Description
OEX LLX33043 LED Bull Bar Combination Lamp 12V/24V
The OEX LLX33043 is a 12V/24V LED bull bar combination lamp with front indicator, park light, and daytime running light (DRL), featuring a polycarbonate lens and ear or flush mounting.
Product Overview
The LLX33043 is an OEX front bull bar LED combination lamp operating from 10 to 30V, combining a front indicator, park light, and daytime running light (DRL) in a single amber/clear fitting. Built with a polycarbonate lens and measuring 226 x 57 x 32mm, the LLX33043 is pre-wired for straightforward installation.
Wiring is colour coded: white for earth, yellow for indicator, brown for park light, and red for daytime running light (DRL). The lamp can be mounted with the ear bracket in place, or converted to a flush mount by removing the ear mount.
Features & Benefits
All-In-One Front Lamp: Combines a front indicator, park light, and daytime running light in a single fitting, simplifying bull bar wiring.
Wide 10-30V Voltage Range: Operating from 10 to 30V, the lamp suits both 12V and 24V vehicle electrical systems.
Clear Wiring Colour Code: Colour coded wiring (white-earth, yellow-indicator, brown-park light, red-DRL) simplifies correct installation.
Ear or Flush Mount: The lamp can be mounted with the ear bracket, or converted to a flush mount by removing the ear mount, suiting different bull bar designs.
Polycarbonate Lens: The polycarbonate lens provides impact resistance suited to the front of a vehicle.
Pre-Wired Connector: The pre-wired connector simplifies installation without additional wiring work.
ADR Compliant: Compliant with ADR 6/00 for the indicator, ADR 49/00 for the park light, and ADR 76/00 for the DRL.
Technical Specs
| Specification | Detail |
| Part No. | LLX33043 |
| Brand | OEX |
| Description | Front Bull Bar LED Combination Lamp, Front Indicator, Park Light, DRL |
| Voltage | 10 to 30V |
| Colour | Amber/Clear |
| Light Type | LED |
| Size | 226 x 57 x 32mm |
| Mount Centre to Centre | 210mm |
| Lens Material | Polycarbonate |
| Current Draw | Indicator: 0.2A, Front: 0.01A @ 12V |
| Mounting | Ear or Flush |
| Connector | Pre-Wired |
| Compliance | Indicator: ADR 6/00, Park: ADR 49/00, DRL: ADR 76/00 |
| Weight | 0.32kg |
Compatible With
The LLX33043 suits 10 to 30V vehicle electrical systems, compatible with both 12V and 24V setups, and is designed for front bull bar mounting with either an ear or flush mount configuration.
Frequently Asked Questions
What functions does the LLX33043 combine?
The LLX33043 combines a front indicator, park light, and daytime running light (DRL) in a single fitting.
What does the wiring colour code mean?
White is earth, yellow is the indicator, brown is the park light, and red is the daytime running light (DRL).
How do I convert the lamp to a flush mount?
Simply remove the ear mount bracket to convert the lamp from ear mount to flush mount.
Does the LLX33043 suit both 12V and 24V vehicles?
Yes. The LLX33043 operates from 10 to 30V, suiting both 12V and 24V electrical systems.
Is the LLX33043 ADR compliant?
Yes. It's compliant with ADR 6/00 for the indicator, ADR 49/00 for the park light, and ADR 76/00 for the DRL.
