Description
OEX ACX2322A 10-80 Volt LED Beacon Amber Materials Handling Strobe/Revolving
Maximise worksite safety with the OEX ACX2322A 10-80V amber LED warning beacon featuring revolving, single flash, and triple flash pattern options for versatile warning signalling, a high-voltage 10-80V input range for compatibility across a uniquely broad spectrum of vehicles and equipment, IP67 waterproof protection for reliable outdoor and industrial performance in all weather conditions, ECE R10 electromagnetic compatibility approval, a rugged polycarbonate base and amber polycarbonate lens for durable all-environment operation, fixed screw mount for secure permanent installation, an operating temperature range of -30°C to +60°C for extreme-condition reliability, and a 12-month OEX warranty.
Product Overview
The OEX ACX2322A is a professional-grade fixed-mount amber LED warning beacon purpose-built for materials handling, industrial, mining, and heavy equipment applications where a reliable, high-visibility warning presence is required across a wide range of vehicle and equipment voltage systems. The defining specification of the ACX2322A is its exceptional 10-80V operating voltage range — a capability that goes far beyond the 12V and 24V coverage of standard automotive warning lights, extending compatibility to 36V and 48V electric forklifts and materials handling equipment, 48V industrial vehicles, 72V heavy machinery, and specialised high-voltage mobile plant where standard 12/24V beacons simply cannot be used. This makes the ACX2322A the beacon of choice for warehousing, distribution centres, manufacturing facilities, ports, and mining operations where the vehicle fleet includes electric forklifts, reach stackers, order pickers, and other materials handling equipment operating on elevated DC voltage systems. Three selectable flash patterns — revolving, single flash, and triple flash — allow the operator to configure the warning output for the specific application and site safety requirements, with the revolving pattern providing a traditional high-visibility sweep effect and the single and triple flash patterns offering more contemporary strobe-style signalling for varied regulatory environments. The compact 130 x 130 x 95mm polycarbonate body and fixed screw mount provide a secure, vibration-resistant installation on cab roofs, overhead guards, masts, and equipment frames across industrial and mobile plant applications. IP67 waterproof protection ensures reliable operation in wash-down environments, outdoor conditions, and the dust and spray exposure common in port, mining, and manufacturing settings. The -30°C to +60°C operating temperature range covers the full spectrum of Australian working conditions from cold-climate alpine and refrigerated warehouse environments through to the extreme heat of open-cut mining and construction sites in tropical and arid regions.
Features & Benefits
10-80V High Voltage Input Range Covers an exceptionally broad voltage spectrum — compatible with 12V and 24V standard vehicles, 36V and 48V electric forklifts and materials handling equipment, 48V industrial vehicles, and up to 80V heavy machinery — a capability no standard automotive 12/24V beacon can match.
Revolving, Single and Triple Flash Patterns Three distinct warning signal options allow configuration for the specific application and site safety requirements, from the traditional revolving sweep effect to contemporary strobe-style single and triple flash patterns suited to varied regulatory and operational environments.
IP67 Waterproof Protection Certified for continuous submersion up to 1 metre depth, ensuring reliable operation in wash-down environments, heavy rain, outdoor exposure, and the dust and spray conditions common in port, mining, warehouse, and manufacturing applications.
ECE R10 Approved Electromagnetic compatibility certification confirms the ACX2322A meets UN ECE Regulation 10 requirements, ensuring the beacon does not generate interference that could affect vehicle electronics, industrial control systems, or communications equipment on the host vehicle or equipment.
Polycarbonate Base and Amber Lens Impact-resistant polycarbonate construction for both the base and amber lens provides excellent durability against knocks, vibration, and UV exposure in demanding industrial and outdoor environments.
Fixed Screw Mount Secure permanent screw mount installation on cab roofs, overhead guards, masts, and equipment frames, providing a vibration-resistant, tamper-resistant connection suitable for high-vibration industrial and off-road equipment.
-30°C to +60°C Operating Temperature Range Reliable performance across extreme cold and heat — from refrigerated warehouse and cold-climate environments through to open-cut mining and construction sites in tropical and arid Australian regions.
Compact 130 x 130 x 95mm Form Factor The low-profile compact dimensions fit neatly on overhead guards, cab roofs, and equipment frames without obstructing operator visibility or adding excessive height to clearance-sensitive materials handling equipment.
Technical Specs
| Specification |
Detail |
| Brand |
OEX |
| SKU |
ACX2322A |
| Beacon Colour |
Amber |
| Lens Colour |
Amber |
| Lens Material |
Polycarbonate |
| Base Material |
Polycarbonate |
| LEDs |
5 |
| Voltage Input |
10-80V DC |
| Flash Patterns |
Revolving, Single Flash, Triple Flash |
| Mount Type |
Fixed Screw Mount |
| IP Rating |
IP67 |
| Compliance |
ECE R10 |
| Dimensions (LxWxH) |
130mm x 130mm x 95mm |
| Operating Temperature |
-30°C to +60°C |
| Weight |
0.512kg |
| Warranty |
1 Year |
Compatible With / Goes Well With
The OEX ACX2322A is compatible with DC electrical systems from 10V to 80V, covering 12V and 24V standard vehicles, 36V and 48V electric forklifts and materials handling equipment, 48V industrial vehicles, and up to 80V heavy machinery and mobile plant. Well suited to electric forklifts, reach stackers, order pickers, pallet jacks, tuggers, airport ground support equipment, mining haul trucks and auxiliary equipment, port and logistics machinery, and any industrial or mobile plant equipment operating outside standard 12/24V automotive voltage ranges. Pairs well with OEX and compatible beacon wiring accessories, OEX switch panels and rocker switches for operator control, OEX circuit breakers and inline fuse holders for circuit protection, and OEX cable management accessories for clean permanent wiring installations.
Frequently Asked Questions
Why does the ACX2322A support 10-80V and which vehicles and equipment does this cover?
The 10-80V input range is specifically designed for materials handling and industrial equipment that operates on elevated DC voltage systems well above the 12V and 24V of standard automotive vehicles. Common applications include 36V and 48V electric forklifts — the most widely used voltage systems in Australian warehousing and logistics — 48V electric order pickers and reach stackers, 72V and 80V heavy industrial tuggers and tow tractors, airport ground support equipment, and various mining auxiliary vehicles. A standard 12/24V automotive beacon cannot be safely connected to these higher-voltage systems, making the ACX2322A a necessary specialist product for industrial fleet safety compliance rather than a like-for-like upgrade from a standard vehicle beacon.
What is the difference between the revolving, single flash, and triple flash patterns on the ACX2322A?
The revolving pattern simulates the traditional rotating beacon effect — the LEDs sequence in a way that creates the appearance of a sweeping rotating light, which is widely recognised as a warning signal in industrial and traffic environments. Single flash produces one sharp burst of light per cycle, while triple flash produces three rapid bursts per cycle before pausing — both are contemporary strobe-style patterns that can be more attention-grabbing in high-ambient-light industrial environments. Pattern selection is typically made via a switch or selector on the unit — refer to the included instructions for the specific procedure on the ACX2322A.
What does ECE R10 approval mean for the ACX2322A?
ECE R10 refers to UN ECE Regulation 10, the electromagnetic compatibility standard for vehicles and their components. R10 approval confirms the ACX2322A does not emit electromagnetic interference exceeding regulated limits that could affect vehicle electronics, industrial control systems, radio communications, or other sensitive equipment on or near the host vehicle. In industrial environments where proximity to automated systems, wireless networks, and precision instrumentation is common, ECE R10 approval is an important assurance that the beacon will not disrupt critical operational or safety systems.
Is the ACX2322A suitable for outdoor and wash-down environments?
Yes. The IP67 waterproof rating certifies the ACX2322A for continuous submersion up to 1 metre depth, making it equally suited to outdoor exposure, heavy rain, road splash, and the regular wash-down cleaning cycles common in food distribution, logistics, port, and agricultural equipment environments. The polycarbonate base and lens also provide strong resistance to the chemical cleaning agents commonly used in industrial wash-down applications, and the -30°C to +60°C operating range covers refrigerated warehouse environments through to outdoor Australian summer conditions.
Are there safety regulations in Australia requiring warning beacons on forklifts and materials handling equipment?
Yes. Safe Work Australia guidance and various state workplace health and safety regulations reference the use of warning devices on powered industrial trucks and materials handling equipment operating in shared pedestrian and vehicle environments. Requirements vary by jurisdiction and workplace, and specific beacon performance standards may be referenced in site safety plans, industry codes of practice, or equipment manufacturer specifications. The ACX2322A's ECE R10 compliance and IP67 rating make it a technically suitable choice for workplace safety applications — always consult the relevant WHS regulations and your workplace safety plan to confirm compliance requirements for your specific site and equipment type.
