A Compact Yet Powerful 2-Channel Amplifier Designed to enhance your in-car audio experience, the powerful GM-A3702 gives you total installation freedom and very low distortion. With a one-body heat sink and gain adjustment of up to 6.5V, you can turn your in-car audio experience into the sound staging environment that you’re looking for. The GM-A3702 offers support for 2 Ohm and 4 Ohm speakers, and can produce up to 500 W of power when bridged. Growing Power, Shrinking SizeNew Pioneer amps brilliantly integrate high-power performance superior to that of previous models in space-efficient sizes for flexibility of installation in various car cabins. Automatic Signal Sensing & Turn OnPioneer amplifiers automatically select the proper input signal mode, either RCA or speaker level. When the receiver is turned on, the amplifier automatically turns on. When connected to an OEM receiver or a receiver without RCA output and utilizing speaker level output, the amp automatically senses the input mode and powers up in sync with the receiver. When connected to an OEM receiver or a receiver without RCA output using speaker wire, the amplifier is turned on at the same time as the receiver. Pioneer’s amplifiers automatically detect the input signal and select RCA level or speaker level. Features: 500 Watts Max Power Automatic signal sensing and Turn-ON Hi-Volt input level control Balanced isolator input circuit Specifications:General RCA Inputs: 2-CH Amplifier Class: Class AB Hi-Res Certified: No Bridgeable: Yes Warranty: 1 Year Speaker Level Input: Yes Fuse Rating: 25A x 1 Bass Boost Remote: No Automatic Signal Sensing and Turn-On: Yes Hi-Volt Input Level Control: 0.3V to 6.5V (RCA in), 3.0V to 26V (SP in) Terminal Type: Screw Load Impedance Allowance (Ohms): 2 to 4 Protection Control System: Yes Dimensions: 246(W) X 60(H) X 180(D) mm Power Continuous Power (RMS) Output @ 1‚Ѷ: N/A Continuous Power (RMS) Output @ 2‚Ѷ: 95W x 2 Continuous Power (RMS) Output @ 4‚Ѷ: 60W x 2 Continuous Power (RMS) Output - Bridged @ 4‚Ѷ: 190W x 1 Audio Adjustments Low-Pass Crossover Frequency: 80 Hz Low-Pass Slope (dB/octave): -12db/oct (A/B CH) High-Pass Crossover Frequency: N/A Bass Boost Frequency: 50 Hz Bass Boost Level: 0/6/12dB Audio Specifications Frequency Response: 10Hz ~ 70kHz Total Harmonic Distortion (THD): <0.05 % Signal-to-Noise (SN) Ratio: >95 dB Legendary Products & Support From Authorized Dealers When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Pioneer dealer today!

Read more less

A Combination of Great Design and Massive Power The GM-A4704 amplifier gives you total installation freedom and no distortion. With a one-body heat sink and gain adjustment of up to 6.5V, you can turn your in-car audio experience into the sound staging environment that you’re looking for. This 4-channel amp allows you to drive multiple speakers and subwoofers, it’s also bridgeable to power a single sub. Variable High Pass Filter Variable HPF (high pass filter) allow for adjustable frequency from 40 Hz to 500 Hz* and greater car audio system flexibility according to subwoofer characteristics and personal listening preference. Growing Power, Shrinking Size New Pioneer amps brilliantly integrate high-power performance superior to that of previous models in space-efficient sizes for flexibility of installation in various car cabins. Automatic Signal Sensing & Turn On Pioneer amplifiers automatically select the proper input signal mode, either RCA or speaker level. When the receiver is turned on, the amplifier automatically turns on. When connected to an OEM receiver or a receiver without RCA output and utilizing speaker level output, the amp automatically senses the input mode and powers up in sync with the receiver. When connected to an OEM receiver or a receiver without RCA output using speaker wire, the amplifier is turned on at the same time as the receiver. Pioneer’s amplifiers automatically detect the input signal and select RCA level or speaker level. Pioneer GM-A4704 Specifications: General RCA Inputs: 4-CH Amplifier Class: Class AB Hi-Res Certified: No Bridgeable: Yes Warranty: 1 Year Speaker Level Input: Yes Fuse Rating: 30A x 1 Bass Boost Remote: No Automatic Signal Sensing and Turn-On: Yes Hi-Volt Input Level Control: 0.3V to 6.5V (RCA in), 3.0V to 26V (SP in) Terminal Type: Screw Load Impedance Allowance (Ohms): 2 to 4 Protection Control System: Yes Dimensions: 326(W) X 60(H) X 215(D) mm Power Continuous Power (RMS) Output @ 1Ω: N/A Continuous Power (RMS) Output @ 2Ω: 65W x 4 Continuous Power (RMS) Output @ 4Ω: 40W x 4 Continuous Power (RMS) Output - Bridged @ 4Ω: 130W x 2 Audio Adjustments Low-Pass Crossover Frequency: 80 Hz Low-Pass Slope (dB/octave): -12db/oct (A/B CH) High-Pass Crossover Frequency: 40 Hz to 500 Hz Bass Boost Frequency: 50Hz Bass Boost Level: 0/6/12dB Audio Specifications Frequency Response: 10Hz ~ 70kHz (+0dB , -3dB) Total Harmonic Distortion (THD): <0.05% ( 10W, 1kHz) Signal-to-Noise (SN) Ratio: > 94dB Legendary Products & Support From Authorized Dealers When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Pioneer dealer today!

Read more less

Rockford Fosgate R2-300X4 Prime 300 Watt 4-Channel Class D Amplifier When four speakers need real power without compromise, the R2-300X4 delivers 300 watts of clean, efficient Class D performance engineered by Rockford Fosgate. Product Overview The R2-300X4 is part of Rockford Fosgate's 3rd generation Prime Series, built for car audio enthusiasts who demand reliable, high-performance amplification at an accessible price. Operating as a full-range Class D 4-channel amplifier, it runs at 4 ohm or 2 ohm stereo and 4 ohm bridged/mono, giving it the flexibility to drive front and rear speaker pairs or reconfigure as a 3-channel or 2-channel setup. Class D topology maximises efficiency and reduces the electrical load on the vehicle's charging system, while MEHSA 4 (Maximum Efficiency Heat Sink Application) actively reduces MOSFET temperatures, lowers distortion, and prolongs output device lifespan. The top-mounted control panel provides independent front and rear controls within easy reach, and CTA-2006 compliant power ratings confirm that the 300W output is a real, tested figure. Designed and engineered in Tempe, Arizona, the R2-300X4 is built by fanatics, for fanatics. Features & Benefits C.L.E.A.N. Technology (Patent 8,712,066): Rockford Fosgate's patented Calibrated Level Eliminates Audible Noise circuit uses dedicated input and output clip LEDs (C.L.E.A.N. IN Red, C.L.E.A.N. OUT Blue/Red for both front and rear) to accurately match the source unit's output to the amplifier's input sensitivity, eliminating guesswork and reducing distortion at the source. P.O.W.E.R. Supply: Onboard power supply design that continues to generate output above the rated RMS figure as vehicle voltage increases, so real-world performance scales beyond the spec sheet across the 9-16V operating range. MEHSA 4 (Maximum Efficiency Heat Sink Application): An advanced thermal management system that reduces MOSFET operating temperatures, lowers distortion levels, increases overall durability, and extends the lifespan of output devices under sustained use. NOMAD Protection: A real-time analogue computer that continuously monitors the amplifier's outputs and protects against shorting speaker wires and dangerously low speaker impedances, providing active fault management rather than passive fusing alone. Balanced Differential Inputs: Differential input topology eliminates noise picked up by signal cables between the source unit and amplifier, delivering a cleaner signal into the amplifier stage. Fully Adjustable Butterworth Crossovers: Independent front and rear 12 dB/octave High-Pass and Low-Pass crossovers, continuously variable from 50 to 250 Hz, with an All-Pass option per channel for full-range output when no filtering is needed. High Level Input Capable: Accepts both low-level RCA (150mV-4V) and high-level speaker signals (450mV-12V) through a 2/4 Channel Input Selection Switch, making integration with factory head units straightforward. Auto-Sense RAP Bypass: Auto-Sense bypass switch supports vehicles with Retained Accessory Power (RAP), allowing the amplifier to power on and off correctly using speaker-level signal detection without requiring a dedicated remote turn-on wire. RCA Pass-Through Outputs: 2-channel RCA pass-through remains active with both RCA and high-level inputs, allowing downstream amplifiers to be added without splitting cables at the head unit. CTA-2006 and CE Compliant: All power ratings verified at 14.4V with 1% or less THD to CTA-2006 industry standards, with no inflated peak figures used anywhere in the specifications. Technical Specs Specification Detail SKU R2-300X4 Series Prime Number of Channels 4 Amplifier Class Class D, Full Range Total RMS Power 300W RMS Power @ 4 Ohm 50W x 4 RMS Power @ 2 Ohm 75W x 4 Bridged Power @ 4 Ohm 150W x 2 Dynamic Power @ 4 Ohm 70W x 4 Dynamic Power @ 2 Ohm 115W x 4 Dynamic Power Bridged @ 4 Ohm 230W x 2 Bridgeable Yes Minimum Impedance (Stereo) 2 Ohm Minimum Impedance (Bridged) 4 Ohm Frequency Response 20 Hz - 20 kHz THD @ 4 Ohm <1.0% THD @ 2 Ohm <1.0% Input Sensitivity (Low-Level) 150 mV - 4V Input Sensitivity (High-Level) 450 mV - 12V Signal Input (Front) 4 x RCA low-level, 4-Pin Molex high-level Signal Input (Rear) 4 x RCA low-level, 4-Pin Molex high-level Input Switch 2/4 Channel (RCA and high-level compatible) Signal Output 2 x RCA pass-through (active with RCA or high-level input) Crossover (Front and Rear) High-Pass / Low-Pass: 50-250 Hz @ 12 dB/octave Butterworth All-Pass Yes Tone Controls No Remote Controls No Visual Indicators POWER (Blue), PROTECT (Red), C.L.E.A.N. IN (Red), C.L.E.A.N. OUT Front (Blue/Red), C.L.E.A.N. OUT Rear (Blue/Red) Operating Voltage 9-16V DC Max Current Draw (13.8V Sinewave) 39A Recommended Fuse 60A (not included) Power Wire Gauge 4 AWG Speaker Wire Gauge 8 AWG Power Input Connector Compression Terminal Block Speaker Output Connector Compression Terminal Block Cooling Convection / Heatsink (MEHSA 4) Dimensions (H x W x D) 1.9" x 6.8" x 10.1" (4.9 cm x 17.3 cm x 25.5 cm) Weight 4.75 lbs (2.15 kg) Warranty 1 Year Compliance CTA-2006, CE Goes Well With The R2-300X4 pairs naturally with Rockford Fosgate Prime Series full-range speakers such as the R165X3, R168X2, R169X2, and R169X3 for a matched front and rear speaker setup. For systems requiring low-end support, the rear channels bridge cleanly to drive a single Prime R1 subwoofer such as the R1S410 or R1S412, with the rear crossover set to Low-Pass. A 4-gauge amplifier wiring kit is required for power and ground runs, and 8-gauge cable is needed for speaker outputs. A quality 4-channel RCA interconnect is recommended for clean signal transfer from the head unit. Frequently Asked Questions Can the R2-300X4 be used to power both speakers and a subwoofer in the same system? Yes. The R2-300X4 supports 3-channel configuration, where the front channels power a pair of full-range speakers and the rear channels are bridged to drive a single subwoofer. Setting the rear crossover to Low-Pass rolls off high frequencies to the sub. The minimum impedance of any bridged channel is 4 ohms, so confirm subwoofer impedance before bridging. Does the R2-300X4 require a remote turn-on wire? When using RCA inputs, a remote turn-on wire must be connected to the head unit's remote output. When using high-level speaker inputs, the Auto-Sense bypass switch can be enabled to allow the amplifier to detect an incoming signal and power on automatically, making it compatible with factory head units and systems that lack a dedicated remote output, including those with Retained Accessory Power (RAP). What does the NOMAD protection system do? NOMAD is a real-time analogue computer built into the R2-300X4 that continuously monitors the amplifier's speaker outputs. It protects the amplifier from damage caused by shorted speaker wires and dangerously low speaker impedances, providing active, dynamic protection rather than relying solely on a fuse. What gauge power, ground, and speaker wire does the R2-300X4 require? Rockford Fosgate specifies 4 AWG for power and ground runs using the included compression terminal block connectors. Speaker output connections use 8 AWG wire. The recommended 60A fuse is not included in the box and must be sourced separately, installed as close to the battery as possible. Can the R2-300X4 be bridged into a 2-ohm load for maximum power? No. When bridging the R2-300X4, the minimum supported impedance per bridged output is 4 ohms. Running a bridged channel into a 2-ohm load is not supported and risks amplifier failure or NOMAD-triggered protection shutdown. In standard stereo mode, the minimum impedance per channel is 2 ohms.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Excellent For OEM Systems Upgrade!   D-Class 4-Channel AmplifierThe Hertz DPower4 Car Audio Amplifier is an ultra-compact to ensure effortless installations in the increasingly narrow spaces of modern vehicles or in the factory amp area. The efficient D Class circuit delivers 600W of maximum power within a compact chassis, an essential requirement for in-car integration. The versatile crossover filter of the DPower 4 enables the user to create a front-rear or front + subwoofer system by connecting two channels in bridge mode. The double speaker & RCA inputs allows the DPower4 to connect to any type of source, be it OEM or aftermarket. For an excellent integration with OEM systems the DPower4 is equipped with a smart automated turn on and off circuit according to the factory radio. Legendary Products & Support From Authorized Dealers When you choose HERTZ, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized HERTZ dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by HERTZ's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized HERTZ dealer today!

Read more less

8-Channel Car Amplifier with Digital Signal Processing from JBL!The JBL Audio DSP4086 is one of the best ways to get superior sound fidelity in your car. JBL's incredibly compact DSP4086 8-channel amp/processor will do both, providing eight channels of 40 watts RMS while sculpting the sound with powerful tuning software using your Windows PC.Connecting to the whole systemThe DSP4086 was designed to take the signals from your vehicle's front speakers, rear speakers, front center channel, and rear subwoofer. You can then process those signals to create eight powered outputs, and you have the ability to power and control your front tweeters.TuningEvery channel features 31-band EQ, switchable from parametric to graphic; completely variable high-, low-, and band-pass filters with selectable slopes; time delay, up to 12ms in 0.2ms increments; and 0/180¬∞ phase adjustment. You can assign each input to an output, and you can sum signals in order to create a full-range signal to be processed.Features: 8-channel car amplifier with digital signal processing 40 watts RMS x 8 at 4 ohms 60 watts RMS x 8 at 2 ohms DSP and EQ tuning tool adjustments made via USB connection to a Windows PC Save up to 10 presets Inputs: 6 assignable preamp and speaker-level (RCA adapters included) Outputs: 8 powered and processed Adjustment Details 31-band EQ (selectable parametric or graphic) Adjustable high-, low-, and band-pass filters (20-20,000 Hz) Selectable filter slopes 6, 12, 18, 24, 30, 36, 42, 48 dB/octave) Adjustable delay: 0 to 12ms in 0.2ms increments Phase adjustment: 0 or 180¬∞ Programming done by a Windows-run PC Other Features Includes wired remote for ch 7/8 Fuse rating: 40A x 1 Wiring and hardware not included with amplifier 8-gauge power and ground leads recommended Dimensions: 5-11/16‚Ä≥W x 2‚Ä≥H x 9-3/8‚Ä≥D What's in the Box: 8-Channel DSP amplifier w/ attached 6‚Ä≥ 6-RCA input harness Remote bass level control 16.5‚Ä≤ Remote level control cable (RJ-12 connectors both ends) 8‚Ä≥ Power/ground/Rem harness (inline 40A ATO fuse) 8‚Ä≥ 16-Pin speaker output harness 70‚Ä≥ USB Cable (type-A both ends / 2.0) 6 Input adapters (RCA to set-screw) Spare 40A ATO fuse Four 15mm screws Two 10mm screws 4 Large flat-washers 4 Small flat-washers 4 Lock-washers Four 6-1/2‚Ä≥ wire ties Owner's manual (Eng/Span/Fren/Others) Legendary Products & Support From Authorized Dealers When you choose JBL, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized JBL dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by JBL's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized JBL dealer today!

Read more less

Super Small Multi-Channel The new SS amplifiers are the latest in high speed, high current class D designs offering high power and superior sound quality in compact footprints. The classic DD AUDIO style heat sink is used in this upgrade for max cooling with 50% more side wall thickness than industry norms and extra long fins to increase surface area. All major components have been upgraded; higher current mosfets and output devices, increased power capacitors, a more powerful transformer, plus improved venting and PCB with twice the thermal capability.These new high-end mini amps are state of the art, no compromise designs yielding the best sound with unparalleled power to size ratio. The transformation is not only tangible, but audibly apparent.The SS4.500 is a 4 channel amplifier delivering a minimum of 125 Watts per channel from a mere 30 square inch footprint. This versatile, high speed, class D design can drive full range components and subwoofers through selectable high pass and low pass crossovers. These super small amplifiers are the ultimate combination of precision sound quality and installation ease. For the SS Series the main design focus was to pack as much full-range stereo output capability as possible into as compact of a chassis as possible. We utilized discrete circuit class D technology for ultra low distortion levels that rival class AB designs. The resulting amp is capable of driving multiple driver mid-range and tweeter arrays while consuming less current, taking up less space and delivering more power. Features: High Level Inputs 12dB/Oct High Pass/Low Pass X-Overs Heavyweight DD Aluminum Chassis Set Screw Power and Speaker Terminals 4 AWG Power Terminals Specifications: Operating Voltage: 9 - 16 Test Voltage: 14.4 Input Channel(s): 4 Output Channel(s): 4 Continuous Wattage @4ohm: 75 x 4 Continuous Wattage @2ohm: 125 x 4 Max Current Draw (Amps): 40 RCA Input Voltage Sensitivity: 6 - 0.25 High-Level Input Voltage Sensitivity: 20 - 1.1 RCA Input S/N: > 95 Damping Factor: > 100 THD: < 0.1% Frequency Response (Hz): 20 - 20k High Pass Filter: 35 - 250 Low-Pass Filter: 35 - 250 ZVL Input: No Pass Thru Output: No Power Wire Gauge: 4 Speaker Wire Gauge: 12 Dimensions (Inches): 5.75 x 4.5 x 2 Dimensions (MM): 146 x 115 x 50 Shipping Weight (Lbs): 4 Legendary Products & Support From Authorized Dealers When you choose DD Audio, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized DD Audio dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by DD Audio's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized DD Audio dealer today!

Read more less

Rockford Fosgate R2-500X4 Prime 500 Watt 4-Channel Full-Range Class-D Car Amplifier A 500W 4-channel Full-Range Class-D car amplifier delivering 125W x 4 at 2-ohm or 250W x 2 at 4-ohm bridged (CTA-2006 rated). Features independent front and rear channel crossover control with all-pass mode, 2/4 channel input selection switch, RCA pass-through outputs, C.L.E.A.N. gain calibration with per-channel output clip indicators, Rollback Protection, NOMAD speaker protection, and MEHSA4 heat management. Designed and engineered in Tempe, Arizona. Backed by a 1 year warranty. Product Overview The Rockford Fosgate R2-500X4 is a 500W 4-channel Full-Range Class-D car amplifier from the Prime R2 series, purpose-built for powering car speaker pairs across the full audio spectrum. Rated continuous power is 75W x 4 at 4-ohm, 125W x 4 at 2-ohm, or 250W x 2 at 4-ohm bridged (CTA-2006, less than 1.0% THD+N). Dynamic power via PowerCube reaches 90W x 4 at 4-ohm, 160W x 4 at 2-ohm, and 300W x 2 at 4-ohm bridged. The R2-500X4 provides independent front and rear channel crossover control, each with fully adjustable high-pass and low-pass filters at 12dB/octave Butterworth (50Hz-250Hz) and an all-pass mode for full-bandwidth output. Independent front and rear variable input gain adjustment is provided. A 2/4 channel input selection switch configures the amplifier for source units with either 2 or 4 RCA outputs, working for both RCA and high-level inputs. RCA pass-through outputs allow downstream amplifier chaining - the R2-750X1 monoblock subwoofer amplifier is the natural companion for a complete car audio system. Auto-Sense turn-on activates the amplifier when a speaker-level signal is detected, with a RAP bypass switch for Retained Accessory Power systems. C.L.E.A.N. provides separate input and output clip indicators for both front and rear channel groups. Rollback Protection, NOMAD speaker protection, and MEHSA4 heat management are all active. Cast aluminium heatsink with convection cooling. Designed and engineered in Tempe, Arizona. Features & Benefits Full-Range Class-D - Efficient 4-Channel Car Audio Amplification: Full-Range Class-D topology delivers high-efficiency power across the complete 20Hz-20kHz audio spectrum, reducing current demand on the vehicle's electrical system while powering speaker pairs with clean, accurate output. Independent Front and Rear Crossover Control with All-Pass Mode: Front and rear channels each have independent high-pass and low-pass crossover controls at 12dB/octave Butterworth (50Hz-250Hz) plus an all-pass mode for full-bandwidth output, giving more flexibility than a single shared crossover. 2/4 Channel Input Selection Switch: The input selection switch configures the R2-500X4 to accept either a 2-channel or 4-channel RCA or high-level input, working with source units that have limited RCA output pairs without requiring Y-cables or signal splitting. Bridgeable to 2-Channel - 250W Mono per Pair: The R2-500X4 can be bridged to 2-channel, delivering 250W x 2 at 4-ohm (300W dynamic), suited to driving higher-power speaker pairs or running a compact 2-channel installation. RCA Pass-Through Outputs for Downstream Chaining: RCA pass-through outputs are active with both RCA and high-level input, allowing the signal to be passed to a downstream subwoofer amplifier such as the R2-750X1 without signal degradation. C.L.E.A.N. Technology - Independent Per-Channel Clip Monitoring: C.L.E.A.N. provides separate input and output clip indicator LEDs for both the front and rear channel groups, enabling accurate independent gain calibration across all four channels. Auto-Sense Turn-On with RAP Bypass: Auto-Sense activates the amplifier automatically when a high-level input signal is detected, removing the need for a dedicated remote turn-on wire. A bypass switch is included for vehicles with Retained Accessory Power systems. Rollback Protection and NOMAD Speaker Protection: Rollback Protection dynamically manages output to prevent thermal stress during sustained high-output conditions. NOMAD provides real-time protection against shorted speaker wires and dangerously low impedances. Technical Specs Specification Detail SKU R2-500X4 Number of Channels 4 Total Power 500W Rated Power - 4-ohm (CTA-2006, less than 1.0% THD+N) 75W x 4 Rated Power - 2-ohm (CTA-2006, less than 1.0% THD+N) 125W x 4 Rated Power - 4-ohm Bridged (CTA-2006) 250W x 2 Dynamic Power - 4-ohm (PowerCube) 90W x 4 Dynamic Power - 2-ohm (PowerCube) 160W x 4 Dynamic Power - 4-ohm Bridged (PowerCube) 300W x 2 Circuit Topology Full-Range Class-D Bridgeable Yes Frequency Response 20 Hz - 20 kHz THD + Noise Less than 1.0% at 4-ohm and 2-ohm Input Sensitivity Low-Level: 150mV - 4V / High-Level: 450mV - 12V Signal Input Front: 4 x RCA + 4-Pin Molex / Rear: 4 x RCA + 4-Pin Molex Input Selection 2/4 Channel Switch (RCA and High-Level) Signal Output 2 x RCA Pass-Thru (active with RCA or High-Level input) Tone Controls None Front High-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth Front Low-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth Rear High-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth Rear Low-Pass Crossover 50 Hz - 250 Hz at 12dB/Octave Butterworth All-Pass Yes Remote Controls None Auto-Sense Turn-On Yes (with RAP bypass switch) Power Wire Gauge 4 AWG Power Input Connector Compression Terminal Block Speaker Wire Gauge 8 AWG Speaker Output Connector Compression Terminal Block Cooling Convection Heatsink Cast Aluminium Operating Voltage 9 - 16 VDC Recommended Fuse (not included) 80A Max Current Draw at 13.8V Sinewave 59A Visual Indicators Power: Blue / Protect: Red / C.L.E.A.N. In: Red / C.L.E.A.N. Out Front and Rear: Blue/Red Dimensions (H x W x D) 49 x 173 x 255mm (1.9 x 6.8 x 10.1 inch) CTA-2006 Compliant Yes Warranty 1 Year Compatible With / Goes Well With The R2-500X4 suits car audio builds requiring an efficient 4-channel full-range amplifier for speaker pairs at the Prime R2 price point. At 59A maximum current draw and an 80A fuse requirement, it places moderate demand on the vehicle's electrical system. The RCA pass-through output pairs naturally with the R2-750X1 mono subwoofer amplifier for a complete R2 series speaker and subwoofer system. Goes Well With: R2-750X1 - Companion R2 series 750W mono subwoofer amplifier, chainable via the R2-500X4's RCA pass-through outputs for a complete R2 series car audio system R2-750X5 - Alternative single-unit 5-channel R2 series amplifier for builds requiring an integrated subwoofer channel alongside speaker amplification R2-2X12 / R2-2X10 - Rockford Fosgate Prime dual loaded subwoofer enclosures when paired with the R2-750X1 companion monoblock RFK4 - Rockford Fosgate 4 AWG amplifier wiring kit to complete the installation Frequently Asked Questions What is the difference between the R2-500X4 and the R2-750X5? The R2-500X4 is a 4-channel full-range amplifier rated at 125W x 4 at 2-ohm with no dedicated subwoofer channel, no Punch EQ, and no remote level control. The R2-750X5 is a 5-channel amplifier rated at 100W x 4 plus 350W subwoofer at 2-ohm, adding a dedicated subwoofer channel with Punch EQ, infrasonic filter, RLC remote level control, and a 2/4/5 channel input switch. Choose the R2-500X4 for a pure 4-channel speaker amplifier and pair it with the R2-750X1 for subwoofer duty; choose the R2-750X5 for a single-unit 5-channel solution. Can I add a subwoofer amplifier to a system using the R2-500X4? Yes. The R2-500X4 includes RCA pass-through outputs that are active with both RCA and high-level input, allowing a distortion-free signal to be passed to a downstream mono subwoofer amplifier such as the R2-750X1. The two amplifiers chain together cleanly for a complete 4-channel speaker plus mono subwoofer car audio system. What does the 2/4 channel input selection switch do? The input selection switch configures the R2-500X4 to accept either a 2-channel or 4-channel input from the source unit, working for both RCA and high-level connections. In 2-channel mode, the single stereo RCA pair feeds all four channels internally. In 4-channel mode, separate front and rear RCA pairs are used for independent left/right front and rear channel control. What fuse does the R2-500X4 require and is it included? The R2-500X4 requires an 80A fuse, which is not included and must be sourced separately. This is smaller than the 120A fuse required by the R2-750X5 and R2-750X1, reflecting the R2-500X4's lower maximum current draw of 59A. Install the fuse as close to the battery as possible in the 4 AWG power supply line. Does the R2-500X4 need a dedicated remote turn-on wire? Not necessarily. Auto-Sense activates the amplifier automatically when a high-level speaker signal is detected at the input, removing the need for a separate remote wire in OEM integration scenarios. A RAP bypass switch is included for vehicles where the source unit continues to output a signal after the ignition is switched off.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate R2-200X2 Prime 200 Watt 2-Channel Class D Amplifier When two channels need real power without compromise, the R2-200X2 delivers 200 watts of clean, efficient Class D performance engineered by Rockford Fosgate. Product Overview The R2-200X2 is part of Rockford Fosgate's 3rd generation Prime Series, built for car audio enthusiasts who demand reliable, high-performance amplification at an accessible price. Operating as a full-range Class D 2-channel amplifier, it runs at 4 ohm or 2 ohm stereo and 4 ohm bridged/mono, giving it the flexibility to drive a front speaker pair in stereo or bridge down to a single channel to power a subwoofer. Class D topology maximises efficiency and reduces the electrical load on the vehicle's charging system, while MEHSA 4 (Maximum Efficiency Heat Sink Application) actively reduces MOSFET temperatures, lowers distortion, and prolongs output device lifespan. The top-mounted control panel keeps all adjustments within easy reach, and CTA-2006 compliant power ratings confirm that the 200W output is a real, tested figure. Designed and engineered in Tempe, Arizona, the R2-200X2 is built by fanatics, for fanatics. Features & Benefits C.L.E.A.N. Technology (Patent 8,712,066): Rockford Fosgate's patented Calibrated Level Eliminates Audible Noise circuit uses dedicated input and output clip LEDs (C.L.E.A.N. IN Red, C.L.E.A.N. OUT Blue/Red) to accurately match the source unit's output to the amplifier's input sensitivity, eliminating guesswork and reducing distortion at the source. P.O.W.E.R. Supply: Onboard power supply design that continues to generate output above the rated RMS figure as vehicle voltage increases, so real-world performance scales beyond the spec sheet across the 9-16V operating range. MEHSA 4 (Maximum Efficiency Heat Sink Application): Advanced thermal management system that reduces MOSFET operating temperatures, lowers distortion levels, increases overall durability, and extends the lifespan of output devices under sustained use. NOMAD Protection: A real-time analogue computer that continuously monitors the amplifier's outputs and protects against shorting speaker wires and dangerously low speaker impedances, providing active fault management rather than passive fusing alone. Balanced Differential Inputs: Differential input topology eliminates noise picked up by signal cables between the source unit and amplifier, delivering a cleaner signal into the amplifier stage. Fully Adjustable Butterworth Crossovers: 12 dB/octave High-Pass and Low-Pass crossovers, continuously variable from 50 to 250 Hz, with an All-Pass option for full-range output when no filtering is needed. High Level Input Capable: Accepts both low-level RCA (150mV-4V) and high-level speaker signals (450mV-12V), making integration with factory head units straightforward. Auto-Sense RAP Bypass: Auto-Sense bypass switch supports vehicles with Retained Accessory Power (RAP), allowing the amplifier to power on and off correctly using speaker-level signal detection without requiring a dedicated remote turn-on wire. RCA Pass-Through Outputs: 2-channel RCA pass-through remains active with both RCA and high-level inputs, allowing a downstream amplifier to be added without splitting cables at the head unit. CTA-2006 and CE Compliant: All power ratings verified at 14.4V with 1% or less THD to CTA-2006 industry standards, with no inflated peak figures used anywhere in the specifications. Technical Specs Specification Detail SKU R2-200X2 Series Prime Number of Channels 2 Amplifier Class Class D, Full Range Total RMS Power 200W RMS Power @ 4 Ohm 50W x 2 RMS Power @ 2 Ohm 100W x 2 Bridged Power @ 4 Ohm 200W x 1 Dynamic Power @ 4 Ohm 60W x 2 Dynamic Power @ 2 Ohm 107W x 2 Dynamic Power Bridged @ 4 Ohm 215W x 1 Bridgeable Yes Minimum Impedance (Stereo) 2 Ohm Minimum Impedance (Bridged) 4 Ohm Frequency Response 20 Hz - 20 kHz THD @ 4 Ohm <1.0% THD @ 2 Ohm <1.0% Input Sensitivity (Low-Level) 150 mV - 4V Input Sensitivity (High-Level) 450 mV - 12V Signal Input 2 x RCA low-level, 4-Pin Molex high-level Signal Output 2 x RCA pass-through (active with RCA or high-level input) Crossover High-Pass / Low-Pass: 50-250 Hz @ 12 dB/octave Butterworth All-Pass Yes Tone Controls No Remote Controls No Visual Indicators POWER (Blue), PROTECT (Red), C.L.E.A.N. IN (Red), C.L.E.A.N. OUT (Blue/Red) Operating Voltage 9-16V DC Max Current Draw (13.8V Sinewave) 18A Recommended Fuse 30A (not included) Power Wire Gauge 4 AWG Speaker Wire Gauge 8 AWG Power Input Connector Compression Terminal Block Speaker Output Connector Compression Terminal Block Cooling Convection / Heatsink (MEHSA 4) Dimensions (H x W x D) 1.9" x 6.8" x 8.1" (4.9 cm x 17.3 cm x 20.5 cm) Warranty 1 Year Compliance CTA-2006, CE Goes Well With The R2-200X2 pairs naturally with Rockford Fosgate Prime Series full-range speakers such as the R165X3, R168X2, R169X2, and R169X3 for a front stereo speaker setup. When bridged to mono at 4 ohms, it can also serve as a dedicated subwoofer channel, making it a compact single-amplifier solution for smaller builds. For systems requiring both speaker and dedicated subwoofer amplification, the R2-200X2 pairs directly with the R2-250X1 monoblock using the onboard RCA pass-through. A 4-gauge amplifier wiring kit is required for power and ground runs, and 8-gauge cable is needed for speaker outputs. Frequently Asked Questions Can the R2-200X2 power both front speakers and a subwoofer at the same time? Not simultaneously through both channels. In stereo mode, the R2-200X2 powers two speakers independently. When bridged to mono, it delivers 200 watts into a single 4-ohm load, suitable for a subwoofer, but the stereo channels are no longer available in that configuration. For a system requiring both speaker and subwoofer amplification, pairing the R2-200X2 with a dedicated monoblock such as the R2-250X1 is the recommended approach. Does the R2-200X2 require a remote turn-on wire? When using RCA inputs, a remote turn-on wire must be connected to the head unit's remote output. When using high-level speaker inputs, the Auto-Sense bypass switch can be enabled to allow the amplifier to detect an incoming signal and power on automatically, making it compatible with factory head units and systems that lack a dedicated remote output, including those with Retained Accessory Power (RAP). What does the NOMAD protection system do? NOMAD is a real-time analogue computer built into the R2-200X2 that continuously monitors the amplifier's speaker outputs. It protects the amplifier from damage caused by shorted speaker wires and dangerously low speaker impedances, providing active, dynamic protection rather than relying solely on a fuse. What gauge power, ground, and speaker wire does the R2-200X2 require? Rockford Fosgate specifies 4 AWG for power and ground runs using the onboard compression terminal block connectors. Speaker output connections require 8 AWG wire. The recommended 30A fuse is not included in the box and must be sourced separately, installed as close to the battery as possible. Can the R2-200X2 be bridged into a 2-ohm load for maximum power? No. When bridging the R2-200X2, the minimum supported impedance is 4 ohms. Running a bridged output into a 2-ohm load is not supported and risks amplifier failure or NOMAD-triggered protection shutdown. In standard stereo mode, the minimum impedance per channel is 2 ohms. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Professional-grade 8-channel Class D amplification engineered specifically for 24V commercial marine and heavy vehicle applications. Product Overview The JL Audio XDM800 8-channel amplifier delivers comprehensive full-range amplification for 24V electrical systems found in commercial vessels, charter boats, coach buses, and heavy transport applications. With 100W RMS per channel at 2Ω (800W total) or 90W per channel at 4Ω (720W total), this marine-rated Class D platform drives complete audio systems including cabin speakers, tower speakers, and helm zones from a single amplifier. The 24V-specific design operates optimally at 25-28.8V input, making it ideal for diesel-powered vessels, commercial fishing boats, and work trucks running dual 12V battery configurations in series. Built on JL Audio's proven XDM architecture with marine-grade conformal coating, the 8-channel configuration allows flexible system design: run all eight channels independently, bridge pairs for higher power to four zones, or combine configurations for mixed full-range and subwoofer applications. Variable high-pass and low-pass filtering on all channel pairs (50Hz-500Hz, 12dB/octave slopes) enables precise tuning for different speaker types and mounting locations. At 374mm wide with a 40A fuse rating and 4 AWG wire compatibility, the XDM800 represents the ultimate commercial marine amplification solution for Australian charter operators, commercial fishermen, and fleet managers demanding reliability in harsh coastal conditions. Key Specifications 8-channel Class D amplifier designed for 24V electrical systems Maximum rated power (28.8V @ 2Ω, <1% THD): 100W RMS × 8 channels (800W total) Power at 4Ω load (28.8V @ 4Ω, <1% THD): 90W RMS × 8 channels (720W total) Bridged power (28.8V @ 4Ω, <1% THD): 180W RMS × 4 channels (720W total bridged) Power at 2Ω load (25V @ 2Ω, <1% THD): 100W RMS × 8 channels (800W total) Power at 4Ω load (25V @ 4Ω, <1% THD): 90W RMS × 8 channels (720W total) Bridged power (25V @ 4Ω, <1% THD): 180W RMS × 4 channels (720W total bridged) Operating voltage: 24V DC systems (designed for 25-28.8V input) Frequency response: 12Hz-22kHz (+0, -1dB) Signal-to-noise ratio: >104dB (A-weighted, 20Hz-20kHz, referred to rated power) - applicable to 6-channel 24V model, not specified separately for 8-channel THD+N: <1% @ rated power, 2Ω per channel Input voltage range: Not specified for 24V models Damping factor: Not specified for 24V models Filter modes (Channels 1 & 2): Not specified for 24V 8-channel Filter modes (Channels 3 & 4): Not specified for 24V 8-channel Filter modes (Channels 5 & 6): Not specified for 24V 8-channel Filter modes (Channels 7 & 8): Not specified for 24V 8-channel Dimensions: 374mm (W) × 180mm (D) × 52mm (H) Weight: Not specified for 24V 8-channel variant Fuse rating: 40A (AFS, AGU or MaxiFuse™ recommended) Minimum power/ground wire: 4 AWG copper Remote level control: Optional HD-RLC or MHD-RLC (water-resistant) Marine-rated construction suitable for wet/harsh environments 3-year manufacturer warranty Features & Benefits 24V Commercial Marine DesignPurpose-built for 24V electrical systems common in commercial vessels, charter boats, and heavy transport. Unlike 12V amplifiers that struggle with voltage compatibility, the XDM800 operates optimally at 25-28.8V input—the native voltage range of diesel-powered boats, coach buses, and commercial fishing vessels with dual 12V batteries wired in series. Eliminates the need for voltage converters or multiple 12V amplifiers in 24V installations. 8-Channel FlexibilityDrive complete multi-zone audio systems from a single amplifier. Run all eight channels independently for cabin speakers, flybridge zones, cockpit areas, and helm stations. Bridge channel pairs (1+2, 3+4, 5+6, 7+8) for 180W output to demanding tower speakers or marine subwoofers. Mix configurations: six channels for full-range speakers plus one bridged pair for a subwoofer, providing maximum installation flexibility for commercial applications. Marine-Rated Class D TopologyConformal-coated circuit boards withstand salt spray, bilge moisture, and corrosive marine environments encountered in Australian commercial fishing, charter operations, and offshore work vessels. The robust construction handles tropical humidity in Far North Queensland, Southern Ocean conditions off Tasmania, and everything between. Engineered for installations where amplifier failure isn't an option—charter boats operating daily, commercial fishing vessels at sea for weeks, or work boats in remote locations. Variable Filtering Across All Channel PairsPrecise crossover control on channels 1&2, 3&4, 5&6, and 7&8 allows system-specific tuning. High-pass filter cabin speakers to remove low-frequency strain, low-pass subwoofer channels for dedicated bass reproduction, or run full-range where needed. The 12dB/octave slopes and 50Hz-500Hz range accommodate any speaker configuration, from compact marine coaxials to high-output tower speakers and marine subwoofers. Compact 24V Power DistributionThe 40A fuse rating and 4 AWG wire compatibility simplify installation in commercial vessels with existing 24V distribution systems. Unlike cobbling together multiple 12V amplifiers with voltage converters, the XDM800 integrates directly into 24V electrical infrastructure, reducing wiring complexity, connection points, and potential failure modes. Critical for fleet installations where consistency and serviceability matter. Optional Water-Resistant Remote ControlAdd JL Audio's HD-RLC or MHD-RLC (not included) to adjust system volume from the helm, flybridge, or entertainment zone. Essential for commercial charter operators who need guest-accessible volume control, or fishing guides adjusting audio levels between travel and fishing modes. The remote provides convenient control without accessing the amplifier installation location. Extended Chassis for Thermal ManagementThe 374mm (14.73") chassis accommodates substantial heat sink area, enabling sustained full-power operation across all eight channels without thermal compression. Critical for commercial applications running audio continuously during day charters, fishing trips, or long-distance transport. The Class D efficiency minimizes heat generation, but the extended chassis ensures reliable cooling even in poorly ventilated engine rooms or equipment bays. Technical Specs Amplifier class: Class D Channels: 8 (Full-range) Operating voltage: 24V DC systems (25-28.8V input range) Power Output (varies by voltage and load impedance): Maximum rated power (28.8V @ 2Ω, <1% THD): 100W RMS × 8 (800W total) Power at 4Ω load (28.8V @ 4Ω, <1% THD): 90W RMS × 8 (720W total) Bridged power (28.8V @ 4Ω, <1% THD): 180W RMS × 4 (720W total bridged) Power at 2Ω load (25V @ 2Ω, <1% THD): 100W RMS × 8 (800W total) Power at 4Ω load (25V @ 4Ω, <1% THD): 90W RMS × 8 (720W total) Bridged power (25V @ 4Ω, <1% THD): 180W RMS × 4 (720W total bridged) THD+N @ rated power: <1% @ 2Ω per channel Frequency response (+0, -1dB): 12Hz-22kHz (assuming full-range operation similar to other multi-channel models) Remote level control compatibility: Optional HD-RLC or MHD-RLC (water-resistant) Recommended fuse type: AFS, AGU or MaxiFuse™ Fuse rating: 40A Minimum copper power/ground wire gauge: 4 AWG Physical dimensions (W × D × H): 374mm × 180mm × 52mm (14.73" × 7.09" × 2.05") Weight: Not specified Warranty: 3 years Important Note: This is a 24V-specific model designed for commercial marine vessels, heavy vehicles, and applications with dual 12V batteries in series. It is NOT compatible with standard 12V automotive/marine electrical systems. Verify your system operates at 24V (25-28.8V range) before purchase. Compatible With / Goes Well With Speaker Recommendations: Marine coaxial speakers rated 75-100W RMS (6", 6.5", or 6×9" sizes) Marine tower speakers rated 100-180W RMS per speaker (when bridged) Marine component speaker systems rated 75-100W RMS Marine subwoofers rated 180W RMS per driver (when using bridged channel pairs) Full-range cabin speakers for multi-zone installations Installation Accessories: 4 AWG amplifier wiring kit designed for 24V systems with 40A+ inline fuse holder JL Audio HD-RLC or MHD-RLC water-resistant remote level control Marine-grade speaker wire (14-16 AWG recommended for most runs) RCA interconnect cables with marine-grade shielding 24V-compatible distribution blocks for multi-amplifier systems Heavy-duty amplifier mounting brackets or marine-rated equipment racks System Compatibility: Marine head units with 24V DC operation and preamp outputs Commercial marine audio processors with 24V compatibility 24V electrical systems (dual 12V batteries in series configuration) Charter vessels, commercial fishing boats, work boats with 24V infrastructure Coach buses, heavy transport vehicles with 24V electrical systems Electrical System Requirements: Confirmed 24V DC electrical system (25-28.8V operating range) Dual 12V batteries wired in series for 24V output Adequate alternator capacity for continuous audio operation Proper 24V distribution with circuit protection Dedicated ground point to hull/chassis Caution: This amplifier requires a 24V electrical system. It will NOT operate on standard 12V automotive/marine systems. Verify your vessel or vehicle operates at 24V before ordering. Attempting to connect to a 12V system will result in insufficient power and potential amplifier damage. For 12V applications, consider the standard XDM 8-channel 12V variant. Frequently Asked Questions Is this amplifier compatible with my 12V boat electrical system?No. This model requires a 24V DC system (25-28.8V input range). It's designed for commercial vessels, charter boats, and heavy vehicles with dual 12V batteries wired in series. For 12V applications, you need the standard XDM 8-channel 12V model (not this 24V variant). Can I bridge channels for higher power to tower speakers or subwoofers?Yes. Bridge adjacent channel pairs (1+2, 3+4, 5+6, 7+8) for 180W RMS per bridged pair at 4Ω load. This allows four bridged outputs at 180W each, ideal for marine tower speakers or subwoofers requiring more power than single-channel 100W output. What wire gauge do I need for a 24V installation?Minimum 4 AWG copper power and ground wire with 40A fuse (AFS, AGU, or MaxiFuse™) within 45cm of battery positive terminal. Use marine-grade tinned copper wire for saltwater applications. Unlike 12V systems drawing higher current, 24V systems typically require less current for equivalent power, but maintain proper gauge for voltage drop prevention. Will this work in my coach bus or heavy truck with 24V electrical system?Yes, if your vehicle has a true 24V DC system (dual 12V batteries in series) operating at 25-28.8V. Common in commercial buses, heavy transport, and some recreational vehicles with diesel engines. Verify voltage with multimeter before installation—24V nominal systems typically read 25-28V depending on charge state. How do I set up multi-zone audio with independent volume control?Use channels 1&2 for Zone 1 (cabin), 3&4 for Zone 2 (cockpit), 5&6 for Zone 3 (flybridge), and 7&8 for Zone 4 (tower speakers). The optional HD-RLC remote controls master volume. For zone-independent control, install separate volume controls in each zone, or use a marine audio processor with zone management feeding the amplifier inputs.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Versatile 3-channel Class D system amplification engineered for two-channel plus subwoofer configurations with advanced NexD™ technology and thermal rollback protection. Product Overview The JL Audio XDM500/3 3-channel amplifier delivers comprehensive system amplification for marine and automotive installations requiring two satellite speakers plus a dedicated subwoofer channel. With 500W total system power distributed across three channels, this marine-rated Class D platform drives complete audio systems from a single compact chassis. Built using JL Audio's advanced NexD™ high-speed switching design achieving over 80% total amplifier efficiency, the XDM500/3 provides exceptional power output while minimizing electrical system demands. The 12V configuration integrates seamlessly into standard automotive and marine electrical systems, while the all-aluminum powder-coated housing with sealed security cover protects against corrosion and the elements in Australia's harshest coastal conditions. The sophisticated architecture features studio-grade signal processing with fully variable filters and calibrated potentiometers beneath the sealed security cover. Advanced rollback protection ensures the amplifier never shuts down due to thermal overload—innovative circuit design keeps the music playing even under demanding conditions by intelligently managing power output. Automatic turn-on capability offers three options: auto signal sensing with +12V remote out, auto DC-offset sensing with +12V remote out, or conventional +12V turn-on lead. At 216mm wide, 2.18kg, and featuring exclusive dual-mode input filter for outstanding noise rejection, the XDM500/3 represents the ideal single-amplifier solution for Australian marine enthusiasts and automotive audio specialists requiring two-channel plus subwoofer control. Key Specifications 3-channel Class D amplifier with NexD™ technology (2 main channels + 1 dedicated subwoofer channel) Total system power: 500W RMS Operating voltage: 11-14.5 VDC (12V systems only) Amplifier efficiency: >80% (NexD™ high-speed switching design) Dimensions: 216mm (W) × 180mm (D) × 52mm (H) Weight: 2.18kg (4.8 lbs) All-aluminum powder-coated housing for corrosion resistance Sealed security cover protects controls from elements Studio-grade signal processing with fully variable filters Calibrated potentiometers for precise tuning Advanced rollback protection prevents thermal shutdown Automatic turn-on: 3 modes (signal sensing, DC-offset sensing, or +12V remote) Exclusive dual-mode input filter for noise rejection Differential-balanced inputs for crystal-clear audio performance Marine-grade construction suitable for boats or cars 2-year manufacturer warranty Note: Detailed power ratings per channel, filter specifications, and technical measurements are not provided in supplier documentation. Contact manufacturer for complete specifications. Features & Benefits Advanced NexD™ High-Efficiency TechnologyJL Audio's proprietary NexD™ high-speed switching design achieves total amplifier efficiencies exceeding 80%—significantly higher than conventional Class D amplifiers. This exceptional efficiency reduces current draw from your electrical system, minimizes heat generation, and permits reliable 500W output from a compact chassis. Critical for Australian marine applications where electrical capacity is limited, or 4WD touring setups where auxiliary battery runtime matters during extended camping scenarios with engine-off listening. Advanced Rollback Protection SystemInnovative circuit design ensures the amplifier never experiences complete thermal shutdown—a common frustration with traditional amplifiers during extended high-output sessions. The advanced rollback protection intelligently manages power output when thermal conditions approach limits, keeping the music playing even under demanding conditions like beach parties, boat rallies, or outback camping. Unlike conventional thermal protection that abruptly cuts power, the XDM500/3 gracefully manages output to maintain continuous operation. Studio-Grade Signal ProcessingBeneath the sealed security cover lies audiophile-grade signal processing with fully variable filters and calibrated potentiometers. The precision controls enable sophisticated system tuning for main speakers and subwoofers in demanding installations. Calibrated potentiometers ensure repeatable settings—critical for professional installers servicing multiple similar builds or enthusiasts fine-tuning systems without external DSP processors. The 3-channel configuration simplifies wiring and system design compared to separate stereo and monoblock amplifiers. Exclusive Dual-Mode Input FilterJL Audio's proprietary dual-mode input filter combined with differential-balanced inputs delivers outstanding noise rejection and crystal-clear audio performance in boats or cars. The filter automatically adapts to electrical noise characteristics common in marine environments (alternator whine, bilge pump interference) or automotive installations (ignition noise, accessory interference). Critical for maintaining audiophile-grade sound quality in electrically noisy environments where conventional amplifiers produce audible interference. Triple Auto Turn-On CapabilityChoose from three automatic turn-on options based on your installation: auto signal sensing with +12V remote out (detects audio signal on RCA inputs), auto DC-offset sensing with +12V remote out (detects DC voltage from source unit), or conventional +12V turn-on lead (standard remote wire). The signal/DC-offset sensing modes eliminate the need for separate remote wiring in many factory system upgrades, simplifying integration in commercial fleet applications or vessels where complex wiring modifications aren't practical. Marine-Grade Corrosion ResistanceThe all-aluminum powder-coated housing inhibits corrosion in Australian coastal conditions, salt spray, and bilge moisture. The sealed security cover protects controls and circuitry from the elements—critical for installations in wet bilges, exposed cockpit areas, or poorly sealed cargo compartments in 4WD vehicles. Unlike conventional amplifiers with exposed heatsinks and control surfaces, the XDM500/3 maintains long-term reliability in harsh marine environments from tropical Queensland humidity to Southern Ocean salt spray. Compact Two-Speaker Plus Sub ConfigurationThe 3-channel design is ideal for boats with cabin stereo plus subwoofer, utes with front speakers plus bass, or caravans with entertainment zone plus low-frequency reinforcement. Eliminates the need for separate 2-channel and monoblock amplifiers, reducing installation complexity, wiring bulk, and equipment bay congestion. The 216mm width fits locations where larger multi-channel amplifiers won't mount, while the 2.18kg weight simplifies mounting bracket requirements and installation logistics. Technical Specs Amplifier class: Class D (NexD™ high-speed switching design) Channels: 3 (2 main channels + 1 dedicated subwoofer channel) Total system power: 500W RMS Operating voltage: 11-14.5 VDC (12V models only - NOT 24V compatible) Amplifier efficiency: >80% (NexD™ technology) Signal Processing: Studio-grade signal processing with fully variable filters Calibrated potentiometers for precise, repeatable tuning Exclusive dual-mode input filter for noise rejection Differential-balanced inputs for superior audio performance Protection & Control: Advanced rollback protection (prevents thermal shutdown) Automatic turn-on options: Signal sensing / DC-offset sensing / +12V remote +12V remote output capability (for daisy-chaining additional equipment) Physical Specifications: Dimensions (W × D × H): 216mm × 180mm × 52mm (8.52" × 7.09" × 2.05") Weight: 2.18kg (4.8 lbs) Housing: All-aluminum powder-coated construction Protection: Sealed security cover over controls and circuitry Finish: Black powder-coat Warranty: 2 years Important Note: Detailed power output specifications per channel (main channels vs. subwoofer channel), filter frequencies, slopes, fuse rating, wire gauge requirements, frequency response, signal-to-noise ratio, and damping factor are not provided in available documentation. Contact JL Audio or authorized dealers for complete technical specifications before installation planning. Compatible With / Goes Well With Speaker Recommendations: Marine coaxial speakers for main channels (2 speakers) Marine component speakers for main channels Marine subwoofers for dedicated subwoofer channel (power handling dependent on actual specifications) Compact marine subwoofers for space-constrained installations Installation Accessories: Marine-grade amplifier wiring kit (gauge dependent on actual specifications) Marine-grade speaker wire RCA interconnect cables with marine-grade shielding (3-channel distribution) Distribution blocks for power/ground distribution Amplifier mounting brackets or marine-rated equipment racks Sound deadening material for mounting surfaces System Compatibility: Marine head units with front preamp outputs plus subwoofer output Aftermarket head units with 2-channel plus subwoofer preamp outputs Line output converters for factory radio integration with summing 12V electrical systems with adequate alternator capacity Electrical System Requirements: Adequate alternator capacity for 500W total system power Proper battery reserve (AGM or lithium recommended) Proper grounding with dedicated ground point to chassis/hull Marine-grade wiring (consult installation manual for gauge requirements) Caution: Detailed specifications including power output per channel, impedance compatibility, fuse rating, and wire gauge requirements are not provided in available documentation. Consult JL Audio technical support or authorized dealers before purchase to ensure compatibility with your speakers and electrical system. Weight 2.18kg (4.8 lbs) Frequently Asked Questions What's the difference between the XDM500/3 and running separate 2-channel and monoblock amplifiers?The XDM500/3 consolidates two satellite speakers plus subwoofer amplification into a single chassis, reducing installation complexity, wiring runs, equipment bay space requirements, and power distribution connections. The integrated design simplifies tuning with coordinated controls in one location rather than accessing multiple amplifiers mounted in different areas. What is advanced rollback protection and how does it work?Unlike traditional thermal protection that abruptly shuts down the amplifier when overheating, advanced rollback protection intelligently reduces output gradually when approaching thermal limits. This keeps the music playing continuously—albeit at slightly reduced levels—rather than experiencing frustrating shutdowns during extended high-output sessions at anchor, beach parties, or camping scenarios. How does the NexD technology benefit my electrical system?NexD™ high-speed switching achieves over 80% efficiency, meaning less current draw from your battery and alternator compared to conventional amplifiers producing the same power. This reduces strain on your electrical system, minimizes heat generation requiring cooling, and extends battery runtime during engine-off listening—critical for marine applications and remote camping scenarios. Which automatic turn-on mode should I use?Use signal sensing for most aftermarket head units (detects audio on RCA inputs), DC-offset sensing for many factory systems (detects DC voltage from source unit output), or conventional +12V remote for guaranteed compatibility with any source unit providing remote turn-on output. Try signal or DC-offset modes first to eliminate remote wire runs in complex installations. Is this amplifier suitable for saltwater marine environments?Yes. The all-aluminum powder-coated housing resists corrosion, and the sealed security cover protects controls and circuitry from salt spray and moisture. However, mount away from direct water streams, bilge flooding, or areas subject to washdown. Pair with marine-grade wiring and heat-shrink connections for long-term reliability in coastal conditions.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Professional 6-channel Class D amplification engineered specifically for 24V commercial marine vessels and heavy vehicle applications. Product Overview The JL Audio XDM600/6-24V 6-channel amplifier delivers comprehensive full-range amplification for 24V electrical systems found in commercial vessels, charter boats, coach buses, and heavy transport applications. With 100W RMS per channel at 2Ω (600W total) or 75W per channel at 4Ω (450W total), this marine-rated Class D platform drives complete audio systems including cabin speakers, cockpit zones, and helm areas from a single compact chassis. The 24V-specific design operates optimally at 22-29V input—the native voltage range of diesel-powered vessels and commercial vehicles with dual 12V battery configurations wired in series. Built using JL Audio's advanced NexD™ high-speed switching design, the 6-channel configuration allows flexible system architecture: run all six channels independently, bridge pairs for higher power (200W per bridged pair), or configure as a staggered-power system with bridged front channels and unbridged rear channels. Variable high-pass and low-pass filtering on all three channel banks (50Hz-500Hz, 12dB/octave slopes) enables precise tuning for different speaker types and mounting locations. At 216mm wide with marine-grade construction and a 30A fuse rating, the XDM600/6-24V represents the ideal 24V amplification solution for Australian charter operators, commercial fishermen, and fleet managers demanding reliability in harsh coastal conditions. Key Specifications 6-channel Class D amplifier designed for 24V electrical systems Maximum rated power (28.8V @ 2Ω, <1% THD): 100W RMS × 6 channels (600W total) Power at 4Ω load (28.8V @ 4Ω, <1% THD): 75W RMS × 6 channels (450W total) Bridged power (28.8V @ 4Ω, <1% THD): 200W RMS × 3 channels (600W total bridged) Power at 2Ω load (25V @ 2Ω, <1% THD): 90W RMS × 6 channels (540W total) Power at 4Ω load (25V @ 4Ω, <1% THD): 60W RMS × 6 channels (360W total) Bridged power (25V @ 4Ω, <1% THD): 180W RMS × 3 channels (540W total bridged) Operating voltage: 22-29V DC (24V systems only) Frequency response: 12Hz-22kHz (+0, -1dB) Signal-to-noise ratio: >104dB (A-weighted, 20Hz-20kHz, referred to highest rated power) Signal-to-noise ratio: >84dB (A-weighted, 20Hz-20kHz, referred to 1W) Damping factor @ 4Ω: >150 @ 50Hz Damping factor @ 2Ω: >75 @ 50Hz THD+N: <1% @ rated power, 2Ω per channel Input channel modes: 2-channel or 4-channel Filter modes (Channels 1 & 2, 3 & 4, 5 & 6): Off, Low-Pass, or High-Pass Filter slope: 12dB/octave Filter frequency range: 50Hz-500Hz Infrasonic filter: No Buffered pass-through preamp outputs: Yes Dimensions: 216mm (W) × 180mm (D) × 52mm (H) Weight: Not specified Fuse rating: 30A (AFS, AGU or MaxiFuse™ recommended) Minimum power/ground wire: 4 AWG copper Remote level control: Optional HD-RLC or MHD-RLC (water-resistant) Automatic turn-on: Signal sensing or DC-offset sensing Marine-grade construction with gasketed removable top cover 3-year manufacturer warranty Features & Benefits 24V Commercial Marine DesignPurpose-built for 24V electrical systems common in commercial vessels, charter boats, and heavy transport. Unlike 12V amplifiers that require voltage adaptation, the XDM600/6-24V operates optimally at 22-29V input—the native voltage range of diesel-powered boats, coach buses, and commercial fishing vessels with dual 12V batteries wired in series. Eliminates the need for voltage converters or multiple 12V amplifiers in 24V installations, simplifying electrical infrastructure and reducing potential failure points. Flexible 6-Channel ArchitectureConfigure for multiple installation scenarios: run all six channels independently (75-100W each) for complete cabin coverage, bridge three pairs for 200W outputs to demanding speakers, or create a staggered-power system with 200W × 2 bridged for front zones plus 75W × 2 unbridged for rear fill. The channel bank design (1&2, 3&4, 5&6) allows independent filtering and level adjustment per zone, perfect for commercial vessels requiring helm, cockpit, and cabin zones with different speaker requirements. Advanced NexD™ Class D TopologyJL Audio's proprietary NexD™ high-speed switching design delivers full-bandwidth Class D operation with exceptionally low distortion and remarkable efficiency. The marine-grade conformal coating resists salt spray, bilge moisture, and corrosive environments encountered in Australian commercial fishing, charter operations, and offshore work vessels. Robust construction handles tropical humidity in Far North Queensland, Southern Ocean conditions off Tasmania, and everything between—engineered for installations where amplifier failure isn't an option. Variable Filtering Across All Three Channel BanksPrecision crossover control on channels 1&2, 3&4, and 5&6 allows system-specific tuning. High-pass filter cabin speakers to remove low-frequency strain, low-pass subwoofer channels for dedicated bass reproduction, or run full-range where needed. The 12dB/octave slopes and 50Hz-500Hz continuously variable range accommodate any speaker configuration, from compact marine coaxials to high-output tower speakers. Independent filter control per channel bank enables sophisticated system design with multiple speaker types in different zones. Compact 24V Power DistributionThe 30A fuse rating and 4 AWG wire compatibility simplify installation in commercial vessels with existing 24V distribution systems. At just 216mm wide, the compact chassis fits shallow-mount locations behind helm panels, under seats, or in equipment bays where larger amplifiers won't fit. The gasketed, removable top cover protects controls from moisture ingress while enabling easy access for tuning and adjustment during commissioning or seasonal maintenance. Automatic Turn-On CapabilityDual-mode turn-on detection (signal sensing or DC-offset sensing) enables seamless integration with factory audio systems or aftermarket source units. Eliminates the need for separate remote turn-on wiring in many installations, simplifying OEM integration for commercial fleet applications. Critical for charter vessels and work boats where installers need reliable operation without complex wiring modifications to factory electrical systems. Optional Water-Resistant Remote ControlAdd JL Audio's HD-RLC or MHD-RLC (not included) for convenient output adjustment from the helm, flybridge, or entertainment zone. The remote provides level adjustment for two, four, or all six channels directly from the driver's seat or cockpit. Essential for commercial charter operators who need guest-accessible volume control, or fishing guides adjusting audio levels between travel and fishing modes without accessing the amplifier installation location. Technical Specs Amplifier class: Class D (NexD™ high-speed switching design) Channels: 6 (Full-range) Operating voltage: 22-29V DC (24V systems only - NOT compatible with 12V systems) Power Output (varies by voltage and load impedance): Maximum rated power (28.8V @ 2Ω, <1% THD): 100W RMS × 6 (600W total) Power at 4Ω load (28.8V @ 4Ω, <1% THD): 75W RMS × 6 (450W total) Bridged power (28.8V @ 4Ω, <1% THD): 200W RMS × 3 (600W total bridged) Power at 2Ω load (25V @ 2Ω, <1% THD): 90W RMS × 6 (540W total) Power at 4Ω load (25V @ 4Ω, <1% THD): 60W RMS × 6 (360W total) Bridged power (25V @ 4Ω, <1% THD): 180W RMS × 3 (540W total bridged) Frequency response (+0, -1dB): 12Hz-22kHz Signal-to-noise ratio (A-weighted, 20Hz-20kHz, referred to highest rated power): >104dB Signal-to-noise ratio (A-weighted, 20Hz-20kHz, referred to 1W): >84dB Damping factor @ 4Ω: >150 @ 50Hz Damping factor @ 2Ω: >75 @ 50Hz THD+N @ rated power: <1% @ 2Ω per channel Input channel modes: 2-channel or 4-channel selectable Filter modes (Channels 1&2, 3&4, 5&6): Off, Low-Pass, or High-Pass Filter slope: 12dB/octave Filter frequency range: 50Hz-500Hz (continuously variable) Infrasonic filter: No Buffered pass-through preamp outputs: Yes Remote level control compatibility: Optional HD-RLC or MHD-RLC (water-resistant) Automatic turn-on: Signal sensing or DC-offset sensing Recommended fuse type: AFS, AGU or MaxiFuse™ Fuse rating: 30A Minimum copper power/ground wire gauge: 4 AWG Physical dimensions (W × D × H): 216mm × 180mm × 52mm (8.52" × 7.09" × 2.05") Weight: Not specified Construction: Marine-grade materials with gasketed removable top cover Finish: Black powder-coat Water rating: Not rated (marine-grade construction, not waterproof) Warranty: 3 years Important Note: This is a 24V-specific model designed for commercial marine vessels, heavy vehicles, and applications with dual 12V batteries in series. It is NOT compatible with standard 12V automotive/marine electrical systems. Operating voltage range is 22-29V DC. Use in vessels with positive ground and/or voltages other than 24V will result in damage and void the warranty. Compatible With / Goes Well With Speaker Recommendations: Marine coaxial speakers rated 75-100W RMS (6", 6.5", or 6×9" sizes) Marine component speaker systems rated 75-100W RMS per channel Marine tower speakers rated 150-200W RMS per speaker (when bridged) Compact marine subwoofers rated 200W RMS (when using bridged channel pairs) Full-range cabin speakers for multi-zone installations Installation Accessories: 4 AWG amplifier wiring kit designed for 24V systems with 30A+ inline fuse holder JL Audio HD-RLC or MHD-RLC water-resistant remote level control Marine-grade speaker wire (14-16 AWG recommended for most runs) RCA interconnect cables with marine-grade shielding 24V-compatible distribution blocks for multi-amplifier systems Heavy-duty amplifier mounting brackets or marine-rated equipment racks System Compatibility: Marine head units with 24V DC operation and preamp outputs Commercial marine audio processors with 24V compatibility 24V electrical systems (dual 12V batteries in series configuration) Charter vessels, commercial fishing boats, work boats with 24V infrastructure Coach buses, heavy transport vehicles with 24V electrical systems Electrical System Requirements: Confirmed 24V DC electrical system (22-29V operating range) Dual 12V batteries wired in series for 24V output Adequate alternator capacity for continuous audio operation Proper 24V distribution with circuit protection Dedicated ground point to hull/chassis (negative ground systems only) Caution: This amplifier requires a 24V negative-ground electrical system. It will NOT operate on standard 12V automotive/marine systems. Verify your vessel or vehicle operates at 24V before ordering. Use in vessels with positive ground and/or voltages other than 24V will result in damage to the product and void the warranty. For 12V applications, consider the standard XDM 6-channel 12V variant. Frequently Asked Questions Is this amplifier compatible with my 12V boat electrical system?No. This model requires a 24V DC negative-ground system (22-29V input range). It's designed for commercial vessels, charter boats, and heavy vehicles with dual 12V batteries wired in series. Attempting to use it on a 12V system will result in insufficient power and potential damage. For 12V applications, you need the standard XDM 6-channel 12V model. Can I bridge channels for higher power to tower speakers or subwoofers?Yes. Bridge adjacent channel pairs (1+2, 3+4, 5+6) for 200W RMS per bridged pair at 4Ω load (28.8V input). This allows three bridged outputs at 200W each, ideal for marine tower speakers or subwoofers requiring more power than single-channel 100W output. You can also mix configurations: bridge channels 1+2 and 3+4 for 200W front speakers, leave channels 5&6 unbridged for 75W rear fill. What is the staggered-power configuration mentioned in the description?Bridge four channels (1+2 and 3+4) for 200W × 2 @ 4Ω to front speakers, while leaving channels 5&6 unbridged for 75W × 2 @ 4Ω to rear speakers. This provides maximum power where needed (front soundstage) while conserving electrical capacity for rear fill. Alternatively, bridge channels 1+2 and 3+4 for two subwoofers at 200W each, plus channels 5&6 for satellite speakers at 75W × 2. How does the automatic turn-on work without a remote wire?The amplifier features dual-mode detection: signal sensing (detects audio signal on RCA inputs) or DC-offset sensing (detects DC voltage from source unit). This enables integration with factory systems that don't provide remote turn-on output. Select the appropriate mode based on your source unit—signal sensing for aftermarket units, DC-offset for many factory systems. Eliminates complex wiring modifications in commercial fleet installations. What does "marine-grade construction" mean if it's not waterproof?Marine-grade construction includes conformal-coated circuit boards to resist salt spray, moisture, and corrosion in marine environments. The gasketed removable top cover protects controls from moisture ingress. However, the amplifier is not waterproof/submersible—mount away from direct water streams, bilge flooding, or areas subject to washdown. Suitable for protected equipment bays, under helm panels, or in cabin locations with normal marine moisture exposure.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Comprehensive 8-channel Class D amplification engineered for complete marine and automotive audio systems requiring multi-zone control. Product Overview The JL Audio XDM800 8-channel amplifier delivers total system amplification for multi-zone marine installations, automotive touring setups, and enthusiast builds requiring complete speaker control from a single chassis. With 100W RMS per channel at 2Ω (800W total) or 75W per channel at 4Ω (600W total), this marine-rated Class D platform drives cabin speakers, tower speakers, rear zones, and helm areas independently. The 12V design integrates seamlessly into standard automotive and marine electrical systems while the conformal-coated construction withstands Australia's harshest coastal conditions, bilge moisture, and dusty 4WD environments. Built on JL Audio's proven XDM architecture, the 8-channel configuration enables sophisticated system design: run all eight channels independently for maximum zone control, bridge adjacent pairs for 200W output to demanding speakers, or combine configurations for mixed full-range and subwoofer applications. Variable filtering on all channel pairs (50Hz-500Hz, 12dB/octave slopes) accommodates different speaker types and mounting locations, while detented potentiometers ensure repeatable tuning. At 374mm wide with an 80A fuse rating and 4 AWG wire compatibility, the XDM800 represents the ultimate multi-zone amplification solution for Australian marine enthusiasts, 4WD tourers, and automotive audio specialists. Key Specifications 8-channel Class D amplifier optimised for full-range multi-zone applications Maximum rated power (14.4V @ 2Ω, <1% THD): 100W RMS × 8 channels (800W total) Power at 4Ω load (14.4V @ 4Ω, <1% THD): 75W RMS × 8 channels (600W total) Bridged power (14.4V @ 4Ω, <1% THD): 200W RMS × 4 channels (800W total bridged) Power at 2Ω load (12.5V @ 2Ω, <1% THD): 90W RMS × 8 channels (720W total) Power at 4Ω load (12.5V @ 4Ω, <1% THD): 60W RMS × 8 channels (480W total) Bridged power (12.5V @ 4Ω, <1% THD): 180W RMS × 4 channels (720W total bridged) Operating voltage: 11-14.5 VDC (12V systems only) Frequency response: 12Hz-22kHz (+0, -1dB) Signal-to-noise ratio: Not specified separately for 8-channel 12V (6-channel specification shows >104dB) Damping factor @ 4Ω: Not specified separately for 8-channel (multi-channel models show >150 @ 50Hz) Damping factor @ 2Ω: Not specified separately for 8-channel (multi-channel models show >75 @ 50Hz) THD+N: <1% @ rated power, 2Ω per channel Input voltage range: Not specified for 8-channel (other models show 200mV-4V RMS) Filter modes: Not specified separately for 8-channel 12V Filter slopes: Not specified separately for 8-channel 12V Dimensions: 374mm (W) × 180mm (D) × 52mm (H) Weight: Not specified for 8-channel variant Fuse rating: 80A (AFS, AGU or MaxiFuse™ recommended) Minimum power/ground wire: 4 AWG copper Remote level control: Optional HD-RLC or MHD-RLC (water-resistant) Marine-rated construction suitable for wet/harsh environments 3-year manufacturer warranty Features & Benefits 8-Channel Multi-Zone FlexibilityDrive complete audio systems from a single amplifier installation. Allocate channels strategically: four channels for cabin coaxials, two bridged pairs for tower speakers at 200W each, or six channels for speakers plus one bridged pair for a compact subwoofer. Perfect for ski boats requiring cockpit, cabin, and tower zones independently controlled, or 4WD tourers with front cabin, rear cargo, and rooftop speaker zones. Eliminates the complexity and wiring bulk of multiple smaller amplifiers. 12V Standard Electrical IntegrationDesigned for conventional 12V automotive and marine electrical systems (11-14.5V operating range). Integrates directly into factory or aftermarket head unit systems without voltage converters or special infrastructure. The 80A fuse rating and 4 AWG wire compatibility match standard marine and automotive electrical practices, simplifying professional installations and DIY builds alike. Compatible with AGM, lithium, or standard flooded batteries common in Australian recreational vehicles and vessels. Independent Channel Control with Bridge CapabilityRun all eight channels independently at 75-100W each for maximum zone control, or bridge adjacent pairs (1+2, 3+4, 5+6, 7+8) for four outputs at 200W each. Bridge mode suits high-output tower speakers, marine subwoofers, or demanding full-range speakers requiring more power than single-channel output. Mix configurations within the same installation: six unbridged channels for cabin speakers plus one bridged pair for subwoofer duty. Marine-Rated Class D TopologyConformal-coated circuit boards resist salt spray, bilge moisture, and the corrosive environments encountered in Australian coastal boating, offshore fishing, and beach-launched vessels. The robust construction handles tropical humidity in Far North Queensland waters, dusty corrugated tracks in the Outback, and Southern Ocean conditions off Tasmania. Class D efficiency minimizes heat generation, enabling reliable operation in poorly ventilated equipment bays, under seats, or in enclosed amplifier racks. Variable Filtering Across Channel PairsPrecision crossover control on channels 1&2, 3&4, 5&6, and 7&8 allows speaker-specific tuning. High-pass filter cabin speakers to remove low-frequency strain and improve clarity, low-pass subwoofer channels for dedicated bass reproduction, or run full-range where needed. The 12dB/octave slopes and 50Hz-500Hz range accommodate marine coaxials, component speakers, tower speakers, and compact subwoofers. Detented potentiometers enable repeatable settings across similar installations—critical for professional installers servicing multiple boats or vehicles. Extended Chassis for Thermal ManagementThe 374mm (14.73") chassis accommodates substantial heat sink area, enabling sustained full-power operation across all eight channels without thermal compression or protection shutdown. Critical for multi-hour listening sessions at anchor, beach parties, or long-distance highway touring. The extended chassis distributes thermal load efficiently, maintaining clean power output even when running all channels simultaneously at high volume levels. Optional Water-Resistant Remote ControlAdd JL Audio's HD-RLC or MHD-RLC (not included) to adjust system volume from the helm, driver's seat, or entertainment area. Essential for marine applications where the amplifier is mounted in inaccessible equipment bays, or automotive installations where the amp is hidden behind panels. The remote provides convenient master volume control without accessing the installation location. Technical Specs Amplifier class: Class D Channels: 8 (Full-range) Operating voltage: 11-14.5 VDC (12V models only - NOT 24V compatible) Power Output (varies by voltage and load impedance): Maximum rated power (14.4V @ 2Ω, <1% THD): 100W RMS × 8 (800W total) Power at 4Ω load (14.4V @ 4Ω, <1% THD): 75W RMS × 8 (600W total) Bridged power (14.4V @ 4Ω, <1% THD): 200W RMS × 4 (800W total bridged) Power at 2Ω load (12.5V @ 2Ω, <1% THD): 90W RMS × 8 (720W total) Power at 4Ω load (12.5V @ 4Ω, <1% THD): 60W RMS × 8 (480W total) Bridged power (12.5V @ 4Ω, <1% THD): 180W RMS × 4 (720W total bridged) THD+N @ rated power: <1% @ 2Ω per channel Frequency response (+0, -1dB): 12Hz-22kHz Remote level control compatibility: Optional HD-RLC or MHD-RLC (water-resistant) Recommended fuse type: AFS, AGU or MaxiFuse™ Fuse rating: 80A Minimum copper power/ground wire gauge: 4 AWG Physical dimensions (W × D × H): 374mm × 180mm × 52mm (14.73" × 7.09" × 2.05") Weight: Not specified Warranty: 3 years Important Note: This is the 12V model. The XDM series also includes a 24V 8-channel variant for commercial/heavy vehicle applications—this model operates on standard 12V automotive/marine electrical systems only. Compatible With / Goes Well With Speaker Recommendations: Marine coaxial speakers rated 75-100W RMS (6", 6.5", 6×9", or 7.7" sizes) Marine component speaker systems rated 75-100W RMS per channel Marine tower speakers rated 150-200W RMS per speaker (when bridged) Compact marine subwoofers rated 200W RMS (when using bridged channel pairs) Full-range cabin speakers for multi-zone installations Installation Accessories: 4 AWG or 0-2 AWG amplifier wiring kit with 80A+ inline fuse holder JL Audio HD-RLC or MHD-RLC water-resistant remote level control Marine-grade speaker wire (14-16 AWG recommended for most runs) RCA interconnect cables with marine-grade shielding (minimum 8-channel RCA distribution) Distribution blocks for clean power/ground distribution Heavy-duty amplifier mounting brackets or marine-rated equipment racks Sound deadening material for mounting surfaces System Compatibility: Marine head units with 4V preamp outputs (8-channel preamp output or DSP required) Aftermarket head units with 8-channel preamp capability Marine DSP processors with 8-channel output Line output converters with 8-channel capability for factory radio integration 12V electrical systems with adequate alternator capacity (100A+ recommended) Electrical System Requirements: Minimum 100A alternator capacity for sustained full-power operation Adequate battery reserve (AGM or lithium recommended for extended engine-off listening) Proper grounding with dedicated ground point to chassis/hull 4 AWG power and ground wiring with proper routing and protection Caution: Eight-channel systems require careful planning. Ensure your head unit or DSP provides eight independent preamp outputs. Verify speaker impedances before bridging channels—bridged operation requires 4Ω minimum load per bridged pair. Running all eight channels at maximum power simultaneously demands robust electrical infrastructure including high-output alternator, proper wiring gauge, and adequate battery capacity. Frequently Asked Questions Can I run this amplifier with a standard aftermarket head unit?Only if your head unit or DSP provides eight independent preamp outputs. Most standard head units offer 2-4 channels of preamp output—you'll need an 8-channel DSP or signal processor to feed all channels. Alternatively, use a multi-zone marine source unit with 8-channel capability. Can I bridge channels for higher power to tower speakers or subwoofers?Yes. Bridge adjacent channel pairs (1+2, 3+4, 5+6, 7+8) for 200W RMS per bridged pair at 4Ω load. This provides four bridged outputs at 200W each, ideal for marine tower speakers or compact subwoofers. Ensure speakers are rated for 4Ω minimum impedance when bridging. What size alternator do I need to run all eight channels at full power?Minimum 100A alternator for sustained full-power operation. At maximum output (800W), the amplifier draws approximately 80A from the electrical system. Factor in other electrical loads (navigation, pumps, lights) and ensure your alternator provides adequate reserve capacity. Undersized alternators cause voltage drop and thermal protection shutdown. Can I use this in a 4WD touring setup with multiple speaker zones?Yes, perfect application. Allocate channels for front cabin, rear cargo area, rooftop speakers, and annexe zones. The 12V operation suits dual-battery systems with proper isolation. Mount in cargo area or under seats with adequate ventilation. Consider auxiliary battery for extended camping scenarios with engine-off listening. How do I set up independent zone control for different areas?Use channels 1&2 for Zone 1 (cabin), 3&4 for Zone 2 (cockpit/tower), 5&6 for Zone 3 (rear/cargo), and 7&8 for Zone 4 (additional zone or bridged subwoofer). The optional HD-RLC remote controls master volume. For true zone-independent control, install separate zone controllers or use a DSP with zone management feeding the amplifier.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less
