, ATVs, and recreational vehicles with limited mounting real estate are the target use cases along with stealth car and marine builds where a standard amplifier chassis simply won't fit. The variable 4–6V hi-level DC offset turn-on circuit allows direct integration with OEM speaker outputs in systems that don't provide a dedicated remote turn-on wire, while high-level inputs eliminate the need for an aftermarket head unit or RCA outputs. A 12dB/octave Butterworth crossover and MOSFET output stage complete a practical, installation-friendly feature set.
Key Specifications
Channels: 2
Total output power: 300W (power per channel and impedance breakdown — not specified)
Power supply technology: BRT (Boosted Rail Technology — no switching power supply)
Output stage: MOSFET
Crossover: 12dB/octave Butterworth (frequency range — not specified)
Signal input: High level
Turn-on method: Variable hi-level DC offset (4–6V)
Chassis: Ultra-compact
Bridgeable: Not specified
Frequency response: Not specified
Input sensitivity: Not specified
Nominal impedance: Not specified
CEA compliance: Not specified in provided data
Power wire gauge: Not specified
Speaker wire gauge: Not specified
Operating voltage: Not specified
Recommended fuse: Not specified
Dimensions: Not specified
Features & Benefits
BRT (Boosted Rail Technology) — No Switching Power Supply — The PBR300X2 uses Rockford Fosgate's patented BRT architecture to produce rated power without a conventional switching power supply. This reduces current draw, minimises electrical noise, and shrinks the chassis to a fraction of the size of a traditional 2-channel amplifier — making it viable for vehicle types and install locations that would otherwise rule out amplification entirely.
Ultra-Compact Chassis — Stereo Power in a Stealth Footprint — Where the PBR300X1 delivers mono output for a single driver, the PBR300X2 provides two independent channels from the same compact BRT platform. This makes it the logical choice for motorcycle stereo builds — left and right speaker channels from a single unit that installs in a saddlebag, underseat compartment, or within a fairing. Exact dimensions are not specified in supplier data — confirm with Rockford Fosgate before planning a space-critical install.
Variable Hi-Level DC Offset Turn-On (4–6V) — Motorcycles, ATVs, and many OEM car audio systems either lack a dedicated remote turn-on output or carry a DC offset on their speaker outputs. The PBR300X2's variable DC offset circuit detects a 4–6V signal on the speaker inputs and uses it to power the amplifier — removing the need to source and run a remote wire in installations where doing so is difficult or impossible.
High-Level Inputs — Accepts signal directly from the speaker outputs of a factory head unit, OEM radio, or handlebar-mounted controller. No line output converter or aftermarket head unit is required, keeping the installation simple and the component count low — particularly relevant for motorcycle and recreational vehicle builds where simplicity and reliability matter.
MOSFET Output Stage — The MOSFET output stage contributes to the compact, efficient character of the PBR300X2 and handles the variable voltage and vibration conditions common in motorcycle and off-road vehicle environments more reliably than earlier output stage designs. It also supports the BRT architecture's low-heat operating profile.
12dB/Octave Butterworth Crossover — The on-board Butterworth crossover allows the two output channels to be filtered, directing appropriate frequency ranges to different speakers in a system. The crossover frequency range is not specified in supplier data — confirm with Rockford Fosgate before planning a multi-speaker install.
Technical Specs
Specification
Detail
Channels
2
Total output power
300W
Power per channel
Not specified
Power by impedance
Not specified
Power supply
BRT — no switching power supply
Output stage
MOSFET
Circuit topology
Not specified
Frequency response
Not specified
Input sensitivity
Not specified
THD+Noise
Not specified
Nominal impedance
Not specified
Bridgeable
Not specified
Crossover type
12dB/octave Butterworth
Crossover frequency range
Not specified
Signal input
High level
Turn-on method
Variable hi-level DC offset, 4–6V
CEA compliance
Not specified
Power wire gauge
Not specified
Speaker wire gauge
Not specified
Operating voltage
Not specified
Recommended fuse
Not specified
Dimensions
Not specified
Weight
4.3 kg
Compatible With / Goes Well With
The PBR300X2 is confirmed by the manufacturer for use in the following applications:
Motorcycles requiring 2-channel (stereo) speaker amplification
ATVs and off-road recreational vehicles
Smaller stealth car, marine, or custom installations with limited space
OEM/factory audio systems (via variable hi-level DC offset turn-on)
Goes well with:
Compact 2-channel speakers suited to motorcycle, ATV, or stealth car audio builds
Factory head units and OEM audio systems (high-level input compatible)
Marine or weatherproof speaker enclosures for recreational vehicle applications
Frequently Asked Questions
What is BRT (Boosted Rail Technology) and why does it matter for a 2-channel amp?
BRT is Rockford Fosgate's patented amplifier architecture that generates rated power without a switching power supply. The result is a significantly smaller and more efficient chassis than a conventional 2-channel amplifier — making stereo amplification viable in motorcycles, ATVs, and stealth builds where space and current draw are limited.
How much power does each channel produce?
Total power is 300W across both channels. The per-channel power rating and impedance breakdown are not specified in supplier-provided data. Contact Rockford Fosgate or your authorised dealer to confirm per-channel output before matching to speakers.
Will the PBR300X2 work on a motorcycle or ATV?
Yes. The PBR300X2 is specifically designed for motorcycles, ATVs, and recreational vehicles. The BRT architecture's low current draw and ultra-compact chassis make it practical for these applications, and the variable DC offset turn-on circuit supports OEM systems that lack a standard remote turn-on output.
What is the variable DC offset turn-on circuit?
Many motorcycle and OEM systems output a 4–6V DC offset on their speaker lines rather than a dedicated remote turn-on signal. The PBR300X2 detects this voltage and uses it to power the amplifier automatically — eliminating the need to wire a separate remote turn-on lead in most factory and recreational vehicle installations.
Can the PBR300X2 be used in a standard car or truck installation?
Yes, though it is engineered primarily for space-constrained and stealth applications. It suits any car or truck installation where a compact chassis, low current draw, and factory head unit compatibility are priorities. Standard amplifier features such as RCA inputs, Punch EQ, and remote level control are not confirmed in supplier data — verify the full feature set with Rockford Fosgate if these are required.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
