OEX ACX1842 Circuit Breaker Manual Reset 30A Protect your 30A automotive circuits with confidence using the OEX ACX1842 Manual Reset Circuit Breaker, featuring IP67 waterproof and dust-resistant housing, stainless steel 8mm studs with rubber protective caps, manual reset function for immediate circuit restoration after a trip, compact 75 x 40 x 50mm dimensions, and robust construction for reliable overcurrent protection in automotive, marine, 4WD, caravan, RV, and commercial vehicle electrical installations. Product Overview The OEX ACX1842 is a 30A manual reset circuit breaker designed to provide reliable, resettable overcurrent protection for individual circuits in automotive, marine, and commercial vehicle electrical systems. Unlike blade fuses that must be replaced after a single overcurrent event, the ACX1842 can be manually reset and returned to service after a trip, making it ideal for circuits that may experience intermittent overloads or for installations where carrying replacement fuses is impractical. Manual reset circuit breakers require a deliberate reset action by the operator, ensuring the fault condition is identified and resolved before the circuit is restored, rather than automatically re-energising a potentially still-faulted circuit. This makes manual reset breakers the preferred choice for circuits connected to motors, winches, compressors, pumps, and high-draw accessories where nuisance tripping from temporary overloads is possible, and where a conscious reset decision improves operational safety. The IP67-rated waterproof and dust-resistant housing makes the ACX1842 suitable for external, under-bonnet, deck-mounted, and exposed installations where moisture and dust ingress would compromise a standard breaker. IP67 certification means the unit is rated for complete dust exclusion and temporary immersion in water, covering river crossings, high-rainfall conditions, and wash-down environments common in 4WD, agricultural, and marine applications. Stainless steel 8mm studs provide corrosion-resistant, high-current connection points compatible with standard automotive cable lugs, while the rubber stud caps protect the terminals from moisture, contamination, and accidental short circuits when not in use. Compact 75 x 40 x 50mm dimensions allow installation in tight spaces including engine bays, under-bonnet panels, chassis rails, and compact electrical enclosures. ISO 9001-certified manufacturing and in-house testing at OEX's Brisbane facility ensures consistent quality and long-term reliability. Features & Benefits Manual Reset for Controlled Circuit Restoration: The manual reset function requires a deliberate operator action to restore the circuit after a trip, ensuring the fault condition is identified and resolved before re-energising, making it the preferred choice for motor, winch, compressor, and pump circuits where automatic re-energisation after a fault could cause damage or create a safety hazard. IP67 Waterproof and Dust-Resistant Housing: IP67 certification provides complete dust exclusion and protection against temporary water immersion, making the ACX1842 suitable for external, under-bonnet, deck-mounted, and exposed installations in 4WD, agricultural, marine, and commercial vehicle applications subject to rain, splash, wash-down, and off-road water exposure. Stainless Steel 8mm Studs for Corrosion-Resistant Connections: Stainless steel 8mm stud terminals provide robust, corrosion-resistant connection points that maintain reliable electrical contact under vibration, thermal cycling, and exposure to moisture and automotive fluids in demanding installation environments. Rubber Stud Caps for Terminal Protection: Rubber protective caps cover the stud terminals when not in use, protecting against moisture ingress, contamination, and accidental short circuits at the connection points between the circuit breaker and the connected cable lugs. Resettable for Long-Term Service Without Consumables: Unlike blade or ANL fuses that must be replaced after a single overcurrent event, the ACX1842 can be tripped and reset repeatedly without replacement, eliminating the need to carry spare fuses for protected circuits and reducing long-term maintenance costs. Compact 75 x 40 x 50mm Dimensions: The compact form factor enables installation in tight spaces including under-bonnet panels, chassis rail mounting locations, compact electrical enclosures, and 4WD accessory panels where full-size circuit breakers would not fit. ISO 9001 Certified Manufacturing: Produced under ISO 9001 quality management certification with in-house product testing at OEX's Brisbane facility, ensuring consistent quality and long-term reliability across automotive, marine, RV, mining, and commercial vehicle applications. Technical Specs Specification Details Part Number ACX1842 Brand OEX Type Manual Reset Circuit Breaker Current Rating 30A Reset Type Manual Reset IP Rating IP67 Stud Size 8mm Stud Material Stainless Steel Terminal Protection Rubber Stud Caps Dimensions 75 x 40 x 50mm (L x W x D) Pack Quantity 1 Warranty 1 Year Quality Certification ISO 9001 Compatible With / Goes Well With The OEX ACX1842 suits 12V and 24V automotive, marine, caravan, RV, 4WD, agricultural, and commercial vehicle electrical systems requiring resettable 30A overcurrent protection on individual circuits. Ideal for winch circuits, air compressor feeds, water pump protection, lighting circuit protection, auxiliary battery circuit breakers, accessory panel protection, and any 30A circuit where a resettable breaker is preferred over a replaceable fuse. Compatible with standard cable lugs for 8mm stud terminals across a range of wire gauges appropriate for 30A circuits. Complements OEX fuse holders, distribution blocks, ANL fuse holders, and battery accessories for complete circuit protection and power management solutions. Frequently Asked Questions What is the difference between a manual reset and an automatic reset circuit breaker? A manual reset circuit breaker requires a deliberate operator action to restore the circuit after it trips on an overcurrent event. An automatic reset breaker re-energises the circuit automatically once it cools down. Manual reset is preferred for motor, winch, compressor, and pump circuits where automatic re-energisation after a fault could cause equipment damage or a safety hazard. It also ensures the operator is aware the circuit has tripped and can investigate the cause before restoring power. Can the ACX1842 be used as a replacement for a blade fuse or ANL fuse? Yes, in principle. A manual reset circuit breaker performs the same overcurrent protection function as a fuse but can be reset rather than replaced. The key difference is that a blown fuse requires the fault current to physically destroy the fuse element, providing a clear record of the overcurrent event, while a circuit breaker can be reset without any physical evidence of the trip. Both are valid overcurrent protection solutions depending on the application and installation requirements. What wire gauge is appropriate for a 30A circuit breaker? For a 30A continuous circuit, a minimum of 4mm² (approximately 11 AWG or 12 B&S) automotive grade cable is typically recommended for runs up to approximately 5 metres. For longer cable runs or high-duty-cycle applications, upsize to 6mm² to reduce voltage drop. Always match wire gauge to both the actual current draw of the circuit and the cable run length for safe, efficient operation. Is the ACX1842 suitable for marine deck installations? Yes. The IP67 rating certifies the ACX1842 for complete dust exclusion and temporary water immersion, making it suitable for marine deck-mounted installations, external 4WD body mounting, and other exposed locations subject to rain, splash, and wash-down. For permanent marine deck installations, apply marine-grade sealant around the mounting surface perimeter and ensure cable entry points are sealed against water tracking along the cable into the breaker housing. Where should the ACX1842 be installed in a circuit? The circuit breaker should be installed as close as practical to the power source, ideally within 300mm of the battery terminal or distribution point it is protecting. Installing the breaker close to the power source ensures the shortest possible length of unprotected cable between the battery and the overcurrent protection device, minimising the risk of cable damage in the event of a short circuit between the battery and the breaker.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2080BL 10A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect low-to-medium current circuits in a compact, compliant package with the OEX ACX2080BL 10A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2080BL is a compact Type 3 mini manual reset circuit breaker delivering professional-grade overcurrent protection and circuit isolation in a space-efficient surface mount form factor purpose-designed for applications where standard full-size circuit breakers would be impractical or unnecessary. At 10 amps, the ACX2080BL is ideally suited to protecting low-to-medium current auxiliary circuits including interior lighting, USB charging systems, small electronic accessories, switch panels, instrumentation, bilge pump controls, and other circuits in automotive, marine, caravan, and 4WD applications where reliable, resettable protection is required without the bulk or cost of a heavy-duty breaker. The compact 58.2 x 35.7 x 34.7mm dimensions allow the ACX2080BL to be installed in electrical panels, junction boxes, switch panels, and tight under-dash or under-bonnet locations where space is at a premium, while the surface mount design simplifies installation without requiring a dedicated housing or enclosure. The switchable Type 3 functionality allows the ACX2080BL to serve a dual role as both overcurrent protection device and manual on/off circuit isolation switch — enabling the operator to deliberately isolate a circuit without requiring a fault event, which is particularly valuable for marine bilge systems, auxiliary lighting circuits, and accessories that require controlled shutdown capability. The SAE J553, J1171, and UL1500 ignition-protected compliance certifications are significant for marine applications, confirming the ACX2080BL meets recognised international standards for use in fuel-vapour environments where ignition risk must be controlled. IP66 housing certification provides reliable protection against powerful water jets and complete dust ingress, making the ACX2080BL suitable for exposed cockpit, deck, and outdoor equipment installations. Features & Benefits 10A Type 3 Switchable Manual Reset Combines overcurrent circuit protection with deliberate manual isolation capability, providing both safety and operational control over the protected circuit without requiring a separate isolator switch. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important additional safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2080BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 10A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2080BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting interior and exterior lighting circuits, USB and accessory charging systems, switch panels, instrumentation, bilge pump controls, navigation electronics, and small auxiliary loads up to 10 amps. Also available in 15A, 20A, 30A, 40A, 50A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions What is the difference between IP66 and IP67 ratings on OEX circuit breakers? Both IP66 and IP67 provide complete dust-tight protection, but differ in water resistance. IP66 is rated for protection against powerful water jets from any direction, making it suitable for wash-down, heavy rain, and exposed outdoor installations. IP67 adds protection against temporary submersion up to 1 metre for 30 minutes, making it more appropriate for bilge and submersion-risk locations. For the majority of panel-mount, under-bonnet, and outdoor accessory circuit applications, IP66 provides more than adequate protection — choose IP67 rated breakers such as the OEX ACX1844 for installations where direct submersion is a genuine risk. What does UL1500 ignition protection compliance mean and why is it important for marine use? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products — it certifies that the ACX2080BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. Can I use the ACX2080BL as both a circuit breaker and an on/off switch for my accessory circuit? Yes. The Type 3 switchable function allows the ACX2080BL to be manually toggled on and off independently of any fault event, eliminating the need for a separate isolation switch on the same circuit. This makes it particularly practical for auxiliary lighting, bilge pumps, USB chargers, and accessory circuits in panels where space is limited and combining protection and switching functions into one device saves both space and wiring complexity. What terminal lug size do I need for the ACX2080BL's #10-32 threaded studs? The ACX2080BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole — sometimes described as a #10 or M5 lug in automotive and marine wiring accessories. For a 10A circuit, appropriately sized wire (typically 14 AWG / 2.5mm² for most applications) terminated with a correctly sized ring terminal lug crimped securely onto the conductor is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and ensure the lug hole matches the 6mm or ¼ inch stud size for a secure fit. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A, 20A, 30A, 40A, 50A, and 60A — allowing you to match the breaker precisely to the current requirements of each individual circuit. For multi-circuit protection panels, 5-packs are also available in 40A, 50A, and 60A ratings. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2081BL 15A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect low-to-medium current circuits with the OEX ACX2081BL 15A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2081BL is a compact Type 3 mini manual reset circuit breaker delivering professional-grade overcurrent protection and circuit isolation in a space-efficient surface mount form factor designed for applications where a standard full-size circuit breaker would be impractical or unnecessary. At 15 amps, the ACX2081BL steps up from the 10A ACX2080BL to cover a broader range of medium-current auxiliary circuits including LED light bars, accessory switch panels, USB charging hubs, navigation electronics, small pumps, electric step motors, and other moderate-draw accessories in automotive, marine, caravan, and 4WD applications where reliable, resettable protection is required without the bulk or cost of a heavy-duty breaker. The compact 58.2 x 35.7 x 34.7mm dimensions allow installation in electrical panels, switch panels, junction boxes, and confined under-dash or under-bonnet locations where space is limited, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality allows the ACX2081BL to serve the dual role of overcurrent protection and manual on/off circuit isolation switch — enabling deliberate circuit shutdown without requiring a fault event, which is particularly useful for marine bilge systems, auxiliary lighting, and accessories requiring controlled operator isolation. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2081BL meets recognised international standards for use in fuel-vapour environments on marine vessels. IP66 housing certification provides reliable protection against powerful water jets and complete dust ingress, making the ACX2081BL suitable for cockpit, deck, outdoor panel, and exposed equipment installations. Features & Benefits 15A Type 3 Switchable Manual Reset Combines overcurrent circuit protection with deliberate manual isolation capability, providing both safety and operational control over the protected circuit without requiring a separate isolator switch. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2081BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 15A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2081BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting LED light bars, accessory switch panels, USB charging hubs, navigation electronics, small pumps, electric step systems, and medium-draw auxiliary loads up to 15 amps. Also available in 10A, 20A, 30A, 40A, 50A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 15A ACX2081BL over the 10A ACX2080BL for my circuit? Choose the 15A ACX2081BL when your circuit's continuous current draw exceeds 10 amps or when protecting circuits with moderate-current loads such as LED light bars, USB charging hubs with multiple ports, small water pumps, navigation electronics clusters, or accessory switch panels feeding several low-current loads simultaneously. A general rule is to size the breaker at approximately 125% of the circuit's maximum continuous current draw — so for a circuit drawing up to 12 amps continuously, the 15A ACX2081BL is the correct choice. The 10A ACX2080BL is more appropriate for single low-draw accessories, interior lighting, and circuits where peak current never approaches 10 amps. Can I use the ACX2081BL as both a circuit breaker and an on/off switch for my accessory circuit? Yes. The Type 3 switchable function allows the ACX2081BL to be manually toggled on and off independently of any fault event, removing the need for a separate isolation switch on the same circuit. This is particularly practical for auxiliary lighting, bilge pumps, USB chargers, and accessory circuits in panels where space is limited and combining protection and switching functions into one device saves both space and wiring complexity. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2081BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What terminal lug size do I need for the ACX2081BL's #10-32 threaded studs? The ACX2081BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole, sometimes described as a #10 or M5 lug in automotive and marine wiring accessories. For a 15A circuit, appropriately sized wire (typically 14 AWG / 2.5mm² for most runs, or 12 AWG / 4mm² for longer runs) terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant fit. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A (ACX2081BL), 20A, 30A, 40A, 50A, and 60A, allowing you to match the breaker precisely to the current requirements of each circuit. For multi-circuit protection panel builds, 5-packs are also available in 40A, 50A, and 60A ratings. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2082BL 20A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect medium-current circuits with the OEX ACX2082BL 20A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2082BL is a compact Type 3 mini manual reset circuit breaker delivering professional-grade overcurrent protection and circuit isolation in a space-efficient surface mount form factor suited to medium-current auxiliary circuits where a standard full-size circuit breaker would be impractical or oversized. At 20 amps, the ACX2082BL covers a wide range of practical medium-current applications including electric cooler and fridge circuits, high-output LED driving lights, dual USB and 12V accessory socket panels, cabin fan systems, electric toilet pumps, windlass control circuits, and multi-accessory distribution feeds in automotive, marine, caravan, and 4WD installations. The compact 58.2 x 35.7 x 34.7mm dimensions allow installation in electrical panels, switch panels, junction boxes, and confined under-dash or under-bonnet locations, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality provides dual capability as both an overcurrent protection device and a manual on/off circuit isolation switch, enabling deliberate circuit shutdown without requiring a fault event — particularly useful for fridge and cooler circuits, cabin fans, and accessories requiring controlled operator isolation. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2082BL meets recognised international standards for use in fuel-vapour environments on marine vessels. IP66 housing certification provides reliable protection against powerful water jets and complete dust ingress for cockpit, deck, outdoor panel, and exposed equipment installations. Features & Benefits 20A Type 3 Switchable Manual Reset Combines overcurrent circuit protection with deliberate manual isolation capability, providing both safety and operational control over the protected circuit without requiring a separate isolator switch. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2082BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 20A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2082BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting portable fridge and cooler circuits, high-output LED driving lights, dual USB and 12V socket panels, cabin fan systems, electric toilet and shower pumps, windlass control feeds, and medium-draw auxiliary loads up to 20 amps. Also available in 10A, 15A, 30A, 40A, 50A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 20A ACX2082BL over the 15A ACX2081BL for my circuit? Choose the 20A ACX2082BL when your circuit's continuous current draw exceeds 15 amps or when protecting loads such as portable fridges and coolers (typically 8–15A continuous), high-output LED driving light bars, multi-port USB and 12V accessory socket panels, cabin fans, or small pump systems drawing up to 16 amps continuously. Applying the standard 125% sizing rule, the 20A ACX2082BL is the correct choice for any circuit with a maximum continuous draw of up to 16 amps. For lighter loads under 12 amps continuous, the 15A ACX2081BL is a better fit, while circuits drawing above 16 amps continuous should step up to the 30A variant. Can the ACX2082BL protect a portable fridge or cooler circuit in my caravan or 4WD? Yes, the 20A ACX2082BL is well suited to portable fridge and cooler circuit protection. Most 12V compressor fridges draw between 3–8 amps during normal running, with short-duration start-up surges that rarely exceed 15 amps. The 20A rating provides comfortable protection headroom above normal operating current while still responding appropriately to genuine fault conditions. The switchable function is a practical bonus for fridge circuits, allowing deliberate isolation when the vehicle is unattended for extended periods without needing a separate isolation switch. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2082BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What terminal lug size do I need for the ACX2082BL's #10-32 threaded studs? The ACX2082BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole, sometimes described as a #10 or M5 lug in automotive and marine wiring accessories. For a 20A circuit, appropriately sized wire (typically 12 AWG / 4mm² for most runs, or 10 AWG / 6mm² for longer runs exceeding 5 metres) terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant fit. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A (ACX2081BL), 20A (ACX2082BL), 30A, 40A, 50A, and 60A, allowing you to match the breaker precisely to each circuit's requirements. For multi-circuit protection panel builds, 5-packs are also available in 40A, 50A, and 60A ratings. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2083BL 30A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect high-demand medium-current circuits with the OEX ACX2083BL 30A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2083BL is the highest-rated single-pack variant in the compact ACX2080 mini circuit breaker series, delivering professional-grade 30-amp overcurrent protection and circuit isolation in the same space-efficient surface mount form factor shared across the range. At 30 amps, the ACX2083BL is the go-to mini breaker for protecting the most demanding circuits a compact breaker is typically asked to handle — including high-current air compressors, electric anchor windlasses, high-draw inverters, dual-battery system feeds, trolling motor circuits, high-power LED light bar installations, and multi-output distribution feeds in automotive, marine, caravan, and 4WD applications where reliable, resettable protection is required in a compact form. The 58.2 x 35.7 x 34.7mm compact dimensions allow installation in electrical panels, switch panels, and confined locations where a full-size 30A heavy duty breaker would be impractical, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality provides the dual capability of overcurrent protection and manual on/off circuit isolation, enabling deliberate circuit shutdown without requiring a fault event — particularly valuable for high-current systems such as compressors, anchor windlasses, and inverter feeds where operator isolation capability is a safety and convenience requirement. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2083BL meets recognised international standards for use in fuel-vapour environments on marine vessels. IP66 housing certification provides reliable protection against powerful water jets and complete dust ingress for cockpit, deck, outdoor panel, and exposed equipment installations. Features & Benefits 30A Type 3 Switchable Manual Reset Combines overcurrent circuit protection with deliberate manual isolation capability at the highest amperage in the compact ACX2080 mini series, handling demanding loads including compressors, windlasses, and high-power light bars without requiring a full-size heavy duty breaker. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2083BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 30A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2083BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting high-current air compressor circuits, electric anchor windlasses, high-power LED light bar installations, small inverter feeds, dual-battery system outputs, trolling motor circuits, and high-demand auxiliary loads up to 30 amps. Also available in 10A, 15A, 20A, 40A, 50A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 30A ACX2083BL over the 20A ACX2082BL for my circuit? Choose the 30A ACX2083BL when your circuit's continuous current draw exceeds 20 amps or when protecting high-demand loads such as air compressors (typically 15–25A continuous), high-power LED light bars drawing above 16 amps, small inverters up to approximately 360W (12V), electric anchor windlasses, or multi-accessory distribution feeds where combined load approaches 24 amps continuous. Applying the standard 125% sizing rule, the 30A ACX2083BL is the correct choice for any circuit with a maximum continuous draw of up to 24 amps. For circuits drawing above 24 amps continuous, step up to the 40A variant in the ACX2080 series or consider the heavy duty OEX ACX1844 for high-current applications. Is the 32VDC voltage rating a limitation for 24V system installations? No. A fully charged 24V lead-acid battery system reaches approximately 28.8V at full charge, and a 24V lithium battery system reaches approximately 29.2V — both well within the 32VDC maximum rating of the ACX2083BL. The 32VDC rating provides an adequate safety margin for all standard 24V automotive, marine, and caravan DC systems. Note that the ACX2083BL is not suitable for 48V systems — for 48V lithium or specialist high-voltage installations, the OEX ACX1844 with its 72VDC rating is the appropriate choice. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2083BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What terminal lug and cable size should I use for the ACX2083BL on a 30A circuit? The ACX2083BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole. For a 30A circuit, appropriately sized wire — typically 10 AWG / 6mm² for runs up to 3 metres, or 8 AWG / 8mm² for longer runs or installations where minimising voltage drop is critical — terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant termination. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A (ACX2081BL), 20A (ACX2082BL), 30A (ACX2083BL), 40A, 50A, and 60A, allowing you to match the breaker precisely to each circuit's requirements. For multi-circuit protection panel builds, 5-packs are also available in 40A, 50A, and 60A ratings. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2084BL 40A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect high-current circuits in a compact, compliant package with the OEX ACX2084BL 40A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2084BL is a high-current capable Type 3 mini manual reset circuit breaker delivering professional-grade 40-amp overcurrent protection and circuit isolation in the compact surface mount form factor of the ACX2080 series — bridging the gap between the 30A ACX2083BL and heavier-duty full-size breakers for applications demanding more current capacity without sacrificing installation flexibility. At 40 amps, the ACX2084BL is suited to protecting high-current circuits including large electric air compressors, heavy-duty winch control feeds, high-output inverters up to approximately 480W (12V) or 960W (24V), high-draw marine thrusters, electric outboard motor control circuits, dual-battery charge feed outputs, and multi-circuit panel distribution feeds in automotive, marine, caravan, and 4WD installations. The compact 58.2 x 35.7 x 34.7mm dimensions allow installation in electrical panels, switch panels, and confined locations where full-size heavy duty breakers would be impractical, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality provides dual capability as both overcurrent protection and manual on/off circuit isolation, enabling deliberate circuit shutdown without requiring a fault event — essential for high-current systems including compressors, winches, and inverter feeds where controlled isolation is a safety and operational requirement. The ACX2084BL is also the entry point into the ACX2080 5-pack range, making it an economical choice for multi-circuit panel builds or fleet installations requiring multiple breakers of the same rating. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2084BL meets recognised international standards for use in fuel-vapour environments on marine vessels. Features & Benefits 40A Type 3 Switchable Manual Reset Handles high-current circuit protection and manual isolation in a compact mini form factor, covering demanding loads including large compressors, winch feeds, and high-output inverter circuits without requiring a full-size heavy duty breaker. Available as Single Pack or 5-Pack The ACX2084BL is the entry point into the ACX2080 5-pack range, offering significant value for multi-circuit panel builds, fleet installations, and workshops requiring multiple 40A breakers for consistent system builds. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2084BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 40A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 (5-pack also available) Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2084BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting large air compressor circuits, heavy-duty winch control feeds, high-output inverter circuits, marine bow and stern thrusters, dual-battery system charge feed outputs, electric outboard motor control circuits, and high-demand auxiliary loads up to 40 amps. Also available in 10A, 15A, 20A, 30A, 50A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 40A ACX2084BL over the 30A ACX2083BL for my circuit? Choose the 40A ACX2084BL when your circuit's continuous current draw exceeds 30 amps or when protecting high-current loads such as large air compressors drawing up to 32 amps continuous, heavy-duty winch control feeds, inverters drawing above 24 amps, marine thrusters, or multi-output distribution feeds where combined load approaches 32 amps continuous. Applying the standard 125% sizing rule, the 40A ACX2084BL is the correct choice for circuits with a maximum continuous draw of up to 32 amps. For circuits drawing above 32 amps continuous, step up to the 50A variant in the ACX2080 series, or consider the heavy duty OEX ACX1844 for applications requiring higher voltage tolerance or IP67 submersion protection. Is the ACX2084BL suitable for protecting a winch circuit on my 4WD? The ACX2084BL at 40A is suitable for winch control circuits and smaller winches, but it is important to note that the maximum voltage rating of 32VDC limits the ACX2084BL to 12V and 24V systems only. For winch protection, it is also critical to note that winch circuits can draw very high peak currents during recovery — often 100A or more under full load — and in these cases the circuit protection device should be installed on the control/signal feed rather than the main high-current winch motor cable. For main winch motor cable protection at full rated draw, a heavy duty ANL fuse or the OEX ACX1844 heavy duty breaker is more appropriate. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2084BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What terminal lug and cable size should I use for the ACX2084BL on a 40A circuit? The ACX2084BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole. For a 40A circuit, appropriately sized wire — typically 8 AWG / 8mm² for runs up to 3 metres, or 6 AWG / 10mm² for longer runs or installations where minimising voltage drop is critical — terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant termination. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A (ACX2081BL), 20A (ACX2082BL), 30A (ACX2083BL), 40A (ACX2084BL), 50A, and 60A, allowing you to match the breaker precisely to each circuit's requirements. The ACX2084BL is also available as a 5-pack for multi-circuit panel builds and fleet installations — as are the 50A and 60A variants. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2085BL 50A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect very high-current circuits in a compact, compliant package with the OEX ACX2085BL 50A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2085BL is the second-highest rated variant in the compact ACX2080 mini circuit breaker series, delivering professional-grade 50-amp overcurrent protection and circuit isolation in the same space-efficient surface mount form factor shared across the range. At 50 amps, the ACX2085BL handles the most demanding loads a compact mini breaker is typically called upon to protect — including large capacity DC-DC charger outputs, high-draw solar charge controller feeds, Anderson plug distribution circuits, heavy-duty electric winch control feeds, large marine thrusters, multi-circuit auxiliary panel main feeds, and high-output inverter input circuits up to approximately 600W (12V) or 1200W (24V) in automotive, marine, caravan, and 4WD installations. The compact 58.2 x 35.7 x 34.7mm dimensions allow installation in electrical panels, switch panels, and confined locations where full-size heavy duty breakers would be impractical or oversized, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality provides dual capability as both overcurrent protection and manual on/off circuit isolation, enabling deliberate circuit shutdown without requiring a fault event — critical for high-current system feeds where controlled isolation is a safety and operational priority. Available as both a single pack and a 5-pack, the ACX2085BL suits both individual circuit installations and larger multi-circuit panel builds requiring consistent high-current protection across multiple outputs. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2085BL meets recognised international standards for use in fuel-vapour environments on marine vessels. Features & Benefits 50A Type 3 Switchable Manual Reset Delivers very high-current circuit protection and manual isolation in a compact mini form factor, covering the most demanding loads a surface mount mini breaker is typically asked to handle including DC-DC charger feeds, solar controller outputs, and large inverter circuits. Available as Single Pack or 5-Pack Suits both single circuit installations and larger multi-circuit panel builds, offering significant value when multiple 50A protection points are required across a system or fleet installation. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2085BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 50A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 (5-pack also available) Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2085BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting DC-DC charger output feeds, solar charge controller distribution circuits, Anderson plug panel feeds, large marine thruster circuits, multi-circuit auxiliary panel main feeds, high-output inverter input circuits, and very high-demand auxiliary loads up to 50 amps. Also available in 10A, 15A, 20A, 30A, 40A, and 60A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX switch panels and accessories, OEX Anderson plug assemblies, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 50A ACX2085BL over the 40A ACX2084BL for my circuit? Choose the 50A ACX2085BL when your circuit's continuous current draw exceeds 40 amps or when protecting very high-current loads such as DC-DC charger outputs (typically 30–40A continuous), large solar charge controller distribution feeds, Anderson plug panel main feeds, or multi-output auxiliary distribution circuits where combined continuous load approaches 40 amps. Applying the standard 125% sizing rule, the 50A ACX2085BL is the correct choice for circuits with a maximum continuous draw of up to 40 amps. For circuits drawing above 40 amps continuous, step up to the 60A ACX2086BL, or consider the heavy duty OEX ACX1844 for applications also requiring 72VDC voltage tolerance or IP67 submersion-rated protection. Can the ACX2085BL protect a DC-DC charger or MPPT solar controller output circuit? Yes, the 50A ACX2085BL is well suited to protecting DC-DC charger and MPPT solar charge controller output distribution circuits, particularly for units rated up to 40A continuous output. As a guide, a 40A DC-DC charger or MPPT controller output circuit requires a protection device rated at approximately 50A — making the ACX2085BL a natural fit. The switchable function also provides a practical means of isolating the charger circuit from the auxiliary battery bank when needed, without requiring a separate isolation switch in the circuit. What terminal lug and cable size should I use for the ACX2085BL on a 50A circuit? The ACX2085BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole. For a 50A circuit, appropriately sized wire — typically 6 AWG / 10mm² for runs up to 3 metres, or 4 AWG / 16mm² for longer runs or installations where minimising voltage drop is critical — terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant termination. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2085BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series is available in single packs across seven amperage ratings: 10A (ACX2080BL), 15A (ACX2081BL), 20A (ACX2082BL), 30A (ACX2083BL), 40A (ACX2084BL), 50A (ACX2085BL), and 60A (ACX2086BL), allowing you to match the breaker precisely to each circuit's requirements. The ACX2085BL is also available as a 5-pack for multi-circuit panel builds and fleet installations — as are the 40A and 60A variants. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2086BL 60A Mini Manual Reset Circuit Breaker Type 3 Switchable Protect the highest-demand circuits in a compact, compliant package with the OEX ACX2086BL 60A mini manual reset circuit breaker featuring Type 3 switchable operation for combined circuit protection and isolation, IP66 waterproof and dustproof housing for exposed installation environments, UL 94VO rated thermal plastic housing for fire-resistant safety, SAE J553, J1171, and UL1500 ignition-protected compliance for marine and automotive applications, an extended operating temperature range of -40°C to 85°C for extreme-condition reliability, #10-32 threaded studs with protective insulators accepting 6mm or ¼ inch terminal lugs, and OEX ISO 9001 certified quality built for demanding Australian automotive, marine, and industrial conditions. Product Overview The OEX ACX2086BL is the highest-rated variant in the compact ACX2080 mini circuit breaker series, delivering professional-grade 60-amp overcurrent protection and circuit isolation at the maximum capacity of the range in the same space-efficient surface mount form factor shared across all ACX2080 models. At 60 amps, the ACX2086BL reaches the upper limit of what a compact surface mount mini breaker can handle, making it the go-to choice for protecting main auxiliary battery feed circuits, high-output solar system main distribution feeds, large capacity dual-battery interconnects, high-draw inverter input circuits up to approximately 720W (12V) or 1440W (24V), heavy marine thruster main feeds, and multi-output panel primary supply circuits in automotive, marine, caravan, and 4WD installations where the full 60A capacity of the compact ACX2080 form factor is required. The 58.2 x 35.7 x 34.7mm compact dimensions allow installation in electrical panels, switch panels, and confined locations where full-size heavy duty breakers would be impractical, while the surface mount design eliminates the need for a dedicated housing or enclosure. The switchable Type 3 functionality provides dual capability as both overcurrent protection and manual on/off circuit isolation, enabling deliberate circuit shutdown without requiring a fault event — essential for primary battery feed circuits and main system supply lines where controlled isolation is a key safety and operational requirement. Available as both a single pack and a 5-pack, the ACX2086BL is equally suited to single circuit protection and larger multi-circuit panel builds requiring maximum-rated compact protection across multiple outputs. SAE J553, J1171, and UL1500 ignition-protected compliance certifications confirm the ACX2086BL meets recognised international standards for use in fuel-vapour environments on marine vessels. Features & Benefits 60A Type 3 Switchable Manual Reset The highest-rated variant in the compact ACX2080 mini series, delivering maximum-capacity circuit protection and manual isolation for primary battery feeds, large inverter circuits, solar main distribution feeds, and heavy marine thruster circuits in a surface mount form factor. Available as Single Pack or 5-Pack Suits both single circuit installations and larger multi-circuit panel builds, offering significant value for installations requiring maximum-rated compact protection across multiple outputs simultaneously. Compact Mini Surface Mount Design The 58.2 x 35.7 x 34.7mm form factor fits neatly into electrical panels, switch panels, and confined spaces where standard full-size circuit breakers are too large, simplifying installation in tight locations. IP66 Waterproof & Dustproof Housing Rated against powerful water jets and complete dust ingress, enabling reliable installation in exposed marine cockpit, deck, outdoor equipment, and under-bonnet panel locations subject to wash-down and environmental exposure. UL 94VO Rated Thermal Plastic Housing Fire-resistant housing material certified to UL 94VO flammability standard, providing an important safety layer in automotive and marine applications where fire risk from electrical faults must be minimised. SAE J553, J1171 & UL1500 Compliant Meets recognised international automotive and marine electrical standards including ignition protection certification, confirming suitability for use in fuel-vapour environments such as marine engine bays and enclosed bilge areas. Extended Operating Temperature Range Rated from -40°C to 85°C for reliable performance across extreme cold and heat conditions encountered in alpine, desert, tropical marine, and industrial mobile equipment applications throughout Australia and beyond. #10-32 Threaded Studs with Protective Insulators Standard threaded studs accept 6mm or ¼ inch terminal lugs for secure, vibration-resistant connections, with included protective stud insulators maintaining terminal safety and preventing accidental contact. Technical Specs Specification Detail Brand OEX SKU ACX2086BL Breaker Type Type 3 Mini Manual Reset (Switchable) Current Rating 60A Max Voltage 32VDC Terminal Studs #10-32 Threaded Terminal / Lug Size 6mm or ¼ inch IP Rating IP66 Waterproof & Dustproof Housing Material Thermal Plastic UL Rated 94VO Operating Temperature -40°C to 85°C Compliance SAE J553, J1171, UL1500 (Ignition Protected) Stud Protection Protective Stud Insulators Included Dimensions (HxWxD) 58.2 x 35.7 x 34.7mm Pack Quantity 1 (5-pack also available) Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX ACX2086BL is compatible with 12V and 24V DC electrical systems up to 32VDC across passenger vehicles, 4WD, caravans, motorhomes, marine vessels, and light industrial mobile equipment. Well suited to protecting main auxiliary battery feed circuits, high-output solar system main distribution feeds, large capacity dual-battery interconnects, high-draw inverter input circuits, heavy marine thruster main feeds, and primary supply circuits for multi-output panels drawing up to 60 amps. Also available in 10A, 15A, 20A, 30A, 40A, and 50A single packs for matching protection to specific circuit requirements, with 5-packs available in 40A, 50A, and 60A for multi-circuit panel builds. Pairs well with OEX distribution blocks, OEX Anderson plug assemblies, OEX switch panels and accessories, OEX wiring harnesses and cable accessories, and OEX terminal connectors and busbars for complete circuit protection and distribution system installations. Frequently Asked Questions When should I choose the 60A ACX2086BL over the 50A ACX2085BL for my circuit? Choose the 60A ACX2086BL when your circuit's continuous current draw exceeds 50 amps or when protecting very high-current loads such as main auxiliary battery feed circuits, primary solar system distribution feeds, large capacity dual-battery interconnects, or combined multi-accessory panel feeds where total continuous draw approaches 48 amps. Applying the standard 125% sizing rule, the 60A ACX2086BL is the correct choice for circuits with a maximum continuous draw of up to 48 amps. The ACX2086BL represents the maximum capacity of the compact ACX2080 mini series — for circuits exceeding 48 amps continuous or applications requiring 72VDC voltage tolerance or IP67 submersion protection, the heavy duty OEX ACX1844 is the appropriate step up. How does the 60A ACX2086BL mini breaker compare to the heavy duty OEX ACX1844 60A breaker? Both breakers are rated at 60A but are designed for different installation scenarios. The ACX2086BL is a compact surface mount mini breaker suited to panel-mount applications in confined spaces, rated to 32VDC with IP66 protection and SAE/UL1500 ignition-protected compliance for marine environments. The OEX ACX1844 is a full-size Type III heavy duty breaker rated to 72VDC with IP67 submersion-rated protection and larger 9.5mm stainless steel studs for heavier cable gauges. Choose the ACX2086BL for compact panel-mount installations on 12V or 24V systems; choose the ACX1844 when the installation requires 48V system compatibility, submersion-rated IP67 protection, or heavier cable terminations in exposed bilge, deck, or under-bonnet locations. What terminal lug and cable size should I use for the ACX2086BL on a 60A circuit? The ACX2086BL's #10-32 threaded studs accept terminal lugs with a 6mm or ¼ inch hole. For a 60A circuit, appropriately sized wire — typically 4 AWG / 16mm² for runs up to 3 metres, or 2 AWG / 25mm² for longer runs or installations where minimising voltage drop is critical — terminated with a correctly crimped ring terminal lug is recommended. Always use a ratchet crimping tool for reliable, gas-tight crimps and confirm the lug hole matches the 6mm or ¼ inch stud size for a secure, vibration-resistant termination. What does the UL1500 ignition protection compliance mean for marine installations? UL1500 is the Underwriters Laboratories standard for ignition protection of marine products. It certifies that the ACX2086BL is designed and tested to not ignite flammable fuel vapours that may be present in marine engine compartments and bilge areas. This compliance is a requirement under many marine safety standards including those referenced by Australian Maritime Safety Authority (AMSA) guidelines, and is an important consideration when installing electrical components in enclosed spaces near fuel tanks, fuel lines, or bilge areas on boats and vessels. What other amperage options are available in the OEX ACX2080 Mini Circuit Breaker range? The ACX2080 series covers seven amperage ratings in single packs: 10A (ACX2080BL), 15A (ACX2081BL), 20A (ACX2082BL), 30A (ACX2083BL), 40A (ACX2084BL), 50A (ACX2085BL), and 60A (ACX2086BL), allowing precise matching of breaker rating to each circuit's requirements. The ACX2086BL is also available as a 5-pack for multi-circuit panel builds and fleet installations — as are the 40A and 50A variants. All variants share the same compact Type 3 switchable mini form factor, IP66 rating, and SAE/UL compliance, making it straightforward to standardise on the ACX2080 series across an entire electrical system build.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX LLX08308 4LED Work Light Nylon Housing Square Brighten your work area with the OEX LLX08308 compact 12W square LED work light delivering 1300 effective lumens from four 3W LEDs in a flood beam pattern, IP67 and IP69K dual-rated waterproof and dustproof thermal plastic nylon housing for reliable performance in demanding outdoor environments, 10-30V wide voltage input compatibility for 12V and 24V system fitment, DT04-2P connector for secure moisture-resistant wiring, single bolt mounting for quick and versatile installation, lightweight 0.22kg construction for low-profile fitment, and OEX ISO 9001 certified quality built for Australian automotive, agricultural, marine, and industrial working conditions. Product Overview The OEX LLX08308 is a compact and versatile square LED work light engineered for reliable task and area illumination in automotive, agricultural, marine, and industrial applications where a durable, low-profile, high-output light is required in a confined or weight-sensitive mounting position. The 12W draw from four 3W LEDs generates 1300 effective lumens in a wide flood beam pattern, providing broad, even illumination of the immediate work area — ideal for underbonnet engine bay lighting, tray and cargo area illumination, equipment bay lighting, reverse and manoeuvring lights, entry and step lighting, and general task lighting on trucks, utes, caravans, trailers, agricultural machinery, and marine vessels. The compact 97 x 71 x 49mm form factor and single bolt mounting system make the LLX08308 exceptionally easy to install in tight or restricted locations where larger work lights would not fit, while the lightweight 0.22kg construction minimises mounting hardware requirements and reduces load on lightweight panels and brackets. The 10-30V wide voltage input rating provides genuine compatibility across 12V and 24V electrical systems without requiring voltage-specific variants, covering the full range of passenger vehicles, commercial trucks, agricultural equipment, and marine vessels in a single product. The dual IP67 and IP69K environmental rating certifies the LLX08308 for continuous submersion and high-pressure high-temperature wash-down, ensuring reliable operation on wash-down vehicles, agricultural machinery, marine craft, and equipment exposed to heavy rain, mud, and water spray in demanding Australian field conditions. The DT04-2P connector provides a secure, weatherproof, vibration-resistant plug-and-play connection widely used in professional automotive and agricultural wiring, enabling clean installation and easy light servicing without cutting wiring. Note that no wiring harness is supplied with the LLX08308 — a compatible harness should be sourced separately to suit your specific installation. Features & Benefits 1300 Effective Lumen Flood Output Four 3W LEDs deliver broad, even flood illumination of the immediate work area from a 12W draw at only 0.9A on 13V, providing excellent task lighting efficiency with minimal electrical system load. IP67 and IP69K Dual-Rated Protection Certified for continuous submersion and high-pressure high-temperature wash-down, enabling reliable operation on wash-down equipment, agricultural machinery, marine vessels, and vehicles operating in wet, muddy, and harsh environmental conditions. Compact 97 x 71 x 49mm Form Factor The square nylon housing fits in tight and restricted mounting locations where larger work lights will not, with single bolt mounting for quick, low-profile installation on panels, brackets, roll bars, and equipment frames. 10-30V Wide Voltage Input Compatible with 12V and 24V electrical systems across passenger vehicles, commercial trucks, agricultural machinery, and marine vessels without requiring voltage-specific variants or additional components. Thermal Plastic Nylon Housing Lightweight and durable nylon construction resists corrosion, impacts, and UV degradation in harsh outdoor environments while keeping the overall weight to just 0.22kg for mounting flexibility in weight-sensitive locations. DT04-2P Connector Industry-standard weatherproof connector provides a secure, vibration-resistant, moisture-proof plug-and-play connection that simplifies installation and enables easy light removal or replacement without cutting wiring. Single Bolt Mount Versatile single bolt mounting system enables quick installation in a wide range of positions and orientations, compatible with standard bracket and surface mount configurations across automotive, marine, and industrial applications. Technical Specs Specification Detail Brand OEX SKU LLX08308 Light Output 1300 Effective Lumen LEDs 4 x 3W Wattage 12W Current Draw 0.9A @ 13V Voltage Input 10-30V (12V / 24V) Beam Pattern Flood Shape Square Dimensions 97mm (H) x 71mm (W) x 49mm (L) Body Material Thermal Plastic Nylon Lens Material Polycarbonate IP Rating IP67 / IP69K Vibration Rating 20G Connector DT04-2P Mount Type Single Bolt Weight 0.22kg Harness Not Supplied Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX LLX08308 is compatible with 12V and 24V electrical systems across passenger vehicles, utes, trucks, caravans, trailers, agricultural machinery, marine vessels, and industrial mobile equipment. Well suited to underbonnet engine bay lighting, tray and cargo area illumination, equipment bay and toolbox lighting, reverse and manoeuvring lights, step and entry lighting, and general task lighting across a wide range of vehicle and equipment types. Pairs well with compatible DT04-2P wiring harnesses and extension leads, OEX automotive cable and cable management accessories, OEX switch panels and rocker switches for light control, OEX circuit breakers and inline fuse holders for circuit protection, and mounting brackets compatible with single bolt 97mm square light bodies. Frequently Asked Questions What applications is the LLX08308 best suited to as a flood beam work light? The LLX08308's wide flood beam pattern makes it ideal for illuminating the immediate work area at close to medium range rather than projecting light at distance. Typical applications include underbonnet engine bay lighting for roadside repairs and servicing, ute tray and cargo area illumination for loading and unloading in the dark, equipment bay and toolbox lighting on service vehicles, reverse and manoeuvring lights on trailers and caravans, entry and step lighting on RVs and motorhomes, and general task lighting on agricultural machinery, fishing vessels, and mobile plant equipment. For applications requiring long-distance forward illumination, a dedicated driving light such as the Great Whites GWR7145KIT or GWR7245KIT would be more appropriate. Does the LLX08308 come with a wiring harness? No — the LLX08308 is supplied with the DT04-2P connector fitted to the light but does not include a wiring harness. A compatible DT04-2P wiring harness or pigtail lead will need to be sourced separately to suit your specific installation. Contact F.A.E. for compatible harness options, or enquire about suitable OEX wiring accessories to complete the installation. What does the IP67 and IP69K dual rating mean for a work light installation? IP67 certifies protection against continuous submersion up to 1 metre depth, while IP69K certifies protection against high-pressure, high-temperature water jets as used in agricultural and industrial wash-down applications. For a work light installed on a wash-down vehicle, agricultural equipment, or a marine vessel subject to heavy weather, carrying both ratings provides comprehensive protection against both submersion events and aggressive cleaning. Many budget work lights carry IP67 alone — the addition of IP69K on the LLX08308 makes it genuinely suitable for wash-down equipment and heavy-duty agricultural applications where high-pressure cleaning is routine. Can I use the LLX08308 on a 24V commercial vehicle or agricultural machine? Yes. The 10-30V wide voltage input rating makes the LLX08308 fully compatible with 24V electrical systems as used in commercial trucks, agricultural tractors, heavy equipment, and specialist vehicles. At 24V, the current draw will be approximately 0.5A — roughly half the 12V draw — making the LLX08308 an extremely low-draw lighting solution on 24V systems. Ensure the wiring harness and any in-line fuse or circuit protection used are also rated for 24V operation. How many LLX08308 work lights can I run from a single 10A circuit? At 12V, each LLX08308 draws 0.9A. A standard 10A circuit can safely support up to eight lights simultaneously with a small safety margin remaining, or up to six lights for a comfortable 125% derating that protects the circuit and wiring. At 24V, current draw drops to approximately 0.5A per light, allowing up to sixteen lights on a single 10A circuit. For most practical installations involving two to four work lights, a 5A fuse or circuit breaker per pair is an appropriate and tidy protection arrangement.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX LLX08309 4LED Work Light Nylon Housing Round Brighten your work area with the OEX LLX08309 compact 12W round LED work light delivering 1300 effective lumens from four 3W LEDs in a flood beam pattern, IP67 and IP69K dual-rated waterproof and dustproof thermal plastic nylon housing for reliable performance in demanding outdoor environments, 10-30V wide voltage input compatibility for 12V and 24V system fitment, DT04-2P connector for secure moisture-resistant wiring, single bolt mounting for quick and versatile installation, lightweight 0.22kg construction for low-profile fitment, and OEX ISO 9001 certified quality built for Australian automotive, agricultural, marine, and industrial working conditions. Product Overview The OEX LLX08309 is the round-body variant of the compact LLX08308 square work light, sharing the same professional-grade 12W LED output, IP67/IP69K dual rating, and 10-30V wide voltage compatibility in a round housing profile suited to applications and mounting positions where a circular light form factor is preferred or required. The round body of the LLX08309 is particularly well suited to installation in round light apertures and pre-drilled holes, circular flush-mount or surface-mount brackets, and mounting positions on roll bars, light bars, and tubular structures where a round profile provides a cleaner, more symmetrical aesthetic alongside other round lighting and accessory components. The 12W draw from four 3W LEDs generates 1300 effective lumens in a wide flood beam pattern, providing broad, even illumination of the immediate work area — ideal for underbonnet engine bay lighting, tray and cargo area illumination, equipment bay lighting, reverse and manoeuvring lights, entry and step lighting, and general task lighting on trucks, utes, caravans, trailers, agricultural machinery, and marine vessels. The compact 97 x 71 x 49mm body and single bolt mounting system make the LLX08309 straightforward to install in a wide range of positions and orientations, while the 0.22kg lightweight construction minimises mounting hardware requirements. The 10-30V wide voltage input covers 12V and 24V systems without requiring voltage-specific variants, and the dual IP67 and IP69K environmental rating certifies the LLX08309 for continuous submersion and high-pressure high-temperature wash-down across the most demanding Australian field conditions. The DT04-2P connector provides a secure, weatherproof, vibration-resistant plug-and-play connection for clean installation and easy light servicing. Note that no wiring harness is supplied with the LLX08309 — a compatible harness should be sourced separately to suit the specific installation. Features & Benefits 1300 Effective Lumen Flood Output Four 3W LEDs deliver broad, even flood illumination of the immediate work area from a 12W draw at only 0.9A on 13V, providing excellent task lighting efficiency with minimal electrical system load. Round Housing Profile The circular body suits round light apertures, pre-drilled holes, circular flush and surface mount brackets, and tubular roll bar and light bar mounting positions where a round profile provides a cleaner fit and more symmetrical appearance than a square light body. IP67 and IP69K Dual-Rated Protection Certified for continuous submersion and high-pressure high-temperature wash-down, enabling reliable operation on wash-down equipment, agricultural machinery, marine vessels, and vehicles operating in wet, muddy, and harsh environmental conditions. Compact 97 x 71 x 49mm Form Factor The round nylon housing fits in tight and restricted mounting locations with single bolt mounting for quick, low-profile installation on panels, brackets, roll bars, and equipment frames. 10-30V Wide Voltage Input Compatible with 12V and 24V electrical systems across passenger vehicles, commercial trucks, agricultural machinery, and marine vessels without requiring voltage-specific variants or additional components. Thermal Plastic Nylon Housing Lightweight and durable nylon construction resists corrosion, impacts, and UV degradation in harsh outdoor environments while keeping the overall weight to just 0.22kg for mounting flexibility in weight-sensitive locations. DT04-2P Connector Industry-standard weatherproof connector provides a secure, vibration-resistant, moisture-proof plug-and-play connection that simplifies installation and enables easy light removal or replacement without cutting wiring. Single Bolt Mount Versatile single bolt mounting system enables quick installation in a wide range of positions and orientations, compatible with standard bracket and surface mount configurations across automotive, marine, and industrial applications. Technical Specs Specification Detail Brand OEX SKU LLX08309 Light Output 1300 Effective Lumen LEDs 4 x 3W Wattage 12W Current Draw 0.9A @ 13V Voltage Input 10-30V (12V / 24V) Beam Pattern Flood Shape Round Dimensions 97mm (H) x 71mm (W) x 49mm (L) Body Material Thermal Plastic Nylon Lens Material Polycarbonate IP Rating IP67 / IP69K Vibration Rating 20G Connector DT04-2P Mount Type Single Bolt Weight 0.22kg Harness Not Supplied Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX LLX08309 is compatible with 12V and 24V electrical systems across passenger vehicles, utes, trucks, caravans, trailers, agricultural machinery, marine vessels, and industrial mobile equipment. Well suited to underbonnet engine bay lighting, tray and cargo area illumination, equipment bay and toolbox lighting, reverse and manoeuvring lights, step and entry lighting, roll bar and light bar auxiliary lighting, and general task lighting across a wide range of vehicle and equipment types. The round body pairs naturally with other round lighting components and accessories on roll bars, roof racks, and tubular mounting systems. Also compatible with the LLX08308 square variant for mixed installations where both round and square positions are required. Pairs well with compatible DT04-2P wiring harnesses and extension leads, OEX automotive cable and cable management accessories, OEX switch panels and rocker switches for light control, and OEX circuit breakers and inline fuse holders for circuit protection. Frequently Asked Questions What is the difference between the LLX08309 round and LLX08308 square work lights and when should I choose each? The LLX08309 and LLX08308 are identical in output, electrical specifications, IP rating, mounting system, and overall dimensions — the only difference is the housing shape. Choose the LLX08309 round body when installing into round light apertures or pre-drilled holes, on roll bars, roof racks, or tubular mounting structures where a round profile fits more naturally, or when the light will be mounted alongside other round accessories for a consistent visual appearance. Choose the LLX08308 square body when installing in rectangular apertures or panels, or when a more industrial flush-panel aesthetic is preferred. Both are equally capable performers — the choice is purely one of fitment and preference. Does the LLX08309 come with a wiring harness? No — the LLX08309 is supplied with the DT04-2P connector fitted to the light but does not include a wiring harness. A compatible DT04-2P wiring harness or pigtail lead will need to be sourced separately to suit the specific installation. Contact F.A.E. for compatible harness options, or enquire about suitable OEX wiring accessories to complete the installation. What applications is the LLX08309 best suited to as a flood beam work light? The LLX08309's wide flood beam pattern makes it ideal for illuminating the immediate work area at close to medium range rather than projecting light at distance. Typical applications include underbonnet engine bay lighting for roadside repairs and servicing, ute tray and cargo area illumination for loading in the dark, equipment bay and toolbox lighting on service vehicles, reverse and manoeuvring lights on trailers and caravans, step and entry lighting on RVs and motorhomes, and general task lighting on agricultural machinery, fishing vessels, and roll bar-mounted auxiliary lighting setups. For applications requiring long-distance forward illumination, a dedicated driving light is more appropriate. Can I use the LLX08309 on a 24V commercial vehicle or agricultural machine? Yes. The 10-30V wide voltage input rating makes the LLX08309 fully compatible with 24V electrical systems as used in commercial trucks, agricultural tractors, heavy equipment, and specialist vehicles. At 24V, the current draw drops to approximately 0.5A — roughly half the 12V draw — making the LLX08309 an extremely low-draw lighting solution on 24V systems. Ensure the wiring harness and any in-line fuse or circuit protection used are also rated for 24V operation. How many LLX08309 work lights can I run from a single 10A circuit? At 12V, each LLX08309 draws 0.9A. A standard 10A circuit can safely support up to eight lights simultaneously with a small safety margin, or up to six lights applying the standard 125% derating rule for continuous loads. At 24V, current draw drops to approximately 0.5A per light, allowing up to sixteen lights on a single 10A circuit. For most practical installations involving two to four work lights, a 5A fuse or circuit breaker per pair is a clean and appropriate protection arrangement.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX LLX08302 5LED Work Light Nylon Housing Square Step up your work area lighting with the OEX LLX08302 18W square LED work light delivering 1750 effective lumens from five 4W LEDs in a flood beam pattern, IP67 and IP69K dual-rated waterproof and dustproof thermal plastic nylon housing for reliable performance in demanding outdoor environments, 10-30V wide voltage input compatibility for 12V and 24V system fitment, DT04-2P connector for secure moisture-resistant wiring, single bolt mounting for quick and versatile installation, and OEX ISO 9001 certified quality built for Australian automotive, agricultural, marine, and industrial working conditions. Product Overview The OEX LLX08302 is a mid-range compact square LED work light stepping up from the 4-LED LLX08308 with a larger five-LED array and 18W output, delivering 1750 effective lumens — a 35% increase in light output — in a slightly larger 138 x 102 x 45mm form factor that remains practical for installation in confined or restricted mounting locations. The five 4W LEDs generate broad, even flood illumination suited to a wider range of task and area lighting applications where the additional output of the LLX08302 is required over the 4-LED variant, including larger tray and cargo areas, wider equipment bay illumination, underbonnet servicing in low-light conditions, step and boarding area lighting on larger vehicles and machinery, and reverse and manoeuvring lights on trailers, caravans, and agricultural equipment requiring greater area coverage. The 10-30V wide voltage input rating provides genuine compatibility across 12V and 24V electrical systems without requiring voltage-specific variants, covering the full range of passenger vehicles, commercial trucks, agricultural equipment, and marine vessels in a single product. The dual IP67 and IP69K environmental rating certifies the LLX08302 for continuous submersion and high-pressure high-temperature wash-down, ensuring reliable operation on wash-down vehicles, agricultural machinery, marine craft, and equipment exposed to heavy rain, mud, and water spray in demanding Australian field conditions. The DT04-2P connector provides a secure, weatherproof, vibration-resistant plug-and-play connection for clean installation and easy light servicing, and the single bolt mounting system enables quick and flexible positioning across a wide range of bracket and surface mount configurations. Note that no wiring harness is supplied with the LLX08302 — a compatible harness should be sourced separately to suit the specific installation. Features & Benefits 1750 Effective Lumen Flood Output Five 4W LEDs deliver a 35% increase in flood illumination over the 4-LED LLX08308, providing greater area coverage for larger trays, wider equipment bays, and work environments where additional light output makes a meaningful difference to task visibility. IP67 and IP69K Dual-Rated Protection Certified for continuous submersion and high-pressure high-temperature wash-down, enabling reliable operation on wash-down equipment, agricultural machinery, marine vessels, and vehicles operating in wet, muddy, and harsh environmental conditions. 18W Efficient High-Output Performance Delivers 1750 lumens from an 18W draw at only 1.3A on 13V, providing strong task lighting output with a minimal electrical system load suitable for multi-light installations without overloading circuits. Compact 138 x 102 x 45mm Square Form Factor The nylon square housing fits in a wide range of mounting locations with single bolt installation, offering a practical balance between increased light output and a body size that remains manageable in space-restricted positions. 10-30V Wide Voltage Input Compatible with 12V and 24V electrical systems across passenger vehicles, commercial trucks, agricultural machinery, and marine vessels without requiring voltage-specific variants or additional components. Thermal Plastic Nylon Housing Lightweight and durable nylon construction resists corrosion, impacts, and UV degradation in harsh outdoor environments while keeping overall weight to just 0.38kg for mounting flexibility in weight-sensitive locations. DT04-2P Connector Industry-standard weatherproof connector provides a secure, vibration-resistant, moisture-proof plug-and-play connection that simplifies installation and enables easy light removal or replacement without cutting wiring. Single Bolt Mount Versatile single bolt mounting system enables quick installation in a wide range of positions and orientations, compatible with standard bracket and surface mount configurations across automotive, marine, and industrial applications. Technical Specs Specification Detail Brand OEX SKU LLX08302 Light Output 1750 Effective Lumen LEDs 5 x 4W Wattage 18W Current Draw 1.3A @ 13V Voltage Input 10-30V (12V / 24V) Beam Pattern Flood Shape Square Dimensions 138mm (H) x 102mm (W) x 45mm (L) Body Material Thermal Plastic Nylon Lens Material Polycarbonate IP Rating IP67 / IP69K Vibration Rating 20G Connector DT04-2P Mount Type Single Bolt Weight 0.38kg Harness Not Supplied Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX LLX08302 is compatible with 12V and 24V electrical systems across passenger vehicles, utes, trucks, caravans, trailers, agricultural machinery, marine vessels, and industrial mobile equipment. Well suited to ute tray and cargo area illumination, equipment bay and toolbox lighting on service vehicles, underbonnet engine bay lighting, reverse and manoeuvring lights on trailers and caravans, step and boarding area lighting on larger vehicles and machinery, and general task lighting across a wide range of vehicle and equipment types. Pairs naturally with the OEX LLX08308 4-LED square and LLX08309 4-LED round work lights for mixed installations requiring different output levels across the same vehicle or equipment build. Pairs well with compatible DT04-2P wiring harnesses and extension leads, OEX automotive cable and cable management accessories, OEX switch panels and rocker switches for light control, and OEX circuit breakers and inline fuse holders for circuit protection. Frequently Asked Questions When should I choose the LLX08302 5-LED over the LLX08308 4-LED square work light? Choose the LLX08302 when the additional 450 lumens of output (1750 vs 1300) makes a practical difference to your application — typically when illuminating larger areas such as full-length ute trays, wide equipment bays, or boarding areas on larger vehicles and machinery where the 4-LED variant leaves edges of the work area underlit. The LLX08302 is also the better choice for applications where the light will be mounted higher or further from the work surface, as the additional output compensates for the greater throw distance. For compact, close-range task lighting in tight locations, the smaller and lighter LLX08308 remains a practical and cost-effective choice. Does the LLX08302 come with a wiring harness? No — the LLX08302 is supplied with the DT04-2P connector fitted to the light but does not include a wiring harness. A compatible DT04-2P wiring harness or pigtail lead will need to be sourced separately to suit the specific installation. Contact F.A.E. for compatible harness options, or enquire about suitable OEX wiring accessories to complete the installation. What does the IP67 and IP69K dual rating mean for a work light installation? IP67 certifies protection against continuous submersion up to 1 metre depth, while IP69K certifies protection against high-pressure, high-temperature water jets as used in agricultural and industrial wash-down applications. For a work light installed on a wash-down vehicle, agricultural equipment, or a marine vessel subject to heavy weather, carrying both ratings provides comprehensive protection against both submersion events and aggressive cleaning. Many budget work lights carry IP67 alone — the addition of IP69K on the LLX08302 makes it genuinely suitable for wash-down equipment and heavy-duty agricultural applications where high-pressure cleaning is routine. Can I use the LLX08302 on a 24V commercial vehicle or agricultural machine? Yes. The 10-30V wide voltage input rating makes the LLX08302 fully compatible with 24V electrical systems as used in commercial trucks, agricultural tractors, heavy equipment, and specialist vehicles. At 24V, the current draw drops to approximately 0.65A per light — roughly half the 12V draw — making the LLX08302 a very low-draw lighting solution even on a 24V system. Ensure the wiring harness and any in-line fuse or circuit protection used are also rated for 24V operation. How many LLX08302 work lights can I run from a single 10A circuit? At 12V, each LLX08302 draws 1.3A. A standard 10A circuit can safely support up to six lights simultaneously with a small safety margin, or up to five lights applying the standard 125% derating rule for continuous loads. At 24V, current draw drops to approximately 0.65A per light, allowing up to twelve lights on a single 10A circuit. For most practical installations involving two to four work lights, a 10A fuse or circuit breaker for a bank of four lights is a clean and appropriate protection arrangement.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX LLX08301 5LED Work Light Nylon Housing Round Step up your work area lighting with the OEX LLX08301 18W round LED work light delivering 1750 effective lumens from five 4W LEDs in a flood beam pattern, IP67 and IP69K dual-rated waterproof and dustproof thermal plastic nylon housing for reliable performance in demanding outdoor environments, 10-30V wide voltage input compatibility for 12V and 24V system fitment, DT04-2P connector for secure moisture-resistant wiring, single bolt mounting for quick and versatile installation, and OEX ISO 9001 certified quality built for Australian automotive, agricultural, marine, and industrial working conditions. Product Overview The OEX LLX08301 is the round-body variant of the mid-range LLX08302 square work light, sharing the same 18W five-LED output, IP67/IP69K dual rating, and 10-30V wide voltage compatibility in a round housing profile suited to applications and mounting positions where a circular light form factor is preferred or required. At 1750 effective lumens from five 4W LEDs, the LLX08301 delivers a 35% increase in flood output over the 4-LED round LLX08309, providing greater area coverage for larger trays, wider equipment bays, and work environments where additional light output makes a meaningful difference to task visibility. The round body of the LLX08301 is well suited to installation in round light apertures and pre-drilled holes, circular flush-mount or surface-mount brackets, and mounting positions on roll bars, light bars, and tubular structures where a round profile provides a cleaner, more symmetrical aesthetic alongside other round lighting and accessory components. The compact 138 x 102 x 45mm body and single bolt mounting system make the LLX08301 straightforward to install across a wide range of positions and orientations, while the lightweight 0.34kg construction minimises mounting hardware requirements. The 10-30V wide voltage input covers 12V and 24V systems without requiring voltage-specific variants, and the dual IP67 and IP69K environmental rating certifies the LLX08301 for continuous submersion and high-pressure high-temperature wash-down across the most demanding Australian field conditions. The DT04-2P connector provides a secure, weatherproof, vibration-resistant plug-and-play connection for clean installation and easy light servicing. Note that no wiring harness is supplied with the LLX08301 — a compatible harness should be sourced separately to suit the specific installation. Features & Benefits 1750 Effective Lumen Flood Output Five 4W LEDs deliver a 35% increase in flood illumination over the 4-LED LLX08309 round variant, providing greater area coverage for larger trays, wider equipment bays, and work environments where additional light output makes a meaningful difference to task visibility. Round Housing Profile The circular body suits round light apertures, pre-drilled holes, circular flush and surface mount brackets, and tubular roll bar and light bar mounting positions where a round profile provides a cleaner fit and more symmetrical appearance alongside other round lighting and accessory components. IP67 and IP69K Dual-Rated Protection Certified for continuous submersion and high-pressure high-temperature wash-down, enabling reliable operation on wash-down equipment, agricultural machinery, marine vessels, and vehicles operating in wet, muddy, and harsh environmental conditions. 18W Efficient High-Output Performance Delivers 1750 lumens from an 18W draw at only 1.3A on 13V, providing strong task lighting output with a minimal electrical system load suitable for multi-light installations without overloading circuits. Compact 138 x 102 x 45mm Form Factor The round nylon housing fits in a wide range of mounting locations with single bolt installation, offering a practical balance between increased light output and a body size that remains manageable in space-restricted positions. 10-30V Wide Voltage Input Compatible with 12V and 24V electrical systems across passenger vehicles, commercial trucks, agricultural machinery, and marine vessels without requiring voltage-specific variants or additional components. Thermal Plastic Nylon Housing Lightweight and durable nylon construction resists corrosion, impacts, and UV degradation in harsh outdoor environments while keeping overall weight to just 0.34kg for mounting flexibility in weight-sensitive locations. DT04-2P Connector Industry-standard weatherproof connector provides a secure, vibration-resistant, moisture-proof plug-and-play connection that simplifies installation and enables easy light removal or replacement without cutting wiring. Technical Specs Specification Detail Brand OEX SKU LLX08301 Light Output 1750 Effective Lumen LEDs 5 x 4W Wattage 18W Current Draw 1.3A @ 13V Voltage Input 10-30V (12V / 24V) Beam Pattern Flood Shape Round Dimensions 138mm (H) x 102mm (W) x 45mm (L) Body Material Thermal Plastic Nylon Lens Material Polycarbonate IP Rating IP67 / IP69K Vibration Rating 20G Connector DT04-2P Mount Type Single Bolt Weight 0.34kg Harness Not Supplied Warranty 1 Year Certification ISO 9001 Country of Testing Australia (Brisbane) Compatible With / Goes Well With The OEX LLX08301 is compatible with 12V and 24V electrical systems across passenger vehicles, utes, trucks, caravans, trailers, agricultural machinery, marine vessels, and industrial mobile equipment. Well suited to ute tray and cargo area illumination, equipment bay and toolbox lighting on service vehicles, underbonnet engine bay lighting, reverse and manoeuvring lights on trailers and caravans, step and boarding area lighting on larger vehicles and machinery, and roll bar and tubular structure auxiliary lighting setups. The round body pairs naturally with other round lighting components and accessories. Also compatible with the LLX08302 5-LED square, LLX08309 4-LED round, and LLX08308 4-LED square work lights for mixed installations requiring different output levels or housing shapes across the same vehicle or equipment build. Pairs well with compatible DT04-2P wiring harnesses and extension leads, OEX automotive cable and cable management accessories, OEX switch panels and rocker switches for light control, and OEX circuit breakers and inline fuse holders for circuit protection. Frequently Asked Questions What is the difference between the LLX08301 round and LLX08302 square 5-LED work lights and when should I choose each? The LLX08301 and LLX08302 are identical in output, electrical specifications, IP rating, and mounting system — the only difference is the housing shape and a slight weight difference of 0.34kg versus 0.38kg. Choose the LLX08301 round body when installing into round light apertures or pre-drilled holes, on roll bars, roof racks, or tubular mounting structures where a round profile fits more naturally, or when the light will be mounted alongside other round accessories for a consistent visual appearance. Choose the LLX08302 square body for rectangular apertures, panel mounts, or when a more industrial flush-panel aesthetic is preferred. Both are equally capable performers — the choice is purely one of fitment and preference. When should I choose the LLX08301 5-LED over the LLX08309 4-LED round work light? Choose the LLX08301 when the additional 450 lumens of output (1750 vs 1300) makes a practical difference to the application — typically when illuminating larger areas such as full-length ute trays, wide equipment bays, or boarding areas on larger vehicles and machinery where the 4-LED variant leaves edges of the work area underlit. The LLX08301 is also the better choice when the light will be mounted higher or further from the work surface, as the additional output compensates for the greater throw distance. For compact, close-range task lighting in tight locations, the smaller and lighter LLX08309 remains a practical and cost-effective choice. Does the LLX08301 come with a wiring harness? No — the LLX08301 is supplied with the DT04-2P connector fitted to the light but does not include a wiring harness. A compatible DT04-2P wiring harness or pigtail lead will need to be sourced separately to suit the specific installation. Contact F.A.E. for compatible harness options, or enquire about suitable OEX wiring accessories to complete the installation. Can I use the LLX08301 on a 24V commercial vehicle or agricultural machine? Yes. The 10-30V wide voltage input rating makes the LLX08301 fully compatible with 24V electrical systems as used in commercial trucks, agricultural tractors, heavy equipment, and specialist vehicles. At 24V, the current draw drops to approximately 0.65A per light — roughly half the 12V draw — making the LLX08301 a very low-draw lighting solution even on a 24V system. Ensure the wiring harness and any in-line fuse or circuit protection used are also rated for 24V operation. How many LLX08301 work lights can I run from a single 10A circuit? At 12V, each LLX08301 draws 1.3A. A standard 10A circuit can safely support up to six lights simultaneously with a small safety margin, or up to five lights applying the standard 125% derating rule for continuous loads. At 24V, current draw drops to approximately 0.65A per light, allowing up to twelve lights on a single 10A circuit. For most practical installations involving two to four work lights, a 10A fuse or circuit breaker for a bank of four lights is a clean and appropriate protection arrangement.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
