OEX ACX1108 Fire Retardant Split Convoluted Tubing 12.6mm Internal Diameter Black 75m Roll The OEX ACX1108 is a split convoluted tubing sleeve in 12.6mm internal diameter, supplied in a 75m length in black. Manufactured from fire retardant polypropylene with a 120°C melting temperature, the split design allows cables to be inserted from the side without threading. At 12.6mm ID and 15.7mm OD with a maximum bundle size of 12.8mm, it accommodates larger cable bundles than the 9.7mm range, suited to heavier wiring harnesses and multi-cable runs. Suited to automotive, marine and caravan wiring environments. Covered by a one year warranty. Product overview The ACX1108 steps up from the 9.7mm range to a 12.6mm internal diameter, suited to heavier wiring harnesses, multi-cable runs and larger-gauge cable groupings that exceed the 9.9mm maximum bundle capacity of the 9.7mm sizes. The fire retardant polypropylene material resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene sleeving in automotive wiring environments. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses and organising wiring runs without disconnecting connectors. The 75m roll suits trade workshops running regular wiring protection work at this size. Confirm the continuous operating temperature rating with OEX if this is a specific requirement for your underbonnet or high-heat application. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. Fire retardant polypropylene: Resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene in automotive wiring environments. 12.6mm internal diameter and 15.7mm outside diameter: Accommodates larger cable bundles than the 9.7mm range, with a maximum bundle size of 12.8mm suited to heavier wiring harnesses and multi-cable runs. Black: Supplied in black, suited to standard automotive wiring presentation. Convoluted construction: Flexible and bendable while maintaining cable protection against abrasion and chafing, suited to routing through bends and tight spaces. 120°C melting temperature: Provides resistance to high-temperature environments. 75m roll: Trade format for workshops running regular wiring protection work at the 12.6mm size. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1108 Brand OEX Sleeve Type Split Convoluted Tubing Material Fire Retardant Polypropylene Colour Black Inside Diameter 12.6mm Outside Diameter 15.7mm Maximum Cable Bundle 12.8mm Length 75m Melting Temperature 120°C Weight 1.78kg Warranty One year Sold As 75m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The convoluted ribbed construction gives it flexibility and abrasion resistance. What is fire retardant polypropylene? Polypropylene is a lightweight, chemical-resistant thermoplastic commonly used for convoluted tubing. The fire retardant grade used in this product resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin in automotive wiring environments over standard polypropylene sleeving. How does the ACX1108 compare to the 9.7mm options in the OEX range? The ACX1108 has a 12.6mm internal diameter and 12.8mm maximum bundle size, suited to heavier wiring harnesses and multi-cable runs that exceed the 9.9mm maximum bundle capacity of the 9.7mm range (ACX1104, ACX1105, ACX1105/250). Select the 9.7mm range for medium-sized bundles and the ACX1108 for larger or heavier cable groupings. What is the continuous operating temperature of the ACX1108? The continuous operating temperature is not confirmed in the current product data for the ACX1108. The melting temperature is 120°C. Contact us to confirm the continuous operating temperature before purchasing if this is a specific requirement for your application. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1105 Fire Retardant Split Convoluted Tubing 9.7mm Internal Diameter Black 125m Roll The OEX ACX1105 is a split convoluted tubing sleeve in 9.7mm internal diameter, supplied in a 125m length in black. Manufactured from fire retardant polypropylene, the split design allows cables to be inserted from the side without threading. At 9.7mm ID and 12.8mm OD with a maximum bundle size of 9.9mm, it accommodates larger cable bundles than the 7mm range. Rated to 90°C continuous with a melting temperature of 120°C. Covered by a one year warranty. Product overview The ACX1105 is the 9.7mm fire retardant polypropylene option in the OEX split convoluted tubing range, combining the larger internal diameter of the ACX1104 with the fire retardant material specification of the 7mm ACX1102 and ACX1100/400 range. This makes it suited to workshops that regularly use 9.7mm tubing for medium-sized cable bundles and require the added safety margin of fire retardant polypropylene over standard corrugated polypropylene. The fire retardant polypropylene material resists ignition and self-extinguishes if a flame source is removed. The split design allows cables to be pressed in from the side along the lengthwise opening without threading from one end, making it practical for retrofitting protection to installed harnesses without disconnecting connectors. The 125m roll is a mid-to-high volume trade format suited to workshops running regular wiring protection work across automotive, 4WD, caravan, trailer and marine installations. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. Fire retardant polypropylene: Resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene in automotive wiring environments. 9.7mm internal diameter and 12.8mm outside diameter: Accommodates larger cable bundles than the 7mm range, with a maximum bundle size of 9.9mm suited to medium-sized wire bundles and individual larger-gauge cables. Black: Supplied in black, suited to standard automotive wiring presentation. Convoluted construction: Flexible and bendable while maintaining cable protection against abrasion and chafing, suited to routing through bends and tight spaces. 90°C continuous temperature rating: Suited to automotive and underbonnet environments where sustained heat is present. 120°C melting temperature: Provides a safety margin above the continuous rating for short-duration heat exposure. 125m roll: Mid-to-high volume trade format for workshops running regular wiring protection work at the 9.7mm size. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1105 Brand OEX Sleeve Type Split Convoluted Tubing Material Fire Retardant Polypropylene Colour Black Inside Diameter 9.7mm Outside Diameter 12.8mm Maximum Cable Bundle 9.9mm Length 125m Temperature Rating 90°C continuous Melting Temperature 120°C Weight 2.48kg Warranty One year Sold As 125m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The convoluted ribbed construction gives it flexibility and abrasion resistance. What is fire retardant polypropylene? Polypropylene is a lightweight, chemical-resistant thermoplastic commonly used for convoluted tubing. The fire retardant grade used in this product resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin in automotive wiring environments over standard polypropylene sleeving. How does the ACX1105 compare to the ACX1104? Both are 9.7mm split convoluted tubing with the same internal and outside diameter. The ACX1104 is made from corrugated polypropylene with a UL HB or V2 flammability rating and is supplied on a 30m workshop roll. The ACX1105 is made from fire retardant polypropylene and is supplied on a 125m mid-to-high volume trade roll. Select the ACX1104 for single-vehicle workshop jobs and the ACX1105 for regular workshop use where fire retardant material is preferred. Is this tubing suitable for underbonnet use? Yes. The 90°C continuous temperature rating and 120°C melting temperature make it suitable for most automotive underbonnet environments. For areas with sustained extreme heat exposure, verify the ambient temperature against the tubing rating before use. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0708 Australian Made 3mm Single Core Automotive Cable Pink 30m Roll OFHC Copper 10A V90 The OEX ACX0708 is a 3mm single core automotive cable in pink, supplied on a 30m roll. Manufactured in Australia from 99.99% oxygen free high conductivity (OFHC) copper, it features a 1.13mm² conductor cross-section and a 10A continuous rating at 30°C, suited to higher-current accessory circuits, lighting runs and general automotive wiring. The pink PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0708 is the pink 30m variant in the OEX 3mm single core automotive cable range, sharing the same conductor specification and insulation rating as the other colours in the range. Pink cable is used in automotive and trailer wiring installations where an expanded colour palette is needed to differentiate circuits in complex multi-wire harness builds and custom vehicle electrical systems where the full standard colour set is already in use. It provides a distinctive identifier in installations requiring a broad range of circuit colours at the 3mm gauge. At 1.13mm² (17AWG) with a 10A continuous rating, the ACX0708 handles higher-current circuits where the 2mm 5A-rated cable would be undersized. The 16-strand conductor construction provides flexibility for routing through tight spaces and around bends. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 30m roll suits workshop jobs and multi-circuit installations without the bulk of a full-length trade roll. Features and benefits 99.99% OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. Pink colour coding: Pink provides a distinctive additional circuit identifier for complex multi-wire harness builds and custom electrical installations where the standard colour set is already allocated, supporting clear differentiation across all circuits. 10A rated at 30°C: Higher current capacity than the 2mm range, suited to lighting circuits, relay feeds, switch wiring and higher-draw accessory circuits in 12V and 24V systems. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 16-strand construction: The 16-strand conductor provides flexibility and resistance to fatigue during installation and in service. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. CAN bus compatible: Meets the signal integrity requirements for use in modern vehicle communication network environments. 30m roll: Workshop-friendly length for multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0708 Brand OEX Cable Type Single Core Automotive Industry Known Size 3mm Conductor Cross Section 1.13mm² Gauge 17AWG Conductor Strands 16 Strand Diameter 0.32mm Conductor Material 99.99% OFHC Copper Amp Rating 10A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Pink Length 30m Weight 0.42kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is the difference between the 3mm and 2mm OEX automotive cable? The 3mm cable has a larger conductor cross-section (1.13mm² vs 0.5mm²), a higher amp rating (10A vs 5A at 30°C) and a higher voltage rating (110V vs 100V). It is suited to circuits drawing more current than the 2mm range can safely handle, including lighting circuits, relay feeds and higher-draw accessories. What is the amp rating for this cable? This cable is rated at 10A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across both the 2mm and 3mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0702 Australian Made 3mm Single Core Automotive Cable Red 30m Roll OFHC Copper 10A V90 The OEX ACX0702 is a 3mm single core automotive cable in red, supplied on a 30m roll. Manufactured in Australia from 99.99% oxygen free high conductivity (OFHC) copper, it features a 1.13mm² conductor cross-section and a 10A continuous rating at 30°C, suited to higher-current accessory circuits, lighting runs and general automotive wiring. The red PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0702 is the red 30m variant in the OEX 3mm single core automotive cable range, sharing the same conductor specification and insulation rating as the black ACX0700 and green ACX0701. Red is the conventional colour for positive wiring in automotive and marine electrical installations, making the ACX0702 the natural choice for positive accessory feeds, lighting circuits and relay feeds in 3mm installations where colour convention supports circuit identification. At 1.13mm² (17AWG) with a 10A continuous rating, this cable handles circuits where the 2mm 5A-rated cable would be undersized. The 16-strand conductor construction provides flexibility for routing through tight spaces and around bends. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 30m roll suits workshop jobs and multi-circuit installations without the bulk of a full-length trade roll. Features and benefits 99.99% OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. Red colour coding: Red is the conventional positive wiring colour in automotive and marine electrical installations, assisting with circuit identification and reducing wiring errors in multi-wire runs. 10A rated at 30°C: Higher current capacity than the 2mm range, suited to lighting circuits, relay feeds, switch wiring and higher-draw accessory circuits in 12V and 24V systems. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 16-strand construction: The 16-strand conductor provides flexibility and resistance to fatigue during installation and in service. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. CAN bus compatible: Meets the signal integrity requirements for use in modern vehicle communication network environments. 30m roll: Workshop-friendly length for multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0702 Brand OEX Cable Type Single Core Automotive Industry Known Size 3mm Conductor Cross Section 1.13mm² Gauge 17AWG Conductor Strands 16 Strand Diameter 0.32mm Conductor Material 99.99% OFHC Copper Amp Rating 10A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Red Length 30m Weight 0.42kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is the difference between the 3mm and 2mm OEX automotive cable? The 3mm cable has a larger conductor cross-section (1.13mm² vs 0.5mm²), a higher amp rating (10A vs 5A at 30°C) and a higher voltage rating (110V vs 100V). It is suited to circuits drawing more current than the 2mm range can safely handle, including lighting circuits, relay feeds and higher-draw accessories. What is the amp rating for this cable? This cable is rated at 10A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across both the 2mm and 3mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0675 Polypropylene Battery Box for N50 Battery with Tie-Down Strap and Mounting Hardware The OEX ACX0675 is a polypropylene plastic battery box designed to safely house and secure a battery in automotive, caravan, marine and 4WD applications. Constructed from acid-impervious polypropylene, it withstands exposure to battery acid without degrading. External dimensions are 285 x 200 x 200mm and internal dimensions are 275 x 180 x 200mm, sized to suit an N50 battery. A tie-down strap and mounting hardware are included. Covered by a one year warranty. Product overview The ACX0675 provides a purpose-built enclosure for securing a battery in installations where the battery cannot be mounted in a factory battery tray, including auxiliary battery setups in 4WD vehicles, caravan and camper trailer battery installations, marine battery compartments and off-grid portable power applications. The acid-impervious polypropylene construction resists degradation from battery acid contact, making it a reliable long-term housing solution for lead-acid and AGM batteries. The rigid polypropylene body provides structural protection for the battery against impact and vibration in mobile applications. A tie-down strap and all necessary mounting hardware are included in the pack, providing a complete installation solution without requiring additional fixings. The external dimensions of 285 x 200 x 200mm keep the footprint compact for tight installation spaces, while the 275 x 180 x 200mm internal cavity is sized specifically for the N50 battery format. Always verify your battery's physical dimensions against the internal dimensions before purchasing to confirm correct fitment. Features and benefits Polypropylene construction: Rigid, durable plastic that resists impact and chemical exposure, providing long-term structural integrity in demanding automotive and marine environments. Acid-impervious material: Will not degrade or corrode from battery acid contact, suited to wet-cell lead-acid and AGM battery installations where acid exposure is a risk. Suits N50 battery: Internal dimensions of 275 x 180 x 200mm are sized specifically for N50 type batteries. Verify your battery's dimensions before purchasing. Tie-down strap included: Secures the battery against movement and vibration during vehicle operation, reducing the risk of terminal damage or battery displacement. Mounting hardware included: All fixings are provided for a complete installation straight from the pack. Compact footprint: External dimensions of 285 x 200 x 200mm suit tight installation spaces in engine bays, under-seat compartments and caravan battery enclosures. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX0675 Brand OEX Material Polypropylene plastic External Dimensions 285 x 200 x 200mm (L x W x H) Internal Dimensions 275 x 180 x 200mm (L x W x H) Compatible Battery Type N50 Included Accessories Tie-down strap, mounting hardware Weight 0.7kg Warranty One year Sold As Each Frequently asked questions What battery type does this box suit? The ACX0675 is sized to suit an N50 battery, with internal dimensions of 275 x 180 x 200mm. Always verify your battery's physical dimensions before purchasing to ensure a correct fit. Is this box suitable for AGM or lithium batteries? The box is a physical housing and is not chemistry-specific. It will house any battery that fits within the internal dimensions. The acid-impervious polypropylene construction is particularly beneficial for wet-cell lead-acid batteries, but the box is equally suitable for AGM batteries of the same physical size. For lithium batteries, confirm the physical dimensions match the internal cavity before purchasing. What hardware is included? A tie-down strap and mounting hardware are included in the pack, providing everything needed to secure the box and battery in place without requiring additional fixings. Is the box waterproof? The polypropylene construction resists acid and moisture, but the ACX0675 is not rated as fully sealed or waterproof. For marine or exposed outdoor installations, ensure battery terminals and connections are protected independently from moisture ingress. Can this box be used in a vehicle engine bay? Yes. Polypropylene battery boxes are commonly used in engine bays for auxiliary battery installations. Ensure adequate clearance around the box and that it is securely mounted using the provided hardware, positioned away from direct heat sources and moving components. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0025 Solid Brass Marine Stud Type 10mm Positive Battery Terminal One Piece Pack of 5 The OEX ACX0025 is a solid brass one-piece marine stud type positive battery terminal with a 10mm stud and wing nut, suited to standard battery posts. Supplied in a pack of 5 with a one-year warranty. Product overview The ACX0025 is a positive-only marine stud terminal with a 10mm diameter stud, designed for automotive, marine and caravan battery installations where a robust threaded stud connection is required. The one-piece brass construction eliminates the jointed construction found in some terminals, providing a more rigid and electrically consistent connection point. The 10mm stud accepts ring terminals, lugs and accessories up to a 10mm hole size, and the wing nut allows connections to be tightened or released by hand. The solid brass body provides corrosion resistance and reliable conductivity in marine, 4WD and outdoor environments. The pack of 5 suits workshop, trade and fleet use. Confirm cable size compatibility with F.A.E. before purchasing if you have specific cable requirements. The negative counterpart to this terminal is the ACX0006N. Features and benefits One-piece brass construction: Single-piece construction provides greater rigidity and a more consistent electrical connection than jointed or multi-part terminals. 10mm marine stud with wing nut: The 10mm threaded stud accepts ring terminals and lugs up to 10mm hole size, with a wing nut for tool-free tightening and release. Solid brass body: Brass provides excellent corrosion resistance and conductivity, suited to marine, automotive and 4WD environments. Positive polarity: Designed for positive standard battery post installations only. Contact us for compatible negative terminal options. Suits standard battery posts: Compatible with standard battery post sizes used across the majority of automotive, marine and caravan batteries. Pack of 5: Five terminals per pack suits workshop, trade and fleet use. One year warranty: Covered by a one-year OEX warranty. Technical specs Specification Detail SKU ACX0025 Brand OEX Terminal Style Marine Stud Type Termination Type Stud with wing nut Stud Diameter 10mm Construction One piece Polarity Positive Terminal Size Standard battery post Material Solid brass Pack Quantity 5 Weight 0.651kg (pack) Warranty One year Sold As Pack of 5 Frequently asked questions Is the ACX0025 suitable for negative battery connections? No. The ACX0025 is a positive-only terminal. Contact us for compatible negative battery terminal options in the OEX range. What is the stud diameter on the ACX0025? The ACX0025 uses a 10mm diameter stud. Ring terminals and cable lugs connected to this terminal must have a hole size of 10mm or larger to fit correctly. What cable sizes does the ACX0025 accept? Cable size compatibility is not confirmed in the current product data. Contact us with your cable size requirements and we can confirm suitability before you purchase. What does one-piece construction mean for this terminal? One-piece construction means the terminal body and stud are manufactured as a single integrated unit rather than being assembled from separate components. This provides greater structural rigidity and eliminates potential weak points at joints, resulting in a more reliable electrical connection over the life of the terminal. How does the ACX0025 differ from the ACX0006P? Both are solid brass positive marine stud terminals with wing nuts for standard battery posts. The ACX0025 specifies a 10mm stud diameter and one-piece construction, and is supplied in a pack of 5. The ACX0006P does not specify a stud diameter in the current product data and is supplied in a pack of 10. Contact us if you need help selecting the correct terminal for your application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX LLX3003 Underbonnet LED Work Light Extendable The OEX LLX3003 is an extendable underbonnet LED work light, stretching from 1.2m to 2.0m, delivering 1000 lumens with magnet and hook mounting options and USB charging. Product Overview The LLX3003 is an extendable underbonnet LED work light from OEX, powered by powerful SMD LEDs producing 1000 lumens of light. Extendable from 1.2m to 2.0m, the light is designed to reach across an engine bay or work area for any job, with two magnets and two soft hooks for mounting to almost any surface. Battery life runs to 8 hours on 500 lumen output, or 4 hours on the full 1000 lumen setting, with an approximate 3 hour charge time using the included USB charge cable. Features & Benefits 1000 Lumen SMD LEDs: Powerful SMD LEDs produce up to 1000 lumens of light for clear visibility during underbonnet or general work. Extendable 1.2m to 2.0m Length: The extendable design stretches from 1.2m to 2.0m, letting the light reach across a wide engine bay or work area. Two Mounting Options: Two strong magnets and two soft hooks allow mounting to almost any surface, whether metal or non-metal. Up to 8 Hours Battery Life: Battery life reaches up to 8 hours on the 500 lumen setting, or 4 hours on the full 1000 lumen output. Fast USB Charging: An approximate 3 hour charge time via the included USB charge cable keeps the light ready to go. Technical Specs Specification Detail Part No. LLX3003 Brand OEX Description Underbonnet LED Work Light, Extendable Length Light Type LED (SMD) Light Output 1000 Lumen Extendable Length 1.2m to 2.0m Battery Life 8 Hours @ 500 Lumen, 4 Hours @ 1000 Lumen Charge Time Approx. 3 Hours (USB) Mounting 2 x Magnets, 2 x Soft Hooks Compatible With The LLX3003 is a standalone rechargeable work light suited to underbonnet inspection and general workshop use, mounting via its included magnets or hooks to almost any surface. Frequently Asked Questions What is the LLX3003 used for? The LLX3003 is an extendable LED work light designed for underbonnet inspection and general workshop lighting tasks. How far does the LLX3003 extend? The LLX3003 extends from 1.2m to 2.0m, letting it reach across a wide engine bay or work area. How long does the battery last? Battery life is up to 8 hours on the 500 lumen setting, or 4 hours on the full 1000 lumen output. How is the LLX3003 mounted? The LLX3003 includes two strong magnets and two soft hooks for mounting to almost any surface. How long does it take to charge? The LLX3003 takes approximately 3 hours to charge using the included USB charge cable. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0902 Australian Made 6 B&S Single Core Battery Cable Black 30m Roll OFHC Copper 13.36mm² V90 The OEX ACX0902 is a 6 B&S single core battery cable in black, supplied on a 30m roll. With a 13.36mm² OFHC copper conductor across 192 strands, this cable steps up from the 8 B&S range and is designed for demanding high-current applications including heavy battery interconnects, starter motor wiring and main supply runs where low resistance and high current capacity are required. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Product overview At 13.36mm² with a 192-strand OFHC copper conductor, the ACX0902 provides significantly lower resistance and higher current-carrying capacity than the 8 B&S range at 7.91mm². This makes it suited to longer battery cable runs, circuits with higher current demand, and applications where minimising voltage drop across the cable is critical. Common applications include battery interconnect and main supply cables, starter motor and alternator wiring, dual battery system main feeds, winch and recovery equipment power cables and heavy-duty accessory wiring requiring a large conductor cross-section. The 192-strand construction provides exceptional flexibility for routing through tight engine bay and battery compartment spaces despite the larger gauge. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for battery and engine bay installations. The voltage rating of up to 120V is slightly wider than the standard automotive cable range. The 30m roll suits workshop jobs and single-vehicle installations without the bulk of a full-length trade roll. Always verify the required cable size with a licensed auto electrician for your specific application, current load and run length. Features and benefits 6 B&S gauge battery cable: Larger battery cable sizing suited to demanding high-current 12V and 24V applications where the 8 B&S range would be undersized. 13.36mm² conductor cross-section: Significantly larger than the 8 B&S (7.91mm²), providing reduced resistance and higher current-carrying capacity for longer runs and more demanding circuits. 192-strand construction: Exceptional flexibility for routing through tight engine bay and battery compartment spaces despite the larger cable gauge, with more strands than the 8 B&S range for improved handling. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across demanding battery and supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments. Up to 120V voltage rating: Slightly wider voltage rating than the standard automotive cable range. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Workshop-friendly length for single-vehicle and multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0902 Brand OEX Cable Type Single Core Battery Cable Gauge 6 B&S Conductor Cross Section 13.36mm² Conductor Strands 192 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 120V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Black Length 30m Weight 4.44kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is B&S gauge and how does it differ from AWG or metric sizing? B&S (Brown and Sharpe) is a wire gauge system commonly used in Australian battery and heavy-duty automotive cable. 6 B&S is equivalent to approximately 6 AWG and corresponds to a conductor cross-section of around 13.36mm². It is a standard sizing reference used by Australian auto electricians and suppliers for battery and starter cables. How does 6 B&S compare to 8 B&S? 6 B&S has a significantly larger conductor cross-section (13.36mm² vs 7.91mm²) and more strands (192 vs 112), giving it lower resistance and higher current-carrying capacity. Select 6 B&S for longer runs or circuits with higher current demand than 8 B&S can comfortably handle. Always verify the correct cable size with a licensed auto electrician for your specific application. Is a 30m roll sufficient for a single-vehicle installation? The 30m roll suits most single-vehicle heavy-duty battery cable installations including dual battery runs, winch feeds and starter motor wiring. For fleet operations or multiple installations from a single roll, the ACX0902L 100m roll version is available. Contact us for details. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX6520 80A Bolt On Mega Fuse SF51 Type Copper Tin Plated Pack of 5 The OEX ACX6520 is an 80A bolt-on mega fuse of SF51 type, rated to 32V DC with copper tin plated contacts. Measuring 68.5mm in length with a 50.8mm centre-to-centre mounting distance, it is supplied in a pack of 5. Covered by a one-year warranty. Also available individually as the ACX6520BL. Product overview The ACX6520 shares the same SF51 mega fuse format and physical dimensions as the ACX6519, with the amperage rating stepped up to 80A for higher-current circuit protection requirements. It is designed for bolt-on fusing applications in 12V and 24V automotive, caravan and marine electrical systems where a secure bolted connection is required. Copper tin plated contacts provide reliable conductivity and oxidation resistance over the service life of the fuse. The pack of 5 suits workshop, trade and owner-installer use where having spare fuses on hand is practical. The 50.8mm centre-to-centre bolt spacing is compatible with a wide range of mega fuse holders. The single-unit version of this fuse is available as ACX6520BL. Features and benefits 80A rated mega fuse: 80A rating suits higher-current circuits in 12V and 24V systems including larger amplifier main feeds, heavy accessory power runs and winch circuits. Bolt-on SF51 type: Bolt-on connection provides a secure, vibration-resistant installation suited to high-current applications where connection integrity is critical. Copper tin plated contacts: Tin-plated copper contacts provide reliable conductivity and resist oxidation over time, maintaining consistent fuse performance. 32V DC rating: Compatible with both 12V and 24V DC vehicle electrical systems within the 32V rating. 50.8mm centre-to-centre mounting: Standard mega fuse bolt spacing compatible with a wide range of mega fuse holders. Pack of 5: Five fuses per pack provides spares for workshop or trade use alongside the installed fuse. One year warranty: Covered by a one-year OEX warranty. Technical specs Specification Detail SKU ACX6520 Brand OEX Fuse Type Mega (SF51) Amperage 80A Voltage Rating 32V DC Contact Material Copper tin plated Length 68.5mm Mount Centre to Centre 50.8mm Pack Quantity 5 Warranty One year Sold As Pack of 5 Frequently asked questions What is the difference between the ACX6519 and the ACX6520? Both are SF51 type bolt-on mega fuses with identical physical dimensions and specifications. The ACX6519 is rated at 60A while the ACX6520 is rated at 80A. Select the correct amperage for your circuit protection requirements. Is the ACX6520 available individually? Yes. The ACX6520BL is the single-unit version of this fuse. Contact us to order the single pack if you only need one fuse. What fuse holder is compatible with the ACX6520? The ACX6520 uses a standard SF51 mega fuse format with 50.8mm centre-to-centre bolt spacing, compatible with mega fuse holders designed for this spacing. Contact us if you need help selecting a compatible OEX fuse holder. Can the ACX6520 be used in a 24V system? Yes. The ACX6520 is rated to 32V DC, covering both 12V and 24V vehicle electrical systems. Is the 80A rating suitable for my application? 80A suits higher-current automotive circuits including larger amplifier feeds and heavy accessory installations. If you are unsure whether 80A is the correct rating for your circuit, contact us for advice. OEX mega fuses are available in other amperage ratings if a different value is required. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1316 Black Nylon 66 UV Resistant Cable Ties 3.6mm x 150mm Pack of 100 The OEX ACX1316 is a pack of 100 black nylon cable ties, each measuring 3.6mm wide by 150mm long. Manufactured from nylon 66 for strength and stability, and UV resistant for outdoor and underbonnet applications, these are a workshop staple for bundling cables, securing wiring harnesses and organising cable runs in automotive, marine and caravan installations. Supplied in a resealable, reusable bag. Also available in a pack of 25 as ACX1316-25. Covered by a one year warranty. Product overview Nylon 66 is the preferred material for automotive-grade cable ties, providing higher tensile strength, heat resistance and dimensional stability than standard nylon 6. The UV resistant black construction makes these ties suited to outdoor, sun-exposed and underbonnet applications where standard cable ties would degrade and become brittle over time. Black ties are the standard choice for automotive wiring work they blend with wiring harnesses and body panels, and the UV resistant black pigment provides better sun resistance than natural or white ties of the same material. At 3.6mm wide by 150mm long, the ACX1316 is a standard light to medium duty cable tie size suited to bundling individual cables and small harnesses. At 150mm length, each tie accommodates bundles up to approximately 35mm to 40mm in diameter. The resealable bag keeps unused ties tidy between jobs. The pack of 100 suits trade workshops keeping cable tie stock on hand. For lower-volume requirements, the ACX1316-25 pack of 25 is also available. Features and benefits Nylon 66 construction: High-strength, stable material providing greater tensile strength, heat resistance and dimensional stability than standard nylon 6, suited to automotive-grade cable bundling applications. UV resistant: Resists degradation and brittleness from prolonged sun exposure, suited to outdoor, sun-exposed and underbonnet applications. 3.6mm x 150mm: Standard cable tie size for light to medium duty bundling of individual cables and small harnesses up to approximately 35mm to 40mm bundle diameter. Black: Standard colour for automotive wiring work, blending with harnesses and body panels with better UV resistance than natural or white ties. Pack of 100: Trade quantity for workshop stock, keeping cable ties on hand across multiple jobs. Resealable, reusable bag: Keeps unused ties tidy and organised between jobs. Also available in pack of 25: The ACX1316-25 is the same cable tie in a smaller pack for lower-volume requirements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1316 Brand OEX Item Type Cable Tie Material Nylon 66 Width 3.6mm Length 150mm Colour Black UV Resistant Yes Pack Quantity 100 Packaging Resealable, reusable bag Weight 0.072kg Warranty One year Sold As Pack of 100 Frequently asked questions What is nylon 66 and why does it matter for cable ties? Nylon 66 is a high-performance polyamide material commonly used for automotive-grade cable ties due to its high tensile strength, heat resistance and dimensional stability. It outperforms standard nylon 6 in both strength and temperature resistance, making it the preferred specification for automotive wiring applications. Are these cable ties suitable for outdoor or underbonnet use? Yes. The UV resistant black nylon 66 construction makes them suitable for outdoor, sun-exposed and underbonnet applications where standard ties may degrade and become brittle over time. What bundle diameter can these ties accommodate? A 150mm cable tie can accommodate bundles up to approximately 35mm to 40mm in diameter depending on how the tie is applied. For larger bundles, OEX produces cable ties in a range of sizes. Contact us for available options. Is this product available in a smaller pack quantity? Yes. The ACX1316-25 is the same 3.6mm x 150mm black nylon 66 cable tie available in a pack of 25, suited to lower-volume requirements. Can these cable ties be reused? Standard nylon cable ties are single-use once the locking head is engaged, the tie cannot be released without cutting. The resealable bag they are supplied in is reusable for storage of unused ties between jobs. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
