OEX ACX1344 IP68 Rated Nylon 66 Cable Gland 32mm Mounting Hole for 18 to 25mm Cable Pack of 2 Largest in the OEX Range The OEX ACX1344 is a nylon 66 cable gland supplied in a pack of 2, providing a waterproof and secure cable entry point through panels, enclosures and junction boxes. Rated IP68 for full submersion protection and UL approved. Suits conduit and cable diameters of 18 to 25mm with a 32mm mounting hole, 25mm internal diameter and 14.7mm thread length the largest size in the OEX cable gland range, suited to large conduit runs and heavy multi-cable entries. Covered by a one year warranty. Product overview The ACX1344 is the largest gland in the OEX cable gland range, stepping up from the ACX1343 (13 to 18mm, 25mm hole) to a 32mm mounting hole and 18 to 25mm cable and conduit range. It accommodates large conduit runs, 21.1mm convoluted tubing, very heavy multi-core cables and thick cable bundles at the top of the OEX range. At this size, installations typically require only one or two glands per panel entry point, which is reflected in the pack of 2 format. The IP68 rating confirms full sealing against dust and continuous water submersion under pressure. The nylon 66 construction is UL approved for chemical resistance and dimensional stability. The 32mm mounting hole is the largest in the OEX gland range and will require a hole saw or step drill to prepare in most panel materials. The 14.7mm thread length limits suitability to panels within that thickness confirm panel thickness before installation. Features and benefits IP68 rated: Fully sealed against dust and continuous water submersion under pressure, the highest standard ingress protection rating, suited to marine, submerged and fully exposed outdoor applications. UL approved nylon 66: High-strength, chemically resistant nylon 66 material meeting UL approval standards for cable gland applications. Suits 18 to 25mm cable and conduit largest in the OEX range: Accommodates large conduit, heavy multi-core cables and thick cable bundles at the top of the OEX cable gland range. 32mm mounting hole: The largest mounting hole in the OEX gland range a hole saw or step drill will typically be required to prepare this hole in panel materials. 25mm internal diameter: Large cable passage bore for heavy conduit runs and thick cable bundles. 14.7mm thread length: Provides secure panel engagement confirm panel thickness is within this measurement before installation. Pack of 2: Suited to installations requiring a small number of large-diameter glands, reflecting the typical usage pattern at this size. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1344 Brand OEX Type Cable Gland Material Nylon 66 (UL Approved) Outside Diameter 32mm Inside Diameter 25mm Thread M1.5 Thread Length 14.7mm Mounting Hole 32mm Conduit and Cable Size 18 to 25mm Total Length 49mm IP Rating IP68 Pack Quantity 2 Weight 0.1kg Warranty One year Sold As Pack of 2 Frequently asked questions What is a cable gland used for? A cable gland is a fitting that provides a secure, sealed entry point for a cable or conduit passing through a panel or enclosure wall. It clamps around the cable to prevent movement and chafing, while the sealing mechanism prevents moisture, dust and contaminants from entering through the cable opening. What does IP68 mean? IP68 is an ingress protection rating indicating the fitting is fully sealed against dust (6) and protected against continuous immersion in water under pressure (8). It is the highest standard IP rating, suited to marine, submerged and fully exposed outdoor applications. What cable or conduit sizes does this gland suit? This gland suits cables and conduit with an outer diameter of 18 to 25mm. Confirm the cable or conduit outer diameter falls within this range before purchasing to ensure a correct seal. What size hole does this gland require and does panel thickness matter? The gland requires a 32mm mounting hole. A hole saw or step drill will typically be required to prepare this hole in panel materials. The thread length is 14.7mm, so confirm panel thickness is within this measurement before installation to ensure the locknut engages correctly. How does the ACX1344 compare to the smaller glands in the OEX range? The ACX1344 is the largest gland in the OEX range, suited to 18 to 25mm cable with a 32mm mounting hole. For smaller cables, the ACX1343 suits 13 to 18mm with a 25mm hole, the ACX1342 suits 10 to 14mm with a 20mm hole, the ACX1341 suits 5 to 10mm with a 16mm hole, and the ACX1340 suits 3 to 6.5mm with a 12mm hole. Select the gland that matches your cable or conduit outer diameter and panel hole size. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1343 IP68 Rated Nylon 66 Cable Gland 25mm Mounting Hole for 13 to 18mm Cable Pack of 5 Largest in the OEX Range The OEX ACX1343 is a nylon 66 cable gland supplied in a pack of 5, providing a waterproof and secure cable entry point through panels, enclosures and junction boxes. Rated IP68 for full submersion protection and UL approved. Suits conduit and cable diameters of 13 to 18mm with a 25mm mounting hole, 18.4mm internal diameter and 15.2mm thread length the largest size in the OEX cable gland range, suited to heavy conduit and large cable bundle entries. Covered by a one year warranty. Product overview The ACX1343 is the largest gland in the OEX cable gland range, stepping up from the ACX1342 (10 to 14mm, 20mm hole) to a 25mm mounting hole and 13 to 18mm cable and conduit range. It accommodates heavy main cable runs, 16.3mm convoluted tubing, thick multi-core cables and large conduit that exceed the capacity of all smaller sizes in the range. At this size, fewer glands are typically required per installation, which is reflected in the pack of 5 rather than pack of 10 format. The IP68 rating confirms full sealing against dust and continuous water submersion under pressure. The nylon 66 construction is UL approved for chemical resistance and dimensional stability. The 15.2mm thread length suits panels within that thickness confirm panel thickness before installation. The 25mm mounting hole is the largest standard drilling size in the OEX gland range and may require a step drill or hole saw to prepare in thicker panel materials. Features and benefits IP68 rated: Fully sealed against dust and continuous water submersion under pressure, the highest standard ingress protection rating, suited to marine, submerged and fully exposed outdoor applications. UL approved nylon 66: High-strength, chemically resistant nylon 66 material meeting UL approval standards for cable gland applications. Suits 13 to 18mm cable and conduit largest in the OEX range: Accommodates heavy main cable runs, large convoluted tubing and thick multi-core cables that exceed the capacity of all smaller glands in the range. 25mm mounting hole: The largest mounting hole in the OEX gland range, suited to heavy cable entry points in automotive, marine and caravan panel installations. 18.4mm internal diameter: The cable passage bore through the gland body. 15.2mm thread length: Provides secure panel engagement confirm panel thickness is within this measurement before installation. Pack of 5: Suited to installations requiring fewer large-diameter glands, reflecting the typical usage pattern at this size. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1343 Brand OEX Type Cable Gland Material Nylon 66 (UL Approved) Outside Diameter 25mm Inside Diameter 18.4mm Thread M1.5 Thread Length 15.2mm Mounting Hole 25mm Conduit and Cable Size 13 to 18mm Total Length 39mm IP Rating IP68 Pack Quantity 5 Weight 0.14kg Warranty One year Sold As Pack of 5 Frequently asked questions What is a cable gland used for? A cable gland is a fitting that provides a secure, sealed entry point for a cable or conduit passing through a panel or enclosure wall. It clamps around the cable to prevent movement and chafing, while the sealing mechanism prevents moisture, dust and contaminants from entering through the cable opening. What does IP68 mean? IP68 is an ingress protection rating indicating the fitting is fully sealed against dust (6) and protected against continuous immersion in water under pressure (8). It is the highest standard IP rating, suited to marine, submerged and fully exposed outdoor applications. What cable or conduit sizes does this gland suit? This gland suits cables and conduit with an outer diameter of 13 to 18mm. Confirm the cable or conduit outer diameter falls within this range before purchasing to ensure a correct seal. What size hole does this gland require and does panel thickness matter? The gland requires a 25mm mounting hole. A step drill or hole saw may be required to prepare this hole in thicker panel materials. The thread length is 15.2mm, so confirm panel thickness is within this measurement before installation to ensure the locknut engages correctly. How does the ACX1343 compare to the smaller glands in the OEX range? The ACX1343 is the largest gland in the OEX range, suited to 13 to 18mm cable with a 25mm mounting hole. For smaller cables, the ACX1342 suits 10 to 14mm with a 20mm hole, the ACX1341 suits 5 to 10mm with a 16mm hole, and the ACX1340 suits 3 to 6.5mm with a 12mm hole. Select the gland that matches your cable or conduit outer diameter and panel hole size. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1342 IP68 Rated Nylon 66 Cable Gland 20mm Mounting Hole for 10 to 14mm Cable Pack of 10 The OEX ACX1342 is a nylon 66 cable gland supplied in a pack of 10, providing a waterproof and secure cable entry point through panels, enclosures and junction boxes. Rated IP68 for full submersion protection and UL approved. Suits conduit and cable diameters of 10 to 14mm with a 20mm mounting hole, 14mm internal diameter and 15mm thread length, suited to the larger cables and conduit used in heavier wiring applications. Suited to automotive, marine, caravan and outdoor electrical installations. Covered by a one year warranty. Product overview The ACX1342 is the largest gland in the OEX cable gland range, stepping up from the ACX1341 (5 to 10mm, 16mm hole) to a 20mm mounting hole and 10 to 14mm cable and conduit range. It is suited to heavier wiring applications where larger-diameter cable runs, multi-core cables, 9.7mm or 12.6mm convoluted tubing, or thick individual cables need to pass through a panel with an IP68 sealed entry. The 15mm thread length suits panels within that thickness confirm panel thickness before installation. Like the other glands in the OEX range, the ACX1342 is rated IP68, confirming full sealing against dust and continuous water submersion under pressure. The nylon 66 construction is UL approved for chemical resistance and dimensional stability. The 20mm mounting hole is a common drilling size for larger cable entries in automotive, marine and caravan panel work. The pack of 10 suits workshops and panel builders running multiple cable entries. Features and benefits IP68 rated: Fully sealed against dust and continuous water submersion under pressure, the highest standard ingress protection rating, suited to marine, submerged and fully exposed outdoor applications. UL approved nylon 66: High-strength, chemically resistant nylon 66 material meeting UL approval standards for cable gland applications. Suits 10 to 14mm cable and conduit: The largest cable range in the OEX gland series, accommodating larger cables, multi-core runs and convoluted tubing up to 14mm outer diameter. 20mm mounting hole: Fits a standard 20mm panel hole, compatible with common panel drilling sizes for larger cable entries. 14mm internal diameter: The cable passage bore through the gland body. 15mm thread length: Provides secure panel engagement confirm panel thickness is within this measurement before installation. Pack of 10: Trade-friendly quantity for workshops and panel builders running multiple cable entries. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1342 Brand OEX Type Cable Gland Material Nylon 66 (UL Approved) Outside Diameter 20mm Inside Diameter 14mm Thread M1.5 Thread Length 15mm Mounting Hole 20mm Conduit and Cable Size 10 to 14mm Total Length 43.5mm IP Rating IP68 Pack Quantity 10 Weight 0.16kg Warranty One year Sold As Pack of 10 Frequently asked questions What is a cable gland used for? A cable gland is a fitting that provides a secure, sealed entry point for a cable or conduit passing through a panel or enclosure wall. It clamps around the cable to prevent movement and chafing, while the sealing mechanism prevents moisture, dust and contaminants from entering through the cable opening. What does IP68 mean? IP68 is an ingress protection rating indicating the fitting is fully sealed against dust (6) and protected against continuous immersion in water under pressure (8). It is the highest standard IP rating, suited to marine, submerged and fully exposed outdoor applications. What cable or conduit sizes does this gland suit? This gland suits cables and conduit with an outer diameter of 10 to 14mm. Confirm the cable or conduit outer diameter falls within this range before purchasing to ensure a correct seal. What size hole does this gland require and does panel thickness matter? The gland requires a 20mm mounting hole. The thread length is 15mm, so the panel must be thin enough for the thread to engage fully and the locknut to tighten against the back face. Confirm panel thickness is within this measurement before installation. How does the ACX1342 compare to the other glands in the OEX range? The OEX cable gland range covers three sizes. The ACX1340 suits 3 to 6.5mm cable with a 12mm mounting hole. The ACX1341 suits 5 to 10mm cable with a 16mm mounting hole. The ACX1342 suits 10 to 14mm cable with a 20mm mounting hole. Select the gland that matches your cable or conduit outer diameter and the available panel hole size. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1340 IP68 Rated Nylon 66 Cable Gland 12mm Mounting Hole for 3 to 6.5mm Cable Pack of 10 The OEX ACX1340 is a nylon 66 cable gland supplied in a pack of 10, providing a waterproof and secure cable entry point through panels, enclosures and junction boxes. Rated IP68 for full submersion protection and UL approved. Suits conduit and cable diameters of 3 to 6.5mm with a 12mm mounting hole, 6.9mm internal diameter and 7.9mm thread length. Suited to automotive, marine, caravan and outdoor electrical installations. Covered by a one year warranty. Product overview Where a cable passes through a panel or enclosure wall, an unsealed hole allows moisture, dust, vibration and debris to enter or damage the cable insulation over time. A cable gland solves both problems simultaneously it seals the opening against the environment and clamps around the cable to prevent movement and chafing at the panel edge. The ACX1340 is rated IP68, the highest standard ingress protection rating, confirming it is fully sealed against dust and continuous water submersion under pressure, suited to marine, outdoor and automotive enclosure applications. The gland suits cables and conduit with an outer diameter of 3 to 6.5mm, covering a wide range of light to medium gauge automotive cables. The 12mm mounting hole is a common panel drilling size for small cable glands. The 7.9mm thread length limits suitability to panels within that thickness confirm panel thickness before installation. The nylon 66 construction is UL approved for chemical resistance and dimensional stability. The pack of 10 suits workshops and panel builders running multiple cable entries. Features and benefits IP68 rated: Fully sealed against dust and continuous water submersion under pressure, the highest standard ingress protection rating and suited to marine, submerged and fully exposed outdoor applications. UL approved nylon 66: High-strength, chemically resistant nylon 66 material meeting UL approval standards for cable gland applications. Suits 3 to 6.5mm cable and conduit: Accommodates a range of light to medium gauge cables and conduit outer diameters within this range for a correct seal. 12mm mounting hole: Fits a standard 12mm panel hole, compatible with common panel drilling sizes for small cable glands. 6.9mm internal diameter: The cable passage bore through the gland body. 7.9mm thread length: Secure panel engagement confirm panel thickness is within this measurement before installation. Pack of 10: Trade-friendly quantity for workshops and panel builders running multiple cable entries. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1340 Brand OEX Type Cable Gland Material Nylon 66 (UL Approved) Outside Diameter 12mm Inside Diameter 6.9mm Thread M1.5 Thread Length 7.9mm Mounting Hole 12mm Conduit and Cable Size 3 to 6.5mm Total Length 39mm IP Rating IP68 Pack Quantity 10 Weight 0.04kg Warranty One year Sold As Pack of 10 Frequently asked questions What is a cable gland used for? A cable gland is a fitting that provides a secure, sealed entry point for a cable or conduit passing through a panel or enclosure wall. It clamps around the cable to prevent movement and chafing, while the sealing mechanism prevents moisture, dust and contaminants from entering through the cable opening. What does IP68 mean? IP68 is an ingress protection rating indicating the fitting is fully sealed against dust (6) and protected against continuous immersion in water under pressure (8). It is the highest standard IP rating, suited to marine, submerged and fully exposed outdoor applications. What cable or conduit sizes does this gland suit? This gland suits cables and conduit with an outer diameter of 3 to 6.5mm. Confirm the cable or conduit outer diameter falls within this range before purchasing to ensure a correct seal. What size hole does this gland require and does panel thickness matter? The gland requires a 12mm mounting hole. The thread length is 7.9mm, so the panel must be thin enough for the thread to engage fully and the locknut to tighten against the back face. Confirm panel thickness is within this measurement before installation. Is this gland available in other sizes? OEX produces cable glands in a range of sizes. Contact us for available options to suit larger or smaller cable and conduit diamet Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1311 PVC Coated Zinc Plated Steel P Clips 18mm Inside Diameter 6mm Mounting Hole Pack of 25 The OEX ACX1311 is an 18mm P clip constructed from PVC coated zinc plated steel, supplied in a pack of 25. P clips are used to secure cables, conduit, hoses and wiring harnesses to body panels, chassis rails and mounting surfaces, providing a neat and rattle-free installation. The 6mm mounting hole is compatible with M6 bolts, screws or pop rivets. Covered by a one year warranty. Product overview The ACX1311 steps up from the 12.7mm ACX1310 to an 18mm inside diameter, suited to larger cables, convoluted tubing, fuel hoses, coolant lines, air lines and hydraulic hoses up to 18mm in diameter. The zinc plated steel core provides rigidity and corrosion resistance, with a PVC outer coating that protects both the clip from rust and the cable or hose insulation from being chafed or damaged by direct metal contact. The 6mm mounting hole is compatible with M6 bolts, screws or 6mm pop rivets the standard fastener size for automotive body panel and chassis rail mounting points. The black PVC coating blends with standard automotive wiring presentation. The pack of 25 suits workshops and installers running multiple cable and hose management jobs where this size is needed in trade volume. Features and benefits 18mm inside diameter: Suits cables, conduit and hoses up to 18mm in diameter, stepping up from the 12.7mm ACX1310 for larger cables, tubing and hose runs. PVC coated zinc plated steel: The zinc plated steel core provides rigidity and corrosion resistance. The PVC coating prevents the clip from directly contacting and chafing cable or hose insulation, reducing wear and damage risk over time. 6mm mounting hole: Compatible with M6 bolts, screws or 6mm pop rivets, the standard mounting fastener used in automotive body panel and chassis rail installation. Black: Standard colour for automotive cable management, blending with wiring harnesses and body panels. Pack of 25: Trade-friendly quantity for workshops and fleet installers managing multiple cable and hose runs. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1311 Brand OEX Clip Type P Clip Inside Diameter 18mm Mounting Hole 6mm Material PVC Coated Zinc Plated Steel Colour Black Pack Quantity 25 Weight 0.263kg Warranty One year Sold As Pack of 25 Frequently asked questions What is a P clip used for? A P clip is a cable and hose mounting clip shaped like the letter P. The loop holds the cable, conduit or hose while the flat tab with a mounting hole is fastened to a surface with a bolt, screw or rivet. They are commonly used in automotive wiring to route and secure cables along body panels, chassis rails and firewalls, providing a clean, rattle-free installation. How does the ACX1311 compare to the ACX1310? Both are PVC coated zinc plated steel P clips with a 6mm mounting hole. The ACX1310 has a 12.7mm inside diameter and the ACX1311 has an 18mm inside diameter. Select the ACX1311 where cables, conduit or hoses exceed 12.7mm in diameter. For smaller bundles and hoses, the ACX1310 is the better fit. What size bolt or fastener does this clip use? The mounting hole is 6mm in diameter, compatible with M6 bolts, screws or 6mm pop rivets the standard fastener size for automotive body panel and chassis rail mounting points. Does the PVC coating protect cables from damage? Yes. The PVC coating on the clip loop prevents the steel from directly contacting and chafing the cable or hose insulation, reducing the risk of wear and abrasion damage over time. Is this clip corrosion resistant? The zinc plated steel core provides a degree of corrosion resistance, and the PVC coating adds further protection against moisture. For highly corrosive environments such as marine applications with sustained saltwater exposure, stainless steel P clips may be a more appropriate choice. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1113 Fire Retardant Split Convoluted Tubing 21.1mm Internal Diameter Black 30m Roll Largest Size in the OEX Range The OEX ACX1113 is a split convoluted tubing sleeve in 21.1mm internal diameter, supplied in a 30m length in black. Manufactured from fire retardant polypropylene with a 120°C melting temperature, the split design allows cables to be inserted from the side without threading. At 21.1mm ID and 25.2mm OD with a maximum bundle size of 21.2mm, this is the largest internal diameter in the OEX split convoluted tubing range, suited to heavy multi-cable harnesses and substantial cable runs. Covered by a one year warranty. Product overview The ACX1113 is the largest size in the OEX split convoluted tubing range, stepping up from the 16.3mm (ACX1109, ACX1111, ACX1111/100) to accommodate heavy multi-cable harnesses and large cable groupings that exceed the 16.6mm maximum bundle capacity of the 16.3mm sizes. The fire retardant polypropylene material resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene sleeving in automotive wiring environments. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses without disconnecting connectors. The 30m roll suits workshop jobs and single-vehicle installations where this large diameter is required. Confirm the continuous operating temperature rating with OEX if this is a specific requirement for your underbonnet or high-heat application. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. Fire retardant polypropylene: Resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene in automotive wiring environments. 21.1mm internal diameter largest in the OEX convoluted tubing range: Accommodates heavy multi-cable harnesses up to 21.2mm maximum bundle diameter, the largest capacity available in the OEX range. Black: Supplied in black, suited to standard automotive wiring presentation. Convoluted construction: Flexible and bendable while maintaining cable protection against abrasion and chafing, suited to routing through bends and tight spaces. 120°C melting temperature: Provides resistance to high-temperature environments. 30m roll: Workshop-friendly length for single-vehicle and multi-circuit jobs at this large diameter. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1113 Brand OEX Sleeve Type Split Convoluted Tubing Material Fire Retardant Polypropylene Colour Black Inside Diameter 21.1mm Outside Diameter 25.2mm Maximum Cable Bundle 21.2mm Length 30m Melting Temperature 120°C Weight 1.76kg Warranty One year Sold As 30m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The convoluted ribbed construction gives it flexibility and abrasion resistance. What is fire retardant polypropylene? Polypropylene is a lightweight, chemical-resistant thermoplastic commonly used for convoluted tubing. The fire retardant grade used in this product resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin in automotive wiring environments over standard polypropylene sleeving. How does the ACX1113 compare to the 16.3mm options? The ACX1113 at 21.1mm ID and 21.2mm maximum bundle is the largest size in the OEX range, suited to heavy multi-cable harnesses that exceed the 16.6mm maximum bundle capacity of the 16.3mm range (ACX1109, ACX1111, ACX1111/100). Select the 16.3mm range where the bundle fits, and step up to the ACX1113 only where the larger diameter is genuinely required. What is the continuous operating temperature of the ACX1113? The continuous operating temperature is not confirmed in the current product data for the ACX1113. The melting temperature is 120°C. Contact us to confirm the continuous operating temperature before purchasing if this is a specific requirement for your application. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1111 Fire Retardant Split Convoluted Tubing 16.3mm Internal Diameter Black 50m Roll Largest Size in the OEX Range The OEX ACX1111 is a split convoluted tubing sleeve in 16.3mm internal diameter, supplied in a 50m length in black. Manufactured from fire retardant polypropylene with a 120°C melting temperature, the split design allows cables to be inserted from the side without threading. At 16.3mm ID and 20.9mm OD with a maximum bundle size of 16.6mm, this is the largest internal diameter in the OEX split convoluted tubing range. Suited to automotive, marine and caravan wiring environments. Covered by a one year warranty. Product overview The ACX1111 combines the largest internal diameter in the OEX convoluted tubing range with a fire retardant polypropylene material specification, providing both maximum cable bundle capacity and the added safety margin of fire retardant construction. It suits heavy main wiring harnesses, large multi-cable bundles and thick individual cables that exceed the capacity of the smaller sizes, in installations where fire retardant material is preferred over standard corrugated polypropylene. The fire retardant polypropylene material resists ignition and self-extinguishes if a flame source is removed. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses without disconnecting connectors. The 50m roll is a practical mid-volume trade format suited to workshops needing more coverage than a 10m single-vehicle length without the bulk of a higher-volume roll. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. Fire retardant polypropylene: Resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene in automotive wiring environments. 16.3mm internal diameter — largest in the OEX convoluted tubing range: Accommodates large cable bundles and heavy harnesses up to 16.6mm maximum bundle diameter, suited to main vehicle wiring harnesses and thick multi-cable runs. Black: Supplied in black, suited to standard automotive wiring presentation. Convoluted construction: Flexible and bendable while maintaining cable protection against abrasion and chafing, suited to routing through bends and tight spaces. 120°C melting temperature: Provides resistance to high-temperature environments. 50m roll: Practical mid-volume trade format for workshops requiring more than a single-vehicle run without committing to a high-volume roll. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1111 Brand OEX Sleeve Type Split Convoluted Tubing Material Fire Retardant Polypropylene Colour Black Inside Diameter 16.3mm Outside Diameter 20.9mm Maximum Cable Bundle 16.6mm Length 50m Melting Temperature 120°C Weight 2.08kg Warranty One year Sold As 50m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The convoluted ribbed construction gives it flexibility and abrasion resistance. What is fire retardant polypropylene? Polypropylene is a lightweight, chemical-resistant thermoplastic commonly used for convoluted tubing. The fire retardant grade used in this product resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin in automotive wiring environments over standard polypropylene sleeving. How does the ACX1111 compare to the ACX1109? Both are 16.3mm split convoluted tubing with the same internal diameter and outside diameter. The ACX1109 is made from corrugated polypropylene with a UL HB or V2 flammability rating and is supplied in a 10m length for single-vehicle jobs. The ACX1111 is made from fire retardant polypropylene and is supplied on a 50m roll for trade and multi-vehicle use. Select based on material preference and quantity required. What is the continuous operating temperature of the ACX1111? The continuous operating temperature is not confirmed in the current product data for the ACX1111. The melting temperature is 120°C. Contact us to confirm the continuous operating temperature before purchasing if this is a specific requirement for your application. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1109 Split Convoluted Tubing 16.3mm Internal Diameter 10m Largest Size in the OEX Convoluted Tubing Range The OEX ACX1109 is a split convoluted tubing sleeve in 16.3mm internal diameter, supplied in a 10m length. Constructed from corrugated polypropylene with a UL flammability rating of HB or V2, the split design allows cables to be inserted from the side without threading. At 16.3mm ID and 20.9mm OD with a maximum bundle size of 16.6mm, this is the largest internal diameter in the OEX split convoluted tubing range. Rated for continuous operation from -20°C to +90°C with a 120°C maximum peak temperature. Covered by a one year warranty. Product overview The ACX1109 is the largest size in the OEX split convoluted tubing range, stepping up from the 12.6mm (ACX1108 and ACX1108/150) to accommodate heavy main wiring harnesses, large multi-cable bundles and thick individual cables that exceed the capacity of the smaller sizes. The corrugated polypropylene construction provides flexibility for routing around bends while maintaining abrasion and chafing protection. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses without disconnecting connectors. The UL flammability rating of HB or V2 confirms a tested level of flame resistance suited to general automotive wiring protection. The operating range of -20°C to +90°C continuous with a 120°C maximum peak covers the wide temperature swings of Australian automotive environments. The 10m length suits single-vehicle and short-run installations where a full trade roll is not required for the main harness sections. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. 16.3mm internal diameter largest in the OEX convoluted tubing range: Accommodates large cable bundles and heavy harnesses up to 16.6mm maximum bundle diameter, suited to main vehicle wiring harnesses and thick multi-cable runs. Corrugated polypropylene construction: Flexible and resistant to abrasion and chafing, suited to routing through bends and tight spaces in automotive and marine wiring installations. UL flammability rating HB or V2: Tested flame resistance confirming the material meets automotive wiring protection standards for general use applications. -20°C to +90°C continuous operating range: Covers automotive, underbonnet and cold-climate applications across the wide temperature range typical of Australian conditions. 120°C maximum peak temperature: Provides a safety margin above the continuous rating for short-duration heat exposure. 10m length: Suited to single-vehicle and short-run installations where a full trade roll is not required. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1109 Brand OEX Sleeve Type Split Convoluted Tubing Material Corrugated Polypropylene Inside Diameter 16.3mm Outside Diameter 20.9mm Maximum Cable Bundle 16.6mm Length 10m Continuous Operating Temperature -20°C to +90°C Maximum Peak Temperature 120°C Flammability Rating UL HB or V2 Weight 0.44kg Warranty One year Sold As 10m length Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The corrugated construction gives it flexibility and abrasion resistance. What does the UL HB or V2 flammability rating mean? UL flammability ratings indicate how a material behaves when exposed to flame. HB is the base horizontal burn rating, indicating the material burns slowly or self-extinguishes. V2 indicates the material self-extinguishes within 30 seconds of a vertical flame test, though it may drip flaming particles. Both ratings confirm a level of flame resistance suitable for general automotive wiring protection. How does the ACX1109 compare to the smaller sizes in the OEX convoluted tubing range? The ACX1109 at 16.3mm ID and 16.6mm maximum bundle is the largest size in the OEX range, suited to main vehicle wiring harnesses and heavy multi-cable runs. For smaller bundles, the 12.6mm range (ACX1108, ACX1108/150), 9.7mm range (ACX1104, ACX1105, ACX1105/250) or 7mm range provide progressively smaller options. Select based on the diameter of the cable bundle to be protected. Is this tubing suitable for underbonnet use? Yes. The -20°C to +90°C continuous operating range and 120°C maximum peak temperature make it suitable for most automotive underbonnet environments. For areas with sustained extreme heat exposure, verify the ambient temperature against the tubing rating before use. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1104 Split Convoluted Tubing 9.7mm Internal Diameter 30m Roll Corrugated Polypropylene UL HB/V2 The OEX ACX1104 is a split convoluted tubing sleeve in 9.7mm internal diameter, supplied in a 30m length. Constructed from corrugated polypropylene with a UL flammability rating of HB or V2, the split design allows cables to be inserted from the side without threading. At 9.7mm ID and 12.8mm OD with a maximum bundle size of 9.9mm, it accommodates larger cable bundles than the 7mm range. Rated for continuous operation from -20°C to +90°C with a 120°C maximum peak temperature. Covered by a one year warranty. Product overview The ACX1104 steps up from the 7mm convoluted tubing range to a 9.7mm internal diameter, suited to medium-sized cable bundles and individual larger-gauge cables that would not fit or would be a tight squeeze in the 7mm options. The corrugated polypropylene construction provides flexibility for routing around bends while maintaining abrasion and chafing protection. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses without disconnecting connectors. The UL flammability rating of HB or V2 confirms a tested level of flame resistance suited to general automotive wiring protection. The operating range of -20°C to +90°C continuous with a 120°C maximum peak temperature covers the wide temperature swings typical of Australian automotive environments. The 30m roll suits workshop jobs and single-vehicle installations across automotive, 4WD, caravan, trailer and marine wiring applications. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. 9.7mm internal diameter and 12.8mm outside diameter: Accommodates larger cable bundles than the 7mm range, with a maximum bundle size of 9.9mm suited to medium-sized wire bundles and individual larger-gauge cables. Corrugated polypropylene construction: Flexible and resistant to abrasion and chafing, suited to routing through bends and tight spaces in automotive and marine wiring installations. UL flammability rating HB or V2: Tested flame resistance confirming the material meets automotive wiring protection standards for general use applications. -20°C to +90°C continuous operating range: Covers automotive, underbonnet and cold-climate applications across the wide temperature range typical of Australian conditions. 120°C maximum peak temperature: Provides a safety margin above the continuous rating for short-duration heat exposure. 30m roll: Workshop-friendly length for single-vehicle and multi-circuit jobs without the bulk of a larger trade roll. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1104 Brand OEX Sleeve Type Split Convoluted Tubing Material Corrugated Polypropylene Inside Diameter 9.7mm Outside Diameter 12.8mm Maximum Cable Bundle 9.9mm Length 30m Continuous Operating Temperature -20°C to +90°C Maximum Peak Temperature 120°C Flammability Rating UL HB or V2 Weight 0.46kg Warranty One year Sold As 30m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The corrugated construction gives it flexibility and abrasion resistance. What does the UL HB or V2 flammability rating mean? UL flammability ratings indicate how a material behaves when exposed to flame. HB is the base horizontal burn rating, indicating the material burns slowly or self-extinguishes. V2 indicates the material self-extinguishes within 30 seconds of a vertical flame test, though it may drip flaming particles. Both ratings confirm a level of flame resistance suitable for general automotive wiring protection. How does the ACX1104 compare to the 7mm options in the OEX range? The ACX1104 has a 9.7mm internal diameter and 9.9mm maximum bundle size, suited to medium-sized cable bundles and larger-gauge individual cables that would not fit comfortably in the 7mm options. For smaller bundles, the ACX1101 (30m, corrugated polypropylene) or ACX1102/100 (100m, fire retardant polypropylene) are better suited. For larger bundles, OEX produces convoluted tubing in larger internal diameter sizes. Is this tubing suitable for underbonnet use? Yes. The -20°C to +90°C continuous operating range and 120°C maximum peak temperature make it suitable for most automotive underbonnet environments. For areas with sustained extreme heat exposure, verify the ambient temperature against the tubing rating before use. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
