OEX ACX1100/400 Fire Retardant Split Convoluted Tubing 7mm Internal Diameter Black 400m Roll The OEX ACX1100/400 is a split convoluted tubing sleeve in 7mm internal diameter, supplied in a 400m roll in black. Manufactured from fire retardant polypropylene, the split design allows cables to be inserted from the side without threading, making it well suited to retrofitting protection onto existing wiring harnesses and tidying up loose or exposed wiring runs. Rated to 90°C continuous with a melting temperature of 120°C. Suited to automotive, marine and caravan wiring environments including underbonnet applications. Product overview The ACX1100/400 builds on the standard split convoluted tubing format with a fire retardant polypropylene material that resists ignition and self-extinguishes if a flame source is removed, providing an added layer of safety in automotive wiring environments where a standard polypropylene sleeve would not be specified. The split design allows cables to be pressed in from the side along the lengthwise opening rather than threaded from one end, making it practical for retrofitting protection to installed harnesses and organising loose cable runs without disconnecting connectors. At 7mm internal diameter and 10.4mm outside diameter, the ACX1100/400 suits a wider range of cable bundles than the 5mm ACX1099/100. Note that the maximum cable bundle diameter for this size is 7mm matching the internal diameter. For bundles approaching this limit, confirm the fit before purchasing. The 400m roll is a high-volume trade format suited to workshop operations running large quantities of wiring protection across multiple jobs. Features and benefits Split design for retrofit installation: Cables snap in from the side without threading, allowing the tubing to be added to existing wiring runs without disconnecting connectors or rerouting cables. Fire retardant polypropylene: Resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin over standard polypropylene in automotive wiring environments. 7mm internal diameter and 10.4mm outside diameter: Suits a wider range of single cables and small wire bundles than the 5mm ACX1099/100. Black: Supplied in black, suited to standard automotive wiring presentation. Convoluted construction: Flexible and bendable while maintaining cable protection against abrasion and chafing, suited to routing through bends and tight spaces. 90°C continuous temperature rating: Suited to automotive and underbonnet environments where sustained heat is present. 120°C melting temperature: Provides a safety margin above the continuous rating for short-duration heat exposure. 400m roll: High-volume trade format for workshop wiring protection operations covering multiple jobs from a single roll. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1100/400 Brand OEX Sleeve Type Split Convoluted Tubing Material Fire Retardant Polypropylene Colour Black Inside Diameter 7mm Outside Diameter 10.4mm Maximum Cable Bundle 7mm Length 400m Temperature Rating 90°C continuous Melting Temperature 120°C Weight 5kg Warranty One year Sold As 400m roll Frequently asked questions What is split convoluted tubing? Split convoluted tubing is a flexible ribbed sleeving with a lengthwise split along one side. Cables can be pressed into the split opening rather than threaded through from the end, making it easy to add protection to existing wiring without disconnecting anything. The convoluted ribbed construction gives it flexibility and abrasion resistance. What is fire retardant polypropylene and why does it matter in automotive wiring? Polypropylene is a lightweight, chemical-resistant thermoplastic commonly used for convoluted tubing. The fire retardant grade used in this product resists ignition and self-extinguishes if a flame source is removed, providing an added safety margin in automotive wiring environments over standard polypropylene sleeving. What size cables fit inside 7mm convoluted tubing? The 7mm internal diameter suits individual cables and small bundles up to 7mm in diameter. For smaller bundles, the 5mm ACX1099/100 may be a better fit. For larger bundles, OEX produces convoluted tubing in larger internal diameter sizes. Is this tubing suitable for underbonnet use? Yes. The 90°C continuous temperature rating and 120°C melting temperature make it suitable for most automotive underbonnet environments. For areas with sustained extreme heat exposure, verify the ambient temperature against the tubing rating before use. How do I cut split convoluted tubing to length? Split convoluted tubing can be cut with scissors, side cutters or a sharp blade. Cut between the ribs rather than through them for a cleaner end. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1329 Black Nylon 66 UV Resistant Cable Ties 3.6mm x 280mm Pack of 100 The OEX ACX1329 is a pack of 100 black nylon cable ties, each measuring 3.6mm wide by 280mm long. Manufactured from nylon 66 for strength and stability, and UV resistant for outdoor and underbonnet applications. The 280mm length suits medium to larger bundle diameters where the 150mm ACX1316 is insufficient but the full 4.8mm strap width of the ACX1317 is not required. Supplied in a resealable, reusable bag. Covered by a one year warranty. Product overview The ACX1329 fills the gap in the OEX 3.6mm cable tie range between the 150mm ACX1316 and the 300mm ACX1319, providing a 280mm option for applications where the 150mm tie does not reach around the bundle but the narrower 3.6mm strap width is preferred over stepping up to the 4.8mm range. The 280mm length accommodates bundles up to approximately 70mm to 75mm in diameter, suited to medium-sized harnesses and multi-cable groupings that fall between the lighter-duty 150mm size and the larger 4.8mm alternatives. Nylon 66 provides higher tensile strength, heat resistance and dimensional stability than standard nylon 6. The UV resistant black construction suits outdoor, sun-exposed and underbonnet applications. The resealable bag keeps unused ties tidy between jobs. Features and benefits Nylon 66 construction: High-strength, stable material providing greater tensile strength, heat resistance and dimensional stability than standard nylon 6, suited to automotive-grade cable bundling applications. UV resistant: Resists degradation and brittleness from prolonged sun exposure, suited to outdoor, sun-exposed and underbonnet applications. 3.6mm x 280mm: Longer than the 3.6mm x 150mm ACX1316 for medium to larger bundle diameters up to approximately 70mm to 75mm, while retaining the narrower 3.6mm strap width for installations where the wider 4.8mm strap is not required. Black: Standard colour for automotive wiring work, blending with harnesses and body panels with better UV resistance than natural or white ties. Pack of 100: Trade quantity for workshop stock. Resealable, reusable bag: Keeps unused ties tidy and organised between jobs. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1329 Brand OEX Item Type Cable Tie Material Nylon 66 Width 3.6mm Length 280mm Colour Black UV Resistant Yes Pack Quantity 100 Packaging Resealable, reusable bag Warranty One year Sold As Pack of 100 Frequently asked questions What is nylon 66 and why does it matter for cable ties? Nylon 66 is a high-performance polyamide material commonly used for automotive-grade cable ties due to its high tensile strength, heat resistance and dimensional stability. It outperforms standard nylon 6 in both strength and temperature resistance, making it the preferred specification for automotive wiring applications. How does the ACX1329 fit into the OEX 3.6mm cable tie range? The OEX 3.6mm range includes the 150mm ACX1316, the 280mm ACX1329 and the 300mm ACX1319. The ACX1329 fills the gap between the light-duty 150mm size and the longer 300mm option, suited to medium bundle diameters up to approximately 70mm to 75mm where the 150mm tie is too short but the full 300mm length is more than required. What bundle diameter can these ties accommodate? A 280mm cable tie can accommodate bundles up to approximately 70mm to 75mm in diameter depending on how the tie is applied. For smaller bundles the 3.6mm x 150mm ACX1316 is better suited, and for larger bundles the 4.8mm x 370mm ACX1320 provides greater capacity. What is the tensile strength of these cable ties? Tensile strength is not confirmed in the current product data. Contact us if a specific tensile strength rating is required for your application. Can these cable ties be reused? Standard nylon cable ties are single-use once the locking head is engaged, the tie cannot be released without cutting. The resealable bag they are supplied in is reusable for storage of unused ties between jobs. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX2805 7 Pin Flat Trailer Socket 15A 12V Surface Mount Chrome Plated Brass Terminals Australian Standard The OEX ACX2805 is a 7-pin flat trailer socket rated at 15A and 12V, with a plastic surface mount housing and chrome plated brass terminals. The 7-pin flat connector is the standard trailer socket format used across Australia for caravans, trailers, horse floats and boat trailers. The surface mount design allows the socket to be fitted to a tow bar, chassis rail or body panel. The matching plug for this socket is the OEX ACX2804. Supplied as a single unit. Covered by a one year warranty. Product overview The 7-pin flat socket is the female, vehicle-side connector in the Australian standard trailer connection system. It mounts to the tow bar, chassis rail or body panel and accepts the 7-pin flat plug from the trailer wiring harness. The ACX2805 carries seven circuits following the Australian standard AS4177, including left indicator, right indicator, tail and marker lights, brake lights, reverse lights, electric brake control and a battery charging circuit. The chrome plated brass terminals provide reliable conductivity and corrosion resistance across all seven circuits. The surface mount housing attaches directly to a flat surface using screws through the housing. At 15A the socket suits standard trailer lighting and electric brake controller circuits. Features and benefits 7-pin flat format: Australian standard trailer socket format for caravans, trailers, horse floats and boat trailers. Surface mount: Mounts directly to a tow bar, chassis rail or body panel using screws through the housing. 15A at 12V: Suited to standard trailer lighting and electric brake controller circuits. Chrome plated brass terminals: Reliable conductivity and corrosion resistance across all seven circuits. Plastic housing: Lightweight and durable for automotive and trailer applications. Matches OEX ACX2804 plug: The ACX2804 7-pin flat plug is the direct counterpart for this socket. Single unit: For new installation or replacement of a damaged 7-pin flat socket. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX2805 Brand OEX Connector Type 7 Pin Flat Style Socket (vehicle and tow bar side) Mount Type Surface mount Current Rating 15A Voltage 12V Housing Material Plastic Terminal Material Chrome plated brass Pack Quantity 1 Weight 0.08kg Warranty One year Sold As Single unit Frequently asked questions What is the difference between a trailer plug and socket? The socket is the female connector, typically mounted on the vehicle tow bar or chassis. The plug is the male connector, typically on the trailer cable or wiring harness. The ACX2805 is the socket (female, vehicle side). The matching plug is the ACX2804. What circuits does a 7-pin flat connector carry? A standard 7-pin flat connector carries left indicator, right indicator, tail and marker lights, brake lights, reverse lights, electric brake control and a battery charging circuit, following the Australian standard AS4177. How is this socket mounted? The ACX2805 is a surface mount socket that mounts directly to a flat surface such as a tow bar, chassis rail or body panel using screws through the housing. Is this socket weatherproof? Weatherproofing is not specified for this SKU. For exposed or demanding installations, consider a heavy duty or sealed trailer socket from the OEX range. What plug does this socket accept? The ACX2805 accepts a standard 7-pin flat trailer plug such as the OEX ACX2804, and any other Australian standard 7-pin flat plug. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX GLX16070 H7 Globe 12V 55W Standard The OEX GLX16070 is a 12V 55W standard H7 globe with a PX26d base, manufactured to international and Australian standards. Product Overview The GLX16070 is a 12V 55W standard H7 globe from OEX, featuring a PX26d base. This long life globe is manufactured to international and Australian standards, offering a high quality product at a standard price. Features & Benefits Long Life Product: Designed as a long life globe, offering extended service life at a standard price point. High Quality Standard: Manufactured to international and Australian standards, ensuring reliable performance. H7 Fitment: The H7 globe style with PX26d base suits a wide range of vehicles using this common headlight fitting. Technical Specs Specification Detail Part No. GLX16070 Brand OEX Description H7 Globe, 12V, 55W, Standard Globe Style H7 Globe Base PX26d Voltage 12V Wattage 55W Globe Type Standard Pack Quantity 1 Weight 0.02kg Compatible With The GLX16070 is compatible with vehicles requiring an H7 globe with a PX26d base, the same fitting used on the OEX GLX16073TP twin pack. Confirm your headlight fitting matches before purchase. Frequently Asked Questions What is the GLX16070 used for? The GLX16070 is a 12V 55W H7 globe used as a standard replacement headlight globe. How many globes are included? The GLX16070 is sold individually, as a single globe. What is the difference between the GLX16070 and GLX16073TP? Both share the same H7 PX26d fitting, but the GLX16070 is a single standard globe, while the GLX16073TP is a Xenon Blue twin pack with bonus wedge globes and named vehicle applications. What base does the GLX16070 use? The GLX16070 uses a PX26d base. Is the GLX16070 a genuine OEX product? Yes. The GLX16070 is a genuine OEX accessory. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0723L Australian Made 4mm Single Core Automotive Cable Black 100m Roll OFHC Copper 15A V90 The OEX ACX0723L is a 4mm single core automotive cable in black, supplied on a 100m roll. Manufactured in Australia from oxygen free high conductivity (OFHC) copper, it features a 1.84mm² conductor cross-section and a 15A continuous rating at 30°C, suited to higher-current lighting circuits, relay feeds, accessory wiring and general automotive applications where additional conductor capacity is required over the 3mm range. The black PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0723L steps up from the OEX 3mm range with a larger 1.84mm² (15AWG) conductor cross-section and a 15A continuous rating, suited to circuits where the 3mm 10A-rated cable would be undersized. Typical applications include higher-output lighting circuits, relay and switch feed wiring, trailer and caravan wiring runs requiring additional capacity, and auxiliary power feeds drawing up to 15A. The 26-strand conductor construction provides flexibility for routing through tight spaces and around bends in vehicle bodywork. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. Compliance with AS/NZS 3808:2000 confirms the cable meets defined requirements for conductor construction, insulation properties and performance under the Australian and New Zealand standard for cables used in the internal wiring of equipment. The 100m roll suits workshops and trade installers covering multiple jobs from a single roll. Features and benefits OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. 15A rated at 30°C: Higher current capacity than the 3mm range, suited to higher-output lighting circuits, relay feeds and heavier accessory loads in 12V and 24V systems drawing up to 15A. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 26-strand construction: The 26-strand conductor provides flexibility and resistance to fatigue during installation and in service, suited to routing through tight spaces and around bends. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 100m roll: Trade-length supply for workshops and fleet installers covering multiple jobs from a single roll. Technical specs Specification Detail SKU ACX0723L Brand OEX Cable Type Single Core Automotive Industry Known Size 4mm Conductor Cross Section 1.84mm² Gauge 15AWG Conductor Strands 26 Strand Diameter 0.32mm Conductor Material OFHC Copper Amp Rating 15A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Black Length 100m Weight 2.1kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 100m roll Frequently asked questions How does 4mm cable compare to 3mm and 2mm in the OEX range? The 4mm cable has a larger conductor cross-section (1.84mm²) and higher amp rating (15A at 30°C) than the 3mm (1.13mm², 10A) and 2mm (0.5mm², 5A) cables. Select the 4mm where circuits draw up to 15A, such as higher-output lighting, relay feeds or heavier accessory loads that would exceed the capacity of the 3mm range. What is the amp rating for this cable? This cable is rated at 15A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across the 2mm, 3mm and 4mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1297R Dual Wall Adhesive-Lined Heat Shrink Tubing 39mm Internal Diameter Red 300mm Lengths Pack of 4 The OEX ACX1297R is a dual wall heat shrink tube in red, supplied as four 300mm lengths with a 39mm internal diameter before shrinking. Constructed from polyolefin with an inner adhesive lining, it provides both mechanical protection and a waterproof seal when applied. The outer polyolefin layer shrinks to grip the cable or connector while the inner adhesive melts and flows to fill gaps and create a moisture-resistant barrier. The red colour suits positive supply identification in conventional automotive wiring colour coding. Shrink ratio is 3:1, shrink temperature is 110°C, and the operating range is -55°C to +105°C. Covered by a one year warranty. Product overview The ACX1297R is the red variant of the OEX ACX1297 dual wall adhesive-lined heat shrink, sharing the same polyolefin construction, shrink ratio, shrink temperature and operating range as the black version. Red is the conventional positive wiring colour in automotive and marine electrical installations, making the ACX1297R the natural choice for positive supply terminations, battery positive cable ends and large positive connector sealing where colour convention assists with circuit identification. The 3:1 shrink ratio means the 39mm ID before shrink reduces to approximately 13mm, giving a wide working range of cable and connector sizes from a single piece. Each pack contains four 300mm pieces, totalling 1.2m, sized for individual joint and termination applications. The adhesive inner lining melts when heat is applied, flowing around the cable to fill gaps and create a weatherproof seal. The shrink temperature of 110°C allows activation with a standard heat gun at a low setting. The operating range of -55°C to +105°C covers the full range of automotive, marine and outdoor environments. Features and benefits Dual wall construction with adhesive inner lining: The polyolefin outer layer shrinks to grip the cable or connector while the inner adhesive melts and flows to fill gaps, creating a mechanical grip and moisture-resistant seal in a single application. Red colour for positive supply identification: Red is the conventional positive wiring colour in automotive and marine installations, assisting with circuit identification at terminations and joins on positive supply cables. 3:1 shrink ratio: Shrinks to one third of the supplied 39mm internal diameter, down to approximately 13mm, accommodating a wide range of cable and connector sizes from a single piece. 39mm internal diameter before shrink: Suits large cables, connectors and terminal ends, making it practical for battery positive cable terminations, large connector sealing and heavy harness joints. 300mm lengths, pack of 4: Four pieces per pack for individual joint and termination applications, totalling 1.2m per pack. Shrinks at 110°C: Activates with a heat gun at a low temperature setting, reducing the risk of damage to surrounding wiring and connectors during application. -55°C to +105°C operating range: Covers cold-climate automotive and marine use through to sustained underbonnet operating temperatures. Polyolefin with adhesive lining: Industry-standard material combination for weatherproof heat shrink applications in automotive and marine environments. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1297R Brand OEX Heat Shrink Type Dual Wall Material Polyolefin with Adhesive Lining Colour Red Inside Diameter (before shrink) 39mm Shrink Ratio 3:1 Piece Length 300mm Pack Quantity 4 pieces Total Length 1.2m Shrink Temperature 110°C Operating Temperature -55°C to +105°C Weight 0.174kg Warranty One year Sold As Pack of 4 x 300mm pieces Frequently asked questions How does the ACX1297R differ from the ACX1297? Both are 39mm dual wall adhesive-lined heat shrink with identical construction, shrink ratio and operating specifications. The ACX1297 is black and the ACX1297R is red. Select red for positive supply terminations where conventional wiring colour coding is being followed, and black for general or negative side applications. What is dual wall heat shrink and how does it differ from standard heat shrink? Standard single wall heat shrink provides a mechanical sleeve that grips the cable or connector when heated but does not seal against moisture. Dual wall heat shrink adds an inner adhesive lining that melts during application, flowing around the cable to fill gaps and create a weatherproof seal. The result is both mechanical protection and moisture resistance from a single piece. What is the shrink ratio and what does it mean for cable sizing? The 3:1 shrink ratio means the tubing shrinks to one third of its original diameter when heated. The ACX1297R has a 39mm internal diameter before shrink, reducing to approximately 13mm after. This covers cables and connectors up to approximately 39mm diameter in a single piece. What tool do I need to apply this heat shrink? A heat gun set to the appropriate temperature is the recommended tool. Avoid open flames as they can cause uneven shrinking or damage to the tubing. The ACX1297R shrinks at 110°C, achievable with most standard heat guns at a low to medium setting. Is this product available in other sizes or colours? OEX produces dual wall heat shrink in a range of diameters and colours. Contact us for available sizes and colours to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1326 Heavy Duty Black Nylon 66 UV Resistant Cable Ties 8.9mm x 530mm Pack of 100 The OEX ACX1326 is a pack of 100 heavy-duty black nylon cable ties, each measuring 8.9mm wide by 530mm long. Manufactured from nylon 66 for strength and stability, these larger ties are suited to securing heavy wiring harnesses, large cable bundles, hoses and conduit runs where the lighter 4.8mm range does not provide sufficient grip width or bundle capacity. UV resistant for outdoor and underbonnet applications. Supplied in a resealable, reusable bag. Covered by a one year warranty. Product overview The ACX1326 is the heaviest cable tie in the OEX range, stepping up significantly from the 4.8mm x 370mm ACX1320 to an 8.9mm wide strap and 530mm length. The wider strap distributes clamping force across a larger surface area, providing a stronger, more secure hold on heavy harnesses and large-diameter bundles without cutting into insulation or conduit under tension. The 530mm length accommodates bundles up to approximately 150mm in diameter, suited to large multi-cable harnesses, main wiring trunk runs, hose groupings and conduit bundles that exceed the capacity of the 4.8mm range. Nylon 66 provides higher tensile strength, heat resistance and dimensional stability than standard nylon 6. The UV resistant black construction suits outdoor, sun-exposed and underbonnet applications where standard cable ties would degrade and become brittle over time. The resealable bag keeps unused ties tidy between jobs. The pack of 100 suits trade workshops handling large-scale cable and hose management installations. Features and benefits 8.9mm wide strap: Significantly wider than the 4.8mm range, distributing clamping force across a larger surface area for a stronger, more secure hold on heavy harnesses and large-diameter bundles without cutting into insulation. 530mm length: Accommodates bundle diameters up to approximately 150mm, suited to large multi-cable harnesses, main wiring trunk runs and hose groupings that exceed the capacity of the 4.8mm x 370mm ACX1320. Nylon 66 construction: High-strength, stable material providing greater tensile strength, heat resistance and dimensional stability than standard nylon 6, suited to heavy-duty automotive-grade cable bundling. UV resistant: Resists degradation and brittleness from prolonged sun exposure, suited to outdoor, sun-exposed and underbonnet applications. Black: Standard colour for automotive wiring work, blending with harnesses and body panels with better UV resistance than natural or white ties. Pack of 100: Trade quantity for workshop stock covering heavy-duty cable and hose management jobs. Resealable, reusable bag: Keeps unused ties tidy and organised between jobs. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1326 Brand OEX Item Type Cable Tie Material Nylon 66 Width 8.9mm Length 530mm Colour Black UV Resistant Yes Pack Quantity 100 Packaging Resealable, reusable bag Weight 0.2kg Warranty One year Sold As Pack of 100 Frequently asked questions What is nylon 66 and why does it matter for cable ties? Nylon 66 is a high-performance polyamide material commonly used for automotive-grade cable ties due to its high tensile strength, heat resistance and dimensional stability. It outperforms standard nylon 6 in both strength and temperature resistance, making it the preferred specification for automotive wiring applications. How does the ACX1326 compare to the rest of the OEX cable tie range? The ACX1326 is the largest and heaviest cable tie in the OEX range at 8.9mm x 530mm. The next largest is the 4.8mm x 370mm ACX1320, suited to bundles up to approximately 100mm. The ACX1326 steps up to approximately 150mm maximum bundle diameter with a wider strap for a stronger hold on heavier loads. Select the ACX1326 where the 4.8mm range does not provide sufficient grip or bundle capacity. What bundle diameter can these ties accommodate? A 530mm cable tie can accommodate bundles up to approximately 150mm in diameter depending on how the tie is applied. For smaller bundles, the 4.8mm x 370mm ACX1320 or 4.8mm x 200mm ACX1317 are better suited. What is the tensile strength of these cable ties? Tensile strength is not specified in the current product data. Contact us to confirm the tensile strength rating if this is a specific requirement for your application. Can these cable ties be reused? Standard nylon cable ties are single-use once the locking head is engaged, the tie cannot be released without cutting. The resealable bag they are supplied in is reusable for storage of unused ties between jobs. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1604 15A Blue Standard Blade ATS Fuse 19x19mm Pack of 100 The OEX ACX1604 is a 15A standard blade fuse in blue, supplied in a pack of 100. Measuring 19x19mm, it is the standard ATS/regular blade fuse format used in automotive fuse boxes and inline fuse holders across a wide range of vehicles. The blue colour coding identifies this as a 15A fuse, following the international automotive fuse colour standard. Also available in a pack of 5 as ACX1604BL. Covered by a one year warranty. Product overview The ACX1604 is a 15A standard blade fuse, one of the most widely used ratings in automotive accessory wiring. The 15A rating suits mid-current circuits including driving lights, accessory power outlets, relay feeds and aftermarket wiring circuits drawing up to 15 amps. The 15A rating also matches the current rating of the OEX 4mm single-core automotive cable range, making the ACX1604 the correct fuse pairing for circuits wired with 4mm cable. The blue colour follows the international automotive blade fuse colour standard, allowing quick visual identification of the 15A rating when inspecting or replacing fuses. The standard blade format (ATS/regular blade) at 19x19mm fits the majority of vehicle fuse boxes and inline blade fuse holders. The pack of 100 suits trade workshops stocking fuses for servicing, installations and general auto electrical work. For lower-volume requirements, the ACX1604BL pack of 5 is available. Features and benefits 15A rating: Mid-current circuit protection for driving lights, accessory power outlets, relay feeds and aftermarket wiring circuits drawing up to 15 amps. Standard blade ATS fuse format: The most common automotive fuse type, fitting the majority of vehicle fuse boxes and inline blade fuse holders. Blue colour coding: Identifies the 15A rating at a glance per the international automotive blade fuse colour coding standard, assisting with quick fuse identification and replacement. 19x19mm standard dimensions: Standard ATS blade fuse sizing, compatible with fuse boxes and holders designed for the regular blade format. Pack of 100: Trade-friendly quantity for workshop stock covering servicing, installations and general auto electrical work. Also available in pack of 5: The ACX1604BL is the same 15A blue standard blade fuse in a pack of 5 for lower-volume requirements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1604 Brand OEX Fuse Type Standard Blade (ATS) Amp Rating 15A Colour Blue Dimensions 19x19mm Pack Quantity 100 Weight 0.178kg Warranty One year Sold As Pack of 100 Frequently asked questions What is a standard blade fuse? A standard blade fuse, also known as ATS or regular blade, is the most common automotive fuse type. It has a flat plastic body with two metal prongs that plug into a fuse box or inline holder. The fuse element inside blows when current exceeds the rated amperage, protecting the circuit from damage. What does the blue colour indicate? Blue identifies this as a 15A fuse per the international automotive blade fuse colour coding standard, allowing quick visual identification of the correct rating when inspecting or replacing fuses. What circuits is a 15A fuse suited to? A 15A fuse is suited to mid-current circuits such as driving lights, accessory power outlets, relay feeds and aftermarket wiring circuits drawing up to 15 amps. Always match the fuse rating to the circuit's required protection level rather than using a higher-rated fuse. What is the difference between standard, mini and micro blade fuses? Standard blade fuses (ATS) measure 19x19mm and are the most common type in older and mid-range vehicles. Mini blade fuses (APM/ATM) are smaller at approximately 10.9x16mm. Micro or low profile mini fuses are smaller again. Check your vehicle's fuse box or owner's manual to confirm which type is required before purchasing. Is this product available in a smaller pack quantity? Yes. The ACX1604BL is the same 15A blue standard blade fuse available in a pack of 5, suited to lower-volume requirements. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1603 10A Red Standard Blade ATS Fuse 19x19mm Pack of 100 The OEX ACX1603 is a 10A standard blade fuse in red, supplied in a pack of 100. Measuring 19x19mm, it is the standard ATS/regular blade fuse format used in automotive fuse boxes and inline fuse holders across a wide range of vehicles. The red colour coding identifies this as a 10A fuse, following the international automotive fuse colour standard. Also available in a pack of 5 as ACX1603BL. Covered by a one year warranty. Product overview The ACX1603 is a 10A standard blade fuse, one of the most commonly stocked ratings in automotive workshops. The 10A rating suits a wide range of mid-current accessories including lighting circuits, USB power hubs, accessory sockets and aftermarket wiring circuits drawing up to 10 amps. The red colour follows the international automotive blade fuse colour standard, allowing quick visual identification of the 10A rating when inspecting or replacing fuses. The standard blade format (ATS/regular blade) at 19x19mm is the most common automotive fuse type, fitting the majority of vehicle fuse boxes and inline blade fuse holders. The pack of 100 suits trade workshops stocking fuses for servicing, installations and general auto electrical work. For lower-volume requirements, the ACX1603BL pack of 5 is available. Features and benefits 10A rating: Mid-current circuit protection for lighting accessories, USB power hubs, accessory sockets and other accessories drawing up to 10 amps. Standard blade ATS fuse format: The most common automotive fuse type, fitting the majority of vehicle fuse boxes and inline blade fuse holders. Red colour coding: Identifies the 10A rating at a glance per the international automotive blade fuse colour coding standard, assisting with quick fuse identification and replacement. 19x19mm standard dimensions: Standard ATS blade fuse sizing, compatible with fuse boxes and holders designed for the regular blade format. Pack of 100: Trade-friendly quantity for workshop stock covering servicing, installations and general auto electrical work. Also available in pack of 5: The ACX1603BL is the same 10A red standard blade fuse in a pack of 5 for lower-volume requirements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1603 Brand OEX Fuse Type Standard Blade (ATS) Amp Rating 10A Colour Red Dimensions 19x19mm Pack Quantity 100 Weight 0.178kg Warranty One year Sold As Pack of 100 Frequently asked questions What is a standard blade fuse? A standard blade fuse, also known as ATS or regular blade, is the most common automotive fuse type. It has a flat plastic body with two metal prongs that plug into a fuse box or inline holder. The fuse element inside blows when current exceeds the rated amperage, protecting the circuit from damage. What does the red colour indicate? Red identifies this as a 10A fuse per the international automotive blade fuse colour coding standard, allowing quick visual identification of the correct rating when inspecting or replacing fuses. What circuits is a 10A fuse suited to? A 10A fuse is suited to mid-current circuits such as lighting accessories, USB power hubs, accessory sockets and other accessories drawing up to 10 amps. Always match the fuse rating to the circuit's required protection level rather than using a higher-rated fuse. What is the difference between standard, mini and micro blade fuses? Standard blade fuses (ATS) measure 19x19mm and are the most common type in older and mid-range vehicles. Mini blade fuses (APM/ATM) are smaller at approximately 10.9x16mm. Micro or low profile mini fuses are smaller again. Check your vehicle's fuse box or owner's manual to confirm which type is required before purchasing. Is this product available in a smaller pack quantity? Yes. The ACX1603BL is the same 10A red standard blade fuse available in a pack of 5, suited to lower-volume requirements. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1644 15A Blue Low Profile Mini Blade APS Fuse 11x9mm Pack of 50 The OEX ACX1644 is a 15A low profile mini blade fuse in blue, supplied in a pack of 50. Measuring 11x9mm, the low profile mini (also known as Mini LP or APS) is a compact blade fuse format widely used in modern passenger vehicles, light commercial vehicles and caravans. The blue colour coding identifies this as a 15A fuse, following the international automotive fuse colour standard. Also available in a pack of 5 as ACX1644BL. Covered by a one year warranty. Product overview The ACX1644 steps up from the 10A ACX1643 to a 15A rating, suited to mid-current circuits drawing up to 15 amps including driving lights, accessory power outlets, relay feeds and aftermarket wiring circuits in modern vehicles using the low profile mini blade format. The 15A rating is one of the most commonly replaced ratings in modern vehicle fuse boxes, making this a useful workshop stock item for workshops regularly servicing newer passenger vehicles and SUVs. The blue colour coding follows the international automotive blade fuse colour standard, consistent across standard, mini and low profile mini formats. The pack of 50 suits workshops servicing modern vehicles where the low profile mini format is commonly encountered. For lower-volume requirements, the ACX1644BL pack of 5 is available. Features and benefits 15A rating: Mid-current circuit protection for driving lights, accessory power outlets, relay feeds and aftermarket wiring circuits drawing up to 15 amps. Low profile mini blade APS format: Compact 11x9mm fuse used in modern vehicle fuse boxes where space is limited, the smallest of the three main automotive blade fuse formats. Blue colour coding: Identifies the 15A rating at a glance per the international automotive blade fuse colour coding standard, consistent across all blade fuse formats. Pack of 50: Workshop-friendly quantity for servicing modern vehicles where the low profile mini format is commonly encountered. Also available in pack of 5: The ACX1644BL is the same 15A blue low profile mini blade fuse in a pack of 5 for lower-volume requirements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1644 Brand OEX Fuse Type Low Profile Mini Blade (APS/Mini LP) Amp Rating 15A Colour Blue Dimensions 11x9mm Pack Quantity 50 Weight 0.052kg Warranty One year Sold As Pack of 50 Frequently asked questions What is a low profile mini blade fuse? A low profile mini blade fuse, also called Mini LP, APS or ATT, is a compact blade fuse measuring 11x9mm. It is shorter in height than a standard mini blade fuse and is used in many modern passenger vehicles and light commercial vehicles where space in the fuse box is limited. How does this differ from a standard or mini blade fuse? Standard blade fuses (ATS) measure 19x19mm. Mini blade fuses (APM/ATM) are approximately 10.9x16mm. Low profile mini fuses are the smallest at 11x9mm. They are not interchangeable always confirm the fuse format required for your vehicle before purchasing by checking the owner manual or fuse box cover. What does the blue colour indicate? Blue identifies this as a 15A fuse per the international automotive blade fuse colour coding standard, consistent across standard, mini and low profile mini formats. What vehicles use low profile mini blade fuses? Low profile mini fuses are found in many modern passenger vehicles, SUVs and light commercial vehicles. Check your vehicle's owner manual or fuse box cover to confirm the fuse format required before purchasing. Is this product available in a smaller pack quantity? Yes. The ACX1644BL is the same 15A blue low profile mini blade fuse available in a pack of 5, suited to lower-volume requirements. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less
