Rockford Fosgate PMX16C Punch Marine 16ft Extension Cable – Extend Your Remote, Keep Control
Product Overview
The Rockford Fosgate PMX16C is a 16-foot (approximately 4.9 metre) extension cable designed to extend the reach of compatible Punch Marine remote controllers and display heads. It is purpose-built for use with the PMX-8DH, PMX-1R, and PMX-0R, allowing you to mount your remote control or display in a more convenient location further from your source unit than the standard cable length permits.
Whether you're running cables across a larger vessel, routing through a centre console, or mounting a remote at the helm of a pontoon or ski boat, the PMX16C provides the additional length needed without requiring a complete wiring overhaul. It is a direct-fit, plug-and-play accessory with no cutting or splicing required.
Key Specifications
Cable length: 16 feet (approximately 4.9 metres)
Compatible with: PMX-8DH, PMX-1R, PMX-0R
Application: Marine remote controller and display head extension
Plug-and-play installation no cutting or splicing required
Designed for Rockford Fosgate Punch Marine source unit ecosystem
Features & Benefits
16-foot cable length: Provides approximately 4.9 metres of additional reach, giving you flexibility to mount remotes and display heads at the helm, dash, or any convenient control point on your vessel.
Compatible with PMX-8DH, PMX-1R, and PMX-0R: Direct-fit replacement for Rockford Fosgate Punch Marine remotes and display heads. No adapters or modifications needed.
Plug-and-play design: Connects directly between the source unit and compatible remote or display head. Straightforward installation suitable for DIY marine audio builds.
Purpose-built for marine environments: Designed as part of the Rockford Fosgate Punch Marine ecosystem, ensuring reliable signal transmission in the moisture-prone, vibration-heavy conditions typical of Australian watercraft.
Technical Specs
Specification
Detail
SKU
PMX16C
Brand
Rockford Fosgate
Cable Length
16 feet (approx. 4.9 metres)
Compatible Devices
PMX-8DH, PMX-1R, PMX-0R
Installation Type
Plug-and-play
Application
Marine remote/display head extension
Connector Type
Not specified confirm with supplier
Warranty
Confirm with supplier
Compatible With
Rockford Fosgate PMX-8DH Punch Marine digital media receiver
Rockford Fosgate PMX-1R Punch Marine wired remote
Rockford Fosgate PMX-0R Punch Marine remote
Marine vessels requiring extended remote mounting distance from source unit: pontoons, ski boats, bow riders, centre console fishing boats, and tinnies
Frequently Asked Questions
What devices is the PMX16C compatible with? The PMX16C is confirmed compatible with the Rockford Fosgate PMX-8DH, PMX-1R, and PMX-0R. If you are unsure whether it suits your specific Punch Marine setup, confirm with your supplier before ordering.
How long is the PMX16C extension cable? The PMX16C is 16 feet in length, which is approximately 4.9 metres providing substantial additional reach for helm or dash-mounted remote installations on larger vessels.
Does the PMX16C require any cutting or special wiring? No. The PMX16C is a plug-and-play extension cable that connects directly between your Rockford Fosgate source unit and compatible remote or display head without cutting, splicing, or modification.
Can I use two PMX16C cables together for even greater length? This is not confirmed by Rockford Fosgate. Using multiple extension cables in series may affect signal integrity. Contact your supplier or Rockford Fosgate directly before attempting a chained installation.
Is the PMX16C suitable for permanent marine installation? Yes. The PMX16C is part of the Rockford Fosgate Punch Marine accessory range, designed for use in the moisture and vibration conditions common in marine environments. Route and secure the cable appropriately during installation to protect it from abrasion and water ingress.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate PMX10C Punch Marine 10ft Extension Cable Short Run, Perfect Fit
Product Overview
The Rockford Fosgate PMX10C is a 10-foot (approximately 3.0 metre) extension cable designed to extend the reach of compatible Punch Marine remote controllers and display heads. Purpose-built for use with the PMX-8DH, PMX-1R, and PMX-0R, it gives you the additional length needed to mount your remote or display head in a more accessible location without the excess cable bulk of longer extension options.
The PMX10C is the shortest cable in the Punch Marine extension range, making it the ideal choice for smaller vessels, compact powersport installations, and tight routing situations where a precise, neat cable run is the priority. Like all PMX extension cables, it is plug-and-play no cutting, splicing, or custom wiring required.
Key Specifications
Cable length: 10 feet (approximately 3.0 metres)
Compatible with: PMX-8DH, PMX-1R, PMX-0R
Application: Marine remote controller and display head extension
Plug-and-play installation no cutting or splicing required
Shortest cable option in the Rockford Fosgate Punch Marine extension range
Features & Benefits
10-foot cable length: Provides approximately 3.0 metres of additional reach. The most compact option in the PMX extension cable range, ideal for smaller vessels and short routing distances where longer cables would create unnecessary bulk.
Compatible with PMX-8DH, PMX-1R, and PMX-0R: Direct-fit accessory for Rockford Fosgate Punch Marine remotes and display heads. No adapters, splicing, or modifications required.
Plug-and-play design: Connects directly between the source unit and compatible remote or display head. Clean, straightforward installation for DIY builders and professional installers alike.
Purpose-built for marine environments: Part of the Rockford Fosgate Punch Marine accessory ecosystem, engineered for reliable signal transmission through the moisture, heat, and vibration conditions typical of Australian watercraft and powersport applications.
Cleaner install on smaller vessels: Less cable to manage means a tidier, more professional-looking installation on jet skis, small tinnies, kayaks with audio systems, and compact UTVs.
Technical Specs
Specification
Detail
SKU
PMX10C
Brand
Rockford Fosgate
Cable Length
10 feet (approx. 3.0 metres)
Compatible Devices
PMX-8DH, PMX-1R, PMX-0R
Installation Type
Plug-and-play
Application
Marine remote/display head extension
Connector Type
Not specified confirm with supplier
Warranty
Confirm with supplier
Compatible With
Rockford Fosgate PMX-8DH Punch Marine digital media receiver
Rockford Fosgate PMX-1R Punch Marine wired remote
Rockford Fosgate PMX-0R Punch Marine remote
Rockford Fosgate PMX16C and PMX25C extension cables (where a longer run is required)
Smaller marine vessels: jet skis, tinnies, kayaks with audio systems, and small runabouts
Compact powersport applications: ATVs, UTVs, and side-by-sides with short source-unit-to-dash distances
Frequently Asked Questions
What devices is the PMX10C compatible with? The PMX10C is confirmed compatible with the Rockford Fosgate PMX-8DH, PMX-1R, and PMX-0R. If you are unsure whether it suits your specific Punch Marine setup, confirm with your supplier before ordering.
How long is the PMX10C extension cable? The PMX10C is 10 feet in length, which is approximately 3.0 metres making it the shortest and most compact option in the Rockford Fosgate Punch Marine extension cable range.
How does the PMX10C compare to the PMX16C and PMX25C? The PMX10C is the shortest of the three options at approximately 3.0 metres. Choose the PMX16C (approx. 4.9 metres) or PMX25C (approx. 7.6 metres) if your installation requires a longer cable run between the source unit and remote mounting location.
Does the PMX10C require any cutting or special wiring? No. The PMX10C is a plug-and-play extension cable that connects directly between your Rockford Fosgate source unit and compatible remote or display head without cutting, splicing, or modification.
Is the PMX10C suitable for permanent marine installation? Yes. The PMX10C is part of the Rockford Fosgate Punch Marine accessory range, designed for the moisture and vibration conditions common in marine environments. Secure and route the cable carefully during installation to protect it from abrasion and water ingress.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate RGB-YC Color Optix Y-Adapter Cable for PMX-RGB Controller (Gen-1)
A plug-and-play Y-adapter cable for the Rockford Fosgate PMX-RGB Color Optix controller, splitting one RGB controller output into two lines to support expanded Color Optix speaker and subwoofer installations. IPX7 rated Deutsch/Amphenol connectors. Backed by a 2 year warranty.
Product Overview
The Rockford Fosgate RGB-YC is a plug-and-play Y-adapter cable designed to simplify and expand Color Optix RGB LED speaker installations using the PMX-RGB controller. By splitting one RGB controller output into two separate lines, the RGB-YC allows more Color Optix speakers and subwoofers to be connected to a single PMX-RGB controller output, making it the essential accessory for larger marine audio builds within the Rockford Fosgate True Marine Ecosystem.
The PMX-RGB controller supports up to 8 Color Optix speakers and/or subwoofers in total. The RGB-YC uses Element Ready Deutsch/Amphenol connectors rated to IPX7, providing protection against heavy splashing and rain at the connection points. No tools or additional wiring are required for installation.
Features & Benefits
Splits One RGB Output to Two Lines: The RGB-YC Y-adapter divides a single PMX-RGB controller output into two separate RGB connections, allowing more Color Optix speakers and subwoofers to be connected to the same controller output for a more complete and evenly distributed lighting installation.
Plug-and-Play - No Wiring Required: The RGB-YC uses the same Deutsch/Amphenol plug-and-play connector system as all Rockford Fosgate Color Optix components, making installation as simple as plugging in a cable with no soldering, crimping, or additional wiring needed.
IPX7 Rated Deutsch/Amphenol Connectors: The Element Ready Deutsch/Amphenol connectors are rated to IPX7, providing protection against heavy splashing and rain at the connection points throughout the service life of the cable in marine and outdoor environments.
Supports Up to 8 Color Optix Speakers and/or Subwoofers Per Controller: The PMX-RGB controller supports a total of up to 8 Color Optix speakers and/or subwoofers. The RGB-YC enables efficient distribution of the controller's output channels to reach this maximum across a broader installation area.
Technical Specs
Specification
Detail
SKU
RGB-YC
Type
Y-Adapter RGB Cable
Compatible Controller
PMX-RGB (Gen-1)
Function
Splits 1 RGB output to 2 lines
Connector Type
Deutsch/Amphenol (Element Ready)
Water Intrusion Rating
IPX7
Max Color Optix Devices (per controller)
8 speakers and/or subwoofers
Warranty
2 Years
Compatible With / Goes Well With
The RGB-YC is compatible with the PMX-RGB Gen-1 Color Optix controller and all Rockford Fosgate M1 and M2 series Color Optix speakers and subwoofers using the integrated Deutsch/Amphenol RGB connector system.
Compatible Color Optix Products:
PMX-RGB - Rockford Fosgate Color Optix RGB controller (required to use the RGB-YC)
M2-65 / M2-65B - M2 series 6.5 inch Color Optix marine speakers
M2-8 / M2-8B - M2 series 8 inch Color Optix marine speakers
M2-8H / M2-8HB - M2 series 8 inch horn Color Optix marine speakers
M2WL-8 / M2WL-8B - M2 series 8 inch wake tower speakers
M2WL-8H / M2WL-8HB - M2 series 8 inch horn wake tower speakers
M2D4-12I / M2D4-10I / M2D2-10I - M2 series Color Optix infinite baffle marine subwoofers
M2D2-10SB - M2 series Color Optix sealed marine subwoofer
M1 series Color Optix speakers and subwoofers - all M1-6, M1-65, M1-8, M1D series products
Frequently Asked Questions
What does the RGB-YC Y-adapter do?
The RGB-YC splits a single RGB output from the PMX-RGB Color Optix controller into two separate RGB lines. This allows the controller's output to be distributed to more Color Optix speakers or subwoofers across a wider installation without the need for additional controllers or complex wiring.
How many Color Optix devices can be connected to one PMX-RGB controller?
The PMX-RGB controller supports up to 8 Color Optix speakers and/or subwoofers in total. The RGB-YC Y-adapter is used to help distribute that capacity efficiently across multiple connection points in the installation.
Is the RGB-YC compatible with all Color Optix speakers and subwoofers?
Yes. The RGB-YC uses the same Deutsch/Amphenol plug-and-play connector system used across all Rockford Fosgate M1 and M2 series Color Optix speakers and subwoofers. It is compatible with all products in the Color Optix ecosystem that use this connector type.
Is the RGB-YC waterproof?
The Deutsch/Amphenol connectors on the RGB-YC are rated to IPX7, providing protection against heavy splashing and rain at the connection points. This makes it suitable for marine and outdoor environments where moisture exposure is expected.
Does the RGB-YC work without the PMX-RGB controller?
No. The RGB-YC is an accessory cable for the PMX-RGB Color Optix controller and does not function independently.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate M2D2-10IB M2 Series 10 Inch DVC 2-Ohm Color Optix Infinite Baffle Marine Subwoofer in Black
A premium marine grade 10 inch dual voice coil 2-ohm infinite baffle subwoofer in black with Color Optix RGB LED lighting, 400W RMS handling, VersaSwitch impedance selection between 1-ohm and 4-ohm, and interchangeable stainless steel and sport grille inserts. Aramid-polyester composite spider, UV stable foam surround, PA66 glass-fill frame, vented motor with nano-coated mesh screen, and integrated Deutsch/Amphenol connectors. Optimised for infinite baffle installations - no enclosure required. IPX6 rated and ASTM B117 and G154 tested. Sold individually (1 each). Backed by a 2 year warranty.
Product Overview
The Rockford Fosgate M2D2-10IB is an M2 series 10 inch dual voice coil (DVC) 2-ohm marine subwoofer in black, featuring Color Optix RGB LED illumination controllable via the PMX-RGB controller and RF Connect app (available on iOS and Android, sold separately). It shares the same physical dimensions and construction as the M2D4-10IB but uses DVC 2-ohm voice coils, giving the VersaSwitch different impedance settings: 1-ohm (parallel) and 4-ohm (series).
Like all M2 series IB subwoofers, the M2D2-10IB is optimised for infinite baffle (free air) marine installations where a dedicated enclosure is not available or practical. A mounting baffle is required to isolate front and rear wavelengths and prevent acoustic cancellation. The cone is injection-moulded mineral-filled polypropylene with UV inhibitors, co-moulded with a UV stable injection-moulded foam surround using Rockford Fosgate's patented VAST technique for up to 25% more effective radiating cone area. The aramid-polyester composite spider provides superior excursion linearity. The ultra-high temperature PA66 frame with 30% glass fill and UV inhibitors provides a rigid, thermally stable mounting platform. The vented motor design with a water-repelling nano-coated mesh screen allows heat dissipation at high output levels while protecting the motor from water ingress. Fully insulated silicone tinsel leads are used throughout.
Industry-first moulded in-frame Deutsch/Amphenol connectors combine Color Optix RGB lighting and audio signal in a single plug-and-play connection. Gold-plated marine grade brass terminals are also included. Both stainless steel and sport grille inserts are included. Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. Klippel Verified certification applied. Sold individually.
Features & Benefits
VersaSwitch - 1-Ohm or 4-Ohm Without Rewiring: The VersaSwitch allows the DVC 2-ohm voice coils to be configured to parallel (1-ohm) or series (4-ohm) by flipping a single switch. The 1-ohm setting maximises output from compatible mono amplifiers, while the 4-ohm setting suits amplifiers better matched to a higher impedance load.
400W RMS - Full M2 Series Power in a 10 Inch Infinite Baffle Format: The M2D2-10IB handles 400W RMS and 1600W peak with 11mm Xmax, delivering premium M2 series output in a 10 inch driver optimised for hull or panel mounting without a dedicated enclosure.
Optimised for Infinite Baffle - No Enclosure Required: The M2D2-10IB is engineered specifically for infinite baffle (free air) installations. A mounting baffle is required to physically separate the front and rear of the cone to prevent acoustic cancellation, but no sealed or ported enclosure box is needed.
UV Stable Foam Surround with VAST Technology: The injection-moulded UV stable foam surround is co-moulded to the cone and attaches vertically via the patented VAST technique, increasing the effective radiating cone area by up to 25%.
Aramid-Polyester Composite Spider and PA66 Glass-Fill Frame: The aramid-polyester composite spider delivers superior excursion linearity and fatigue resistance. The PA66 frame with 30% glass fill and UV inhibitors provides a rigid, thermally stable, and UV resistant mounting structure.
Vented Motor with Nano-Coated Water-Repelling Mesh Screen: The vented motor design allows heat to dissipate from the 2 inch (50mm) Kapton voice coil former at high output levels, while the nano-coated mesh screen prevents water from entering the motor assembly.
Industry-First Moulded In-Frame Deutsch/Amphenol Connectors: Moulded in-frame connectors combine speaker signal and Color Optix RGB lighting in a single error-proof plug-and-play connection. Gold-plated marine grade brass spade terminals are also included.
Interchangeable Grille Options - Stainless Steel and Sport Inserts Included: Both stainless steel and sport grille inserts are included, with additional grille options available separately for further customisation.
Technical Specs
Specification
Detail
SKU
M2D2-10IB
Size
10 inch
Colour
Black
Voice Coil Type
Dual Voice Coil (DVC)
Nominal Impedance (each coil)
2 Ohm
VersaSwitch Parallel
1 Ohm
VersaSwitch Series
4 Ohm
Enclosure Type
Infinite Baffle (no enclosure required)
Power Handling
400W RMS / 1600W Peak
SPL
90.3 dB (1W/1m)
Frequency Response
20 Hz - 750 Hz
Fs (Hz)
43
Vas (Litres)
30.5
Qts
0.74
Qes
0.86
Qms
5.69
Xmax
11.0mm
Re (Ohms)
3.3
Le (mH)
1.17
Sd (cm2)
363
Woofer Displacement
0.06 cu.ft (1.74 Litres)
Voice Coil Diameter
2 inch (50.8mm)
Voice Coil Former
High Temp Kapton
Magnet Weight
55.02 oz (1.56kg)
Cutout Diameter
8.87 inch (225.3mm)
Mounting Depth
4.44 inch (112.7mm)
Surround
UV Stable Injection-Moulded Foam (VAST)
Spider
Aramid-Polyester Composite
Motor Design
Vented with Nano-Coated Water-Repelling Mesh Screen
Frame
PA66 + 30% Glass Fill, UV Inhibitor
Grille
100% UV Stable Centrex Plastic
Grille Options
Stainless Steel (included) + Sport Insert (included)
Speaker Connector
Integrated Deutsch/Amphenol + Gold-Plated Brass Terminals
Lighting Control
Color Optix via PMX-RGB + RF Connect App
Surround Technology
VAST
Water Intrusion Rating
IPX6
Salt/Fog Testing
ASTM B117 (500 hours)
UV Testing
ASTM G154 (500 hours)
Vibration Testing
ISO60068-2-64
Sold As
Individually (1 each)
Certifications
Klippel Verified
Shipping Weight
6.26kg
Warranty
2 Years
Compatible With / Goes Well With
The M2D2-10IB is suited to marine watercraft requiring a premium 10 inch infinite baffle subwoofer in black with 1-ohm or 4-ohm VersaSwitch capability. A mounting baffle must be used to separate the front and rear acoustic wavelengths. Sold individually.
Goes Well With:
PMX-RGB - Rockford Fosgate Color Optix RGB controller required to access full Color Optix lighting control and RF Connect app integration
M5-1000X1 - M5 series 1000W marine monoblock amplifier, capable of 750W at 1-ohm - well matched to the M2D2-10IB at 1-ohm VersaSwitch setting
M5-1500X5 - M5 series 1500W 5-channel marine amplifier for full system builds pairing the M2D2-10IB with marine full-range speakers
M2D2-10I - White version of this subwoofer for colour-matched installations
M2D4-10IB - Black DVC 4-ohm version (VersaSwitch 2-ohm/8-ohm) for comparison when amplifier impedance requirements differ
M2D2-10SB - M2 series 10 inch DVC 2-ohm Color Optix sealed enclosure subwoofer in black for builds where an enclosure is available
Frequently Asked Questions
What is the difference between the M2D2-10IB and the M2D4-10IB?
Both are black M2 series 10 inch Color Optix infinite baffle subwoofers with identical construction and physical dimensions. The only difference is voice coil impedance. The M2D2-10IB has DVC 2-ohm coils with VersaSwitch settings of 1-ohm (parallel) or 4-ohm (series), and Xmax of 11mm. The M2D4-10IB has DVC 4-ohm coils with VersaSwitch settings of 2-ohm (parallel) or 8-ohm (series), and Xmax of 12mm. Choose the M2D2-10IB for amplifiers designed to deliver maximum power at 1-ohm or 2-ohm loads; choose the M2D4-10IB for amplifiers better matched to 2-ohm or 8-ohm impedance.
What is an infinite baffle installation and is an enclosure required?
An infinite baffle (free air) installation mounts the subwoofer directly into a hull panel, storage lid, or partition rather than in a sealed or ported enclosure box. No dedicated enclosure is required, making it ideal for vessels with limited below-deck space. A mounting baffle is required to physically separate the front and rear of the subwoofer cone to prevent the front and rear acoustic waves from cancelling each other.
What is the difference between the M2D2-10IB and the M2D2-10SB?
Both are black M2 series 10 inch DVC 2-ohm Color Optix subwoofers with VersaSwitch settings of 1-ohm and 4-ohm. The M2D2-10IB is optimised for infinite baffle (free air) installations with no enclosure required. The M2D2-10SB is optimised for sealed enclosure installations requiring a 0.5 cu.ft box. Choose the M2D2-10IB for hull or panel mounting; choose the M2D2-10SB when a sealed enclosure is available.
Is the M2D2-10IB sold as a single unit or as a pair?
The M2D2-10IB is sold individually - one subwoofer per purchase. Two units will need to be added to the order if a dual subwoofer installation is required.
Does the Color Optix lighting require a separate controller?
Yes. Color Optix RGB lighting requires the PMX-RGB controller and the RF Connect app (available on iOS and Android) to access full colour control, lighting effects, and brightness adjustment. The PMX-RGB controller is sold separately. The subwoofer can also be used without the controller at a fixed default colour setting straight out of the box.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate M2-8H M2 Series 8 Inch 2-Way Color Optix Marine Horn Speaker - Pair
A pair of marine grade 8 inch 2-way flush-mount speakers with an integrated 1 inch high-efficiency horn tweeter, Color Optix RGB LED lighting, 300W RMS handling, and 94dB sensitivity at 1W/1m. Features a fully sealed 12dB/octave Integrated Concealed Crossover, aramid fiber spider, TPE surround, vented motor with nano-coated mesh screen, and integrated Deutsch/Amphenol plug-and-play connectors. IPX6 rated and ASTM B117 and G154 tested. Sold as a pair. Backed by a 2 year warranty.
Product Overview
The Rockford Fosgate M2-8H is a pair of M2 series 8 inch 2-way marine speakers with an integrated 1 inch (25mm) high-efficiency horn tweeter, purpose-built for flush or surface mounting in marine watercraft. Unlike the M2WL-8H wake tower loaded enclosure, the M2-8H is a bare speaker designed for custom installation into a hull panel, dash, or similar mounting surface.
The horn tweeter delivers high-efficiency output and extended projection with a frequency response of 20Hz-25kHz, and at 94dB sensitivity (1W/1m) the M2-8H is one of the most efficient speakers in the M2 marine range, requiring less amplifier power to achieve high output levels. The fully sealed 12dB/octave Integrated Concealed Crossover (ICC) network uses metallised polyester film capacitors and is hidden inside the basket for a clean installation. A vented motor design with a water-repelling nano-coated mesh screen protects the motor structure from water ingress without compromising airflow.
The driver construction features a moisture, tear, and fatigue resistant aramid fiber spider, UV and salt-fog resistant TPE (Thermo-Plastic Elastomer) surround, co-moulded surround and cone body, and an injection-moulded mineral-filled polypropylene cone with UV inhibitors. The frame is constructed from ultra-high temperature PA66 with 30% glass fill and UV inhibitors. Integrated Deutsch RGB and speaker receptacles combine Color Optix lighting and audio signal into a single plug-and-play connection. Color Optix RGB LED lighting is controllable via the PMX-RGB controller and RF Connect app (available on iOS and Android, sold separately). VAST surround technology and Klippel Verified certification are applied throughout. Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards.
Features & Benefits
Integrated 1 Inch High-Efficiency Horn Tweeter - Extended Projection: The integrated 1 inch (25mm) horn tweeter projects high-frequency sound with greater efficiency and directional accuracy than a conventional dome tweeter, delivering clear, far-reaching audio across the full 20Hz-25kHz frequency range.
94dB Sensitivity - High Efficiency Output: At 94dB sensitivity (1W/1m), the M2-8H achieves high output levels with less amplifier power than lower-sensitivity marine speakers, making it an efficient choice for marine audio systems where amplifier headroom and battery drain are considerations.
Fully Sealed ICC Crossover - 12dB/Octave: The Integrated Concealed Crossover (ICC) is a fully sealed 12dB/octave network using metallised polyester film capacitors, hidden inside the basket for a clean external appearance and simplified installation without a separate crossover component.
Vented Motor with Nano-Coated Water-Repelling Mesh Screen: The vented motor design allows heat dissipation at high output levels while the nano-coated mesh screen repels water from the motor assembly, protecting the voice coil and motor structure in spray-intensive marine environments.
Aramid Fiber Spider and TPE Surround: The moisture, tear, and fatigue resistant aramid fiber spider and UV and salt-fog resistant TPE (Thermo-Plastic Elastomer) surround are chosen specifically for long-term durability in the marine environment, maintaining linear excursion and consistent performance over time.
Color Optix RGB LED Lighting - App Controlled: Ultra-bright wide-angle tri-colour surface mount LEDs with flat mould lenses are driven by a multiplexed RGB input, controlled via the PMX-RGB controller and RF Connect app on iOS and Android. Lighting colour, effects, and intensity are fully customisable.
VAST Surround Technology - Up to 25% More Cone Area: Rockford Fosgate's Vertical Attach Surround Technique increases the effective radiating cone area by up to 25%, delivering more output from the same 8 inch driver size.
ASTM and ISO Tested for Marine Environments: Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. IPX6 water intrusion rating confirms protection against powerful jets of water from any direction.
Technical Specs
Specification
Detail
SKU
M2-8H
Speaker Type
2-Way
Speaker Size
8 inch
Tweeter
1 inch (25.4mm) High-Efficiency Horn
Nominal Impedance
4 Ohm
Power Handling
300W RMS / 1200W Peak
Sensitivity
94 dB (1W/1m) / 96 dB (2.83V)
Frequency Response
20 Hz - 25 kHz
Crossover
ICC 12dB/Octave (Fully Sealed)
Crossover Capacitors
Metallised Polyester Film
Spider
Aramid Fiber (Moisture, Tear and Fatigue Resistant)
Surround
UV and Salt-Fog Resistant TPE
Cone
Injection-Moulded Mineral-Filled Polypropylene with UV Inhibitors
Frame
PA66 + 30% Glass Fill, UV Inhibitor (High Temperature)
Voice Coil Former
1 inch (25mm) High Temp Kapton
Motor Design
Vented with Nano-Coated Water-Repelling Mesh Screen
LED Type
Ultra-Bright Wide-Angle Tri-Colour SMD with Flat Mould Lenses
LED PCB
Optically Clear UV Stable Encapsulated
Speaker Connector
Integrated Deutsch/Amphenol + Gold-Plated Brass Spade Terminals
RGB Input
Multiplexed RGB
Lighting Control
Color Optix via PMX-RGB + RF Connect App
Mounting Depth
3.35 inch (85mm)
Grille / Trim Ring
Included (100% UV Stable Centrex)
Mounting Hardware
Yes
Surround Technology
VAST
Water Intrusion Rating
IPX6
Salt/Fog Testing
ASTM B117 (500 hours)
UV Testing
ASTM G154 (500 hours)
Vibration Testing
ISO60068-2-64
Sold As
Pair (2 each)
Certifications
Klippel Verified
Shipping Weight
2.35kg (pair)
Warranty
2 Years
Compatible With / Goes Well With
The M2-8H is suited to marine watercraft requiring a high-output, high-sensitivity flush-mount speaker for hull panels, dash, or custom enclosure mounting. It is not a tower-clamp speaker - for wake tower bar mounting, refer to the M2WL-8H. Pairs well with M2 series marine subwoofers connected through the same Color Optix ecosystem.
Goes Well With:
PMX-RGB - Rockford Fosgate Color Optix RGB controller required to access full Color Optix lighting control and RF Connect app integration
M5-800X4 - M5 series 800W 4-channel marine amplifier to power the M2-8H pair alongside additional speakers or a subwoofer
M5-1500X5 - M5 series 1500W 5-channel marine amplifier for complete system builds pairing the M2-8H with a marine subwoofer
M2D4-12I - M2 series 12 inch Color Optix infinite baffle subwoofer, the recommended subwoofer pairing within the M2 Color Optix ecosystem
M2D2-10SB - M2 series 10 inch Color Optix sealed subwoofer for compact subwoofer installations alongside the M2-8H
M2WL-8H - Wake tower loaded enclosure version of this speaker for installations requiring clamp mounting to tower bars from 1.5 to 3.0 inches
Frequently Asked Questions
What is the difference between the M2-8H and the M2WL-8H?
Both are M2 series 8 inch 2-way horn speakers with Color Optix lighting, 300W RMS power handling, and the same horn tweeter and frequency response. The M2-8H is a bare speaker designed for flush or surface mounting directly into a hull panel, dash, or custom enclosure. The M2WL-8H is a complete loaded enclosure pre-fitted in a sealed housing with a universal clamp system for mounting on wake tower bars from 1.5 to 3.0 inches. Choose the M2-8H for in-hull or in-dash flush mounting; choose the M2WL-8H for tower-mounted applications.
Does the Color Optix lighting require a separate controller?
Yes. Color Optix RGB lighting requires the PMX-RGB controller and the RF Connect app (available on iOS and Android) to access full colour control, lighting effects, and brightness adjustment. The PMX-RGB controller is sold separately and is not included. The speakers can also operate without the controller at a fixed default colour setting straight out of the box.
What does the vented motor with nano-coated mesh screen do?
The vented motor allows the voice coil assembly to breathe and dissipate heat at high output levels, which is important for sustained performance during long listening sessions. The nano-coated mesh screen covers the vent opening with a water-repelling coating that prevents water from entering the motor assembly in spray-intensive marine environments without restricting airflow.
Why does the M2-8H have higher sensitivity than many marine speakers?
The M2-8H achieves 94dB sensitivity (1W/1m) largely because of the integrated horn tweeter, which concentrates and focuses high-frequency energy more efficiently than a conventional dome tweeter. This means the speaker produces more volume from the same input power, which is beneficial in marine environments where long cable runs, battery capacity, and amplifier efficiency are all considerations.
What mounting depth is required for the M2-8H?
The M2-8H requires a mounting depth of 3.35 inches (85mm). Measure the available depth behind the mounting surface before purchasing to confirm the speaker will fit your specific installation location without interference from hull structure or wiring behind the panel.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate M1WL-65MB M1 Series 6.5 Inch Color Optix 2-Way Motorsports Moto-Can Speakers in Black - Pair
A pair of Element Ready 6.5 inch 2-way motorsports moto-can speakers with Color Optix RGB LED lighting, 75W RMS handling, and a universal clamp system fitting SXS ROPS bars from 1.0 to 2.0 inches in diameter. Loaded sealed enclosures in black with integrated Deutsch/Amphenol 6-pin connectors, 360-degree rotating 3DIL rear logo, and IPX6 water intrusion rating. Sold as a pair. Backed by a 2 year warranty.
Product Overview
The Rockford Fosgate M1WL-65MB is a pair of M1 series 6.5 inch 2-way loaded motorsports moto-can speaker enclosures in black, purpose-built for the off-road environment. Each enclosure houses the M1-65 Element Ready 2-way speaker and is constructed from 100% UV stable high-density ASA plastic with IPX6 water intrusion rating and full Element Ready protection against dust, UV radiation, temperature extremes, water, mud, corrosion, and vibration.
The included universal clamp system fits SXS ROPS (Roll Over Protection System) bars from 1.0 to 2.0 inches in diameter, with rubber inserts for both 1.0-1.6 inch and 1.6-2.0 inch bars included in the box. Integrated Deutsch/Amphenol connectors and speaker inputs provide error-proof plug-and-play connectivity. Deutsch connectors incorporate front and rear silicone seals for environmental protection.
Color Optix RGB LED lighting is controllable via the PMX-RGB controller and RF Connect app (available on iOS and Android, sold separately). The 3DIL (3D Illuminated Logo) technology allows the rear illuminated Rockford Fosgate medallion to rotate infinitely so it remains correctly oriented regardless of mounting angle. Klippel Verified certification and VAST surround technology are applied throughout. The M1WL-65MB is the mid-tier option in the 6.5 inch moto-can range, sitting between the base M0WL-65MB and the higher-output M2WL-65MB.
Features & Benefits
Color Optix RGB LED Lighting - App Controlled: The Color Optix system delivers bright, wide-angle RGB illumination across the front speaker LEDs and rear 3DIL medallion, controllable via the PMX-RGB controller and RF Connect app on iOS and Android. Colour, effects, and intensity are fully customisable. The PMX-RGB controller is sold separately.
Element Ready Motorsports Construction - Built for Off-Road: All components are protected against dust, UV radiation, temperature extremes, water, mud, corrosion, and vibration. IPX6 water intrusion rating confirms protection against powerful jets of water from any direction. Deutsch connectors incorporate front and rear silicone seals to protect against environmental ingress at the connection point.
3DIL Technology - Infinitely Rotatable Rear Logo: The 3D Illuminated Logo (3DIL) allows the rear Rockford Fosgate medallion to rotate infinitely so it is always correctly oriented regardless of the angle the moto-can is mounted on the roll cage, maintaining a professional appearance from any viewing position.
Universal Clamp - Fits 1.0 to 2.0 Inch ROPS Bars: The included mounting clamp fits SXS Roll Over Protection System bars from 1.0 to 2.0 inches in diameter. Rubber inserts for both 1.0-1.6 inch and 1.6-2.0 inch bars are included, providing secure fitment across a wide range of SXS and powersports roll cage bar sizes.
VAST Surround Technology - Up to 25% More Cone Area: Rockford Fosgate's Vertical Attach Surround Technique attaches the surround vertically to the cone, increasing the effective radiating cone area by up to 25% and delivering more output from the same physical 6.5 inch speaker size.
True Off-Road Ecosystem - Integrated Deutsch/Amphenol Connectors: Integrated Deutsch/Amphenol connectors provide error-proof plug-and-play speaker and RGB connectivity, with environmental seals at each connection point to maintain system integrity in off-road conditions.
Technical Specs
Specification
Detail
SKU
M1WL-65MB
Colour
Black
Speaker Type
2-Way Loaded Enclosure
Speaker Series
M1-65
Speaker Size
6.5 inch
Speaker Quantity
2 (sold as a pair)
Nominal Impedance
4 Ohm
Power Handling
75W RMS / 300W Peak
Frequency Response
38 Hz - 22 kHz
Enclosure Design
Sealed
Enclosure Material
High Density ASA (100% UV Stable)
Speaker Connector
6-Pin Deutsch/Amphenol
Pigtail Connector
2-Pin Deutsch
LED Voltage Range
9-16 VDC
LED Current Draw
0.25A
LED Recommended Fuse
1A
Clamp Bar Diameter
1.0 to 2.0 inches (SXS ROPS)
Water Intrusion Rating
IPX6
Lighting Control
Color Optix via PMX-RGB + RF Connect App
Logo Technology
3DIL (Infinitely Rotating Illuminated Logo)
Surround Technology
VAST
Certifications
Klippel Verified
Dimensions
243.2 x 180.5 x 206.4mm (9.6 x 7.1 x 8.1 inch)
Shipping Weight
4.8kg
Warranty
2 Years
Compatible With / Goes Well With
The M1WL-65MB is purpose-built for SXS (side-by-side) vehicles, ATVs, UTVs, and powersports applications with roll cage bars from 1.0 to 2.0 inches in diameter. It is not a wake tower speaker and is not designed for marine tower bar mounting. Please review the Rockford Fosgate compatibility chart for your specific vehicle before purchasing.
Goes Well With:
PMX-RGB - Rockford Fosgate Color Optix RGB controller required to access full Color Optix lighting control and RF Connect app integration
M5-800X4 - M5 series 800W 4-channel Element Ready amplifier for powering the M1WL-65MB pair in an SXS audio system build
M2WL-65MB - Higher-output M2 series black moto-can speakers (150W RMS) for riders requiring more output than the M1WL-65MB provides
M0WL-65MB - Base M0 series black moto-can speakers for builds where the M1WL-65MB exceeds the required budget
M1WL-65M - White version of these speakers for colour-matched installations
Frequently Asked Questions
What is the difference between the M1WL-65MB and the M2WL-65MB?
Both are black 6.5 inch Color Optix motorsports moto-cans with the same clamp system, ROPS bar compatibility, 3DIL rotating logo, IPX6 rating, and VAST surround technology. The M2WL-65MB is the higher-output model handling 150W RMS and 600W peak, while the M1WL-65MB handles 75W RMS and 300W peak. The M2WL-65MB also includes ASTM B117, G154 and ISO vibration test certifications. Choose the M2WL-65MB for maximum output and the most comprehensive testing credentials; choose the M1WL-65MB as a strong mid-tier option for builds where 75W RMS per pair is sufficient.
What ROPS bar sizes are compatible with the M1WL-65MB clamps?
The included universal clamps fit SXS Roll Over Protection System bars from 1.0 to 2.0 inches in diameter. Rubber inserts for 1.0-1.6 inch bars and 1.6-2.0 inch bars are both included in the box. Please measure your vehicle's roll cage bar diameter before purchasing to confirm the clamps will fit your specific SXS.
Does the Color Optix lighting require a separate controller?
Yes. Color Optix RGB lighting requires the PMX-RGB controller and the RF Connect app (available on iOS and Android) to access full colour control, lighting effects, and brightness adjustment. The PMX-RGB controller is sold separately and is not included. The speakers can also operate without the controller at a fixed default colour setting straight out of the box.
Is the M1WL-65MB suitable for marine or boat applications?
The M1WL-65MB is an Element Ready motorsports product designed and rated for off-road and powersports environments. While it carries IPX6 water intrusion rating, it is a moto-can designed for SXS roll cage bars from 1.0 to 2.0 inches. For marine wake tower applications requiring bars up to 3.0 inches, the M2WL-8B or M2WL-8HB wake tower speakers are the appropriate products.
What is the difference between the M1WL-65MB and the M0WL-65MB?
Both are black 6.5 inch motorsports moto-cans in the same form factor. The M1WL-65MB is the mid-tier M1 series option handling 75W RMS and includes Klippel Verified certification and VAST surround technology. The M0WL-65MB is the base entry-level option in the moto-can range with lower power handling. Choose the M1WL-65MB for a step up in output and audio quality from the base M0 series.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate M1D4-12 M1 Series 12 Inch DVC 4-Ohm Color Optix Marine Subwoofer in White
A marine grade 12 inch dual voice coil 4-ohm subwoofer in white with Color Optix RGB LED lighting, 300W RMS handling, and VersaSwitch impedance selection between 2-ohm and 8-ohm. Santoprene VAST surround, mineral-filled polypropylene cone, vented motor with nano-coated mesh screen, and integrated Deutsch/Amphenol plug-and-play connectors. Compatible with sealed (1.65 cu.ft) and vented (2.45 cu.ft) enclosures. IPX6 rated and ASTM B117 and G154 tested. Sold individually (1 each). Backed by a 2 year warranty.
Product Overview
The Rockford Fosgate M1D4-12 is an M1 series 12 inch dual voice coil (DVC) 4-ohm marine subwoofer in white, featuring Color Optix RGB LED illumination controllable via the PMX-RGB controller and RF Connect app (available on iOS and Android, sold separately). The M1 series sits between the M0 entry level and the premium M2 series, adding Color Optix lighting, Deutsch/Amphenol integrated connectors, VersaSwitch impedance selection, and ASTM and ISO-tested marine construction.
The VersaSwitch allows impedance to be changed between 2-ohm (parallel) and 8-ohm (series) by flipping a single switch, without any additional wiring. Integrated Deutsch/Amphenol connectors are moulded directly into the basket frame, providing error-proof plug-and-play connectivity for both the speaker signal and Color Optix RGB lighting. Conventional zinc nickel-plated marine grade brass spade terminals are also included as an alternative wiring option.
The cone is injection-moulded mineral-filled polypropylene with UV inhibitors, co-moulded with a Santoprene VAST surround. Rockford Fosgate's patented VAST technique increases the effective radiating cone area by up to 25%. A linear synthetic fiber blend spider provides consistent excursion control. The vented motor design with a water-repelling nano-coated mesh screen allows heat dissipation at high output levels while protecting the motor from water ingress. The 100% UV stable ASA plastic frame and grille resist discolouration in marine environments. Optically clear UV stable RGB lighting encapsulation protects the LED PCB throughout.
The M1D4-12 is compatible with both sealed (1.65 cu.ft / 46.72 litres) and vented (2.45 cu.ft / 69.38 litres) enclosure configurations. Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. Klippel Verified certification applied. Sold individually - one subwoofer per purchase. The black version is available as the M1D4-12B.
Features & Benefits
VersaSwitch - 2-Ohm or 8-Ohm Without Rewiring: The VersaSwitch allows the DVC 4-ohm voice coils to be configured to parallel (2-ohm) or series (8-ohm) by flipping a single switch, enabling flexible amplifier matching without additional wiring or soldering.
Color Optix RGB LED Lighting - App Controlled: Ultra-bright wide-angle RGB LEDs are protected by optically clear UV stable encapsulation, controllable via the PMX-RGB controller and RF Connect app on iOS and Android. The PMX-RGB controller is sold separately.
Integrated Deutsch/Amphenol Connectors - True Marine Ecosystem: Moulded in-frame Deutsch/Amphenol connectors combine speaker signal and Color Optix RGB lighting into a single error-proof plug-and-play connection. Zinc nickel-plated marine grade brass spade terminals are also included for standard wiring installations.
Santoprene VAST Surround - UV and Salt-Fog Resistant: The Santoprene VAST surround is co-moulded to the mineral-filled polypropylene cone and attaches vertically using Rockford Fosgate's patented VAST technique, increasing the effective radiating cone area by up to 25% for more bass output from the same 12 inch driver.
Vented Motor with Nano-Coated Water-Repelling Mesh Screen: The vented motor design allows heat to dissipate from the 2 inch (50mm) Kapton voice coil former at high output levels, while the nano-coated mesh screen prevents water from entering the motor assembly in spray-intensive marine environments.
Sealed and Vented Enclosure Compatible: The M1D4-12 supports both sealed (1.65 cu.ft) and vented (2.45 cu.ft) enclosure configurations, giving installers the flexibility to match the subwoofer to the available space and desired bass response characteristic.
ASTM and ISO Tested - Purpose-Built Marine Construction: Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. IPX6 water intrusion rating confirms protection against powerful jets of water from any direction.
Technical Specs
Specification
Detail
SKU
M1D4-12
Size
12 inch
Colour
White
Voice Coil Type
Dual Voice Coil (DVC)
Nominal Impedance (each coil)
4 Ohm
VersaSwitch Parallel
2 Ohm
VersaSwitch Series
8 Ohm
Power Handling
300W RMS / 1200W Peak
SPL
92 dB (1W/1m)
Frequency Response
20 Hz - 750 Hz
Fs (Hz)
27
Vas (Litres)
113.1
Qts
0.59
Qes
0.63
Qms
8.20
Xmax
6.0mm
Re (Ohms)
7.6
Le (mH)
3.40
Sd (cm2)
585.4
Woofer Displacement
3.49 cu.in (0.12 Litres)
Voice Coil Diameter
2 inch (50mm)
Voice Coil Former
High Temp Kapton
Magnet Weight
39.75 oz (1.13kg)
Sealed Box Volume
1.65 cu.ft (46.72 Litres)
Vented Box Volume
2.45 cu.ft (69.38 Litres)
Cutout Diameter
10.85 inch (275.6mm)
Mounting Depth
6.65 inch (169.1mm)
Surround
Santoprene VAST
Spider
Linear Synthetic Fiber Blend
Motor Design
Vented with Nano-Coated Water-Repelling Mesh Screen
Frame
100% UV Stable ASA Plastic
Speaker Connector
Integrated Deutsch/Amphenol + Zinc Nickel-Plated Brass Spade Terminals
Lighting Control
Color Optix via PMX-RGB + RF Connect App
Surround Technology
VAST
Water Intrusion Rating
IPX6
Salt/Fog Testing
ASTM B117 (500 hours)
UV Testing
ASTM G154 (500 hours)
Vibration Testing
ISO60068-2-64
Sold As
Individually (1 each)
Certifications
Klippel Verified
Shipping Weight
4.1kg
Warranty
2 Years
Compatible With / Goes Well With
The M1D4-12 is suited to marine watercraft, pontoon boats, ski boats, and any vessel requiring a 12 inch marine subwoofer with Color Optix lighting. Compatible with sealed (1.65 cu.ft) and vented (2.45 cu.ft) enclosures. The VersaSwitch enables pairing with amplifiers rated at 2-ohm or 8-ohm. Sold individually - two units are required for a stereo or dual subwoofer installation. The black version is available as the M1D4-12B.
Goes Well With:
PMX-RGB - Rockford Fosgate Color Optix RGB controller required to access full Color Optix lighting control and RF Connect app integration
M5-1000X1 - M5 series 1000W marine monoblock amplifier, compatible with the M1D4-12 at both 2-ohm and 8-ohm VersaSwitch settings
M2-500X1 - M2 series 500W mono marine amplifier for a matched M2 ecosystem pairing at 2-ohm or 8-ohm
M5-1500X5 - M5 series 1500W 5-channel marine amplifier for full system builds pairing the M1D4-12 with marine full-range speakers
M1D4-12B - Black version of this subwoofer for colour-matched installations
M2D4-12I - M2 series premium 12 inch Color Optix infinite baffle subwoofer for comparison
Frequently Asked Questions
What impedance settings does the VersaSwitch provide on the M1D4-12?
The M1D4-12 uses DVC 4-ohm voice coils. The VersaSwitch configures the coils to parallel (2-ohm total) or series (8-ohm total) without any rewiring. Use the 2-ohm setting when pairing with an amplifier rated for lower impedance loads for maximum output, or the 8-ohm setting for amplifiers better suited to a higher impedance. Contact us if you need help selecting the correct setting for your amplifier.
What enclosure types are compatible with the M1D4-12?
The M1D4-12 is compatible with both sealed (1.65 cu.ft / 46.72 litres) and vented (2.45 cu.ft / 69.38 litres) enclosure configurations. A sealed enclosure delivers tighter, more accurate bass with a shallower roll-off, while a vented enclosure produces more output at the tuning frequency with a steeper low-frequency roll-off below the port tuning point. Choose based on your installation space and preferred bass character.
What is the difference between the M1D4-12 and the M2D4-12I?
The M1D4-12 is the M1 series 12 inch DVC 4-ohm subwoofer in white, compatible with sealed and vented enclosures, using a Santoprene VAST surround and linear synthetic fiber blend spider. The M2D4-12I is the premium M2 series 12 inch DVC 4-ohm infinite baffle subwoofer, optimised for free-air hull mounting without an enclosure, featuring more advanced construction throughout. Choose the M1D4-12 for sealed or vented enclosure builds; choose the M2D4-12I for infinite baffle installations where no enclosure is available.
Is the M1D4-12 sold as a single unit or as a pair?
The M1D4-12 is sold individually - one subwoofer per purchase. If your installation requires two subwoofers, two units will need to be added to the order.
Does the M1D4-12 come in a black version?
Yes. The black version is available as the M1D4-12B, sharing the same specifications and construction.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Rockford Fosgate M1 6.5‚Äù Color Optix Marine 2-Way Speakers - Black: Delivers Loud, Clear, Accurate Sound, and Light the Way for Your Journey! The M1-65B Color Optix™ 2-way 6.5‚Äù speakers deliver loud, clear, accurate sound, and light the way for your journey! The speakers connect with the Rockford Fosgate Color Optix™ Controller and RF Connect App, allowing you to customize your own color patterns. The Element Ready™ design and IP67 certification makes them truly purpose-built for marine or motorsport applications where protection from damaging UV rays and water spray is essential. The M1 series of Element Ready™ speakers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the speaker. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To complete your sound experience, the M1 speakers are complimented by 8-inch, 10-inch and 12-inch subwoofers, also controlled through the Color Optix™ lighting system. Color Optix™ Experience Experience the Color Optix™ speaker and subwoofer line from Rockford Fosgate. Designed for watercraft of all kinds, they are Element Ready to withstand water, salt, and UV rays. Rockford Fosgate M1-65B Features: Optically clear UV stable RGB Lighting Encapsulation Multiplexed RGB Input Ultra-Bright, Wide Angle Tri-Color Surface Mount LED's with Flat Mold Lenses Grill Integrated 1" (25 mm) LCP Balanced Dome Tweeter 1" (25mm) High Temp Kapton™ Woofer Voice Coil Former Sealed motor design 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment Zinc Nickel-plated Marine grade brass connection terminals Proprietary Dual Function Input Terminals Integrated Deutsch RGB and Speaker receptacles Linear Synthetic Fiber Blend Spiders Santoprene VAST Surround VAST vertical attach surround technique increases effective radiating cone area up to 25% Co-molded surround and mineral filled polypropylene cone body 6dB/Octave crossover network Fully sealed integrated concealed crossover (ICC) network
Legendary Products & Support From Authorized Dealers
When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Rockford Fosgate dealer today!
JBL Club Marine Speakers Are Ready to Take on Your Next Outdoor Adventure!
High performance marine audio multi-element speakers and subwoofer systems engineered to meet the demands of extreme environments. These fully marinized speakers not only deliver JBL sound, but select models also feature RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structure, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropylene cone and balanced dome tweeter provide great bass, smooth highs and lots of output to ensure every note can be heard loud and clear.
Features:
8" marine speakers (pair)
Built-in RGB LED lighting (green/red/blue)
Durable polypropylene cone
Synthetic rubber surround
Grille-mounted balanced-dome tweeter
UV- and corrosion-resistant polymer basket and grille
Stainless steel hardware included
Specifications:
Power Handling 150W RMS, 450W peak
Sensitivity (@ 2.83V) 92dB
Frequency Response 30Hz – 20kHz
Impedance 4 ohms
What's in the box:
1 x Speakers with grilles, pr.
1 x Stainless steel mounting hardware
1 x Foam gasket, pr.
1 x RGB lighting pigtail harness, pr.
1 x JBL logo 2prs
1 x Quick start guide
Legendary Products & Support From Authorized Dealers
When you choose JBL, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized JBL dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by JBL's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized JBL dealer today!
JBL Club Marine Speakers Are Ready to Take on Your Next Outdoor Adventure!
High performance marine audio multi-element speakers and subwoofer systems engineered to meet the demands of extreme environments. These fully marinized speakers not only deliver JBL sound, but select models also feature RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structure, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropylene cone and balanced dome tweeter provide great bass, smooth highs and lots of output to ensure every note can be heard loud and clear.
Features:
8" marine speakers (pair)
Built-in RGB LED lighting (green/red/blue)
Durable polypropylene cone
Synthetic rubber surround
Grille-mounted balanced-dome tweeter
UV- and corrosion-resistant polymer basket and grille
Stainless steel hardware included
Specifications:
Power Handling 150W RMS, 450W peak
Sensitivity (@ 2.83V) 92dB
Frequency Response 30Hz – 20kHz
Impedance 4 ohms
What's in the box:
1 x Speakers with grilles, pr.
1 x Stainless steel mounting hardware
1 x Foam gasket, pr.
1 x RGB lighting pigtail harness, pr.
1 x JBL logo 2prs
1 x Quick start guide
Legendary Products & Support From Authorized Dealers
When you choose JBL, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized JBL dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by JBL's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized JBL dealer today!
JBL Club Marine Speakers Are Ready to Take on Your Next Outdoor Adventure!
High performance marine audio multi-element speakers and subwoofer systems engineered to meet the demands of extreme environments. These fully marinized speakers not only deliver JBL sound, but select models also feature RGB lighting to bring the sound to life. Engineered to withstand sun, salt, sea spray and wash downs, they feature sealed motor structure, UV resistant one-piece cast-polymer baskets, a sealed magnet and rubber surrounds. The polypropylene cone and balanced dome tweeter provide great bass, smooth highs and lots of output to ensure every note can be heard loud and clear.
Features:
8" 2-way marine speakers (pair)
Durable polypropylene cone
Synthetic rubber surround
Grille-mounted dome tweeter
UV- and corrosion-resistant polymer basket and grille
Stainless steel hardware included
Specifications:
Power Handling 150W RMS, 450W peak
Sensitivity (@ 2.83V) 92dB
Frequency Response 30Hz – 20kHz
Impedance 4 ohms
What's in the box:
1 x Speakers with grilles, pr.
1 x Stainless steel mounting hardware
1 x Foam gasket, pr.
1 x JBL logo 2prs
1 x Quick start guide
Legendary Products & Support From Authorized Dealers
When you choose JBL, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized JBL dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by JBL's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized JBL dealer today!
GME VHF Marine Radio White: Designed to Suit Vessels with Limited Dash Space The GX700W VHF Marine Radio is a compact communication and safety device.Waterproof to IPX7, the GX700W is the ideal communication tool for your boating lifestyle whether you're sailing inland waters, or heading offshore.The compact design makes installation of the GX700W simple and enables installation in locations where space is limited.The GX700W's innovative rear microphone input socket enables you to run a 5m or 8m extension cable (available as an optional accessory) from the rear input to a convenient location on the vessel where the waterproof flush mount socket can be installed. The MC616W speaker mic can now be input from this location. By adding the waterproof blanking plug to the front mic input socket, obstruction caused by the mic cable hanging in the skipper's field of view is eliminated. This setup is ideal for “above windscreen” installations in hard-top vessels.Clear audio is delivered via the GX700W's dual speaker system, and can be further enhanced by the addition of the SPK45 extension speaker.The GX700W's LCD display features large, easy to read numbers and adjustable brightness. Designed with ease of use in mind, the screen can be read from virtually any angle, day or night.Dual Watch, Triple Watch and two programmable priority channels provide easy access to regularly used channels. Channel scanning is programmable, making it easy to monitor all important communications. The GX700W comes complete with International, USA and Canadian channel sets making it versatile for use anywhere in the world.The GX700W's sleek design will compliment the appearance of your vessel and matches perfectly with GME's 27MHz and Entertainment products.Also available in Black (GX700B).GME GX700W Features: 25/1 Watt Switchable Power Waterproof Speaker Mic Compact Design IPX7 Ingress Protection Dual & Triple Watch with Programmable Priority Channel Two Working Channel Memories Rear Microphone Input Socket What's in the Box: VHF Marine Radio (GX700W) Cabin Cover Mounting Hardware Microphone Bracket 12V DC Power Lead
Legendary Products & Support From Authorized Dealers
When you choose GME, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized GME dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by GME's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized GME dealer today!
