Description
OEX DXA561 12V 105A Denso Style Alternator Pad Mount 161mm CTC 7-Groove 60mm Pulley IR43 CW Rotation New Unit
The OEX DXA561 is a new 12V 105A alternator in the Denso style with a pad mount configuration and clockwise rotation. Replacement regulator for this unit is RGX2071. Adaptor available to suit HXK-34, HXK-31 or HXK-29. Confirm all mounting dimensions and pin code against your vehicle's existing alternator before ordering. 3-year passenger vehicle warranty, 1-year commercial warranty.
Product overview
The DXA561 is a 105A Denso-style pad mount alternator with clockwise rotation. The pad mount configuration bolts directly to a flat mounting surface via a solid pad base rather than through separate mounting legs, and is used on certain commercial and industrial vehicle applications. Confirm your vehicle uses a pad mount bracket before ordering.
The replacement regulator for this unit is the OEX RGX2071. Adaptors HXK-34, HXK-31 and HXK-29 are listed as compatible for this unit. The IR43 pin code is specific to this unit within the OEX Denso range.
Features and benefits
New unit: Brand new, not remanufactured.
105A output: Suited to vehicles with moderate to elevated electrical demands.
Pad mount, 161mm CTC, 41mm leg thickness: Pad mount configuration. Confirm all mounting dimensions against the vehicle before ordering.
7-groove 60mm OD pulley: 7-groove multi-rib pulley for serpentine belt drive systems.
Clockwise rotation: Confirm rotation direction suits your vehicle before ordering.
8mm pivot hole: Confirm hole size suits the vehicle's mounting points.
IR43 pin code: Confirm pin code and all dimensions against your vehicle.
Replacement regulator RGX2071: Available separately for future regulator replacement.
Compatible adaptors HXK-34, HXK-31, HXK-29: Listed adaptors available to suit this unit.
Internal regulator: Voltage regulation handled internally.
3-year passenger / 1-year commercial warranty: Extended warranty for passenger vehicle applications.
Technical specs
| Specification |
Detail |
| SKU |
DXA561 |
| Brand |
OEX |
| Voltage |
12V |
| Output |
105A |
| Style |
Denso |
| Regulator |
Internal |
| Mount |
Pad |
| Pulley Section |
7-groove |
| Pulley OD |
60mm |
| Rotation |
Clockwise |
| Mount CTC |
161mm |
| Leg Thickness |
41mm |
| Pivot Hole |
8mm |
| Pin Code |
IR43 |
| Replacement Regulator |
RGX2071 |
| Compatible Adaptors |
HXK-34, HXK-31, HXK-29 |
| Condition |
New |
| Weight |
5.64kg |
| Warranty |
3 years (passenger), 1 year (commercial) |
Frequently asked questions
Is this a new or remanufactured unit? New. The DXA561 is a brand new unit, not remanufactured or rebuilt.
What is the replacement regulator for this alternator? The replacement regulator for the DXA561 is the OEX RGX2071, available separately.
What adaptors are compatible with this alternator? The DXA561 is compatible with adaptors HXK-34, HXK-31 and HXK-29. Contact us to confirm which adaptor suits your specific application.
What is the warranty on this alternator? 3 years for passenger vehicle applications, 1 year for commercial use.
What should I confirm before ordering this alternator? Confirm mount type (pad), CTC (161mm), leg thickness (41mm), pivot hole (8mm), pulley section (7-groove), pulley OD (60mm), rotation (clockwise) and pin code (IR43) all match your vehicle's requirements. Alternators are vehicle-specific, verify fitment before purchasing.
