OEX ACX1980BL 12V 20A Normally Open Micro Relay Japanese Configuration 4 Pin Resistor Spike Protection IP67 Single Unit The OEX ACX1980BL is a 12V, 20A normally open micro relay with resistor spike protection, supplied as a single unit. Smaller than the standard mini relay format, the micro relay suits installations where mounting space is limited or where the vehicle's factory relay socket uses the micro relay footprint common in many Japanese-configuration vehicles. Four-terminal layout with coil connections (85 and 86) and normally open switching contacts (30 and 87) no normally closed contact. Silver tin oxide contacts and IP67 sealed housing. Covered by a one year warranty. Product overview The ACX1980BL is a micro relay physically smaller than the standard mini relay (ACX1940RBL series) and using a different terminal footprint. Micro relays are commonly found in Japanese-market vehicles and are not interchangeable with standard ISO mini relay sockets. The Japanese configuration footprint matches the relay socket used in many vehicles manufactured by Japanese brands. Always confirm the relay format required for your vehicle or application before purchasing using a micro relay in a mini relay socket or vice versa will not produce a secure connection. At 20A the ACX1980BL covers accessory and auxiliary circuit switching in applications where the smaller footprint is required. The resistor spike protection suppresses the voltage spike generated when the relay coil is de-energised, protecting ECU and control module outputs in the triggering circuit. The IP67 sealed housing provides full protection against dust and temporary water immersion. Features and benefits Micro relay format: Physically smaller than the standard mini relay, suited to tight installation spaces and Japanese vehicle configurations where the micro relay footprint is required. Japanese configuration: Terminal layout and footprint matches the relay socket used in many Japanese-brand vehicles. Not interchangeable with standard ISO mini relay sockets. 20A rating: Suited to accessory and auxiliary circuit switching up to 20A in applications requiring the micro relay format. Normally open contact: Circuit is open at rest and closes when the relay coil is energised. 4 pin configuration: Coil connections (85 and 86) and normally open switching contacts (30 and 87). No normally closed contact (87a). Resistor spike protection: Suppresses the voltage spike generated when the relay coil is de-energised, protecting ECU and control module outputs. IP67 sealed housing: Fully protected against dust and temporary water immersion, suited to underbonnet and exposed mounting positions. Silver tin oxide contacts: Reliable switching performance with excellent contact life. Single unit: For individual installations or replacements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1980BL Brand OEX Type Micro Relay Voltage 12V Current Rating 20A Relay Action Normally Open Terminals 4 Pin Configuration Japanese Spike Protection Resistor Contact Material Silver Tin Oxide IP Rating IP67 Pack Quantity 1 Weight 0.026kg Warranty One year Sold As Single unit Frequently asked questions What is a micro relay and how does it differ from a mini relay? A micro relay is physically smaller than a standard mini relay and uses a different terminal footprint. Micro relays are commonly found in Japanese-market vehicles and are not interchangeable with mini relay sockets. Always confirm the relay format required for your vehicle or application before purchasing. What does "Japanese configuration" mean? Japanese configuration refers to the terminal layout and footprint used in many vehicles manufactured by Japanese brands. This differs from the standard ISO mini relay footprint used in European and most aftermarket applications. Confirm your vehicle's relay socket configuration before purchasing. Why does this relay have 4 terminals instead of 5? As a normally open relay there is no normally closed contact (87a), resulting in 4 terminals: 85 (coil negative), 86 (coil positive), 30 (common) and 87 (normally open). If a change over relay with both NO and NC contacts is required, a 5-terminal relay is needed. What does resistor spike protection do? When a relay coil is de-energised it generates a voltage spike that can damage sensitive electronics. A resistor across the coil terminals suppresses this spike, protecting ECU and control module outputs used to trigger the relay. Is this relay suitable for underbonnet use? Yes. The IP67 sealed housing provides full protection against dust and temporary water immersion, making it suitable for underbonnet and exposed mounting positions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1975BL 20A Carling Style SPST Illuminated Rocker Switch Blue LED 12V and 24V 21x37mm Panel Mount The OEX ACX1975BL is a Carling style blue illuminated On/Off SPST (Single Pole Single Throw) rocker switch rated at 20A, suitable for both 12V and 24V systems. The Carling style format uses a 21x37mm rectangular mounting hole, compatible with Carling-format switch panels and marine-style consoles widely used in 4WD, caravan and marine dash configurations. The blue LED illuminates when the switch is in the On position. Three blade terminals accommodate the separate illumination circuit alongside the switching circuit. Supplied as a single unit. Covered by a one year warranty. Product overview Carling style rocker switches use a 21x37mm rectangular mounting footprint that is widely adopted in aftermarket marine and 4WD switch panels, consoles and housings. Many purpose-built switch panel enclosures are designed around this format, making the ACX1975BL a direct-fit replacement or addition in these panel types without modification. The Carling format is physically distinct from the 12mm round mount used by the ACX1971BL and ACX1973BL confirm your panel format before purchasing. The blue LED illuminates when the switch is in the On position, providing clear status indication in low-light conditions. The third terminal powers the LED independently of the main switching circuit, allowing connection to a constant 12V or 24V supply. At 20A the ACX1975BL handles lighting and general accessory switching. For loads exceeding 20A, the switch should be used to trigger a relay. Features and benefits Carling style format 21x37mm rectangular mount: Compatible with Carling-format switch panels and marine-style consoles used in 4WD, caravan and marine applications. 20A at 12V and 24V: Suited to lighting and general accessory switching on both passenger vehicles and commercial vehicle systems. For loads exceeding 20A, use the switch to trigger a relay. SPST On/Off configuration: Single pole single throw switching with one input and one output for straightforward accessory on/off control. Blue LED illuminated: Glows when the switch is in the On position for clear status indication in switch panels and consoles in low-light conditions. 12V and 24V compatible: Suits passenger vehicles, 4WDs and commercial vehicles including trucks and buses. 3 blade terminals: Separate connections for the switching circuit (2 terminals) and the LED illumination circuit (1 terminal), allowing the LED to be powered from a constant 12V or 24V supply. Single unit: For individual panel installation. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1975BL Brand OEX Switch Type Carling Style Rocker Switch Action On/Off (SPST) Poles 1 Positions 2 Current Rating 20A Voltage 12V and 24V Illumination Blue LED Terminals 3 Blade Mounting Hole 21mm x 37mm Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What is a Carling style switch? Carling style refers to a rocker switch format with a 21x37mm rectangular mounting footprint, widely used in marine and 4WD switch panels. Many aftermarket switch panels, consoles and housings are designed around this format, making it a popular and interchangeable switch type for custom builds and panel replacements. What mounting hole does this switch require? The switch requires a 21x37mm rectangular panel cutout. This is a different format to the 12mm round mount used by the ACX1971BL and ACX1973BL confirm your panel format before purchasing. Does this switch work on both 12V and 24V systems? Yes. The ACX1975BL is rated for both 12V and 24V systems, making it suitable for passenger vehicles, 4WDs and commercial vehicles. Why does this switch have 3 terminals? The third terminal is for the LED illumination circuit. It connects to a constant 12V or 24V supply to power the blue LED indicator, separate from the main switching circuit. What is the maximum current this switch can handle? This switch is rated at 20A. For loads exceeding 20A, use the switch to trigger a relay rather than wiring the load directly through the switch. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1962BL 12V 10A SPST Pre-Wired Push Button Switch Green and Red Dual LED Adhesive Surface Mount The OEX ACX1962BL is a pre-wired 12V mouse-style push button switch in an On/Off SPST (Single Pole Single Throw) configuration, rated at 10A. Designed for simple surface mounting with an adhesive backing, it requires no panel cutout a practical solution for adding a switch to a dash, console or trim surface without modification. Dual-colour LED illumination provides clear status indication: green when on and red when off. Pre-wired leads eliminate the need for separate terminal connections. Supplied as a single unit. Covered by a one year warranty. Product overview Most rocker and toggle switches require a rectangular or round panel cutout and terminal connections, adding installation time and requiring panel modification. The ACX1962BL eliminates both requirements the adhesive backing attaches the switch directly to a flat surface without drilling or cutting, and the pre-wired leads connect directly to the circuit without crimping connectors onto individual blade terminals. This makes it a practical choice for adding a switch to a finished dash, console or trim piece where modification is not desirable. The dual-colour LED provides clear, unambiguous status indication green when the circuit is active and red when it is inactive allowing instant visual confirmation at a glance even in low-light conditions. At 10A the switch handles lighting circuits, LED strips and general accessory switching directly. For loads exceeding 10A, the switch should be used to trigger a relay rather than wiring the load directly through the switch. Features and benefits Pre-wired: Leads are already attached, connecting directly to the circuit without crimping connectors onto individual blade terminals. Faster installation, particularly in tight spaces. Adhesive surface mount no panel cutout required: Attaches directly to a flat surface such as a dash, console or trim piece without drilling or cutting. SPST On/Off: Single pole single throw switching for straightforward accessory circuit on/off control. 10A at 12V: Suited to lighting circuits, LED strips and general 12V accessory switching up to 10A. For loads exceeding 10A, use the switch to trigger a relay. Green (On) and red (Off) dual LED: Green illuminates when the circuit is active and red when inactive unambiguous status indication in any lighting condition. Mouse-style compact form factor: Low-profile design for discreet installation on dash panels, consoles and trim surfaces. Single unit: For individual installation. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1962BL Brand OEX Switch Type Push Button Switch Action On/Off (SPST) Poles 1 Positions 1 Current Rating 10A Voltage 12V Illumination Green (On) and Red (Off) LED Wiring Pre-wired Mounting Surface mount, adhesive backing Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What does pre-wired mean? Pre-wired means the switch comes with leads already attached to its terminals, so it can be connected directly to the circuit without crimping connectors onto individual blade terminals. This makes installation faster and simpler, particularly in tight spaces or on finished surfaces. Does this switch require a panel cutout? No. The ACX1962BL uses adhesive backing for surface mounting it attaches directly to a flat surface such as a dash panel, console or trim piece without any drilling or cutting. What do the green and red LEDs indicate? Green illuminates when the switch is in the On position (circuit active). Red illuminates when the switch is in the Off position (circuit inactive). This dual-colour indication allows instant confirmation of circuit state at a glance, even in low-light conditions. What is SPST? SPST stands for Single Pole Single Throw the simplest switch configuration with one input and one output. It either connects or disconnects a single circuit conductor. Most basic On/Off accessory switches are SPST. What is the maximum current this switch can handle? This switch is rated at 10A at 12V. For loads exceeding 10A, use the switch to trigger a relay rather than wiring the load directly through the switch. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1960BL 12V 20A DPST Illuminated Rocker Switch with Red LED Driving Light Symbol The OEX ACX1960BL is a 12V illuminated rocker switch in an On/Off DPST (Double Pole Single Throw) configuration, rated at 20A per contact. Designed for driving light control and accessory switching, it features a red LED illuminated driving light symbol for easy identification in a switch panel. The DPST configuration switches both poles simultaneously, suited to circuits requiring simultaneous positive and negative switching. Mounts in a 20x35mm panel cutout with four blade terminals for direct wiring. Supplied as a single unit. Covered by a one year warranty. Product overview A DPST switch has two separate switching contacts that operate simultaneously with a single On/Off action, switching both the positive and negative conductors of a circuit at the same time. This provides complete circuit isolation when the switch is off a feature that single pole (SPST) switches do not provide. The ACX1960BL is rated at 20A per contact at 12V, suited to driving lights, LED light bars and other high-current accessories. The red LED illuminates when the switch is in the On position, providing clear status indication in a multi-switch panel or in low-light driving conditions. The driving light symbol identifies the switch function at a glance without labelling. With a 20x35mm mounting hole and 34.5mm mount length, the ACX1960BL fits standard automotive switch panel cutouts used in 4WD, caravan and marine switch panels. Features and benefits DPST On/Off configuration: Switches both poles simultaneously for complete circuit isolation, suited to circuits requiring simultaneous positive and negative switching. 20A at 12V: Rated for driving lights, LED light bars and other high-current 12V accessories drawing up to 20A. Red LED illuminated: Glows when the switch is in the On position for clear status indication in low-light conditions and multi-switch panels. Driving light symbol: Identifies switch function at a glance in a multi-switch panel without additional labelling. 4 blade terminals: Direct wiring connections standard automotive blade connectors or insulated terminals suit these connections, no socket required. 20x35mm mounting hole: Fits standard automotive switch panel cutouts used in 4WD, caravan and marine installations. Single unit: For individual panel installation. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1960BL Brand OEX Switch Type Rocker Switch Action On/Off (DPST) Poles 2 Positions 2 Current Rating 20A Voltage 12V Illumination Red LED Symbol Driving Light Terminals 4 Blade Mounting Hole 20mm x 35mm Mount Length 34.5mm Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What does DPST mean? DPST stands for Double Pole Single Throw. It means the switch has two separate switching contacts that operate simultaneously with a single On/Off action, allowing both the positive and negative conductors of a circuit to be switched at the same time and providing complete circuit isolation when the switch is off. What is the difference between DPST and SPST? An SPST (Single Pole Single Throw) switch controls one conductor typically just the positive supply. A DPST switch controls two conductors simultaneously. DPST is used when complete circuit isolation is required or when switching both supply wires at once is preferred. Does the red LED indicate the switch is on or just that power is available? The red LED illuminates when the switch is in the On position, providing a clear visual indication that the circuit is active. It is not a power-available indicator it only glows when the switch is actively switched on. What mounting hole size does this switch require? The switch requires a 20x35mm rectangular mounting hole in the panel. Confirm your panel cutout dimensions before installing. What terminal connections does this switch use? The switch has 4 blade terminals for direct wiring. Standard automotive blade connectors or insulated terminals suit these connections no socket is required. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1942RBL 24V 20A Normally Open Mini Relay Resistor Spike Protection IP67 Sealed 5 Blade Terminals Single Unit The OEX ACX1942RBL is a 24V, 20A normally open mini relay with resistor spike protection, supplied as a single unit. Designed specifically for 24V electrical systems found in trucks, buses, heavy commercial vehicles and 24V auxiliary setups, it provides reliable accessory switching where a 12V relay would not operate correctly. Silver tin oxide contacts, IP67 sealed housing and a removable mounting tab. Five-blade ISO mini relay footprint. Covered by a one year warranty. Product overview A relay's coil is designed to operate at a specific voltage a 24V relay requires 24V to energise its coil, and a 12V relay placed in a 24V system will not operate reliably. The ACX1942RBL is the correct relay for 24V electrical systems including trucks, buses, heavy commercial vehicles and 24V dual battery or auxiliary setups. At 20A it covers accessory and auxiliary circuit switching at 24V driving lights, fans, auxiliary loads and general accessory circuits. The resistor spike protection suppresses the voltage spike generated when the relay coil is de-energised, protecting sensitive electronics and control outputs in the switching circuit. The IP67 sealed housing provides full protection against dust and temporary water immersion for underbonnet and exposed mounting. The five-blade ISO footprint matches the same mini relay socket used for 12V applications, so the same relay holders and harness adapters apply across both voltage systems. Features and benefits 24V coil voltage: Designed for 24V electrical systems will not operate correctly in a 12V system. A 12V relay will not energise reliably in a 24V system either. Always match relay coil voltage to the vehicle's system voltage. 20A rating: Suited to accessory and auxiliary circuit switching on 24V trucks, buses, commercial vehicles and 24V dual battery systems. Normally open contact: Circuit is open at rest and closes when the relay coil is energised the most common relay configuration for switching accessories on in response to a trigger signal. Resistor spike protection: Suppresses the voltage spike generated when the relay coil is de-energised, protecting sensitive electronics and control outputs in the switching circuit. IP67 sealed housing: Fully protected against dust and temporary water immersion, suited to underbonnet, exposed and commercial vehicle mounting positions. 5 blade terminals standard ISO mini relay footprint: Compatible with standard mini relay sockets and harnesses across both 12V and 24V applications. Silver tin oxide contacts: Reliable switching performance with excellent contact life. Removable mounting tab: Flexible installation options for panel and bracket mounting. Single unit: For individual installations or replacements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1942RBL Brand OEX Type Mini Relay Voltage 24V Current Rating 20A Relay Action Normally Open Terminals 5 Blade Spike Protection Resistor Contact Material Silver Tin Oxide IP Rating IP67 Mounting Removable tab Pack Quantity 1 Weight 0.02kg Warranty One year Sold As Single unit Frequently asked questions Why is a 24V relay needed instead of a 12V relay? A relay's coil is designed to operate at a specific voltage. A 24V relay requires 24V to energise its coil a 12V relay will not operate reliably in a 24V system, and a 24V relay will not energise correctly in a 12V system. Always match the relay coil voltage to the vehicle's system voltage. What is a normally open relay? A normally open relay has a contact that is open (disconnected) when the relay coil is not energised. When the coil receives a trigger signal it closes the contact, completing the circuit to the load. This is the most common relay configuration for switching accessories on in response to a signal. What does resistor spike protection do? When a relay coil is de-energised it generates a voltage spike that can damage sensitive electronics in the triggering circuit. A resistor across the coil terminals suppresses this spike, providing protection for ECU outputs and control module switching. What is the standard mini relay terminal layout? The 5-blade mini relay uses the standard ISO automotive relay terminal layout: 85 (coil negative), 86 (coil positive), 30 (common/battery), 87 (normally open active when energised) and 87a (normally closed not active on a normally open relay). This layout is the same across both 12V and 24V mini relays. Is this relay suitable for underbonnet use? Yes. The IP67 sealed housing provides full protection against dust and temporary water immersion, making it suitable for underbonnet, exposed and commercial vehicle mounting positions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1941RBL 12V Change Over SPDT Mini Relay 30A NC and 40A NO Resistor Spike Protection IP67 Sealed Single Unit The OEX ACX1941RBL is a 12V change over (SPDT) mini relay with resistor spike protection, supplied as a single unit. Unlike a normally open relay, the change over configuration provides both a normally open (NO) and a normally closed (NC) contact, allowing it to switch between two circuits making it the correct choice for applications requiring circuit routing or polarity reversal. Dual current rating of 30A (NC contact) and 40A (NO contact). Silver tin oxide contacts, IP67 sealed housing and a removable mounting tab. Covered by a one year warranty. Product overview A change over (SPDT) relay has three switching terminals a common (30), a normally closed contact (87a, active at rest) and a normally open contact (87, active when energised). This allows the relay to route a circuit between two different paths depending on whether the coil is energised, which is something a standard normally open relay cannot do. Typical applications include dual circuit switching, polarity reversal, interlock circuits and any application where a circuit needs to be confirmed in a known state at rest. The dual current rating of 30A on the NC contact and 40A on the NO contact is standard for change over relays where contact ratings differ between positions. Always confirm the circuit current against the rating for the specific contact position being used. The resistor spike protection suppresses the voltage spike generated when the relay coil is de-energised. The IP67 sealed housing provides full protection against dust and temporary water immersion for underbonnet and exposed mounting. Features and benefits Change over (SPDT) contacts: Provides both normally open and normally closed switching in a single relay, allowing the circuit to be routed between two paths depending on the coil state. 30A (NC) and 40A (NO) dual rating: The normally closed contact is rated at 30A and the normally open contact at 40A. Confirm the circuit current does not exceed the rating for the contact position being used. Resistor spike protection: Suppresses the voltage spike generated when the relay coil is de-energised, protecting sensitive electronics and ECU outputs in the triggering circuit. IP67 sealed housing: Fully protected against dust and temporary water immersion, suited to underbonnet, exposed and marine-adjacent mounting positions. 5 blade terminals standard ISO mini relay footprint: Compatible with standard mini relay sockets and harnesses. On a change over relay all five terminals are active. Silver tin oxide contacts: Reliable switching performance with excellent contact life. Removable mounting tab: Flexible installation options for panel and bracket mounting. Single unit: For individual installations or replacements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1941RBL Brand OEX Type Mini Relay Voltage 12V Current Rating 30A (NC) and 40A (NO) Relay Action Change Over (SPDT) Terminals 5 Blade Spike Protection Resistor Contact Material Silver Tin Oxide IP Rating IP67 Mounting Removable tab Pack Quantity 1 Weight 0.02kg Warranty One year Sold As Single unit Frequently asked questions What is a change over relay? A change over relay (SPDT Single Pole Double Throw) has three switching terminals: a common (terminal 30), a normally closed contact (terminal 87a connected when the relay is at rest) and a normally open contact (terminal 87 connected when the relay is energised). This allows the relay to switch a circuit between two different paths depending on whether it is energised or not. What does the 30A and 40A dual rating mean? The normally closed (NC) contact is rated at 30A and the normally open (NO) contact is rated at 40A. This is standard in change over relays where contact ratings differ between positions. Ensure the circuit current does not exceed the rating for the contact position being used. How does this differ from the normally open ACX1940RBL? The ACX1940RBL is a normally open relay it has one switching contact that is open at rest and closes when energised. The ACX1941RBL is a change over relay with both a normally open and a normally closed contact, allowing it to route a circuit between two paths. Select the change over relay when you need to switch between two circuits or when a known circuit state at rest is required. What is the standard mini relay terminal layout for a change over relay? The 5-blade mini relay uses the standard ISO layout: 85 (coil negative), 86 (coil positive), 30 (common), 87 (normally open active when energised) and 87a (normally closed active at rest). On a change over relay all five terminals are active, unlike a normally open relay where 87a is unused. Is this relay suitable for underbonnet use? Yes. The IP67 sealed housing provides full protection against dust and temporary water immersion, making it suitable for underbonnet, exposed and marine-adjacent mounting positions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1868BL 50A Type I Cycling Automatic Reset Circuit Breaker Plated Steel 10-32 Stud Terminals The OEX ACX1868BL is a Type I cycling automatic reset circuit breaker rated at 50A. It automatically cycles and resets until the overload condition is cleared, providing self-recovering protection for circuits where momentary overloads are expected or where unattended operation is required. Plated steel case with integrated mounting bracket and two 10-32 stud terminals. Mounts via two 5.61mm holes at 39.62mm centre-to-centre spacing. Supplied as a single unit. Covered by a one year warranty. Product overview The ACX1868BL steps up from the 30A ACX1864BL to a 50A rating in the OEX Type I cycling auto reset range. The same cycling reset behaviour applies the breaker trips when current exceeds the rated threshold and automatically resets once the element cools, repeating this cycle until the overload is corrected or removed. At 50A it suits higher-draw circuits including electric winches on lighter loads, dual fan setups and other accessories drawing up to 50 amps where self-recovering protection without operator intervention is required. The plated steel case and integrated mounting bracket provide durable construction for panel and bracket installation. The 10-32 stud terminals accept standard #10 ring terminals. The two 5.61mm mounting holes at 39.62mm centre-to-centre suit standard panel and bracket mounting configurations, matching the same footprint as the ACX1864BL. Features and benefits Type I cycling auto reset: Automatically resets after tripping and cycles until the overload is corrected no user intervention required. 50A rating: Higher capacity than the ACX1864BL (30A), suited to electric winches on lighter loads, dual fan setups and other higher-current accessories drawing up to 50 amps. Two 10-32 stud terminals: Standard threaded stud connections accepting #10 ring terminals for reliable wiring. Plated steel case and mounting bracket: Durable and corrosion-resistant construction for automotive panel and bracket installations. Two 5.61mm mounting holes at 39.62mm centres: Standard mounting pattern matching the ACX1864BL footprint for panel and bracket installation. Single pack: For individual circuit installations. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1868BL Brand OEX Type Circuit Breaker Breaker Type Type I, Auto Reset (Cycling) Current Rating 50A Terminal Type 2 x 10-32 stud Mounting Holes 2 x 5.61mm, 39.62mm on centre Case Material Plated steel Weight 0.037kg Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What is a Type I cycling circuit breaker? A Type I circuit breaker automatically resets by cycling it trips when current exceeds its rating, then automatically resets once the element cools, repeating this cycle until the overload is corrected or removed. This differs from a Type III manual reset breaker, which stays tripped until physically reset by the user. How does the ACX1868BL differ from the ACX1864BL? Both are Type I cycling auto reset circuit breakers with identical construction, mounting pattern and 10-32 stud terminals. The ACX1868BL is rated at 50A and the ACX1864BL at 30A. Select the ACX1868BL for higher-draw circuits such as electric winches on lighter loads, dual fan setups or any circuit drawing up to 50 amps. How does this differ from the manual reset circuit breakers in the OEX range? The ACX1868BL automatically cycles on and off until the fault is cleared without user intervention. The OEX manual reset breakers (ACX1842 through ACX1848) stay tripped until physically reset. Automatic reset suits accessories, fans and auxiliary circuits where brief overloads are expected and self-recovery is desirable. Manual reset is generally preferred for main battery protection where sustained fault re-energisation could cause damage. What cable terminals suit the 10-32 studs? The 10-32 thread accepts standard #10 ring terminals. Select ring terminals sized for your cable gauge with a #10 (approximately 3.5mm) hole. Is this breaker weatherproof? An IP rating is not confirmed in the current product data for the ACX1868BL. Contact us to confirm the weatherproofing rating if this is a requirement for your installation location. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1864BL 30A Type I Cycling Automatic Reset Circuit Breaker Plated Steel 10-32 Stud Terminals The OEX ACX1864BL is a Type I cycling automatic reset circuit breaker rated at 30A. It automatically cycles and resets until the overload condition is cleared, providing self-recovering protection for circuits where momentary overloads are expected or where unattended operation is required. Plated steel case with integrated mounting bracket and two 10-32 stud terminals. Mounts via two 5.61mm holes at 39.62mm centre-to-centre spacing. Supplied as a single unit. Covered by a one year warranty. Product overview A Type I cycling circuit breaker trips when current exceeds the rated threshold and then automatically resets once the element cools, repeating this cycle until the overload is corrected or removed. This self-recovering behaviour suits circuits with expected momentary overloads electric cooling fans, electric actuators, trailer accessory feeds and marine auxiliary circuits where brief current spikes are normal and self-recovery without operator intervention is desirable. The cycling behaviour also provides a warning signal in some installations, as repeated on/off cycling indicates a persistent overload that needs attention. At 30A the ACX1864BL covers mid-to-high current accessory circuits, stepping up from the 25A ACX1862BL. The plated steel case and integrated mounting bracket provide durable construction for panel and bracket installation. The 10-32 stud terminals accept standard #10 ring terminals. The two 5.61mm mounting holes at 39.62mm centre-to-centre suit standard panel and bracket mounting configurations. Features and benefits Type I cycling auto reset: Automatically resets after tripping and cycles until the overload is corrected no user intervention required. 30A rating: Suited to mid-to-high current accessory circuits requiring automatic reset functionality. Two 10-32 stud terminals: Standard threaded stud connections accepting #10 ring terminals for reliable wiring. Plated steel case and mounting bracket: Durable and corrosion-resistant construction for automotive panel and bracket installations. Two 5.61mm mounting holes at 39.62mm centres: Standard mounting pattern for panel and bracket installation. Single pack: For individual circuit installations. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1864BL Brand OEX Type Circuit Breaker Breaker Type Type I, Auto Reset (Cycling) Current Rating 30A Terminal Type 2 x 10-32 stud Mounting Holes 2 x 5.61mm, 39.62mm on centre Case Material Plated steel Weight 0.037kg Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What is a Type I cycling circuit breaker? A Type I circuit breaker automatically resets by cycling it trips when current exceeds its rating, then automatically resets once the element cools, repeating this cycle until the overload is corrected or removed. This differs from a Type III manual reset breaker, which stays tripped until physically reset by the user. How does this differ from the manual reset circuit breakers in the OEX range? The ACX1864BL automatically cycles on and off until the fault is cleared without user intervention. The OEX manual reset breakers (ACX1842 through ACX1848) stay tripped until physically reset. Automatic reset suits accessories, fans and auxiliary circuits where brief overloads are expected and self-recovery is desirable. Manual reset is generally preferred for main battery protection where sustained fault re-energisation could cause damage. What cable terminals suit the 10-32 studs? The 10-32 thread accepts standard #10 ring terminals. Select ring terminals sized for your cable gauge with a #10 (approximately 3.5mm) hole. Is this breaker weatherproof? An IP rating is not confirmed in the current product data for the ACX1864BL. Contact us to confirm the weatherproofing rating if this is a requirement for your installation location. What is the voltage rating for this breaker? Voltage rating is not confirmed in the current product data. Contact us to confirm the voltage rating if this is a specific requirement for your application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1848 200A Type III Heavy Duty Switchable Manual Reset Circuit Breaker IP67 Waterproof Stainless Steel 9.5mm Studs Up to 72VDC The OEX ACX1848 is a 200A Type III heavy duty manual reset circuit breaker designed for very high-current circuit protection in automotive, marine, caravan and 4WD applications. Unlike a blade fuse, this circuit breaker can be manually reset after tripping, eliminating the need to carry spare fuses and reducing downtime in the field. IP67 waterproof and dustproof housing with stainless steel 9.5mm studs and rubber protective caps. Rated up to 72VDC. The switchable function also allows the breaker to operate as a manual isolation switch. Covered by a one year warranty. Product overview The ACX1848 is the highest-rated circuit breaker in the OEX Type III manual reset series at 200A, suited to the most demanding high-current protection applications where even the 150A ACX1847 is undersized. Very high-draw main battery supply circuits, high-capacity winch and recovery equipment, large dual battery installations with high current demand, marine main power feeds, and solar and battery storage systems at 12V, 24V or 48V are the primary applications. All specifications are shared with the rest of the Type III series Type III switchable for both overcurrent protection and manual isolation, IP67 waterproof and dustproof housing, 9.5mm stainless steel studs for heavy gauge cable lugs and ring terminals, rubber stud caps and up to 72VDC. The manual reset function requires deliberate operator action to restore the circuit after a trip, preventing repeated cycling into a fault condition. Features and benefits 200A rating highest in the OEX Type III series: Suited to very high-draw main battery supply circuits, high-capacity winch and recovery equipment, large dual battery installations and marine main power feeds where lower-rated breakers would be undersized. Manual reset (switchable): Resets after tripping without replacing a fuse, reducing downtime in the field. Can also function as a manual isolation switch. Type III heavy duty construction: Robust housing for demanding automotive, marine and 4WD environments. IP67 waterproof and dustproof: Fully sealed against dust and temporary water immersion, suited to exposed, underbonnet and deck-mounted installations. Up to 72VDC: Suits 12V, 24V and 48V DC electrical systems including solar and battery storage applications. Stainless steel 9.5mm studs: Corrosion-resistant terminations for heavy cable connections. Select cable lugs and ring terminals with a 9.5mm hole to suit. Rubber stud caps: Protect terminals from moisture, corrosion and accidental contact. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1848 Brand OEX Type Circuit Breaker Breaker Type Type III, Manual Reset (Switchable) Current Rating 200A Voltage Rating Up to 72V DC IP Rating IP67 Terminal Studs Stainless steel, 9.5mm Terminal Protection Rubber stud caps Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What is the advantage of a circuit breaker over a fuse? A circuit breaker can be manually reset after it trips, whereas a fuse must be replaced. In remote or off-road situations where carrying spare fuses may not be practical, a resettable circuit breaker provides a significant convenience and safety advantage. This breaker can also be used as a manual isolation switch when required. How does the ACX1848 compare to the rest of the OEX Type III series? The ACX1848 is rated at 200A, the highest in the OEX Type III series, extending above the ACX1847 (150A), ACX1846 (100A), ACX1845 (80A), ACX1844 (60A) and ACX1843 (50A). All share the same Type III switchable design, 9.5mm stainless studs, IP67 rating and up to 72VDC voltage range. Select based on your circuit's current requirements. What cable termination size does this breaker use? The breaker uses 9.5mm stainless steel studs. Select cable lugs and ring terminals with a 9.5mm hole to suit these studs. Is this breaker suitable for marine use? Yes. The IP67 rating confirms full dust protection and resistance to temporary water immersion. Stainless steel studs and rubber caps further protect the terminals from corrosion in marine environments. Where should this circuit breaker be installed? As close as practical to the power source ideally within 300mm of the battery terminal or distribution point to minimise the length of unprotected cable between the battery and the breaker. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1847 150A Type III Heavy Duty Switchable Manual Reset Circuit Breaker IP67 Waterproof Stainless Steel 9.5mm Studs Up to 72VDC The OEX ACX1847 is a 150A Type III heavy duty manual reset circuit breaker designed for high-current circuit protection in automotive, marine, caravan and 4WD applications. Unlike a blade fuse, this circuit breaker can be manually reset after tripping, eliminating the need to carry spare fuses and reducing downtime in the field. IP67 waterproof and dustproof housing with stainless steel 9.5mm studs and rubber protective caps. Rated up to 72VDC. The switchable function also allows the breaker to operate as a manual isolation switch. Covered by a one year warranty. Product overview The ACX1847 extends the OEX Type III circuit breaker series to 150A, suited to the highest-current protection applications including main battery positive supply protection, large dual battery system main feeds, winch circuits, high-capacity inverter protection and marine main power feeds. At 150A it steps well above the ACX1846 (100A) for circuits where the full main supply lead requires protection at this level. The Type III switchable design allows the breaker to function as both a manual reset circuit breaker and a manual on/off isolation switch. The IP67 housing provides complete dust exclusion and protection against temporary water immersion, suited to exposed and deck-mounted installations. The 9.5mm stainless steel studs with rubber protective caps provide secure, corrosion-resistant cable terminations compatible with standard cable lugs and ring terminals with a 9.5mm hole. Rated up to 72VDC, the ACX1847 covers 12V, 24V and 48V DC vehicle and battery systems including solar and battery storage applications. Features and benefits 150A rating: Suited to main battery supply protection, large dual battery feeds, winch circuits, high-capacity inverter protection and marine main power feeds at the highest current level in the OEX circuit breaker range. Manual reset (switchable): Resets after tripping without replacing a fuse, reducing downtime in the field. Can also function as a manual isolation switch. Type III heavy duty construction: Robust housing for demanding automotive, marine and 4WD environments. IP67 waterproof and dustproof: Fully sealed against dust and temporary water immersion, suited to exposed, underbonnet and deck-mounted installations. Up to 72VDC: Suits 12V, 24V and 48V DC electrical systems including solar and battery storage applications. Stainless steel 9.5mm studs: Corrosion-resistant terminations for heavy cable connections. Select cable lugs and ring terminals with a 9.5mm hole to suit. Rubber stud caps: Protect terminals from moisture, corrosion and accidental contact. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1847 Brand OEX Type Circuit Breaker Breaker Type Type III, Manual Reset (Switchable) Current Rating 150A Voltage Rating Up to 72V DC IP Rating IP67 Terminal Studs Stainless steel, 9.5mm Terminal Protection Rubber stud caps Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions What is the advantage of a circuit breaker over a fuse? A circuit breaker can be manually reset after it trips, whereas a fuse must be replaced. In remote or off-road situations where carrying spare fuses may not be practical, a resettable circuit breaker provides a significant convenience and safety advantage. This breaker can also be used as a manual isolation switch when required. How does the ACX1847 compare to the rest of the OEX Type III series? The ACX1847 is rated at 150A, extending the series above the ACX1846 (100A), ACX1845 (80A), ACX1844 (60A) and ACX1843 (50A). All share the same Type III switchable design, 9.5mm stainless studs, IP67 rating and up to 72VDC voltage range. Select based on your circuit's current requirements. What cable termination size does this breaker use? The breaker uses 9.5mm stainless steel studs. Select cable lugs and ring terminals with a 9.5mm hole to suit these studs. Is this breaker suitable for marine use? Yes. The IP67 rating confirms full dust protection and resistance to temporary water immersion. Stainless steel studs and rubber caps further protect the terminals from corrosion in marine environments. Where should this circuit breaker be installed? As close as practical to the power source ideally within 300mm of the battery terminal or distribution pointto minimise the length of unprotected cable between the battery and the breaker. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
