AXIS CHD074W - Wireless HD Camera to Suit HD074WK System
High-resolution wireless reversing camera designed specifically for AXIS HD074WK system featuring Full HD 1080p resolution providing crystal-clear image quality, IP69K waterproof rating withstanding high-pressure hot water washing up to 100°C and 100 bar, wide 10-36V DC operating range compatible with 12V light commercial, 24V heavy trucks, and 36V industrial machinery, 170° diagonal viewing angle capturing wide rear coverage, 12 infrared LED night vision for complete darkness operation, 2.4GHz wireless transmission eliminating complex cable installation, ideal for trucks, buses, mining equipment, construction vehicles, and commercial machinery requiring robust wireless reversing camera.
Product Overview
The AXIS CHD074W is a professional-grade wireless HD camera engineered specifically as a replacement or additional camera for the AXIS HD074WK wireless reversing camera system. The Full HD 1080p resolution delivers significantly sharper image quality compared to standard analogue reversing cameras, enabling drivers to identify smaller obstacles and make more precise judgments about clearances. The exceptional IP69K rating represents the highest level of ingress protection - complete dust-tight sealing plus resistance to high-pressure (100 bar) high-temperature (100°C) water jets, making this camera ideal for mining equipment requiring regular pressure washing and construction vehicles operating in dusty environments. The wide 10-36V operating voltage accommodates light commercial 12V systems, heavy commercial 24V trucks, and industrial machinery up to 36V without requiring voltage converters. The 170° diagonal viewing angle provides exceptionally wide rear coverage reducing blind spots, while the integrated 12 infrared LED array enables clear night vision in complete darkness. The 2.4GHz wireless transmission eliminates running video cables through truck chassis and frame rails. The 1/2.7-inch Starlight HD image sensor with 0.5 lux minimum illumination ensures excellent low-light performance.
Important Notes:
HD074WK System Required: This camera is designed specifically for AXIS HD074WK wireless system. It will NOT work as standalone camera or with other wireless systems.
Wireless Range Limitations: Typical wireless range 15-30 metres depending on vehicle construction and obstructions. Verify adequate range before permanent installation.
High-Pressure Washing Capability: IP69K rating withstands industrial pressure washing. However, avoid direct prolonged spray on camera lens which may temporarily affect image quality.
Voltage Compatibility: While rated 10-36V, verify your specific vehicle voltage falls within this range. Some heavy mining equipment exceeds 36V.
Professional Installation Recommended: Proper mounting angle, wireless pairing, and power connection ensures optimal performance and system reliability.
Key Features
Full HD 1080p Resolution - 1920x1080 pixel resolution provides crystal-clear image quality for precise reversing and obstacle identification.
IP69K Waterproof Rating - Highest ingress protection withstanding high-pressure (100 bar) hot water (100°C) washing for mining and commercial cleaning.
Wide Voltage Range - 10-36V DC compatibility works across 12V, 24V, and 36V systems without voltage-specific models.
170° Diagonal View - Exceptionally wide viewing angle (127° horizontal) captures broad rear coverage reducing blind spots.
12 IR LED Night Vision - Infrared illumination enables clear imaging in complete darkness for 24-hour operation capability.
Starlight HD Sensor - 1/2.7-inch image sensor with 0.5 lux minimum illumination provides excellent low-light performance.
Wireless Transmission - 2.4GHz wireless (2400-2483.5MHz) eliminates complex cable routing through vehicle chassis.
18dBm Transmitter Power - Strong wireless signal maintains reliable transmission through metal vehicle structures.
1000 TV Lines Resolution - High-resolution imaging exceeds standard reversing camera quality for detailed rear view.
250,000 Pixel Element - High pixel count delivers sharp, clear images for professional reversing operations.
PAL Signal Type - Compatible with Australian/Asian video standards for proper display on monitors.
Heavy-Duty Construction - Robust housing withstands impacts, vibration, and harsh industrial environments.
Wide Temperature Range - Operates -20°C to +70°C suitable for extreme climate conditions and industrial heat.
Compact Design - 100W x 50H x 70D mm (excluding mount) fits tight mounting locations on machinery and vehicles.
U-Bracket Mounting - Included adjustable bracket allows precise camera angle adjustment for optimal rear coverage.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CHD074W
SKU
CHD074W
Barcode
9321886016642
MPN
CHD074W
Product Type
Wireless Reversing Camera
Compatibility
AXIS HD074WK Wireless Camera System
Image Sensor
1/2.7" Starlight HD
Resolution
Full HD 1080p (1920 x 1080 pixels)
TV Lines
1000 TV lines
Picture Element
250,000 pixels
Diagonal Viewing Angle
170°
Horizontal Viewing Angle
127°
Signal Type
PAL
Effective Pixels
1920(H) x 1080(V)
IP Rating
IP69K (Waterproof & Dustproof)
Night Vision
12 IR LED Array
Minimum Illumination
0.5 lux
Operating Voltage
10-36V DC
Wireless Frequency
2400-2483.5MHz (2.4GHz)
Transmitter Power
18dBm
Operating Temperature
-20°C to +70°C (RH 95% Max)
Storage Temperature
-30°C to +80°C (RH 95% Max)
Camera Dimensions (Excluding Mount)
100W x 50H x 70D mm
Package Includes
Camera, U-Bracket, Antenna
Mounting
Adjustable U-Bracket Included
High-Pressure Washing
Withstands 100 bar at 100°C
Applications
Trucks, Buses, Machinery, Mining Equipment, Construction Vehicles
Warranty
2 Years
Shipping Weight
0.65kg
Shipping Dimensions
200 x 110 x 60 mm
Country of Origin
Not specified
Frequently Asked Questions
Q: Will this camera work with any wireless reversing camera system?
A: No, the CHD074W is designed specifically for the AXIS HD074WK wireless camera system and will NOT work with other brands. If you don't already own an HD074WK system, you need to purchase the complete kit. This camera is ideal as a replacement for damaged HD074WK cameras or as an additional camera for multi-camera installations.
Q: What does IP69K rating mean, and do I really need it?
A: IP69K is the highest ingress protection rating - complete dust-tight sealing plus resistance to high-pressure (100 bar) hot water (100°C) jets. You need IP69K if you regularly pressure-wash equipment, operate in extremely dusty environments like mines or quarries, or require absolute sealing. For standard vehicles with occasional washing, IP67 cameras suffice.
Q: What's the actual wireless range, and will it work on my long vehicle?
A: Typical wireless range is 15-30 metres in real-world installations, depending on vehicle construction. Most rigid trucks (8-12m), buses (10-15m), and semi-trailers (15-20m) work reliably. Very long B-doubles or road trains may experience signal issues. Test wireless range before permanent installation to verify stable signal.
Q: Can I use this camera for side-view or front-view applications?
A: Physically yes, but it's optimized for reversing with rear-mounting design. The 170° viewing angle provides excessive coverage for side-view applications. The HD074WK system supports multiple camera inputs, so you can add additional CHD074W cameras in various positions for multi-angle coverage.
Q: How do I clean the camera lens without damaging it?
A: Use soft microfiber cloth with water or mild detergent to wipe lens surface. For heavy mud, rinse from oblique angle rather than direct frontal spray. Despite IP69K body rating, avoid direct prolonged spray on lens which may force water into seals or temporarily fog image quality.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS CLR5G - 4G 5G Stealth Phone Antenna
Compact stealth antenna designed for mobile telephone and data applications featuring 3dBi gain providing enhanced signal reception for 4G and 5G networks, wide frequency range covering 700-2700-3400-3800MHz supporting multiple Australian mobile network bands including Telstra, Optus, and Vodafone 4G/5G services, discreet black 11.5cm length design minimizing visual impact on vehicle aesthetics while maintaining performance, included 3-metre coaxial cable with SMA male connector allowing flexible mounting locations, FME termination providing compatibility with mobile phone signal boosters and cellular modems, 10W power rating suitable for mobile data applications, ideal for vehicles requiring improved mobile phone reception in regional areas, 4WD touring with marginal coverage, caravans and motorhomes needing reliable internet connectivity, commercial vehicles with fleet tracking systems, and any application requiring discreet external antenna for enhanced 4G/5G signal strength.
Product Overview
The AXIS CLR5G is a low-profile stealth antenna engineered for 4G and 5G mobile phone and data applications where improved signal reception is required without compromising vehicle appearance. The 11.5cm compact black design blends into vehicle rooflines, providing discreet installation compared to traditional longer whip antennas that draw attention or create clearance issues in car parks. The 3dBi gain offers moderate signal boost - sufficient to improve reception in fringe coverage areas, regional locations between towers, or vehicles with tinted windows and metallic coatings that block internal phone signals. The wide frequency coverage spans 700-2700-3400-3800MHz, encompassing the primary Australian 4G LTE bands (700MHz Band 28, 850MHz Band 5, 900MHz Band 8, 1800MHz Band 3, 2100MHz Band 1, 2600MHz Band 7) plus emerging 5G bands (3400-3800MHz). The included 3-metre coaxial cable with SMA male connector allows mounting flexibility - install the antenna on the vehicle roof for optimal 360-degree coverage while routing the cable to dash-mounted signal boosters, cellular modems, or mobile WiFi routers inside the cabin. The FME termination provides standard connection to most commercial mobile phone signal boosters and 4G/5G routers used in vehicles for improved connectivity.
Important Notes:
Signal Booster Usually Required: This antenna improves signal reception but typically connects to signal boosters or cellular modems rather than directly to mobile phones.
3dBi Moderate Gain: Provides improved reception in marginal coverage areas but won't overcome complete dead zones without tower coverage.
Frequency Band Verification: Check your mobile carrier's frequency bands. Antenna covers most Australian bands but international frequency allocations may differ.
Professional Installation Recommended: Proper roof mounting and cable routing ensures optimal performance and prevents water ingress through mounting holes.
Ground Plane Required: Mount on metal vehicle roof for best performance. Fibreglass roofs may require ground plane kit.
Key Features
4G/5G Frequency Coverage - 700-2700-3400-3800MHz range covers Australian mobile network 4G LTE and 5G bands.
3dBi Gain - Moderate signal boost improves reception in fringe coverage areas and regional locations.
Stealth Design - Compact 11.5cm black antenna blends into vehicle aesthetics minimizing visual impact.
Black Finish - Matches most vehicle colours for discreet installation on roofs and body panels.
3 Metre Cable Included - Coaxial cable allows flexible mounting with cable routing to cabin-mounted equipment.
SMA Male Connector - Standard connector compatible with most signal boosters and cellular modems.
FME Termination - Connects to mobile phone signal boosters and 4G/5G routers commonly used in vehicles.
10W Power Rating - Adequate power handling for mobile data applications and signal booster systems.
Compact Length - 11.5cm size reduces clearance issues in car parks and minimizes wind resistance.
Multi-Band Support - Wide frequency range supports Telstra, Optus, and Vodafone 4G/5G networks.
Low Profile - Stealth design avoids attention and reduces risk of antenna theft or damage.
Vehicle Integration - Suitable for cars, 4WDs, caravans, motorhomes, and commercial vehicles.
Weather Resistant - Designed for external mounting withstanding rain, UV, and temperature extremes.
Easy Installation - Standard mounting base simplifies roof or panel installation.
Regional Coverage - Improves mobile phone and data reception in areas with marginal tower coverage.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CLR5G
SKU
CLR5G
Barcode
Not specified
Product Type
Mobile Phone Antenna
Frequency Range
700-2700-3400-3800MHz
Network Compatibility
4G LTE / 5G
Gain
3dBi
Antenna Length
11.5cm
Colour
Black
Cable Length
3 Metres
Cable Type
Coaxial
Connector Type
SMA Male
Termination
FME
Power Rating
10W
Impedance
50 Ohms (typical)
Polarization
Vertical
VSWR
Not specified
Mounting
Roof Mount or Panel Mount
Design
Stealth / Low Profile
Australian Band Coverage
Band 28 (700MHz), Band 5 (850MHz), Band 8 (900MHz), Band 3 (1800MHz), Band 1 (2100MHz), Band 7 (2600MHz), 5G (3400-3800MHz)
Weather Resistance
UV and Moisture Resistant
Applications
Mobile Phone, Mobile Data, Signal Boosters, 4G/5G Routers
Suitable Vehicles
Cars, 4WD, Caravans, Motorhomes, Commercial Vehicles
Ground Plane
Metal Roof Recommended
Warranty
Standard Manufacturer Warranty
Weight
Not specified
Country of Origin
Not specified
Frequently Asked Questions
Q: Will this antenna improve my mobile phone signal directly?
A: This antenna typically connects to mobile phone signal boosters or 4G/5G routers rather than directly to phones. Most modern phones don't have external antenna connectors. The antenna mounts externally (roof) to capture stronger signal, connects via 3m cable to a signal booster inside the vehicle, and the booster rebroadcasts improved signal to your phone wirelessly. Alternatively, connect to 4G/5G WiFi routers providing internet connectivity for multiple devices.
Q: What's the difference between 3dBi and higher gain antennas?
A: 3dBi provides moderate signal improvement (approximately 2x signal strength) sufficient for marginal coverage areas. Higher gain antennas (5dBi, 7dBi, 9dBi) offer better range but are physically longer - 5dBi antennas typically 30-50cm, 9dBi antennas 100cm+. The CLR5G prioritizes discreet installation over maximum gain. If you frequently operate in very remote areas, consider higher gain antennas despite increased length.
Q: Which Australian mobile carriers does this work with?
A: The 700-3800MHz frequency range covers primary bands used by Telstra, Optus, and Vodafone for 4G LTE and 5G services. Specifically includes Band 28 (700MHz), Band 5 (850MHz), Band 8 (900MHz), Band 3 (1800MHz), Band 1 (2100MHz), Band 7 (2600MHz), and 5G frequencies (3400-3800MHz). All three major Australian carriers use combinations of these bands depending on location.
Q: Can I mount this on a fibreglass canopy or roof?
A: Performance degrades significantly without proper metal ground plane. Fibreglass doesn't provide adequate ground plane for optimal antenna performance. If mounting on fibreglass, install a ground plane kit (metal sheet) underneath the antenna mount. Best results come from mounting on vehicle metal roof where the entire roof acts as ground plane providing 360-degree coverage.
Q: Do I need a signal booster, or can I use just the antenna?
A: You need signal booster or 4G/5G router for this antenna to improve phone reception. The antenna alone captures external signal but requires booster equipment to amplify and rebroadcast to your phone, or router equipment to convert cellular signal to WiFi. Popular combinations include antenna + vehicle signal booster (wireless rebroadcast to phones) or antenna + 4G router (WiFi internet for laptops/tablets/phones).
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS CR010 - AM/FM Antenna Extension 1M
1-metre Harada-compatible AM/FM antenna extension cable designed for extending factory car radio antenna connections where additional cable length is required between antenna and head unit, compatible with Harada antenna systems commonly fitted to Japanese and Australian-delivered vehicles, enables antenna relocation during dashboard modifications or aftermarket head unit installations requiring extended cable reach, suitable for vehicles with factory antenna mounting relocated during bull bar installation, roof rack additions, or body panel replacements, ideal for custom car audio installations, vehicle modifications requiring antenna repositioning, and any application where standard factory antenna cable length is insufficient to reach relocated head units or modified mounting positions.
Product Overview
The AXIS CR010 is a 1-metre antenna extension cable engineered for Harada antenna systems, the predominant factory antenna brand fitted to many Japanese-manufactured vehicles sold in Australia including Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. When installing aftermarket head units, relocating dashboards, or modifying vehicle bodywork, the factory antenna cable often becomes too short to reach the new head unit location. This extension cable provides the additional metre of length needed to bridge the gap between antenna base and relocated head unit without requiring complete antenna replacement. The Harada-compatible connectors ensure proper fitment with factory antenna systems maintaining signal quality for AM and FM radio reception. Common scenarios requiring extension cables include: installing double-DIN head units in vehicles originally fitted with single-DIN units requiring dashboard relocation, mounting head units in custom console locations, relocating antennas during bull bar installation where original fender mounting is obstructed, or routing antenna cables around newly installed equipment like UHF radios or amplifiers occupying original cable routing space.
Important Notes:
Harada System Specific: This extension is designed for Harada antenna systems. Verify your vehicle uses Harada antennas before purchasing.
1 Metre Length Only: Provides 1m additional reach. If you need more length, multiple extensions can be connected but signal degradation may occur.
Signal Quality: Each extension introduces slight signal loss. Minimize extensions where possible for optimal AM/FM reception.
Connector Compatibility: Ensure connectors match your specific Harada antenna configuration. Some models have different connector types.
Not Universal: This is NOT a universal antenna extension. It's specifically for Harada systems common in Japanese vehicles.
Key Features
Harada Compatible - Designed for Harada antenna systems fitted to many Japanese and Australian-delivered vehicles.
1 Metre Length - Provides additional cable reach for relocated head units or modified installations.
AM/FM Signal - Maintains radio frequency signal transmission for standard broadcast radio reception.
Factory Connector Match - Compatible connectors ensure proper fitment with existing Harada antenna systems.
Dashboard Modification Solution - Enables head unit relocation during custom dashboard installations or double-DIN upgrades.
Antenna Relocation - Allows antenna repositioning when factory mounting is obstructed by accessories or body modifications.
Aftermarket Head Unit Installation - Bridges gap between factory antenna and relocated aftermarket stereo systems.
Bull Bar Compatible - Accommodates antenna relocation when bull bars obstruct original fender mounting positions.
Custom Audio Installation - Facilitates professional car audio installations requiring non-standard cable routing.
Vehicle Modification Ready - Suits vehicles with body panel replacements or modifications affecting antenna cable routing.
Quality Construction - Maintains signal integrity over 1-metre extension minimizing reception degradation.
Toyota/Nissan/Mazda Fitment - Compatible with Harada systems commonly used in these manufacturers' vehicles.
Professional Installation - Enables clean cable routing during professional automotive electrical modifications.
Cost-Effective Solution - Extends existing antenna system without requiring complete antenna replacement.
Standard AM/FM Bands - Covers standard broadcast AM (530-1710kHz) and FM (88-108MHz) frequency ranges.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CR010
SKU
CR010
Product Type
Antenna Extension Cable
Description
Harada Antenna Extension - 1m
Length
1 Metre
Signal Type
AM/FM Radio
Warranty
Standard Manufacturer Warranty
Frequently Asked Questions
Q: How do I know if my vehicle has a Harada antenna system?
A: Check your vehicle's antenna base or consult your vehicle manual. Harada is common on Japanese-manufactured vehicles including many Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. If your antenna is factory-fitted and you drive a Japanese vehicle, there's good probability it's Harada. Alternatively, check the connector at the back of your head unit - compare with product images or bring photos to us for verification.
Q: Will this extension reduce my radio reception quality?
A: Yes, but minimally. Each extension introduces slight signal loss - typically 1-2dB per metre. For 1m extension, most users won't notice reception quality change in strong signal areas. In marginal reception areas (rural locations, underground car parks), you may experience slightly reduced clarity. Minimize extensions where possible and avoid connecting multiple extensions which compound signal loss.
Q: Can I connect multiple CR010 extensions together for longer reach?
A: Physically yes, but not recommended. Each additional extension increases signal loss. Two 1m extensions (2m total) will noticeably degrade AM reception, particularly affecting weaker stations. If you need more than 1m extension, consider relocating your head unit closer to antenna, or installing new antenna with longer factory cable.
Q: Will this work with my aftermarket head unit?
A: Yes, if your vehicle originally had a Harada antenna system. The extension goes between factory Harada antenna and any head unit (factory or aftermarket). The extension doesn't care about head unit brand - it simply extends the antenna cable. Ensure your aftermarket head unit has appropriate antenna input connector matching your vehicle's factory setup.
Q: Can I use this for amplified or powered antennas?
A: If your Harada antenna is powered (receives 12V from head unit for amplification), this extension should maintain power transmission. However, voltage drop over extensions may affect amplifier performance. Test before permanent installation to ensure powered antenna operates correctly. Most factory Harada antennas are passive and don't require power.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS CR16 - AM/FM Antenna Extension 0.5M
0.5-metre Harada-compatible AM/FM antenna extension cable designed for extending factory car radio antenna connections where additional cable length is required between antenna and head unit, compatible with Harada antenna systems commonly fitted to Japanese and Australian-delivered vehicles, enables antenna relocation during dashboard modifications or aftermarket head unit installations requiring extended cable reach, suitable for vehicles with factory antenna mounting relocated during bull bar installation, roof rack additions, or body panel replacements, ideal for custom car audio installations, vehicle modifications requiring antenna repositioning, and any application where standard factory antenna cable length is insufficient to reach relocated head units or modified mounting positions.
Product Overview
The AXIS CR16 is a 0.5-metre antenna extension cable engineered for Harada antenna systems, the predominant factory antenna brand fitted to many Japanese-manufactured vehicles sold in Australia including Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. When installing aftermarket head units, relocating dashboards, or modifying vehicle bodywork, the factory antenna cable often becomes too short to reach the new head unit location. This extension cable provides the additional half-metre of length needed to bridge the gap between antenna base and relocated head unit without requiring complete antenna replacement. The Harada-compatible connectors ensure proper fitment with factory antenna systems maintaining signal quality for AM and FM radio reception. Common scenarios requiring extension cables include: installing double-DIN head units in vehicles originally fitted with single-DIN units requiring dashboard relocation, mounting head units in custom console locations, relocating antennas during bull bar installation where original fender mounting is obstructed, or routing antenna cables around newly installed equipment like UHF radios or amplifiers occupying original cable routing space.
Important Notes:
Harada System Specific: This extension is designed for Harada antenna systems. Verify your vehicle uses Harada antennas before purchasing.
0.5 Metre Length Only: Provides 0.5m additional reach. If you need more length, multiple extensions can be connected but signal degradation may occur.
Signal Quality: Each extension introduces slight signal loss. Minimize extensions where possible for optimal AM/FM reception.
Connector Compatibility: Ensure connectors match your specific Harada antenna configuration. Some models have different connector types.
Not Universal: This is NOT a universal antenna extension. It's specifically for Harada systems common in Japanese vehicles.
Key Features
Harada Compatible - Designed for Harada antenna systems fitted to many Japanese and Australian-delivered vehicles.
0.5 Metre Length - Provides additional cable reach for relocated head units or modified installations.
AM/FM Signal - Maintains radio frequency signal transmission for standard broadcast radio reception.
Factory Connector Match - Compatible connectors ensure proper fitment with existing Harada antenna systems.
Dashboard Modification Solution - Enables head unit relocation during custom dashboard installations or double-DIN upgrades.
Antenna Relocation - Allows antenna repositioning when factory mounting is obstructed by accessories or body modifications.
Aftermarket Head Unit Installation - Bridges gap between factory antenna and relocated aftermarket stereo systems.
Bull Bar Compatible - Accommodates antenna relocation when bull bars obstruct original fender mounting positions.
Custom Audio Installation - Facilitates professional car audio installations requiring non-standard cable routing.
Vehicle Modification Ready - Suits vehicles with body panel replacements or modifications affecting antenna cable routing.
Quality Construction - Maintains signal integrity over 0.5-metre extension minimizing reception degradation.
Toyota/Nissan/Mazda Fitment - Compatible with Harada systems commonly used in these manufacturers' vehicles.
Professional Installation - Enables clean cable routing during professional automotive electrical modifications.
Cost-Effective Solution - Extends existing antenna system without requiring complete antenna replacement.
Standard AM/FM Bands - Covers standard broadcast AM (530-1710kHz) and FM (88-108MHz) frequency ranges.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CR16
SKU
CR16
Product Type
Antenna Extension Cable
Description
Harada Antenna Extension - 50cm
Length
0.5 Metre (50cm)
Compatibility
Harada Antenna Systems
Signal Type
AM/FM Radio
Warranty
Standard Manufacturer Warranty
Frequently Asked Questions
Q: How do I know if my vehicle has a Harada antenna system?
A: Check your vehicle's antenna base or consult your vehicle manual. Harada is common on Japanese-manufactured vehicles including many Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. If your antenna is factory-fitted and you drive a Japanese vehicle, there's good probability it's Harada. Alternatively, check the connector at the back of your head unit - compare with product images or bring photos to us for verification.
Q: Will this extension reduce my radio reception quality?
A: Yes, but minimally. Each extension introduces slight signal loss - typically 1-2dB per metre. For 0.5m extension, most users won't notice reception quality change in strong signal areas. In marginal reception areas (rural locations, underground car parks), you may experience slightly reduced clarity. Minimize extensions where possible and avoid connecting multiple extensions which compound signal loss.
Q: Can I connect multiple CR16 extensions together for longer reach?
A: Physically yes, but not recommended. Each additional extension increases signal loss. Two 0.5m extensions (1m total) will noticeably degrade AM reception, particularly affecting weaker stations. If you need more than 0.5m extension, consider relocating your head unit closer to antenna, or installing new antenna with longer factory cable.
Q: Will this work with my aftermarket head unit?
A: Yes, if your vehicle originally had a Harada antenna system. The extension goes between factory Harada antenna and any head unit (factory or aftermarket). The extension doesn't care about head unit brand - it simply extends the antenna cable. Ensure your aftermarket head unit has appropriate antenna input connector matching your vehicle's factory setup.
Q: Can I use this for amplified or powered antennas?
A: If your Harada antenna is powered (receives 12V from head unit for amplification), this extension should maintain power transmission. However, voltage drop over extensions may affect amplifier performance. Test before permanent installation to ensure powered antenna operates correctly. Most factory Harada antennas are passive and don't require power.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS CR813 - AM/FM Antenna Extension 3M
3-metre Harada-compatible AM/FM antenna extension cable designed for extending factory car radio antenna connections where additional cable length is required between antenna and head unit, compatible with Harada antenna systems commonly fitted to Japanese and Australian-delivered vehicles, enables antenna relocation during dashboard modifications or aftermarket head unit installations requiring extended cable reach, suitable for vehicles with factory antenna mounting relocated during bull bar installation, roof rack additions, or body panel replacements, ideal for custom car audio installations, vehicle modifications requiring antenna repositioning, and any application where standard factory antenna cable length is insufficient to reach relocated head units or modified mounting positions.
Product Overview
The AXIS CR813 is a 3-metre antenna extension cable engineered for Harada antenna systems, the predominant factory antenna brand fitted to many Japanese-manufactured vehicles sold in Australia including Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. When installing aftermarket head units, relocating dashboards, or modifying vehicle bodywork, the factory antenna cable often becomes too short to reach the new head unit location. This extension cable provides the additional three metres of length needed to bridge the gap between antenna base and relocated head unit without requiring complete antenna replacement. The Harada-compatible connectors ensure proper fitment with factory antenna systems maintaining signal quality for AM and FM radio reception. Common scenarios requiring extension cables include: installing double-DIN head units in vehicles originally fitted with single-DIN units requiring dashboard relocation, mounting head units in custom console locations, relocating antennas during bull bar installation where original fender mounting is obstructed, or routing antenna cables around newly installed equipment like UHF radios or amplifiers occupying original cable routing space.
Important Notes:
Harada System Specific: This extension is designed for Harada antenna systems. Verify your vehicle uses Harada antennas before purchasing.
3 Metre Length: Provides 3m additional reach. Longer extensions may introduce more signal loss than shorter alternatives.
Signal Quality: Each extension introduces slight signal loss. Minimize extensions where possible for optimal AM/FM reception.
Connector Compatibility: Ensure connectors match your specific Harada antenna configuration. Some models have different connector types.
Not Universal: This is NOT a universal antenna extension. It's specifically for Harada systems common in Japanese vehicles.
Key Features
Harada Compatible - Designed for Harada antenna systems fitted to many Japanese and Australian-delivered vehicles.
3 Metre Length - Provides extended cable reach for relocated head units or modified installations requiring longer runs.
AM/FM Signal - Maintains radio frequency signal transmission for standard broadcast radio reception.
Factory Connector Match - Compatible connectors ensure proper fitment with existing Harada antenna systems.
Dashboard Modification Solution - Enables head unit relocation during custom dashboard installations or double-DIN upgrades.
Antenna Relocation - Allows antenna repositioning when factory mounting is obstructed by accessories or body modifications.
Aftermarket Head Unit Installation - Bridges gap between factory antenna and relocated aftermarket stereo systems.
Bull Bar Compatible - Accommodates antenna relocation when bull bars obstruct original fender mounting positions.
Custom Audio Installation - Facilitates professional car audio installations requiring non-standard cable routing.
Vehicle Modification Ready - Suits vehicles with body panel replacements or modifications affecting antenna cable routing.
Quality Construction - Maintains signal integrity over 3-metre extension minimizing reception degradation.
Toyota/Nissan/Mazda Fitment - Compatible with Harada systems commonly used in these manufacturers' vehicles.
Professional Installation - Enables clean cable routing during professional automotive electrical modifications.
Cost-Effective Solution - Extends existing antenna system without requiring complete antenna replacement.
Standard AM/FM Bands - Covers standard broadcast AM (530-1710kHz) and FM (88-108MHz) frequency ranges.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CR813
SKU
CR813
Product Type
Antenna Extension Cable
Description
Harada Antenna Extension - 3m
Length
3 Metres
Compatibility
Harada Antenna Systems
Signal Type
AM/FM Radio
Warranty
Standard Manufacturer Warranty
Frequently Asked Questions
Q: How do I know if my vehicle has a Harada antenna system?
A: Check your vehicle's antenna base or consult your vehicle manual. Harada is common on Japanese-manufactured vehicles including many Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. If your antenna is factory-fitted and you drive a Japanese vehicle, there's good probability it's Harada. Alternatively, check the connector at the back of your head unit - compare with product images or bring photos to us for verification.
Q: Will this 3-metre extension reduce my radio reception quality?
A: Yes, longer extensions introduce more signal loss than shorter ones. A 3m extension typically causes 3-6dB signal loss depending on cable quality and frequency. In strong signal areas (metropolitan locations, near transmission towers), this loss is usually acceptable. In marginal reception areas (rural locations, valleys, underground car parks), you may experience noticeably reduced reception quality, particularly for weaker AM stations. Test reception after installation and consider relocating head unit closer to antenna if reception is unsatisfactory.
Q: Can I connect multiple extensions together for even longer reach?
A: Not recommended. Connecting multiple extensions compounds signal loss significantly. A 3m extension already introduces moderate signal degradation - adding another extension would likely result in poor reception, especially for AM radio. If 3m is insufficient, consider: (1) relocating your head unit closer to the antenna, (2) relocating your antenna closer to the head unit, or (3) installing a new antenna with longer factory cable.
Q: Will this work with my aftermarket head unit?
A: Yes, if your vehicle originally had a Harada antenna system. The extension goes between factory Harada antenna and any head unit (factory or aftermarket). The extension doesn't care about head unit brand - it simply extends the antenna cable. Ensure your aftermarket head unit has appropriate antenna input connector matching your vehicle's factory setup.
Q: Can I use this for amplified or powered antennas?
A: If your Harada antenna is powered (receives 12V from head unit for amplification), this extension should maintain power transmission. However, voltage drop over 3m extension may affect amplifier performance more than shorter extensions. Test before permanent installation to ensure powered antenna operates correctly. Most factory Harada antennas are passive and don't require power.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS CR814 - AM/FM Antenna Extension 4M
4-metre Harada-compatible AM/FM antenna extension cable designed for extending factory car radio antenna connections where additional cable length is required between antenna and head unit, compatible with Harada antenna systems commonly fitted to Japanese and Australian-delivered vehicles, enables antenna relocation during dashboard modifications or aftermarket head unit installations requiring extended cable reach, suitable for vehicles with factory antenna mounting relocated during bull bar installation, roof rack additions, or body panel replacements, ideal for custom car audio installations, vehicle modifications requiring antenna repositioning, and any application where standard factory antenna cable length is insufficient to reach relocated head units or modified mounting positions.
Product Overview
The AXIS CR814 is a 4-metre antenna extension cable engineered for Harada antenna systems, the predominant factory antenna brand fitted to many Japanese-manufactured vehicles sold in Australia including Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. When installing aftermarket head units, relocating dashboards, or modifying vehicle bodywork, the factory antenna cable often becomes too short to reach the new head unit location. This extension cable provides the additional four metres of length needed to bridge the gap between antenna base and relocated head unit without requiring complete antenna replacement. The Harada-compatible connectors ensure proper fitment with factory antenna systems maintaining signal quality for AM and FM radio reception. Common scenarios requiring extension cables include: installing double-DIN head units in vehicles originally fitted with single-DIN units requiring dashboard relocation, mounting head units in custom console locations, relocating antennas during bull bar installation where original fender mounting is obstructed, or routing antenna cables around newly installed equipment like UHF radios or amplifiers occupying original cable routing space.
Important Notes:
Harada System Specific: This extension is designed for Harada antenna systems. Verify your vehicle uses Harada antennas before purchasing.
4 Metre Length: Provides 4m additional reach. Longer extensions introduce more signal loss than shorter alternatives.
Signal Quality: Each extension introduces slight signal loss. Minimize extensions where possible for optimal AM/FM reception.
Connector Compatibility: Ensure connectors match your specific Harada antenna configuration. Some models have different connector types.
Not Universal: This is NOT a universal antenna extension. It's specifically for Harada systems common in Japanese vehicles.
Key Features
Harada Compatible - Designed for Harada antenna systems fitted to many Japanese and Australian-delivered vehicles.
4 Metre Length - Provides extended cable reach for relocated head units or modified installations requiring longer runs.
AM/FM Signal - Maintains radio frequency signal transmission for standard broadcast radio reception.
Factory Connector Match - Compatible connectors ensure proper fitment with existing Harada antenna systems.
Dashboard Modification Solution - Enables head unit relocation during custom dashboard installations or double-DIN upgrades.
Antenna Relocation - Allows antenna repositioning when factory mounting is obstructed by accessories or body modifications.
Aftermarket Head Unit Installation - Bridges gap between factory antenna and relocated aftermarket stereo systems.
Bull Bar Compatible - Accommodates antenna relocation when bull bars obstruct original fender mounting positions.
Custom Audio Installation - Facilitates professional car audio installations requiring non-standard cable routing.
Vehicle Modification Ready - Suits vehicles with body panel replacements or modifications affecting antenna cable routing.
Quality Construction - Maintains signal integrity over 4-metre extension minimizing reception degradation.
Toyota/Nissan/Mazda Fitment - Compatible with Harada systems commonly used in these manufacturers' vehicles.
Professional Installation - Enables clean cable routing during professional automotive electrical modifications.
Cost-Effective Solution - Extends existing antenna system without requiring complete antenna replacement.
Standard AM/FM Bands - Covers standard broadcast AM (530-1710kHz) and FM (88-108MHz) frequency ranges.
Technical Specifications
Specification
Details
Brand
AXIS
Model
CR814
SKU
CR814
Product Type
Antenna Extension Cable
Description
Harada Antenna Extension - 4m
Length
4 Metres
Compatibility
Harada Antenna Systems
Signal Type
AM/FM Radio
Warranty
Standard Manufacturer Warranty
Frequently Asked Questions
Q: How do I know if my vehicle has a Harada antenna system?
A: Check your vehicle's antenna base or consult your vehicle manual. Harada is common on Japanese-manufactured vehicles including many Toyota, Nissan, Mazda, Honda, Subaru, and Mitsubishi models. If your antenna is factory-fitted and you drive a Japanese vehicle, there's good probability it's Harada. Alternatively, check the connector at the back of your head unit - compare with product images or bring photos to us for verification.
Q: Will this 4-metre extension reduce my radio reception quality?
A: Yes, longer extensions introduce more signal loss than shorter ones. A 4m extension typically causes 4-8dB signal loss depending on cable quality and frequency. In strong signal areas (metropolitan locations, near transmission towers), this loss may be acceptable. In marginal reception areas (rural locations, valleys, underground car parks), you will likely experience noticeably reduced reception quality, particularly for weaker AM stations. Consider shorter extensions or antenna/head unit relocation if reception becomes unsatisfactory.
Q: Can I connect multiple extensions together for even longer reach?
A: Not recommended. Connecting multiple extensions compounds signal loss significantly. A 4m extension already introduces considerable signal degradation - adding another extension would likely result in poor or unusable reception, especially for AM radio. If 4m is insufficient, strongly consider: (1) relocating your head unit closer to the antenna, (2) relocating your antenna closer to the head unit, or (3) installing a new antenna with longer factory cable.
Q: Will this work with my aftermarket head unit?
A: Yes, if your vehicle originally had a Harada antenna system. The extension goes between factory Harada antenna and any head unit (factory or aftermarket). The extension doesn't care about head unit brand - it simply extends the antenna cable. Ensure your aftermarket head unit has appropriate antenna input connector matching your vehicle's factory setup.
Q: Can I use this for amplified or powered antennas?
A: If your Harada antenna is powered (receives 12V from head unit for amplification), this extension should maintain power transmission. However, voltage drop over 4m extension may significantly affect amplifier performance. Test before permanent installation to ensure powered antenna operates correctly. Most factory Harada antennas are passive and don't require power.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS HD1409Q - 9 Inch High Resolution Quad View Monitor
High resolution 9-inch quad view monitor featuring 1024x600 resolution, capacitive touchscreen, 8 split-screen modes, 4-camera connectivity via 4-pin aviation connectors, 650 cd/m² brightness, 85-degree viewing angles, auto PAL/NTSC/720P/1080P detection, 5 camera triggers, selectable guidelines, built-in speaker, 10-32V DC operation, -20°C to +70°C temperature range, and heavy-duty construction for trucks, machinery, and vehicle applications.
Product Overview
The AXIS HD1409Q is an exceptional high resolution 12/24V quad view monitor designed to provide crystal-clear image and enhanced viewing experience. With robust heavy duty construction, this monitor is perfect for trucks, machinery, and various vehicles. The HD1409Q offers the added advantage of connecting up to 4 cameras providing incredible flexibility for monitoring multiple angles simultaneously. The 9-inch LCD display features 16:9 widescreen format with 1024x600 pixel resolution delivering sharp detailed imagery essential for safe vehicle operation and reversing maneuvers in commercial and industrial environments. The 650 cd/m² brightness specification ensures excellent visibility even in direct sunlight conditions typical of outdoor work environments and Australian summer conditions. Wide 85-degree viewing angles in all directions (left, right, up, down) maintain image clarity from various operator seating positions eliminating need for constant monitor adjustment during operation. The capacitive touchscreen interface provides intuitive control enabling quick switching between camera views and split-screen configurations without physical buttons that can fail in harsh operating conditions. Eight versatile split-screen modes (Single, Dual, Triplex, Quad, Trefoil, Y-Split, H-Split, PIP) accommodate different monitoring scenarios from simple reversing to complex multi-angle surveillance during loading operations or tight maneuvering situations. Auto video system detection supporting PAL, NTSC, 720P, and 1080P formats ensures compatibility with various camera types from different manufacturers eliminating configuration complexity during installation. Four 4-pin aviation male connectors provide secure weatherproof camera connections resistant to vibration, moisture, and dust ingress typical in heavy equipment and commercial vehicle applications. Five independent camera triggers enable automatic view switching based on vehicle functions such as reverse gear engagement, turn signal activation, or brake application improving operator situational awareness without manual intervention. Selectable on/off guidelines assist with distance judgment and obstacle avoidance during reversing and parking operations with option to disable when not required. Built-in speaker delivers audio alerts and proximity warnings from compatible camera systems enhancing safety during blind-spot maneuvers. Wide 10-32V DC voltage input accommodates both 12V and 24V vehicle electrical systems common in light commercial vehicles through heavy trucks and machinery. Extended operating temperature range from -20°C to +70°C ensures reliable performance in extreme Australian climates from alpine winter conditions to desert summer heat. Compact 234mm width, 158mm height, and 39.75mm depth (excluding bracket and visor) dimensions facilitate installation in cramped dashboard locations typical of commercial vehicle cabins.
Features & Benefits
High Resolution 1024x600 Display The 9-inch LCD screen with 1024x600 resolution delivers crisp detailed imagery essential for identifying obstacles, reading signage, and monitoring surroundings during vehicle operation. This resolution significantly exceeds basic VGA displays providing clarity necessary for professional applications where accurate visual information affects safety and operational efficiency.
8 Flexible Split-Screen Modes Eight different viewing configurations (Single, Dual, Triplex, Quad, Trefoil, Y-Split, H-Split, Picture-in-Picture) accommodate diverse monitoring requirements. Operators can view single camera for detailed observation, multiple cameras simultaneously for comprehensive situational awareness, or prioritize one view while monitoring others in smaller windows adapting to different operational scenarios.
4-Camera Connectivity with Aviation Connectors Four independent camera inputs via rugged 4-pin aviation male connectors enable comprehensive vehicle coverage monitoring front, rear, and side blind spots simultaneously. Aviation-grade connectors provide superior vibration resistance, weatherproofing, and connection reliability compared to standard RCA or BNC connectors ensuring long-term durability in harsh operating environments.
Capacitive Touchscreen Control Intuitive touchscreen interface eliminates mechanical buttons prone to failure from dust, moisture, and repeated use in commercial applications. Operators switch between views and adjust settings with simple touch gestures maintaining focus on vehicle operation rather than searching for physical controls.
650 cd/m² High Brightness Panel High brightness specification ensures screen remains visible in direct sunlight typical of outdoor work environments and Australian conditions. Standard low-brightness monitors wash out in bright light requiring operators to shade screens or reposition vehicles compromising safety and productivity.
Wide 85° Viewing Angles Consistent image quality from 85-degree angles in all directions accommodates various operator seating positions and heights without requiring monitor adjustment. This wide viewing angle prevents image inversion or color shift typical of inferior displays when viewed off-axis ensuring multiple operators or passengers view clear imagery.
5 Independent Camera Triggers Five camera trigger inputs enable automatic view switching based on vehicle functions such as reverse gear, turn signals, brake application, or auxiliary switches. This automation improves safety by displaying relevant camera views without manual intervention allowing operators to maintain focus on vehicle controls during critical maneuvers.
Auto Video Format Detection Automatic recognition of PAL, NTSC, 720P, and 1080P video formats ensures compatibility with cameras from various manufacturers worldwide. This eliminates manual configuration requirements and prevents compatibility issues during installation or camera replacement simplifying system maintenance.
Selectable Parking Guidelines Distance reference lines assist with obstacle avoidance and parking precision with option to disable when not required. Operators judge distances accurately during reversing reducing property damage and improving safety in confined spaces typical of loading docks, construction sites, and urban deliveries.
Built-In Audio Speaker Integrated speaker delivers audio alerts and proximity warnings from compatible camera systems providing additional safety feedback beyond visual information. Audio warnings alert distracted operators to immediate hazards even when not actively monitoring screen improving overall situational awareness.
Wide Voltage Compatibility 10-32V DC input accommodates 12V light commercial vehicles, 24V heavy trucks, and machinery with varying electrical system voltages. This flexibility eliminates need for voltage converters or multiple monitor models simplifying inventory management and installation across diverse fleet compositions.
Extended Temperature Range Operating range from -20°C to +70°C ensures reliable performance in extreme climates from alpine construction sites to outback mining operations. Standard electronics fail in temperature extremes but this monitor maintains functionality throughout Australia's diverse climate zones.
Heavy Duty Construction Robust build quality withstands vibration, shock, and environmental exposure typical in commercial vehicles, construction equipment, and agricultural machinery. This durability reduces replacement frequency and maintenance costs compared to consumer-grade displays unsuitable for professional applications.
Technical Specifications
Specification
Details
Model
AXIS HD1409Q
LCD Size
9 Inches
Display Format
16:9 Widescreen
Resolution
1024 x 600 Pixels
Split Screen Modes
Single/Dual/Triplex/Quad/Trefoil/Y-Split/H-Split/PIP (8 Modes)
Brightness
650 cd/m²
Viewing Angles
85° Left/Right/Up/Down
Touchscreen Type
Capacitive Touch
Video System
Auto PAL/NTSC/720P/1080P Select
Video Input Connectors
4 x 4-Pin Aviation Male Connectors
Connection Standard
Universal 4-Pin Configuration (Male)
Camera Triggers
5 Independent Triggers
Parking Guidelines
Selectable On/Off
Audio
Built-In Speaker
Operating Temperature
-20°C to +70°C
Voltage Input
10-32V DC (Negative Ground)
Voltage Compatibility
12V and 24V Systems
Dimensions (Monitor)
234mm (W) x 158mm (H) x 39.75mm (D)
Dimensions Note
Excluding Bracket & Visor
Barcode/EAN
9321886017182
Installation & Compatibility
Camera Compatibility The HD1409Q accepts video input from backup cameras, side cameras, and forward-facing cameras utilizing 4-pin aviation connector standard. Compatible with most aftermarket vehicle cameras outputting PAL, NTSC, 720P, or 1080P video signals. The auto-detection feature automatically identifies camera video format eliminating manual configuration. Verify camera output connectors match 4-pin aviation male configuration or obtain appropriate adapter cables. Camera systems should operate within 10-32V DC range matching vehicle electrical system voltage.
Mounting Considerations Select mounting location providing optimal viewing angle from driver position while minimizing windshield obstruction or interference with vehicle controls. Dashboard mounting positions work well in commercial vehicles with flat dash surfaces. Consider sun visor attachment for managing screen glare in bright conditions. Ensure mounting position allows access to rear panel connectors for camera cable routing without excessive cable bending or strain.
Electrical Installation Connect monitor power supply to vehicle electrical system observing correct polarity (negative ground). The 10-32V DC input accommodates both 12V and 24V systems automatically without switches or jumpers. Route power cable away from high-current components, ignition systems, and radio frequency sources that may introduce electrical noise. Install inline fuse rated appropriately for monitor current draw protecting vehicle electrical system and monitor from short circuit damage.
Camera Connection Process Route camera cables from camera mounting locations to monitor position avoiding pinch points, moving components, and high-heat areas near engine or exhaust systems. Connect cameras to corresponding 4-pin aviation male connectors on monitor rear panel ensuring secure connection with connector locking mechanism engaged. Label camera cables during installation identifying camera location (front, rear, left side, right side) simplifying future troubleshooting and maintenance.
Trigger Wire Configuration Connect camera trigger wires to appropriate vehicle circuits for automatic view switching. Common trigger sources include reverse light circuit for rear camera activation, turn signal circuits for side camera activation, and brake circuit for front camera activation. The five independent triggers accommodate complex installations with multiple automatic switching requirements. Verify trigger voltage levels match monitor input specifications preventing damage to trigger circuitry.
System Testing After installation completion, test all camera views individually confirming clear video display without interference, distortion, or color abnormalities. Verify automatic view switching via trigger inputs functions correctly when engaging reverse gear or activating turn signals. Test touchscreen responsiveness and split-screen mode transitions. Adjust parking guidelines positioning matching specific vehicle dimensions and camera mounting angles for accurate distance reference.
Frequently Asked Questions
Can this monitor display all 4 cameras simultaneously?
Yes, the HD1409Q supports Quad split-screen mode displaying all four camera inputs simultaneously in equal-sized quadrants. Additionally, seven other split-screen configurations provide flexibility for different monitoring scenarios. Single mode displays one camera full-screen for detailed observation. Dual mode splits screen between two cameras. Triplex mode shows three cameras simultaneously. Trefoil, Y-Split, and H-Split modes offer alternative three-camera arrangements. Picture-in-Picture (PIP) mode displays one camera large with smaller overlay windows showing other cameras. Switch between modes using capacitive touchscreen interface selecting optimal configuration for current operation whether reversing, maneuvering in tight spaces, or highway driving requiring blind-spot monitoring.
Will this work with my existing backup cameras?
The HD1409Q is compatible with most aftermarket backup cameras using 4-pin aviation connector configuration and outputting PAL, NTSC, 720P, or 1080P video signals. The auto video format detection automatically identifies camera signal type eliminating manual configuration. If existing cameras use different connectors (RCA, BNC, etc.), adapter cables are available to convert to 4-pin aviation male connectors required by this monitor. Verify existing camera operating voltage matches monitor's 10-32V DC range ensuring compatibility with 12V or 24V vehicle electrical systems. Cameras must provide composite video or AHD (Analog High Definition) signals within supported resolution specifications.
How does the automatic camera switching work?
The HD1409Q features five independent trigger inputs that automatically switch camera views based on vehicle functions. Connect trigger wires to appropriate vehicle circuits such as reverse light positive wire for rear camera activation, turn signal wires for side camera activation, or brake circuit for front camera activation. When trigger input receives voltage signal, monitor automatically switches to corresponding camera view. For example, engaging reverse gear energizes reverse lights sending signal to trigger input causing monitor to display rear camera automatically. This hands-free operation improves safety by displaying relevant camera views during critical maneuvers without requiring operator to manually switch views using touchscreen controls. Multiple simultaneous triggers can activate split-screen modes showing combined views.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS HDC/AX-F - 4-Pin (F) to Universal 4-Pin (F) Converter
Pin configuration converter cable featuring AXIS 4-pin female to Universal 4-pin female aviation connector compatibility, flexible pin arrangement conversion, camera-to-monitor signal adaptation, weatherproof aviation-grade construction, and compatibility bridge enabling AXIS proprietary pinout devices to connect with universal standard 4-pin equipment in vehicle camera and monitoring systems.
Product Overview
The AXIS HDC/AX-F allows for flexible pin configuration offering the ability to switch from AXIS type to Universal type. This converter cable solves compatibility challenges between AXIS proprietary 4-pin pinout configuration and universal standard 4-pin pinout used by various camera and monitor manufacturers. The 4-pin aviation connector format maintains weatherproof sealing and vibration resistance essential for vehicle applications while converting signal pin arrangement between incompatible standards. AXIS brand cameras, monitors, and extension cables utilize specific pin configuration placing power, ground, and video signals on designated pins within 4-pin aviation connector. Universal standard equipment from other manufacturers uses different pin arrangement placing identical signals on different pin positions within physically identical 4-pin aviation connector. Without this converter, physically compatible connectors fail to establish proper electrical connection because power may connect to video pin, ground to power pin, or other incorrect pin mapping causing equipment malfunction or damage. This adapter cable features AXIS 4-pin female connector on one end accepting male connectors from AXIS equipment such as cameras or extension cables. The opposite end features Universal 4-pin female connector accepting male connectors from universal standard equipment such as monitors or recorders utilizing industry-standard pinout. Internal wiring within converter cable routes signals from AXIS pin positions to corresponding universal pin positions ensuring proper power, ground, and video signal connections. The female-to-female configuration enables inline installation between existing male-terminated camera cables and male-terminated monitor input cables without requiring connector removal or cable modification. Aviation-grade connector construction provides IP67-rated weatherproof sealing protecting internal connections from moisture ingress, dust contamination, and corrosive salt spray typical in marine, agricultural, and mining vehicle applications. Threaded coupling nuts on both connectors ensure secure mechanical connection resistant to vibration, shock, and cable tension preventing accidental disconnection during vehicle operation. Gold-plated contact pins minimize electrical resistance and prevent corrosion ensuring reliable signal transmission and power delivery over extended service life in harsh environmental conditions. Compact inline design minimizes additional cable bulk and maintains installation flexibility in confined spaces typical of vehicle wiring harnesses and equipment mounting locations.
Features & Benefits
AXIS to Universal Pin Conversion Bridges compatibility gap between AXIS proprietary 4-pin pinout and universal standard 4-pin configuration enabling equipment from different manufacturers to interconnect properly. This compatibility eliminates need to replace entire camera systems or monitors when upgrading or mixing equipment brands reducing total system cost.
Female-to-Female Configuration Both ends feature female connectors accepting male plugs from cameras and monitors enabling inline installation without cutting cables or removing existing connectors. This preserves original equipment cables maintaining manufacturer warranties and simplifying future equipment changes or troubleshooting.
Aviation-Grade Weatherproof Construction IP67-rated sealing protects electrical connections from moisture, dust, and environmental contamination typical in outdoor vehicle applications. This weatherproofing ensures reliable operation in rain, dust storms, vehicle washing, and extreme humidity conditions preventing corrosion-related failures.
Threaded Locking Mechanism Coupling nuts on both connectors provide secure mechanical connection resistant to vibration and accidental disconnection. This positive locking prevents intermittent connections or complete disconnection during vehicle operation over rough terrain maintaining continuous monitoring capability.
Gold-Plated Contact Pins Gold plating on electrical contacts minimizes contact resistance and prevents oxidation ensuring long-term signal integrity and power delivery reliability. Standard tin or nickel contacts corrode over time increasing resistance and causing video signal degradation or intermittent power delivery.
Compact Inline Design Minimal additional cable length and compact connector housings maintain wiring harness flexibility and enable installation in tight spaces. Bulky adapters or conversion boxes consume valuable mounting space and create cable management challenges in cramped vehicle installations.
Plug-and-Play Installation Simple connection between existing cables requires no tools, soldering, or technical expertise enabling quick field installation or system reconfiguration. This simplicity reduces installation labor costs and allows operators to perform equipment changes without specialized technical support.
Signal Integrity Preservation Quality internal wiring and proper shielding maintain video signal quality without introducing noise, interference, or voltage drop. Inferior adapters use inadequate wire gauge or poor shielding causing video distortion, power supply problems, or electromagnetic interference affecting camera and monitor performance.
Technical Specifications
Specification
Details
Model
AXIS HDC/AX-F
Connector Type
4-Pin Aviation
End 1 Configuration
AXIS 4-Pin Female
End 2 Configuration
Universal 4-Pin Female
Pin Conversion
AXIS Pinout to Universal Standard Pinout
Gender
Female to Female (F-F)
Weatherproof Rating
IP67 Sealed
Coupling Method
Threaded Locking Nuts
Contact Plating
Gold-Plated Pins
Compatible Equipment
Camera Systems, Monitors, Extension Cables
Application
Vehicle Camera/Monitor Systems
Barcode/EAN
9321886015508
Installation & Compatibility
Equipment Compatibility The HDC/AX-F converter enables connection between AXIS proprietary pinout equipment and universal standard pinout equipment. AXIS-compatible equipment includes AXIS brand cameras, monitors, and extension cables utilizing AXIS-specific pin configuration. Universal-compatible equipment includes monitors and cameras from manufacturers using industry-standard 4-pin pinout configuration. Verify equipment pinout specifications before purchasing converter to confirm compatibility requirements. Incorrect converter selection results in continued incompatibility despite physical connector compatibility.
Pin Configuration Understanding 4-pin aviation connectors for camera systems typically carry power positive, ground negative, video signal positive, and video signal ground on four pins within connector. AXIS pinout assigns these signals to specific pin positions differing from universal standard pin position assignments. This converter internally routes signals from AXIS pin positions to universal pin positions enabling proper electrical connection. Understanding this distinction prevents damage from connecting incompatible equipment without appropriate converter.
Connection Process Connect AXIS 4-pin female end of converter to male connector from AXIS equipment such as camera cable or AXIS monitor input cable. Connect Universal 4-pin female end of converter to male connector from universal standard equipment such as camera cable or universal monitor input cable. Ensure threaded coupling nuts engage fully and tighten hand-tight preventing moisture ingress and securing mechanical connection. Verify correct converter orientation matching AXIS equipment to AXIS converter end and universal equipment to universal converter end.
System Testing After Installation After connecting converter between equipment, power system and verify video display appears on monitor confirming proper pin mapping and signal routing. Test image should show clear video without distortion, color abnormalities, or interference indicating successful conversion. If video fails to appear, verify converter orientation ensuring AXIS equipment connects to AXIS converter end and universal equipment connects to universal end. Check all coupling nuts tightened securely and inspect connectors for damaged pins or contamination.
Cable Management Position converter in accessible location enabling future disconnection for system maintenance or equipment replacement without disassembling surrounding components. Secure converter cable to vehicle structure using cable ties preventing excessive movement that could stress connectors or cause vibration-induced wear. Protect converter from sharp edges, moving components, and high-heat sources that could damage cable insulation or connector housings.
Multiple Converter Use In systems with multiple cameras, separate converter may be required for each camera connection if mixing AXIS and universal equipment. Label converters identifying which camera or monitor connection each serves simplifying future troubleshooting and maintenance. Alternatively, use consistent pinout standard throughout system avoiding need for multiple converters by selecting all AXIS or all universal equipment during initial purchase.
Frequently Asked Questions
How do I know if I need this converter?
You need the HDC/AX-F converter when connecting AXIS proprietary pinout equipment to universal standard pinout equipment in 4-pin aviation connector camera systems. If connecting AXIS camera to universal monitor (or vice versa) and video fails to display despite proper physical connection, incompatible pin configurations are likely cause. AXIS equipment and universal equipment use different pin position assignments for power, ground, and video signals within physically identical 4-pin aviation connectors. This converter bridges the gap by routing signals from AXIS pin positions to corresponding universal pin positions. Check equipment specifications or contact manufacturers to determine pinout standard used. If mixing equipment brands and experiencing connection issues, this converter typically resolves compatibility problems.
Can I use this converter in both directions?
Yes, the HDC/AX-F functions bidirectionally converting either AXIS-to-Universal or Universal-to-AXIS depending on connection orientation. Connect AXIS equipment to the AXIS female end and universal equipment to the Universal female end regardless of whether AXIS device is camera or monitor. For example, connecting AXIS camera to universal monitor requires AXIS camera male connector into AXIS converter female end and universal monitor male cable into universal converter female end. Conversely, connecting universal camera to AXIS monitor reverses orientation with universal camera connecting to universal converter end and AXIS monitor connecting to AXIS converter end. The converter simply routes signals between pin positions functioning equally well in either direction.
Will this converter affect video quality?
The HDC/AX-F maintains video signal integrity without introducing noticeable quality degradation when properly installed. Quality internal wiring and gold-plated contacts minimize resistance and signal loss preserving original video quality from camera to monitor. However, converter introduces additional connection points which could potentially affect signal if connectors become corroded or contaminated over time. Ensure coupling nuts tighten securely maintaining weatherproof seal and inspect connectors periodically for corrosion or damage. Proper maintenance preserves video quality throughout converter service life. Any video quality issues typically result from incompatible equipment or damaged cables rather than converter itself when converter selected correctly for application.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS HDC/AX-M - 4-Pin (M) to Universal 4-Pin (M) Converter
Pin configuration converter cable featuring AXIS 4-pin male to Universal 4-pin male aviation connector compatibility, flexible pin arrangement conversion, direct equipment-to-equipment connection adaptation, weatherproof aviation-grade construction, and compatibility bridge enabling AXIS proprietary pinout devices to connect with universal standard 4-pin equipment female ports in vehicle camera and monitoring systems.
Product Overview
The AXIS HDC/AX-M allows for flexible pin configuration offering the ability to switch from AXIS type to Universal type. This converter cable solves compatibility challenges between AXIS proprietary 4-pin pinout configuration and universal standard 4-pin pinout used by various camera and monitor manufacturers. The 4-pin aviation connector format maintains weatherproof sealing and vibration resistance essential for vehicle applications while converting signal pin arrangement between incompatible standards. AXIS brand cameras, monitors, and equipment utilize specific pin configuration placing power, ground, and video signals on designated pins within 4-pin aviation connector.
Universal standard equipment from other manufacturers uses different pin arrangement placing identical signals on different pin positions within physically identical 4-pin aviation connector. Without this converter, physically compatible connectors fail to establish proper electrical connection because power may connect to video pin, ground to power pin, or other incorrect pin mapping causing equipment malfunction or damage.
This adapter cable features AXIS 4-pin male connector on one end plugging into female ports on AXIS equipment such as monitors, recorders, or distribution panels. The opposite end features Universal 4-pin male connector plugging into female ports on universal standard equipment such as monitors, recorders, or cameras utilizing industry-standard pinout. Internal wiring within converter cable routes signals from AXIS pin positions to corresponding universal pin positions ensuring proper power, ground, and video signal connections.
The male-to-male configuration enables direct connection between equipment female ports without requiring intermediate extension cables or additional adapters when bridging AXIS and universal equipment. Aviation-grade connector construction provides IP67-rated weatherproof sealing when properly mated to equipment female ports protecting electrical connections from moisture ingress, dust contamination, and corrosive salt spray typical in marine, agricultural, and mining vehicle applications. Threaded coupling nuts on both connectors ensure secure mechanical connection resistant to vibration, shock, and cable tension preventing accidental disconnection during vehicle operation.
Gold-plated contact pins minimize electrical resistance and prevent corrosion ensuring reliable signal transmission and power delivery over extended service life in harsh environmental conditions. Compact design minimizes cable bulk and maintains installation flexibility in confined spaces typical of equipment mounting locations and wiring harnesses behind vehicle dashboards or equipment panels.
Features & Benefits
AXIS to Universal Pin Conversion Bridges compatibility gap between AXIS proprietary 4-pin pinout and universal standard 4-pin configuration enabling direct equipment connection between different manufacturer standards. This compatibility eliminates need to replace entire camera systems or monitors when mixing equipment brands reducing total system cost and enabling gradual system upgrades.
Male-to-Male Configuration Both ends feature male connectors plugging directly into equipment female ports enabling connection between monitor inputs, camera outputs, or distribution panel ports without intermediate extension cables. This direct connection reduces connection points minimizing potential failure locations and maintaining compact installation in equipment-dense mounting areas.
Aviation-Grade Weatherproof Construction IP67-rated sealing when properly mated to equipment female ports protects electrical connections from moisture, dust, and environmental contamination typical in outdoor vehicle applications. This weatherproofing ensures reliable operation in rain, dust storms, vehicle washing, and extreme humidity conditions preventing corrosion-related failures.
Threaded Locking Mechanism Coupling nuts on both connectors provide secure mechanical connection resistant to vibration and accidental disconnection when properly tightened into equipment female ports. This positive locking prevents intermittent connections or complete disconnection during vehicle operation over rough terrain maintaining continuous monitoring capability.
Gold-Plated Contact Pins Gold plating on electrical contacts minimizes contact resistance and prevents oxidation ensuring long-term signal integrity and power delivery reliability. Standard tin or nickel contacts corrode over time increasing resistance and causing video signal degradation or intermittent power delivery especially in high-humidity or salt-spray environments.
Direct Equipment Connection Male-to-male design enables connection directly between equipment female ports without requiring separate extension cables or additional female-to-female adapters. This simplifies system wiring reducing cable clutter and eliminating unnecessary connection points that could introduce signal degradation or mechanical failure points.
Plug-and-Play Installation Simple connection into equipment female ports requires no tools, soldering, or technical expertise enabling quick field installation or system reconfiguration. This simplicity reduces installation labor costs and allows operators to perform equipment changes without specialized technical support or extensive downtime.
Signal Integrity Preservation Quality internal wiring and proper shielding maintain video signal quality without introducing noise, interference, or voltage drop. Inferior adapters use inadequate wire gauge or poor shielding causing video distortion, power supply problems, or electromagnetic interference affecting camera and monitor performance.
Technical Specifications
Specification
Details
Model
AXIS HDC/AX-M
Connector Type
4-Pin Aviation
End 1 Configuration
AXIS 4-Pin Male
End 2 Configuration
Universal 4-Pin Male
Pin Conversion
AXIS Pinout to Universal Standard Pinout
Gender
Male to Male (M-M)
Weatherproof Rating
IP67 Sealed (when mated)
Coupling Method
Threaded Locking Nuts
Contact Plating
Gold-Plated Pins
Compatible Equipment
Monitors, Cameras, Recorders, Distribution Panels
Application
Vehicle Camera/Monitor Systems
Barcode/EAN
9321886015515
Installation & Compatibility
Equipment Compatibility The HDC/AX-M converter enables connection between AXIS proprietary pinout equipment and universal standard pinout equipment with female input/output ports. AXIS-compatible equipment includes AXIS brand monitors, recorders, and distribution panels utilizing AXIS-specific pin configuration on female ports. Universal-compatible equipment includes monitors, cameras, and recorders from manufacturers using industry-standard 4-pin pinout configuration on female ports. Verify equipment pinout specifications before purchasing converter to confirm compatibility requirements. Incorrect converter selection results in continued incompatibility despite physical connector compatibility.
Pin Configuration Understanding 4-pin aviation connectors for camera systems typically carry power positive, ground negative, video signal positive, and video signal ground on four pins within connector. AXIS pinout assigns these signals to specific pin positions differing from universal standard pin position assignments. This converter internally routes signals from AXIS pin positions to universal pin positions enabling proper electrical connection. Understanding this distinction prevents damage from connecting incompatible equipment without appropriate converter.
Connection Process Insert AXIS 4-pin male end of converter into female port on AXIS equipment such as monitor input, recorder input, or AXIS distribution panel output. Insert Universal 4-pin male end of converter into female port on universal standard equipment such as monitor input, camera connector, or universal distribution panel. Ensure threaded coupling nuts engage equipment female port threads and tighten hand-tight securing mechanical connection and maintaining weatherproof seal. Verify correct converter orientation matching AXIS equipment port to AXIS converter end and universal equipment port to universal converter end.
System Testing After Installation After connecting converter between equipment ports, power system and verify video display appears on monitor confirming proper pin mapping and signal routing. Test image should show clear video without distortion, color abnormalities, or interference indicating successful conversion. If video fails to appear, verify converter orientation ensuring AXIS equipment connects to AXIS converter end and universal equipment connects to universal end. Check all coupling nuts tightened securely into equipment ports and inspect connectors for damaged pins or contamination.
Cable Management Position converter cable to minimize stress on equipment female ports preventing leverage forces that could damage port mounting or internal circuit board connections. Use cable ties to secure converter cable to vehicle structure near equipment mounting location reducing movement and vibration transmission to delicate port connections. Protect converter from sharp edges, moving components, and high-heat sources that could damage cable insulation or connector housings.
Multiple Converter Use In systems with multiple cameras or monitors, separate converter may be required for each connection if mixing AXIS and universal equipment throughout system. Label converters identifying which equipment connection each serves simplifying future troubleshooting and maintenance. Alternatively, use consistent pinout standard throughout system avoiding need for multiple converters by selecting all AXIS or all universal equipment during initial purchase.
Frequently Asked Questions
What is the difference between HDC/AX-M and HDC/AX-F converters?
The HDC/AX-M features male-to-male (M-M) connectors while HDC/AX-F features female-to-female (F-F) connectors serving different connection scenarios. HDC/AX-M male connectors plug directly into equipment female ports connecting monitor inputs to camera outputs or linking distribution panels without intermediate cables. HDC/AX-F female connectors accept existing male cable ends enabling inline conversion between camera cables and monitor input cables. Choose HDC/AX-M when connecting directly between equipment female ports. Choose HDC/AX-F when connecting between existing male-terminated cables. Both converters perform identical pin configuration conversion between AXIS and universal standards but accommodate different physical connection requirements. Some installations may require both converter types depending on equipment configuration and existing cable terminations.
Can I use this converter to connect AXIS camera to universal monitor?
Yes, if both camera and monitor have female ports accepting male connectors. Insert AXIS male end into camera female output port and Universal male end into monitor female input port. However, if camera has male connector cable or monitor has male input cable, you need HDC/AX-F female-to-female converter instead to accept existing male cables. Verify your equipment connection types before selecting converter. Many cameras come with attached male cables requiring female-to-female converters while some cameras and most monitors have female ports requiring male-to-male converters. Check equipment specifications or physically inspect connection types to determine correct converter gender configuration for your application.
Will this converter work with extension cables?
The HDC/AX-M does not directly connect to standard extension cables which typically feature male-to-female configuration. This male-to-male converter connects between two female ports on equipment or distribution panels. To use converter with extension cables, you need extension cable with female-to-female configuration or additional gender-changing adapters. Alternatively, use HDC/AX-F female-to-female converter which accepts male connectors from standard extension cables enabling inline conversion. For complex systems mixing AXIS and universal equipment with various cable types, consider creating complete wiring diagram identifying all connection points and required converter types before purchasing to ensure correct adapter selection for each connection point.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS HDC/AX-M - 4-Pin (M) to Universal 4-Pin (M) Converter
Pin configuration converter cable featuring AXIS 4-pin male to Universal 4-pin male aviation connector compatibility, flexible pin arrangement conversion, direct equipment-to-equipment connection adaptation, weatherproof aviation-grade construction, and compatibility bridge enabling AXIS proprietary pinout devices to connect with universal standard 4-pin equipment female ports in vehicle camera and monitoring systems.
Product Overview
The AXIS HDC/AX-M allows for flexible pin configuration offering the ability to switch from AXIS type to Universal type. This converter cable solves compatibility challenges between AXIS proprietary 4-pin pinout configuration and universal standard 4-pin pinout used by various camera and monitor manufacturers. The 4-pin aviation connector format maintains weatherproof sealing and vibration resistance essential for vehicle applications while converting signal pin arrangement between incompatible standards. AXIS brand cameras, monitors, and equipment utilize specific pin configuration placing power, ground, and video signals on designated pins within 4-pin aviation connector. Universal standard equipment from other manufacturers uses different pin arrangement placing identical signals on different pin positions within physically identical 4-pin aviation connector. Without this converter, physically compatible connectors fail to establish proper electrical connection because power may connect to video pin, ground to power pin, or other incorrect pin mapping causing equipment malfunction or damage. This adapter cable features AXIS 4-pin male connector on one end plugging into female ports on AXIS equipment such as monitors, recorders, or distribution panels. The opposite end features Universal 4-pin male connector plugging into female ports on universal standard equipment such as monitors, recorders, or cameras utilizing industry-standard pinout. Internal wiring within converter cable routes signals from AXIS pin positions to corresponding universal pin positions ensuring proper power, ground, and video signal connections. The male-to-male configuration enables direct connection between equipment female ports without requiring intermediate extension cables or additional adapters when bridging AXIS and universal equipment. Aviation-grade connector construction provides IP67-rated weatherproof sealing when properly mated to equipment female ports protecting electrical connections from moisture ingress, dust contamination, and corrosive salt spray typical in marine, agricultural, and mining vehicle applications. Threaded coupling nuts on both connectors ensure secure mechanical connection resistant to vibration, shock, and cable tension preventing accidental disconnection during vehicle operation. Gold-plated contact pins minimize electrical resistance and prevent corrosion ensuring reliable signal transmission and power delivery over extended service life in harsh environmental conditions. Compact design minimizes cable bulk and maintains installation flexibility in confined spaces typical of equipment mounting locations and wiring harnesses behind vehicle dashboards or equipment panels.
Features & Benefits
AXIS to Universal Pin Conversion Bridges compatibility gap between AXIS proprietary 4-pin pinout and universal standard 4-pin configuration enabling direct equipment connection between different manufacturer standards. This compatibility eliminates need to replace entire camera systems or monitors when mixing equipment brands reducing total system cost and enabling gradual system upgrades.
Male-to-Male Configuration Both ends feature male connectors plugging directly into equipment female ports enabling connection between monitor inputs, camera outputs, or distribution panel ports without intermediate extension cables. This direct connection reduces connection points minimizing potential failure locations and maintaining compact installation in equipment-dense mounting areas.
Aviation-Grade Weatherproof Construction IP67-rated sealing when properly mated to equipment female ports protects electrical connections from moisture, dust, and environmental contamination typical in outdoor vehicle applications. This weatherproofing ensures reliable operation in rain, dust storms, vehicle washing, and extreme humidity conditions preventing corrosion-related failures.
Threaded Locking Mechanism Coupling nuts on both connectors provide secure mechanical connection resistant to vibration and accidental disconnection when properly tightened into equipment female ports. This positive locking prevents intermittent connections or complete disconnection during vehicle operation over rough terrain maintaining continuous monitoring capability.
Gold-Plated Contact Pins Gold plating on electrical contacts minimizes contact resistance and prevents oxidation ensuring long-term signal integrity and power delivery reliability. Standard tin or nickel contacts corrode over time increasing resistance and causing video signal degradation or intermittent power delivery especially in high-humidity or salt-spray environments.
Direct Equipment Connection Male-to-male design enables connection directly between equipment female ports without requiring separate extension cables or additional female-to-female adapters. This simplifies system wiring reducing cable clutter and eliminating unnecessary connection points that could introduce signal degradation or mechanical failure points.
Plug-and-Play Installation Simple connection into equipment female ports requires no tools, soldering, or technical expertise enabling quick field installation or system reconfiguration. This simplicity reduces installation labor costs and allows operators to perform equipment changes without specialized technical support or extensive downtime.
Signal Integrity Preservation Quality internal wiring and proper shielding maintain video signal quality without introducing noise, interference, or voltage drop. Inferior adapters use inadequate wire gauge or poor shielding causing video distortion, power supply problems, or electromagnetic interference affecting camera and monitor performance.
Technical Specifications
Specification
Details
Model
AXIS HDC/AX-M
Connector Type
4-Pin Aviation
End 1 Configuration
AXIS 4-Pin Male
End 2 Configuration
Universal 4-Pin Male
Pin Conversion
AXIS Pinout to Universal Standard Pinout
Gender
Male to Male (M-M)
Weatherproof Rating
IP67 Sealed (when mated)
Coupling Method
Threaded Locking Nuts
Contact Plating
Gold-Plated Pins
Compatible Equipment
Monitors, Cameras, Recorders, Distribution Panels
Application
Vehicle Camera/Monitor Systems
Barcode/EAN
9321886015515
Installation & Compatibility
Equipment Compatibility The HDC/AX-M converter enables connection between AXIS proprietary pinout equipment and universal standard pinout equipment with female input/output ports. AXIS-compatible equipment includes AXIS brand monitors, recorders, and distribution panels utilizing AXIS-specific pin configuration on female ports. Universal-compatible equipment includes monitors, cameras, and recorders from manufacturers using industry-standard 4-pin pinout configuration on female ports. Verify equipment pinout specifications before purchasing converter to confirm compatibility requirements. Incorrect converter selection results in continued incompatibility despite physical connector compatibility.
Pin Configuration Understanding 4-pin aviation connectors for camera systems typically carry power positive, ground negative, video signal positive, and video signal ground on four pins within connector. AXIS pinout assigns these signals to specific pin positions differing from universal standard pin position assignments. This converter internally routes signals from AXIS pin positions to universal pin positions enabling proper electrical connection. Understanding this distinction prevents damage from connecting incompatible equipment without appropriate converter.
Connection Process Insert AXIS 4-pin male end of converter into female port on AXIS equipment such as monitor input, recorder input, or AXIS distribution panel output. Insert Universal 4-pin male end of converter into female port on universal standard equipment such as monitor input, camera connector, or universal distribution panel. Ensure threaded coupling nuts engage equipment female port threads and tighten hand-tight securing mechanical connection and maintaining weatherproof seal. Verify correct converter orientation matching AXIS equipment port to AXIS converter end and universal equipment port to universal converter end.
System Testing After Installation After connecting converter between equipment ports, power system and verify video display appears on monitor confirming proper pin mapping and signal routing. Test image should show clear video without distortion, color abnormalities, or interference indicating successful conversion. If video fails to appear, verify converter orientation ensuring AXIS equipment connects to AXIS converter end and universal equipment connects to universal end. Check all coupling nuts tightened securely into equipment ports and inspect connectors for damaged pins or contamination.
Cable Management Position converter cable to minimize stress on equipment female ports preventing leverage forces that could damage port mounting or internal circuit board connections. Use cable ties to secure converter cable to vehicle structure near equipment mounting location reducing movement and vibration transmission to delicate port connections. Protect converter from sharp edges, moving components, and high-heat sources that could damage cable insulation or connector housings.
Multiple Converter Use In systems with multiple cameras or monitors, separate converter may be required for each connection if mixing AXIS and universal equipment throughout system. Label converters identifying which equipment connection each serves simplifying future troubleshooting and maintenance. Alternatively, use consistent pinout standard throughout system avoiding need for multiple converters by selecting all AXIS or all universal equipment during initial purchase.
Frequently Asked Questions
What is the difference between HDC/AX-M and HDC/AX-F converters?
The HDC/AX-M features male-to-male (M-M) connectors while HDC/AX-F features female-to-female (F-F) connectors serving different connection scenarios. HDC/AX-M male connectors plug directly into equipment female ports connecting monitor inputs to camera outputs or linking distribution panels without intermediate cables. HDC/AX-F female connectors accept existing male cable ends enabling inline conversion between camera cables and monitor input cables. Choose HDC/AX-M when connecting directly between equipment female ports. Choose HDC/AX-F when connecting between existing male-terminated cables. Both converters perform identical pin configuration conversion between AXIS and universal standards but accommodate different physical connection requirements. Some installations may require both converter types depending on equipment configuration and existing cable terminations.
Can I use this converter to connect AXIS camera to universal monitor?
Yes, if both camera and monitor have female ports accepting male connectors. Insert AXIS male end into camera female output port and Universal male end into monitor female input port. However, if camera has male connector cable or monitor has male input cable, you need HDC/AX-F female-to-female converter instead to accept existing male cables. Verify your equipment connection types before selecting converter. Many cameras come with attached male cables requiring female-to-female converters while some cameras and most monitors have female ports requiring male-to-male converters. Check equipment specifications or physically inspect connection types to determine correct converter gender configuration for your application.
Will this converter work with extension cables?
The HDC/AX-M does not directly connect to standard extension cables which typically feature male-to-female configuration. This male-to-male converter connects between two female ports on equipment or distribution panels. To use converter with extension cables, you need extension cable with female-to-female configuration or additional gender-changing adapters. Alternatively, use HDC/AX-F female-to-female converter which accepts male connectors from standard extension cables enabling inline conversion. For complex systems mixing AXIS and universal equipment with various cable types, consider creating complete wiring diagram identifying all connection points and required converter types before purchasing to ensure correct adapter selection for each connection point.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS XR53 - 5 Inch 3-Way Coaxial Speakers
5.25-inch 3-way coaxial speaker system featuring long-throw acoustic drivers, 48mm slim depth, 150W peak power, 93dB sensitivity, 60-23,000Hz response, and 4-ohm impedance for door or shelf installation.
Product Overview
Experience clear and superior sound quality with the AXIS XR53 5.25" 3-Way Coaxial Speaker System. Designed with slim mounting depth of 48mm, these speakers are perfect for installation in vehicle doors or rear shelves. The long-throw acoustic drivers have been specially engineered to deliver exceptional sound ensuring enjoyment of music and entertainment while on the open road. The 3-way coaxial design integrates woofer, midrange, and tweeter into single compact assembly providing full-range audio reproduction from deep bass through crisp high frequencies. Anti-resonance steel basket construction provides rigid mounting platform minimizing vibrations while mica-filled polypropylene cone combines lightweight responsiveness with rigidity preventing distortion during loud passages. Long-throw acoustic engineering maximizes cone excursion within compact mounting depth allowing greater air displacement and improved bass output. The flux-density strontium magnet weighing 10 ounces provides strong magnetic field ensuring precise voice coil control while ferro-cooled voice coil design improves thermal management preventing thermal compression during high-power operation. Peak power handling of 150 watts accommodates dynamic musical peaks while 35-watt nominal rating provides sustainable output for extended listening. Recommended amplification of 25-50 watts matches typical aftermarket head unit outputs ensuring optimal performance. Wide 60Hz-23,000Hz frequency response reproduces entire audible spectrum while high 93dB sensitivity enables loud playback from modest amplifier power. Standard 4-ohm impedance matches most aftermarket equipment and the shallow 48mm mounting depth enables installation in doors with limited clearance behind speaker locations.
Features & Benefits
3-Way Coaxial Design Integrated woofer, midrange, and tweeter provide full-range audio reproduction from single speaker assembly. This design eliminates complexity of separate component systems while delivering superior sound quality with excellent frequency response.
5.25-Inch Driver Size Optimal size balances bass output capability with universal fitment compatibility. Provides significantly improved bass response compared to smaller speakers while maintaining compact dimensions for installation without extensive modifications.
48mm Slim Mounting Depth Shallow profile enables installation in doors with limited clearance accommodating power window mechanisms and door lock assemblies. Expands installation possibilities compared to deeper speakers in space-constrained locations.
Long-Throw Acoustic Drivers Engineered design maximizes cone excursion within compact mounting depth allowing greater air displacement and improved bass output. Provides dynamic range typically associated with larger speakers while maintaining slim installation profile.
Anti-Resonance Steel Basket Rigid steel frame minimizes vibrations and resonances ensuring accurate sound reproduction. Maintains structural integrity under high power levels preserving audio fidelity where standard stamped baskets would flex.
Mica-Filled Polypropylene Cone Advanced cone material combines lightweight responsiveness with rigidity maintaining cone shape under high excursion. Mica reinforcement increases stiffness extending piston range and improving midrange clarity.
High-Excursion Foam Surround Specialized surround accommodates extended cone travel without mechanical failure. Maintains linear excursion throughout power range preventing edge distortion typical of inferior surrounds.
Flux-Density Strontium Magnet High-strength 10-ounce magnet provides strong consistent magnetic field ensuring precise voice coil control and efficient power conversion. Improves transient response, extends bass output, and increases power handling.
Ferro-Cooled Voice Coil Advanced thermal management dissipates heat during high-power operation preventing thermal compression and voice coil damage. Maintains consistent performance during extended high-volume listening.
150W Peak Power Handling High peak rating accommodates brief musical transients and dynamic peaks without distortion or damage. Provides headroom for loud passages ensuring clean reproduction during demanding musical content.
Wide Frequency Response 60Hz-23,000Hz range reproduces entire audible spectrum from deep bass fundamentals through ultrasonic harmonics. Extended response ensures full-range reproduction contributing to perceived clarity and natural sound quality.
93dB High Sensitivity Efficient design produces high output with relatively low amplifier power. Speakers sound louder with same amplifier power compared to low-sensitivity designs or maintain same volume with reduced distortion.
4-Ohm Standard Impedance Standard impedance matches most aftermarket head units and amplifiers ensuring optimal power transfer. Extracts maximum power from head units while maintaining compatibility with amplifier outputs.
Technical Specifications
Specification
Details
Model
AXIS XR53
System Type
3-Way Coaxial
Driver Size
5.25" (130mm)
Frame Construction
Anti-Resonance Steel Basket
Woofer Cone
Mica-Filled Polypropylene
Driver Engineering
Long Throw Acoustic Design
Surround Type
High Excursion Foam Surround Edge
Magnet Type
Flux Density Strontium
Magnet Weight
10oz (283g)
Voice Coil
Ferro-Cooled Design
Peak Power Handling
150W
Nominal Power Handling
35W RMS
Recommended Amplification
25-50W RMS
Frequency Response
60-23,000Hz (+/-3dB)
Sensitivity
93dB (1m/1w)
Nominal Impedance
4 Ohms
Mounting Depth
48mm (1.89")
Mounting Application
Flush Mount Door or Rear Shelf
Quantity
Pair (2 Speakers)
Barcode/EAN
9321886014778
Installation & Compatibility
Vehicle Compatibility The XR53 5.25-inch speakers fit most vehicles with factory 5.25" or 5x7" speaker locations in doors or rear shelves. The shallow 48mm mounting depth accommodates doors with power window mechanisms and door lock assemblies. Verify mounting depth clearance by measuring distance from mounting surface to obstructions behind speaker location before purchase.
Amplification Requirements Speakers perform optimally with 25-50 watts RMS amplification per channel matching typical aftermarket head unit outputs and small amplifiers. Speakers function adequately powered directly from head unit outputs but benefit from dedicated amplifier providing increased volume, improved bass response, and reduced distortion. Avoid exceeding 50 watts RMS continuous power.
Installation Planning Gather necessary materials including speaker wire (16-18 gauge), wire connectors, and mounting hardware. Remove factory speakers noting wire colors and polarity markings. Measure mounting depth clearance verifying 48mm minimum clearance. Consider sound deadening installation on door panels improving bass response and reducing rattles.
Wiring Process Connect speaker wires observing correct polarity ensuring positive terminal connects to positive amplifier output and negative to negative output. Incorrect polarity causes phase cancellation reducing bass output. Use crimp connectors, solder connections, or spring terminals ensuring secure electrical connections preventing intermittent contact.
Physical Mounting Mount speakers in factory locations using supplied or factory mounting hardware ensuring secure attachment. Tighten mounting screws evenly preventing speaker frame warping. Verify speaker clears window mechanism and door lock assembly. Test window operation through full travel confirming no interference with speaker frame or magnet.
System Testing Test speakers at moderate volume confirming both speakers produce sound without distortion or rattling. Verify correct polarity by checking bass response; properly phased speakers produce strong focused bass whereas out-of-phase speakers sound hollow. Adjust head unit or amplifier gain settings optimizing volume without clipping.
Break-In Period Play speakers at moderate volume levels for 10-20 hours before demanding maximum output. During break-in, foam surrounds soften and suspension loosens improving excursion linearity and bass response. Avoid maximum volume during initial hours preventing mechanical damage before proper break-in completion.
Frequently Asked Questions
Will these speakers fit my vehicle doors?
The XR53 5.25-inch speakers fit most vehicles with factory 5.25" or 5x7" locations. You need minimum 48mm clearance behind the mounting surface. Measure your door depth before purchasing to confirm fitment.
Do I need an amplifier or can I power these from my head unit?
These speakers work well powered directly from aftermarket head units (18-25W RMS). An amplifier provides louder volume and better bass but isn't required. The high 93dB sensitivity means they sound great with modest power.
How do these compare to factory speakers?
The XR53 provides significant upgrade with louder output, stronger bass, and clearer sound. The 3-way design and quality materials deliver noticeably better performance than standard factory speakers.
What's included in the package?
The package includes a pair of speakers (2 speakers) with mounting hardware. You'll need to supply speaker wire (16-18 gauge recommended) and wire connectors separately.
Can I install these myself?
Yes, installation is straightforward if you're comfortable removing door panels and connecting wires. Ensure correct polarity when wiring and verify the speakers clear your window mechanism before final installation.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
AXIS XR622 - 6 Inch 2-Way Coaxial Speakers
6-inch 2-way coaxial speaker system featuring ABS material construction, rubber surround, 25mm ASV voice coil, 10oz magnet, 110W peak power, 90dB sensitivity, 60Hz-20kHz response, 4-ohm impedance, and 51mm mounting depth for door or shelf installation.
Product Overview
The AXIS XR622 is a cutting-edge 6-inch 2-Way Coaxial Performance Speaker System meticulously crafted to deliver unparalleled audio experience within vehicle confines. Immerse yourself in captivating sound that resonates with sheer power and pristine clarity catering to auditory senses precisely when craved most. The 2-way coaxial design integrates woofer and tweeter into single compact assembly providing full-range audio reproduction from deep bass through crisp high frequencies. ABS material construction provides lightweight durable speaker frame resistant to environmental conditions typical in vehicle applications. Rubber surround accommodates cone excursion providing reliable long-term performance resistant to UV degradation and temperature extremes. The 25mm ASV (Aluminum Square Voice Coil) design improves thermal management and power handling compared to standard round voice coils. The 10-ounce magnet provides strong magnetic field ensuring precise voice coil control and efficient power conversion. Peak power handling of 110 watts accommodates dynamic musical peaks while 25-watt nominal rating provides sustainable output for extended listening. The 60Hz-20kHz frequency response reproduces wide audio spectrum from bass fundamentals through detailed high frequencies. High 90dB sensitivity enables loud playback from modest amplifier power suitable for direct head unit connection. Standard 4-ohm impedance matches most aftermarket equipment ensuring optimal power transfer. Mounting hole diameter of 124-142mm accommodates various factory speaker locations while 51mm mounting depth enables installation in doors with moderate clearance behind speaker locations.
Features & Benefits
2-Way Coaxial Design Integrated woofer and tweeter provide full-range audio reproduction simplifying installation while delivering superior sound quality. Eliminates complexity of separate component systems while maintaining excellent frequency response.
6-Inch Driver Size Larger 6-inch size delivers improved bass output and overall volume compared to smaller 5.25-inch speakers. Fits most vehicles with factory 6-inch or 6x9-inch locations providing upgrade path for enhanced audio performance.
ABS Material Construction Lightweight durable ABS frame provides stable mounting platform resistant to environmental conditions. ABS material withstands temperature extremes and moisture exposure typical in vehicle door installations.
Rubber Surround Durable rubber surround accommodates cone excursion while resisting UV degradation and temperature extremes. Provides reliable long-term performance compared to foam surrounds prone to deterioration in harsh conditions.
25mm ASV Voice Coil Aluminum Square Voice Coil design improves thermal management and power handling compared to standard round coils. Enhanced cooling maintains consistent performance during high-power operation preventing thermal compression.
10-Ounce Magnet Strong magnet structure provides consistent magnetic field ensuring precise voice coil control and efficient power conversion. Improves transient response, extends bass output, and increases power handling.
110W Peak Power Handling High peak rating accommodates brief musical transients and dynamic peaks without distortion. Provides headroom for loud passages ensuring clean reproduction during demanding musical content.
90dB Sensitivity Efficient design produces high output with modest amplifier power enabling loud playback from head unit outputs. High sensitivity provides satisfactory volume without requiring dedicated amplifier installation.
4-Ohm Impedance Standard impedance matches most aftermarket head units and amplifiers ensuring optimal power transfer. Extracts maximum power from head units while maintaining amplifier compatibility.
51mm Mounting Depth Moderate mounting depth accommodates most vehicle doors with standard clearance behind speaker locations. Enables installation without extensive modifications in typical door configurations.
Technical Specifications
Specification
Details
Model
AXIS XR622
System Type
2-Way Coaxial
Driver Size
6 Inches (152mm)
Frame Material
ABS
Surround Type
Rubber
Voice Coil Size
25mm
Voice Coil Type
ASV (Aluminum Square Voice Coil)
Magnet Size
80 x 32 x 12mm
Magnet Weight
10oz (283g)
Peak Power Handling
110W
Nominal Power Handling
25W RMS
Frequency Response
60Hz-20kHz
Sensitivity
90dB (1m/1w)
Nominal Impedance
4 Ohms
Mounting Hole Diameter
124-142mm
Mounting Depth
51mm (2.0")
Mounting Application
Door or Rear Shelf
Quantity
Pair (2 Speakers)
Barcode/EAN
9321886016024
Installation & Compatibility
Vehicle Compatibility The XR622 6-inch speakers fit most vehicles with factory 6-inch or 6x9-inch speaker locations in doors or rear shelves. The 51mm mounting depth accommodates standard door configurations with moderate clearance. Verify mounting hole diameter (124-142mm) and depth clearance before purchase by measuring existing speaker locations.
Amplification Requirements Speakers perform well with 25-50 watts RMS amplification per channel. The 90dB sensitivity enables satisfactory volume powered directly from aftermarket head unit outputs. Dedicated amplifier provides increased volume and improved bass response but isn't required for most listeners.
Installation Planning Gather speaker wire (16-18 gauge), wire connectors, and mounting hardware. Remove factory speakers noting wire colors and polarity markings. Measure mounting hole diameter and depth clearance verifying compatibility. Consider sound deadening material on door panels for improved bass response.
Wiring Process Connect speaker wires observing correct polarity with positive terminal to positive amplifier output and negative to negative. Use crimp connectors, solder connections, or spring terminals ensuring secure electrical connections. Incorrect polarity causes phase cancellation reducing bass output.
Physical Mounting Mount speakers using supplied or factory mounting hardware ensuring secure attachment. Tighten screws evenly preventing speaker frame warping. Verify speaker clears window mechanism and door lock assembly. Test window operation through full travel confirming no interference.
System Testing Test speakers at moderate volume confirming both speakers produce sound without distortion or rattling. Verify correct polarity by checking bass response; properly phased speakers produce strong focused bass. Adjust head unit gain settings optimizing volume without clipping.
Break-In Period Play speakers at moderate volume for 10-20 hours before demanding maximum output. During break-in, rubber surround and suspension components loosen improving excursion linearity and bass response. Avoid maximum volume during initial hours preventing mechanical damage.
Frequently Asked Questions
Will these speakers fit my vehicle?
The XR622 6-inch speakers fit most vehicles with factory 6" or 6x9" locations. You need 124-142mm mounting hole diameter and minimum 51mm depth clearance. Measure your existing speaker locations to confirm fitment.
Do I need an amplifier?
These speakers work well powered directly from aftermarket head units. The 90dB sensitivity provides satisfactory volume without amplifier. Dedicated amplifier improves bass and maximum volume but isn't required for most users.
How do these compare to 5.25-inch speakers?
The 6-inch size delivers noticeably stronger bass output and higher overall volume compared to 5.25-inch speakers. The larger cone area moves more air providing improved low-frequency performance and dynamic range.
What's included in the package?
The package includes a pair of speakers (2 speakers) with mounting hardware. You'll need to supply speaker wire (16-18 gauge recommended) and wire connectors separately.
Can I install these myself?
Yes, installation is straightforward if you're comfortable removing door panels and connecting wires. Ensure correct polarity when wiring and verify speakers clear your window mechanism before final installation.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
