10" P3S Shallow 4-Ohm DVC 300W RMS, 83dB, 42Hz Fs, 89mm Depth, 230mm Cutout. Confirmed Enclosure Volumes: 14.1L Sealed, 28.3L Vented. Product Overview The Rockford Fosgate Punch P3SD4-10 is a 10" 4-Ohm Dual Voice Coil (DVC) shallow subwoofer rated at 300W RMS (600W peak) the most completely specified P3S model in the supplier data. The full specification set includes 83dB sensitivity, 42Hz free-air resonance, 8.1mm Xmax, 89mm (3.50") mounting depth, 230mm (9.06") cutout diameter, and Rockford Fosgate's confirmed enclosure recommendations: 0.5 cu ft (14.1 litres) sealed, 1.0 cu ft (28.3 litres) vented. CEA-2031 compliant. Input terminals are confirmed Dual 10-AWG compression consistent with the P3D2-10 and P2D4-10 spec tables, and confirming that "push terminals" in P3S features lists is a supplier data error. The 4-Ohm DVC provides wiring options of 2-Ohm (parallel), 8-Ohm (series), or 4-Ohm per coil for bi-amplification no 1-Ohm stability requirement. All confirmed P3S construction applies: anodised aluminium cone and dustcap, M-Roll Santoprene surround, dual linear spider, StampCast basket with spider venting, and diamond-cut cast aluminium trim ring. Key Specifications Subwoofer size: 10 inch (shallow) Voice coil configuration: Dual Voice Coil (DVC) Impedance: 4-Ohm per coil (2-Ohm parallel / 8-Ohm series / 4-Ohm biamp) Power handling (RMS): 300W ✓ (CEA-2031) Power handling (peak): 600W ✓ Sensitivity (SPL): 83dB @ 1W/1M ✓ Free-air resonance (Fs): 42Hz ✓ Xmax: 8.1mm ✓ Mounting depth: 3.50" (89mm) ✓ Cutout diameter: 9.06" (230mm) ✓ Voice coil diameter: 2.5" (65.5mm) ✓ Magnet weight: 47 oz (1.32 kg) ✓ Effective piston area (Sd): 333 cm² ✓ Equivalent air volume (Vas): 14.3 litres ✓ Total Q (Qts): 0.78 ✓ Electrical Q (Qes): 0.90 ✓ Mechanical Q (Qms): 6.00 ✓ Voice coil inductance (Le): 4.3 mH ✓ DC resistance (Re): 6.80 Ohms ✓ Woofer displacement: 0.074 cu ft (2.1 litres) ✓ Recommended sealed enclosure: 0.5 cu ft (14.1L) ✓ Recommended vented enclosure: 1.0 cu ft (28.3L) ✓ Shipping weight: 11.9 lbs (5.39 kg) ✓ CEA-2031 compliant: Yes ✓ Input terminals: Dual 10-AWG compression ✓ Cone: Anodised aluminium ✓ Dustcap: Anodised aluminium ✓ Surround: M-Roll Santoprene ✓ Spider: Dual linear with embedded 16 AWG tinsel leads ✓ Basket: StampCast with integrated spider venting ✓ Trim ring: Diamond-cut cast aluminium (grille insert compatible) ✓ Motor assembly: Shallow ✓ Enclosure compatibility: Sealed and vented ✓ Sold as: Individual unit Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits 300W RMS / 600W Peak — CEA-2031 — 300W RMS confirmed to the CEA-2031 standard — the same sustained power as the P3SD2-10, delivered in the 4-Ohm impedance format. 89mm Mounting Depth — Confirmed — At 3.50" (89mm), the P3SD4-10's mounting depth is confirmed. This is significantly shallower than the standard P3D2-10 (156.8mm) — making the P3SD4-10 suitable for shallow enclosures, rear doors with limited depth, or under-seat installations that the full-depth P3 cannot fit. 230mm Cutout Diameter — The confirmed 9.06" (230mm) cutout is slightly smaller than the standard 10" P3 (232mm) — check baffle dimensions against this confirmed figure. Confirmed Enclosure Volumes: Sealed: 0.5 cu ft (14.1 litres) Vented: 1.0 cu ft (28.3 litres) 83dB Sensitivity — The 83dB @ 1W/1M is slightly lower than the standard P3D4-10 (from the P3D2-10's 82dB reference), consistent with the shallow motor's Fs of 42Hz and Qts of 0.78. 42Hz Free-Air Resonance (Fs) — The Fs of 42Hz is higher than full-depth P3 subwoofers (P3D2-10: 26.6Hz), reflecting the shallow motor's stiffer suspension. This affects the enclosure design: the sealed box resonance will be higher than full-depth drivers in the same volume. 8.1mm Xmax — 8.1mm of linear peak excursion — less than the 15.2mm of the full-depth P3D2-10, consistent with the shallow motor's reduced excursion range. Qts = 0.78 — The higher Qts (versus 0.49 for the full-depth P3D2-10) is characteristic of shallow motor designs. At 0.78, the driver is well-suited to the 14.1L sealed box recommendation; the vented alignment at 28.3L provides additional output at bass frequencies above the port tuning point. 4-Ohm DVC — Broad Amplifier Compatibility: 2-Ohm (parallel): Most common configuration 8-Ohm (series): For amplifiers with higher minimum impedance 4-Ohm per coil (biamp): Separate channels Compression Terminals Confirmed — The spec table confirms Dual 10-AWG compression — the correct terminal type across the P2/P3/P3S range. Update all P3S features list descriptions accordingly. Anodised Aluminium Cone, M-Roll Santoprene Surround — P3S platform materials confirmed. Technical Specs Specification Detail Brand Rockford Fosgate Part Number P3SD4-10 Series Punch P3S (Shallow) Subwoofer Size 10 inch (shallow) Voice Coil Dual Voice Coil (DVC) Impedance per Coil 4-Ohm ✓ Wiring Options 2-Ohm (parallel) / 8-Ohm (series) / 4-Ohm biamp ✓ Power Handling (RMS) 300W ✓ (CEA-2031) Power Handling (Peak) 600W ✓ Sensitivity 83dB @ 1W/1M ✓ Fs 42Hz ✓ Xmax 8.1mm ✓ Cutout Diameter 9.06" (230mm) ✓ Mounting Depth 3.50" (89mm) ✓ Voice Coil Diameter 2.5" (65.5mm) ✓ Magnet Weight 47 oz (1.32 kg) ✓ Sd 333 cm² ✓ Vas 14.3 litres ✓ Qts 0.78 ✓ Qes 0.90 ✓ Qms 6.00 ✓ Le 4.3 mH ✓ Re 6.80 Ohms ✓ Woofer Displacement 0.074 cu ft / 2.1L ✓ Sealed Enclosure (Vb) 0.5 cu ft (14.1L) ✓ Vented Enclosure (Vb) 1.0 cu ft (28.3L) ✓ Shipping Weight 11.9 lbs (5.39 kg) ✓ CEA-2031 Compliant Yes ✓ Input Terminals Dual 10-AWG Compression ✓ Cone Anodised Aluminium ✓ Dustcap Anodised Aluminium ✓ Surround M-Roll Santoprene ✓ Spider Dual Linear, Embedded 16 AWG Tinsel Leads ✓ Basket StampCast with Integrated Spider Venting ✓ Motor Shallow ✓ Trim Ring Diamond-Cut Cast Aluminium (Grille Compatible) ✓ Enclosure Type Sealed and Vented ✓ Sold As Individual Unit Warranty Not specified — confirm with Rockford Fosgate Compatible With / Goes Well With Confirmed enclosure volumes: Sealed: 0.5 cu ft (14.1 litres) net internal Vented: 1.0 cu ft (28.3 litres) net internal — confirm port dimensions from Rockford Fosgate Wiring: 2-Ohm → parallel 8-Ohm → series 4-Ohm per coil → biamp Pairs well with: A mono amplifier rated at 300W RMS at 2-Ohm A shallow sealed 14.1L or vented 28.3L enclosure Weight 5.39 kg (11.9 lbs) Frequently Asked Questions What are the confirmed enclosure volumes for the P3SD4-10? Sealed: 0.5 cu ft (14.1 litres); Vented: 1.0 cu ft (28.3 litres). Both are Rockford Fosgate's official confirmed recommendations. Confirm vented port dimensions from the official P3SD4-10 installation guide. Why is the Fs of the P3SD4-10 higher than a full-depth subwoofer? An Fs of 42Hz reflects the shallow motor's stiffer suspension — required to control the cone within a reduced excursion range. Full-depth subwoofers with long-travel motors have lower Fs values (e.g. the P3D2-10 at 26.6Hz) because their suspensions are more compliant over a greater travel distance. The higher Fs means the P3SD4-10's useful bass extension begins at a higher frequency than full-depth drivers. What is the confirmed mounting depth? 89mm (3.50") — confirmed in the specification table. What does the 230mm cutout mean for enclosure building? A 9.06" (230mm) cutout is required in the baffle. This is 2mm smaller than the standard 232mm cutout on the full-depth P3D4-10 and P2D4-10 — a meaningful difference if using a pre-drilled enclosure. Confirm the exact cutout before purchase. Are the terminals push or compression? The specification table confirms Dual 10-AWG compression terminals — the correct type across the P2, P3, and P3S range. The "push terminals" language in features lists is a consistent supplier data error. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Small chassis. Full range. Punch power for sub or centre channel builds. Product Overview The Rockford Fosgate P300X1 is a 300W mono amplifier from the Punch series, built around a compact chassis capable of fitting where conventional amplifiers cannot. Unlike dedicated subwoofer-only mono amplifiers, the P300X1 features a full-range frequency response making it equally suited to powering a dedicated subwoofer system or a single centre channel speaker. Whether you're running one driver or multiple speakers off a single channel, the 2-ohm capable design delivers 300W of Punch-series output with headroom to spare. The P300X1 is a feature-rich unit for its class. The built-in C.L.E.A.N. setup system simplifies gain calibration, reducing the risk of clipping and distortion from a poorly set amplifier. High-level inputs with an Auto Turn-On circuit allow direct integration with factory head units without requiring a dedicated remote turn-on wire. RCA pass-through outputs enable daisy-chaining to additional amplifiers, and the stealth top-mounted control panel keeps all adjustments accessible without removing the amplifier from its install location. An optional PLC2 remote Punch Level Control (sold separately) connects to add driver-accessible output adjustment and an input clip indicator for real-time gain monitoring. Key Specifications Channels: 1 (mono) Output power: 300W @ 2 ohms (power at other impedances — not specified) Frequency response: Full-range (exact Hz range — not specified) Circuit topology: Not specified Crossover: 12dB/octave Butterworth (frequency range — not specified) Punch EQ: +18dB boost @ 45Hz (see Red-flags) Signal input: High level with Auto Turn-On Signal output: RCA pass-through Remote control: Optional PLC2 (not included — sold separately) Clip indicator: Yes (active when PLC2 is connected) Control panel: Top-mounted (stealth) Setup system: C.L.E.A.N. Input sensitivity: Not specified Nominal impedance load: Not specified CEA compliance: Not specified in provided data Power wire gauge: Not specified Speaker wire gauge: Not specified Operating voltage: Not specified Recommended fuse: Not specified Dimensions: Not specified Features & Benefits Full-Range Frequency Response — Sub or Centre Channel — Most compact mono amplifiers are subwoofer-only units with a fixed low-pass filter. The P300X1's full-range response opens up a second use case: powering a dedicated centre channel speaker in a vehicle with a more complex audio setup. One amplifier, two legitimate applications. C.L.E.A.N. Setup System — Rockford Fosgate's C.L.E.A.N. (Clean Level Efficient Amplifier Noise) setup process uses an on-board indicator to guide accurate gain calibration between the head unit and amplifier. Setting gain by ear or by eye is a common cause of distortion and clipping — C.L.E.A.N. removes the guesswork, protecting your speakers and ensuring the amplifier performs to its rated output without distortion. High-Level Input with Auto Turn-On — The P300X1 accepts high-level speaker wire inputs from factory or OEM head units and powers on automatically when it detects signal — no remote turn-on wire required. This significantly simplifies integration with factory audio systems, particularly in vehicles where accessing the head unit remote output is difficult or impractical. On-Board Punch EQ (+18dB @ 45Hz) — A bass boost centred at 45Hz is available directly from the amplifier, allowing low-end tuning without an external equaliser. The +18dB figure is sourced from the supplier features list — refer to Red-flags below for an important note on this specification. Optional PLC2 Remote Level Control with Clip Indicator — The P300X1 is wired ready for the optional Rockford Fosgate PLC2 remote level control (sold separately). When connected, the PLC2 adds driver-accessible output adjustment and activates an input clip indicator — a LED that warns when the incoming signal is clipping before it reaches the amplifier. This combination helps protect speakers and ensures clean output at all listening levels. RCA Pass-Through Outputs — Signal can be chained to a second amplifier via the RCA pass-through outputs, enabling clean multi-amp builds without splitters or Y-adaptors. Useful in systems running the P300X1 on a centre channel or sub with a separate amplifier on front and rear speakers. Stealth Top-Mounted Control Panel — All controls — gain, crossover, EQ — are located on the top surface of the amplifier rather than on the endplate. This allows access to adjustments after installation in boot floors, under-seat locations, or tight enclosures without the need to remove or reposition the unit. Compact Chassis — The P300X1 is specifically designed to fit installation locations where a conventional amplifier will not physically fit. Exact dimensions are not specified in supplier-provided data — confirm with Rockford Fosgate before planning a space-critical install. Muted Turn-On + Full Protection Circuit — Muted turn-on prevents startup thumps that can stress tweeters and subwoofer cones. Over-current and short-circuit protection safeguard the amplifier and connected drivers during fault conditions. Technical Specs Specification Detail Channels 1 (mono) Output power 300W @ 2Ω Power by impedance Not specified Frequency response Full-range (Hz range not specified) Circuit topology Not specified Crossover type 12dB/octave Butterworth Crossover frequency range Not specified Punch EQ +18dB @ 45Hz (unverified — see Red-flags) Signal input High level (auto turn-on) Signal output RCA pass-through Setup system C.L.E.A.N. Remote control Optional PLC2 (sold separately) Clip indicator Yes (when PLC2 connected) Control panel Top-mounted (stealth) Turn-on method Auto (from high-level input signal) Muted turn-on Yes Protection Over-current / Short circuit Input sensitivity Not specified CEA compliance Not specified Power wire gauge Not specified Speaker wire gauge Not specified Operating voltage Not specified Recommended fuse Not specified Dimensions Not specified Weight 4.3 kg Compatible With / Goes Well With The P300X1 is confirmed for the following applications based on manufacturer-provided information: Dedicated subwoofer systems (single driver or multiple speakers on one channel) Dedicated centre channel speaker amplification (full-range frequency response confirmed) 2-ohm subwoofer or speaker loads (300W RMS — power at other impedances not confirmed) Factory head units without RCA outputs (via high-level Auto Turn-On input) Goes well with: Rockford Fosgate Punch series subwoofers or centre channel drivers rated to 300W Rockford Fosgate PLC2 Remote Punch Level Control (optional — sold separately) Factory head units or OEM audio systems (via high-level auto turn-on) Aftermarket head units with RCA preamp outputs Frequently Asked Questions Can the P300X1 power a centre channel speaker as well as a subwoofer? Yes. Unlike most compact mono amplifiers, the P300X1 features a full-range frequency response — making it suitable for a dedicated centre channel speaker or a subwoofer system. The exact frequency range is not confirmed in the provided data; verify with Rockford Fosgate for your specific application. What is the C.L.E.A.N. setup system? C.L.E.A.N. is Rockford Fosgate's on-board gain calibration system. It uses an indicator to guide correct gain matching between the head unit and amplifier, preventing clipping and distortion that commonly results from gain set too high — protecting speakers and maximising clean output. Is the Punch Level Control included with the P300X1? No. The PLC2 remote Punch Level Control is an optional accessory and is sold separately. The P300X1 is wired and ready to accept the PLC2, and when connected it adds driver-accessible level control and an active input clip indicator. Does the Auto Turn-On circuit require a remote wire from the head unit? No. The high-level Auto Turn-On circuit powers the amplifier when it detects signal at the speaker-level inputs — no dedicated remote turn-on wire is needed. This simplifies installation with factory head units where accessing the remote output is difficult. Can I chain another amplifier off the P300X1? Yes. RCA pass-through outputs allow signal to be routed to a second amplifier cleanly, without splitters or Y-adaptors. This is useful in systems running the P300X1 alongside a separate full-range or multichannel amplifier. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate P300-8P Punch 8" 300 Watt Powered Vented Enclosure When space is the deciding factor but bass cannot be left behind, the P300-8P packs a high-output 8" woofer and 300-watt Class D amplifier into a slim vented enclosure suited for trucks and small car applications alike. Product Overview The P300-8P is Rockford Fosgate's compact all-in-one powered subwoofer enclosure, designed for installations where a 10" or 12" powered enclosure will not fit but genuine low-end performance is still required. The slim vented MDF enclosure houses an 8" proprietary woofer impedance-optimised for the integrated 300-watt Class D amplifier in a closed-loop design, ensuring the driver and amplifier work together as a matched system from the factory. The vented slot-port enclosure extends low-frequency output down to 30 Hz, delivering powerful bass reproduction from a compact footprint. An onboard variable Low-Pass crossover (50-200 Hz), Bass EQ with 0 to +12 dB of boost, and a 0-180 degree phase switch are accessible on the amplifier plate, while the included Punch Level Control remote handles bass adjustment from the driver's seat. An intelligent auto turn-on/off circuit with three selectable modes (Remote Trigger, DC Offset Sense, and Audio Sense) eliminates the need for a dedicated remote turn-on wire in OEM installations. Separate RCA and high-level speaker inputs make it compatible with both aftermarket and factory head units. Quick-release input connectors allow the enclosure to be removed when space is needed. The heat-activated vinyl finish resists marks and scuffs in daily use. CEA-2006 (amplifier) and CEA-2031 (woofer) compliant, Klippel verified, with a 1-year warranty. Features & Benefits 300-Watt Class D Amplifier with Closed-Loop Design: The integrated amplifier is an impedance-matched, closed-loop Class D design tuned specifically for the P300-8P's proprietary 8" woofer, ensuring maximum efficiency and precise driver control at all output levels within the compact enclosure footprint. High-Efficiency, Low Current Amplifier Design: The Class D amplifier topology keeps current consumption low relative to output, making the P300-8P compatible with stock electrical systems in trucks and small vehicles where alternator capacity has not been upgraded. Vented Enclosure for Extended Low-Frequency Output: The slot-port vented enclosure extends bass reproduction down to 30 Hz, providing powerful low-frequency output from an 8" driver in a slim footprint, suited to both truck under-seat and small car boot installations. Slim Design for Truck and Small Car Applications: The compact enclosure dimensions make the P300-8P well suited to tight installation locations, including truck under-seat positions and the limited boot spaces of sub-compact and small hatchback vehicles. Klippel Verified Woofer: The 8" proprietary woofer has been verified through the Klippel certification programme, which measures and corrects non-linear distortion parameters to deliver the best possible transient accuracy and low-frequency output from a compact, impedance-matched driver. Intelligent Auto Turn-On/Off: Three selectable turn-on modes (Remote Trigger, DC Offset Sense, and Audio Sense) allow the P300-8P to power on automatically in any installation scenario, including factory head units without a dedicated remote output. Variable Low-Pass Crossover: Continuously variable from 50 to 200 Hz at 12 dB/octave Butterworth, the onboard crossover integrates cleanly with full-range speakers across virtually any crossover point set by the main system amplifier or head unit. Onboard Bass EQ: 0 to +12 dB of onboard bass boost corrects for acoustic deficiencies in the vehicle interior and adds presence to the low-frequency output without an external equaliser. Phase Switch: A 0 to 180 degree phase control allows the subwoofer to be time-aligned with the main speakers acoustically, compensating for physical placement differences for a coherent, integrated bass response. Included Punch Level Control Remote: The Punch Level Control is included in the box, allowing bass output to be adjusted from the driver's seat in real time without accessing the amplifier plate directly. Quick-Release Input Connections: Input connections use quick-disconnect fittings, allowing the enclosure to be removed from the vehicle quickly when cargo or passenger space is needed, without tools or cable work. High and Low-Level Inputs: Separate RCA (low-level, 150mV-6V) and speaker-level (high-level, 300mV-12V) inputs via a single RCA pair summed L/R support both aftermarket and OEM head unit installations from the same unit. Thermal and Over/Under Voltage Protection: Onboard protection monitors both operating temperature and supply voltage, shutting the amplifier down safely before damage occurs under fault conditions. Precision MDF Enclosure with Vinyl Finish: Constructed from 5/8" Medium Density Fiberboard for optimal acoustic properties, covered with a heat-activated vinyl finish that resists marks and scuffs in daily use. CEA-2006 and CEA-2031 Compliant: Amplifier power ratings conform to CEA-2006 industry standards at 14.4V with 1% or less THD. Woofer power handling conforms to CEA-2031, confirming both ratings are real, tested figures. Technical Specs Specification Detail SKU P300-8P Series Punch Woofer Size 8" Woofer Quantity 1 Woofer Series Proprietary Power Handling 300W RMS Integrated Amplifier 300W RMS Amplifier Class Class D Enclosure Type Vented Enclosure Material 5/8" MDF Enclosure Finish Heat-Activated Vinyl Frequency Response 30 Hz - 200 Hz Low-Pass Crossover Variable 50-200 Hz @ 12 dB/octave Butterworth Bass EQ 0 to +12 dB Phase Control 0 to 180 degrees Input Switch High-Level (Speaker) / Low-Level (RCA) Signal Input 1 x RCA Pair (L/R Summed) Input Sensitivity (Low-Level) 150 mV - 6V Input Sensitivity (High-Level) 300 mV - 12V Input Impedance 20k Ohms Auto Turn-On Selector Remote Trigger / DC Offset Sense / Audio Sense Remote Control Punch Level Control (included) Visual Indicators POWER / PROTECT LED Heatsink Type Extruded Aluminium Cooling Convection Power Wire Gauge 8 AWG (B+/GND), 18 AWG (Remote) Power Input Connector Quick Disconnect Fuses 20A total (2 x 10A ATO) Compliance CEA-2006 (amplifier), CEA-2031 (woofer), Klippel Verified Dimensions (H x W x D) 11.4" x 17.6" x 5.6" (289 mm x 448 mm x 141 mm) Shipping Weight 19 lbs (8.6 kg) Warranty 1 Year Goes Well With The P300-8P is a standalone bass solution requiring no separate subwoofer amplifier or enclosure. For factory head unit installations, the high-level speaker inputs and Audio Sense auto turn-on allow direct connection without additional interface hardware. For aftermarket head unit installations, the RCA input connects directly from the head unit's subwoofer pre-out. To complement the P300-8P with front and rear speaker amplification, the PBR400X4D or R2-200X2 pair naturally via a standard RCA pre-out from the head unit. For installations in trucks where a larger driver is preferred and space allows, the P300-10T or P300-12T are direct step-up options in the same powered truck enclosure range. An 8-gauge power and ground cable run to the battery is required, along with the 2 x 10A ATO fuses included in the box. Frequently Asked Questions How does the P300-8P differ from the P300-10T and P300-12T? All three are 300-watt powered enclosures sharing the same amplifier specification, feature set, and installation approach. The P300-8P uses an 8" vented enclosure with a frequency response from 30 Hz and the smallest physical footprint, making it the right choice for the tightest installation spaces in small cars and trucks. The P300-10T and P300-12T use sealed enclosures with 10" and 12" drivers respectively, each in progressively larger wedge-profile enclosures suited to larger truck under-seat locations where more space is available. Why does the P300-8P use a vented enclosure while the P300-10T and P300-12T are sealed? The vented design allows the 8" driver to produce extended low-frequency output down to 30 Hz, matching the low-end reach of the larger sealed 10" and 12" enclosures despite the smaller driver size. The port tuning compensates for the reduced cone area of the 8" woofer, delivering strong bass output from a notably more compact enclosure footprint. Can the P300-8P be connected directly to a factory head unit? Yes. The high-level speaker inputs accept signal from the factory head unit's speaker outputs directly, and the Audio Sense or DC Offset Sense auto turn-on modes allow the enclosure to power on without a dedicated remote turn-on wire. This makes the P300-8P a straightforward plug-in bass upgrade for OEM systems without requiring head unit replacement. What are the three auto turn-on modes, and which should I use? Remote Trigger mode powers the amplifier on when a 12V signal is received at the remote input terminal, requiring a remote turn-on wire from the head unit. DC Offset Sense mode detects a DC voltage change on the high-level speaker input to trigger turn-on, suitable for OEM systems where the speaker output changes state when the head unit powers on. Audio Sense mode detects an incoming audio signal and triggers turn-on automatically, making it the most universal option for both OEM and aftermarket installations without a dedicated remote output. What is Klippel Verification, and why does it matter for a compact powered enclosure? Klippel is an independent speaker measurement and certification programme that identifies and corrects non-linear distortion parameters in speaker drivers, including suspension non-linearities and motor force variation across the cone's travel range. In a compact powered enclosure where the driver and amplifier are a matched system and the 8" cone is working hard to deliver 30 Hz output, Klippel verification confirms that the woofer's performance envelope has been accurately measured and optimised to deliver clean, low-distortion bass at the rated 300 watts across its full operating range. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate P300-10 Punch 10" 300W Amplified Subwoofer All-In-One Bass, Compact Footprint Product Overview The Rockford Fosgate P300-10 is a complete all-in-one amplified subwoofer system, combining a proprietary Punch 10" high-output woofer, a 300 Watt internal amplifier, and a custom sealed enclosure in a single self-contained unit. A step down in size from the P300-12 but identical in power handling, the P300-10 is the choice for builds where a slightly more compact footprint is needed without sacrificing output ideal for smaller boot spaces, hatchbacks, and vehicles where the 12" version simply won't fit. Like its 12" sibling, the P300-10 requires only a power feed, ground, and audio signal to operate no separate amplifier, no separate enclosure, and no component matching required. The closed-loop design ensures the woofer, amplifier, and enclosure are engineered and tuned together as a matched system. A built-in adjustable bass boost EQ, adjustable 12 dB/octave low-pass crossover, 0°/180° phase switch, intelligent auto turn-on, and an included remote bass level control give you complete system management straight out of the box in virtually any Australian vehicle. Key Specifications Subwoofer: 10" Rockford Fosgate Punch proprietary high-output woofer Amplifier: Internal 300W Enclosure type: Sealed (custom closed-loop) Construction: 5/8" MDF Finish: Industrial heat-activated vinyl Crossover: Adjustable 12 dB/octave low-pass Phase switch: 0°/180° Inputs: Low-level RCA and speaker-level Auto turn-on: Intelligent auto turn-on/off Remote bass control: Included Protection: Thermal and over/under voltage Features & Benefits All-in-one amplified subwoofer system: Woofer, amplifier, and sealed enclosure in a single unit. No separate amplifier purchase, no enclosure building, and no impedance matching required. The most straightforward bass upgrade path for factory systems and space-restricted installs in Australian hatchbacks, sedans, and SUVs. 300W internal amplifier with closed-loop design: Matched and tuned by Rockford Fosgate engineers to the specific 10" driver and sealed enclosure, ensuring consistent optimised performance without the guesswork of pairing separate components. The same 300W power handling as the P300-12 in a more compact 10" package. Compact 10" driver for tighter spaces: The P300-10 delivers the same amplifier output as the P300-12 in a smaller enclosure footprint the choice when boot dimensions, seat clearance, or vehicle size rules out the larger 12" version without compromising on power. Proprietary high-output Punch woofer: The 10" driver is purpose-engineered for this specific sealed enclosure and power level, delivering the punchy, controlled bass response the Punch series is built on across a wide range of music genres. Adjustable 12 dB/octave low-pass crossover: Match the crossover point to your existing speaker system for clean frequency integration, ensuring the subwoofer handles only the bass frequencies it is designed for. Built-in adjustable bass boost EQ: Dial in additional low-frequency emphasis without an external equaliser, compensating for the natural bass roll-off common in hatchbacks and acoustically compact vehicle interiors. 0°/180° phase switch: Align the subwoofer's output phase with your main speakers for coherent, integrated bass reproduction, particularly important when the subwoofer is mounted in a different location to the main speakers. Separate low-level (RCA) and speaker-level inputs: Connects to aftermarket head units via RCA or directly to factory speaker outputs via speaker-level inputs. No head unit replacement required for factory system integration in Australian vehicles. Intelligent auto turn-on/off: Senses the audio signal and powers on and off automatically no remote turn-on wire required, simplifying installation in OEM audio systems common in Australian vehicles. Remote bass level control included: Adjust bass output from the driver's seat without accessing the subwoofer. Included in the box with no additional purchase needed. Thermal and over/under voltage protection: Built-in protection circuits monitor operating temperature and supply voltage, shutting the system down safely before damage can occur important in the high boot temperatures typical of Australian summers. Detachable power/ground connector: Simplifies installation and clean removal. Practical for vehicles where the subwoofer may need to be temporarily removed or transferred. 5/8" MDF construction with industrial heat-activated vinyl: Rigid walls minimise enclosure flex and resonance at high output levels. The heat-activated vinyl finish is more durable and scratch-resistant than carpet, better suited to daily cargo area and boot use. High-efficiency, low current design: Draws less current from the vehicle's electrical system than a comparable traditional amplifier and subwoofer combination important for Australian vehicles running factory electrical systems without upgrades. Technical Specs Specification Detail SKU P300-10 Brand Rockford Fosgate Subwoofer Driver 10" Rockford Fosgate Punch proprietary high-output woofer Internal Amplifier 300W Enclosure Type Sealed (closed-loop) Construction Material 5/8" MDF Finish Industrial heat-activated vinyl Crossover Adjustable 12 dB/octave low-pass Bass Boost EQ Built-in adjustable Phase Switch 0° / 180° Signal Inputs Low-level RCA + speaker-level Auto Turn-On Intelligent auto turn-on/off Power/Ground Connector Detachable Input Terminals Large AWG Remote Bass Control Included Protection Thermal + over/under voltage Dimensions Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With Factory (OEM) head units via speaker-level inputs and intelligent auto turn-on Aftermarket head units via low-level RCA inputs and remote turn-on Hatchbacks, sedans, and small SUVs with compact boot spaces where the P300-12 footprint is too large Vehicles requiring a complete self-contained bass solution without a separate amplifier Utes and dual-cab trucks with under-seat or behind-seat mounting where 10" enclosure depth fits Rockford Fosgate RCA cables and wiring accessories for signal connection Frequently Asked Questions What is the difference between the P300-10 and P300-12? Both the P300-10 and P300-12 feature a 300W internal amplifier and identical feature sets. The key difference is driver size the P300-10 uses a 10" woofer in a more compact enclosure, making it the better choice when boot or cargo space rules out the larger P300-12 footprint. Do I need a separate amplifier to run the P300-10? No. The P300-10 has a 300W amplifier built directly into the enclosure. Connect power, ground, and an audio signal from your head unit or factory system and it is ready to use straight out of the box. Can the P300-10 connect directly to a factory head unit? Yes. The P300-10 features separate speaker-level inputs for direct connection to factory head unit speaker outputs, and an intelligent auto turn-on that senses the audio signal no remote wire or aftermarket head unit required. Is a remote bass control included with the P300-10? Yes. A remote bass level control is included in the box, allowing driver's seat adjustment of bass output without accessing the subwoofer unit no additional purchase required. Is the P300-10 suitable for daily boot and cargo area use in Australian conditions? Yes. The industrial heat-activated vinyl finish resists scrapes and bumps, the 5/8" MDF construction minimises resonance, and the built-in thermal and over/under voltage protection safeguards the system against high boot temperatures common in Australian vehicles during summer. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

12" 4-Ohm SVC Punch Subwoofer 250W RMS, Kevlar Fibre-Reinforced Paper Cone, VAST, Nomex® Voice Coil Collar, Extended Pole Piece, 10-AWG Nickel Push Terminals. Product Overview The Rockford Fosgate Punch P1S4-12 is a 12" 4-Ohm Single Voice Coil (SVC) subwoofer rated at 250W RMS the 4-Ohm variant of the 12" Punch P1 platform. Identical construction to the P1S2-12 with the sole difference being the 4-Ohm voice coil impedance, which suits a broader range of mono amplifiers than the 2-Ohm variant. Optimised for sealed and vented enclosures. Sold as an individual unit. All confirmed Punch P1 construction applies: Kevlar fibre-reinforced paper cone, VAST surround (up to 25% increased cone area), high-temperature voice coil with spun-laced Nomex® reinforcement collar, extended pole piece with bumped vented backplate, StampCast basket with integrated spider venting, 10-AWG nickel-plated push terminals, rubberized ABS trim ring with grille insert provision, and protective PVC textured magnet cover. Key Specifications Subwoofer size: 12 inch Voice coil configuration: Single Voice Coil (SVC) Impedance: 4-Ohm Power handling (RMS): 250W (confirmed) Peak power: Not specified — confirm with Rockford Fosgate Surround technique: VAST (up to 25% increased cone area) Sensitivity: Not specified — confirm with Rockford Fosgate Frequency response: Not specified — confirm with Rockford Fosgate Xmax: Not specified — confirm with Rockford Fosgate Voice coil: High-temp, Nomex® reinforcement collar Cone: Kevlar fibre-reinforced paper Spider: Linear with embedded 16 AWG tinsel leads Basket: StampCast with integrated spider venting Pole piece: Extended Backplate: Bumped and vented Input terminals: 10-AWG nickel-plated push terminals Trim ring: Rubberized ABS (grille insert compatible) Magnet cover: Protective PVC textured Enclosure compatibility: Sealed and vented ✓ Mounting depth: Not specified — confirm with Rockford Fosgate Cutout diameter: Not specified — confirm with Rockford Fosgate Sold as: Individual unit Weight: Not specified — confirm with Rockford Fosgate Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits 4-Ohm SVC — Broad Amplifier Compatibility — A 4-Ohm SVC presents a universally compatible load to most mono subwoofer amplifiers. Two P1S4-12 units in parallel = 2-Ohm; in series = 8-Ohm. 12" Cone — Larger cone area than the 10" P1 models for greater air movement, more bass output, and lower frequency extension. 250W RMS — Confirmed 250W RMS sustained power handling. Kevlar Fibre-Reinforced Paper Cone — Kevlar reinforcement for improved stiffness and breakup resistance at high output levels, with paper's natural damping and low mass. VAST — Up to 25% increased effective cone area for improved efficiency and output. Nomex® Voice Coil Reinforcement Collar — Heat and mechanical reinforcement at the voice coil-to-cone junction. Extended Pole Piece and Bumped Vented Backplate — Extended pole for increased Xmax; vented backplate eliminates air spring compression. 10-AWG Nickel-Plated Push Terminals — Heavier gauge for lower contact resistance at 250W. StampCast Basket with Integrated Spider Venting — Motor cooling during operation. Rubberized ABS Trim Ring / Grille Provision / PVC Magnet Cover — Clean installation finish with optional grille. Sealed and Vented Compatible — Both enclosure types confirmed. Technical Specs Specification Detail Brand Rockford Fosgate Part Number P1S4-12 Series Punch P1 Subwoofer Size 12 inch Voice Coil Single Voice Coil (SVC) Impedance 4-Ohm ✓ Power Handling (RMS) 250W ✓ Peak Power Not specified Surround Technique VAST (up to 25% increased cone area) ✓ Sensitivity Not specified Frequency Response Not specified Xmax Not specified Voice Coil High-Temp, Nomex® Collar ✓ Cone Kevlar Fibre-Reinforced Paper ✓ Spider Linear, Embedded 16 AWG Tinsel Leads Basket StampCast with Integrated Spider Venting Pole Piece Extended ✓ Backplate Bumped and Vented ✓ Input Terminals 10-AWG Nickel-Plated Push Terminals ✓ Trim Ring Rubberized ABS (Grille Insert Compatible) ✓ Magnet Cover Protective PVC Textured ✓ Enclosure Type Sealed and Vented ✓ Mounting Depth Not specified Cutout Diameter Not specified Sold As Individual Unit Weight Not specified Warranty Not specified — confirm with Rockford Fosgate Compatible With / Goes Well With Suitable enclosure types: Sealed — tight, accurate bass Vented — higher efficiency at tuning frequency Wiring: 4-Ohm SVC — single 4-Ohm load per unit Two units in parallel = 2-Ohm; two units in series = 8-Ohm Pairs well with: Rockford Fosgate T1000-1BDCP, T1500-1BDCP, or T2500-1BDCP mono amplifiers at 4-Ohm Frequently Asked Questions What is the difference between the P1S4-12 and P1S2-12? Both are identical 12" Punch P1 subwoofers with the same 250W RMS rating and construction. The only difference is impedance: the P1S4-12 is 4-Ohm SVC, the P1S2-12 is 2-Ohm SVC. The 4-Ohm is compatible with a wider range of amplifiers; the 2-Ohm suits amplifiers that produce their maximum rated output at 2-Ohm. What amplifier power is appropriate? 250W RMS at 4-Ohm. Confirm the amplifier's RMS output at 4-Ohm before purchasing. What enclosure volume is recommended? Not confirmed in the supplier data. Pull the official Rockford Fosgate P1S4-12 datasheet for sealed and vented volume recommendations. Is a grille available? The rubberized ABS trim ring accommodates an optional grille insert. Confirm the compatible grille SKU with Rockford Fosgate. Does this subwoofer suit trucks as well as cars? The supplier description confirms this model is designed for cars and trucks. The sealed and vented enclosure compatibility provides flexibility for the range of install locations common in both passenger vehicles and utes, vans, and trucks. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

5.25" 2-Way Punch Component System 50W RMS, 87dB, 70Hz–22kHz, CEA-2031. 1" Tweeter, 3.5kHz Crossover. Grilles Included. Product Overview The Rockford Fosgate Punch P152-S is a 5.25" 2-way component speaker system rated at 50W RMS (100W peak) the most comprehensively specified Punch series component system in this catalogue, with confirmed sensitivity (87dB), frequency response (70Hz–22kHz), full crossover specification (HP: 3.5kHz @ 12dB/octave Butterworth), tweeter and woofer mounting depths, tweeter size (1"/25.4mm), and CEA-2031 compliance. The kit includes two woofers with grilles, two tweeters, integrated crossovers, an OEM adapter plate, and mounting hardware. The 1" (25.4mm) tweeter shares the same dome diameter as the Punch P1T-S dedicated tweeter kit, mounted within the component system's installation framework with an ICC design that eliminates an external crossover box. Woofer mounting depth is 1.87" (47mm) and the recessed tweeter mount uses a standard 1-3/4" hole saw. Key Specifications Woofer size: 5.25 inch Configuration: 2-way component system Power handling (RMS): 50W per woofer (CEA-2031 compliant) Power handling (peak): 100W per woofer Sensitivity: 87dB @ 1W/1M Frequency response: 70Hz – 22kHz Woofer mounting depth: 1.87" (47mm) Tweeter size: 1.0" (25.4mm) Tweeter mounting depth: 0.50" (13mm) Tweeter dome material: PEI  Crossover (tweeter HP): 3.5kHz @ 12dB/octave Butterworth Crossover (woofer LP): Natural acoustic 12dB/octave roll-off Crossover type: ICC (Integrated Concealed Crossover) Recessed tweeter mount: 1-3/4" hole saw Cone: Injection-moulded mineral-filled polypropylene Surround: Butyl rubber Basket: FlexFit OEM adapter plate: Included Grilles: Included ✓ Mounting hardware: Included Kit contents: 2 woofers + 2 tweeters + crossovers + grilles + OEM adapter + hardware CEA-2031 compliant: Yes Shipping weight: 5.5 lbs (2.49 kg) Impedance: Not specified — confirm with Rockford Fosgate Cutout diameter: Not specified — confirm with Rockford Fosgate Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits Complete Component System Kit — Two woofers with grilles, two tweeters, crossovers, OEM adapter plate, and all mounting hardware — a complete two-channel front component system in a single purchase. 50W RMS CEA-2031 — 10W more than the Prime R152-S (40W), and measured to the industry standard CEA-2031. The sustained 100W peak rating provides dynamic headroom for programme material transients. 87dB Sensitivity — 87dB is a meaningful step above the Prime R152-S (sensitivity not confirmed) and above the Punch coaxial P132 (85dB) — producing good output from head unit power while benefiting significantly from amplification. 70Hz – 22kHz Frequency Response — Extending to 70Hz, the 5.25" woofer reproduces usable upper bass — covering bass guitar fundamentals, kick drum, and male vocal presence range without requiring a subwoofer for many moderate-level listening environments. 3.5kHz Crossover — 12dB/Octave Butterworth — The tweeter's high-pass crossover activates at 3.5kHz with a 12dB/octave Butterworth slope — a well-chosen crossover point for a 1" tweeter that keeps the tweeter well within its comfortable operating range while handing off to the woofer in the midrange. The woofer relies on its natural acoustic roll-off above 3.5kHz at an equivalent 12dB slope. 1" (25.4mm) PEI Dome Tweeter — The same dome diameter as the Punch P1T-S dedicated tweeter — larger than the Prime R152-S's 1/2" Mylar tweeter, providing improved dispersion and a more substantial high-frequency presence. 1.87" (47mm) Woofer Mounting Depth — Confirmed mounting depth for installation planning. Vehicles with limited door panel cavity depth should verify clearance before purchasing. Recessed Tweeter Mount — 1-3/4" Hole Saw — The recessed tweeter bezel uses a standard 1-3/4" hole saw for a clean, flush installation in A-pillars, sail panels, and door trim without custom tooling. FlexFit Basket with OEM Adapter Plate — Non-standard basket geometry for OEM cavity compatibility, with adapter plate for additional fitment options. Mica-Injected Polypropylene Cone, Butyl Rubber Surround — Stiffened cone for reduced resonance colouration; butyl rubber surround for long-term durability in Australian vehicle conditions. Technical Specs Specification Detail Brand Rockford Fosgate Part Number P152-S Series Punch Woofer Size 5.25 inch Configuration 2-Way Component Power Handling (RMS) 50W per woofer ✓ (CEA-2031) Power Handling (Peak) 100W per woofer ✓ Sensitivity 87dB @ 1W/1M ✓ Frequency Response 70Hz – 22kHz ✓ Woofer Mounting Depth 1.87" (47mm) ✓ Tweeter Size 1.0" (25.4mm) ✓ Tweeter Mounting Depth 0.50" (13mm) ✓ Tweeter Dome Material PEI Crossover (Tweeter HP) 3.5kHz @ 12dB/octave Butterworth ✓ Crossover (Woofer LP) Natural acoustic 12dB/octave roll-off ✓ Crossover Type ICC (Integrated Concealed) Recessed Tweeter Mount 1-3/4" hole saw ✓ Cone Injection-Moulded Mineral-Filled Polypropylene Surround Butyl Rubber Basket FlexFit CEA-2031 Compliant Yes ✓ OEM Adapter Plate Included ✓ Grilles Included ✓ Mounting Hardware Included ✓ Kit Contents 2 woofers + 2 tweeters + crossovers + grilles + adapter + hardware Shipping Weight 5.5 lbs / 2.49 kg ✓ Impedance Not specified — confirm with Rockford Fosgate Cutout Diameter Not specified — confirm with Rockford Fosgate Warranty Not specified — confirm with Rockford Fosgate Compatible With / Goes Well With Suitable installation: 5.25" front door speaker positions OEM factory locations with standard or non-standard mounting profiles (FlexFit + adapter plate) Punch vs Prime component system comparison — 5.25": Feature R152-S (Prime) P152-S (Punch) RMS 40W ✓ 50W ✓ Sensitivity TBC 87dB ✓ Freq. Response TBC 70Hz–22kHz ✓ Tweeter Size 1/2" (13mm) 1" (25.4mm) ✓ Tweeter Material Mylar PEI Cone Std Polypropylene Mineral-Filled Surround Foam Butyl Rubber Crossover In-Line ICC CEA-2031 Not stated Yes ✓ Pairs well with: Rockford Fosgate T400-4, T600-4, or T1000-4AD 4-channel amplifiers Dedicated subwoofer for bass below 70Hz Weight 2.49 kg shipping weight per kit. Frequently Asked Questions What crossover is used in the P152-S and where is it mounted? The P152-S uses an ICC (Integrated Concealed Crossover) — the crossover circuitry is built into the tweeter assembly rather than requiring a separate outboard crossover box to be mounted in the door or cabin. The tweeter high-pass activates at 3.5kHz with a 12dB/octave Butterworth slope; the woofer relies on its natural acoustic roll-off above this frequency. How does the P152-S compare to the Prime R152-S? The Punch P152-S delivers more power (50W vs 40W RMS), a larger 1" tweeter (vs 1/2"), mineral-filled polypropylene cone and butyl rubber surround (vs standard polypropylene and foam surround on the Prime), and CEA-2031 compliance. It is the higher-tier 5.25" component system. The full crossover specification and key sensitivity data are confirmed for the P152-S — the Prime R152-S has fewer confirmed specifications in this catalogue. What is the mounting depth for the woofer? Confirmed at 1.87" (47mm). Verify this against your vehicle's available door panel cavity depth before purchasing. What tweeter dome material is used — PEI or "soft dome"? The supplier description refers to "1" soft dome tweeters" while the features list states "PEI dome tweeter." PEI is a rigid engineering thermoplastic — not a soft dome material. This is a conflict in the supplier data. Confirm the correct tweeter dome material with Rockford Fosgate before purchasing if tweeter character is a specific consideration. Are grilles included with the P152-S? Yes — grilles are confirmed for the woofers. The kit includes two woofers with grilles, two tweeters, crossovers, OEM adapter plate, and mounting hardware. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate M1D2-10B M1 Series 10 Inch DVC 2-Ohm Color Optix Marine Subwoofer in Black A marine grade 10 inch dual voice coil 2-ohm subwoofer in black with Color Optix RGB LED lighting, 300W RMS handling, and VersaSwitch impedance selection between 1-ohm and 4-ohm. Santoprene VAST surround, mineral-filled polypropylene cone, vented motor with nano-coated mesh screen, and integrated Deutsch/Amphenol plug-and-play connectors. Compatible with sealed and vented enclosures. IPX6 rated and ASTM B117 and G154 tested. Sold individually (1 each). Backed by a 2 year warranty. Product Overview The Rockford Fosgate M1D2-10B is an M1 series 10 inch dual voice coil (DVC) 2-ohm marine subwoofer in black, featuring Color Optix RGB LED illumination controllable via the PMX-RGB controller and RF Connect app (available on iOS and Android, sold separately). It shares the same physical dimensions and construction as the M1D4-10B but uses DVC 2-ohm voice coils, giving the VersaSwitch different impedance settings: 1-ohm (parallel) and 4-ohm (series). The VersaSwitch allows impedance to be changed between 1-ohm (parallel) and 4-ohm (series) by flipping a single switch, without any additional wiring. Integrated Deutsch/Amphenol connectors are moulded directly into the basket frame, providing error-proof plug-and-play connectivity for both the speaker signal and Color Optix RGB lighting. Conventional zinc nickel-plated marine grade brass spade terminals are also included as an alternative wiring option. The cone is injection-moulded mineral-filled polypropylene with UV inhibitors, co-moulded with a Santoprene VAST surround. Rockford Fosgate's patented VAST technique increases the effective radiating cone area by up to 25%. A linear synthetic fiber blend spider provides consistent excursion control. The vented motor design with a water-repelling nano-coated mesh screen allows heat dissipation at high output levels while protecting the motor from water ingress. The 100% UV stable ASA plastic frame and grille resist discolouration in marine environments. Optically clear UV stable RGB lighting encapsulation protects the LED PCB throughout. Compatible with both sealed and vented enclosure configurations. Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. Klippel Verified certification applied. Sold individually - one subwoofer per purchase. Features & Benefits VersaSwitch - 1-Ohm or 4-Ohm Without Rewiring: The VersaSwitch allows the DVC 2-ohm voice coils to be configured to parallel (1-ohm) or series (4-ohm) by flipping a single switch. The 1-ohm setting maximises output from compatible mono amplifiers, while the 4-ohm setting suits amplifiers better matched to a higher impedance load. Compact 10 Inch Format - Space-Efficient Marine Bass: The M1D2-10B is the 2-ohm version of Rockford Fosgate's compact M1 series 10 inch marine subwoofer, with a 4.23 inch mounting depth and 8.90 inch cutout diameter, suited to under-seat compartments and vessels with limited enclosure space. Color Optix RGB LED Lighting - App Controlled: Ultra-bright wide-angle RGB LEDs are protected by optically clear UV stable encapsulation, controllable via the PMX-RGB controller and RF Connect app on iOS and Android. The PMX-RGB controller is sold separately. Integrated Deutsch/Amphenol Connectors - True Marine Ecosystem: Moulded in-frame Deutsch/Amphenol connectors combine speaker signal and Color Optix RGB lighting into a single error-proof plug-and-play connection. Zinc nickel-plated marine grade brass spade terminals are also included for standard wiring installations. Santoprene VAST Surround - UV and Salt-Fog Resistant: The Santoprene VAST surround is co-moulded to the mineral-filled polypropylene cone and attaches vertically using Rockford Fosgate's patented VAST technique, increasing the effective radiating cone area by up to 25% for more bass output from the same 10 inch driver. Vented Motor with Nano-Coated Water-Repelling Mesh Screen: The vented motor design allows heat to dissipate from the 2 inch (50mm) Kapton voice coil former at high output levels, while the nano-coated mesh screen prevents water from entering the motor assembly in spray-intensive marine environments. ASTM and ISO Tested - Purpose-Built Marine Construction: Tested to ASTM B117 (500-hour salt/fog), ASTM G154 (500-hour accelerated UV), and ISO60068-2-64 vibration standards. IPX6 water intrusion rating confirms protection against powerful jets of water from any direction. Technical Specs Specification Detail SKU M1D2-10B Size 10 inch Colour Black Voice Coil Type Dual Voice Coil (DVC) Nominal Impedance (each coil) 2 Ohm VersaSwitch Parallel 1 Ohm VersaSwitch Series 4 Ohm Power Handling 300W RMS / 1200W Peak SPL 91.5 dB (1W/1m) Frequency Response 20 Hz - 750 Hz Fs (Hz) 34 Vas (Litres) 44.2 Qts 0.44 Qes 0.47 Qms 7.80 Xmax 7.0mm Re (Ohms) 3.7 Le (mH) 2.22 Sd (cm2) 394.1 Woofer Displacement 0.10 cu.ft (2.80 Litres) Voice Coil Diameter 2 inch (50mm) Voice Coil Former High Temp Kapton Magnet Weight 47.70 oz (1.35kg) Cutout Diameter 8.90 inch (226mm) Mounting Depth 4.23 inch (107.4mm) Surround Santoprene VAST Spider Linear Synthetic Fiber Blend Motor Design Vented with Nano-Coated Water-Repelling Mesh Screen Frame 100% UV Stable ASA Plastic Speaker Connector Integrated Deutsch/Amphenol + Zinc Nickel-Plated Brass Spade Terminals Lighting Control Color Optix via PMX-RGB + RF Connect App Surround Technology VAST Water Intrusion Rating IPX6 Salt/Fog Testing ASTM B117 (500 hours) UV Testing ASTM G154 (500 hours) Vibration Testing ISO60068-2-64 Sold As Individually (1 each) Certifications Klippel Verified Shipping Weight 3.9kg Warranty 2 Years Compatible With / Goes Well With The M1D2-10B is suited to marine watercraft, pontoon boats, ski boats, and any vessel requiring a compact 10 inch marine subwoofer with Color Optix lighting. The VersaSwitch enables pairing with amplifiers rated at 1-ohm or 4-ohm. Sold individually. Goes Well With: PMX-RGB - Rockford Fosgate Color Optix RGB controller required to access full Color Optix lighting control and RF Connect app integration M5-1000X1 - M5 series 1000W marine monoblock amplifier, capable of 750W at 1-ohm - well matched to the M1D2-10B at 1-ohm VersaSwitch setting M2-500X1 - M2 series 500W mono marine amplifier for a matched M2 ecosystem pairing M5-1500X5 - M5 series 1500W 5-channel marine amplifier for full system builds pairing the M1D2-10B with marine full-range speakers M1D4-10B - Black DVC 4-ohm version of this subwoofer (VersaSwitch 2-ohm/8-ohm) for comparison when amplifier impedance requirements differ M1D2-10 - White version of this subwoofer for colour-matched installations Frequently Asked Questions What is the difference between the M1D2-10B and the M1D4-10B? Both are black M1 series 10 inch Color Optix marine subwoofers with identical construction, power handling, and physical dimensions. The only difference is voice coil impedance. The M1D2-10B has DVC 2-ohm coils, giving VersaSwitch settings of 1-ohm (parallel) or 4-ohm (series). The M1D4-10B has DVC 4-ohm coils, giving VersaSwitch settings of 2-ohm (parallel) or 8-ohm (series). Choose the M1D2-10B for amplifiers that deliver maximum power at 1-ohm or 2-ohm loads; choose the M1D4-10B for amplifiers better suited to 2-ohm or 8-ohm impedance. What impedance settings does the VersaSwitch provide on the M1D2-10B? The M1D2-10B uses DVC 2-ohm voice coils. The VersaSwitch configures the coils to parallel (1-ohm total) or series (4-ohm total) without any rewiring. Use the 1-ohm parallel setting when pairing with an amplifier rated for 1-ohm operation for maximum power output, or the 4-ohm series setting when your amplifier is better suited to a higher impedance load. What is the difference between the M1D2-10B and the M1D2-12B? Both are black M1 series DVC 2-ohm Color Optix marine subwoofers with the same VersaSwitch settings (1-ohm parallel / 4-ohm series) and power handling (300W RMS). The M1D2-10B is the 10 inch version with a shallower 4.23 inch mounting depth, smaller enclosure requirements, and a higher Fs of 34Hz suited to a more compact enclosure. The M1D2-12B is the 12 inch version with deeper mounting depth and a lower Fs of 26Hz for deeper bass extension. Choose the M1D2-10B for space-constrained installations; choose the M1D2-12B for maximum bass depth. Is the M1D2-10B sold as a single unit or as a pair? The M1D2-10B is sold individually - one subwoofer per purchase. Two units will need to be added to the order if a dual subwoofer installation is required. Does the Color Optix lighting require a separate controller? Yes. Color Optix RGB lighting requires the PMX-RGB controller and the RF Connect app (available on iOS and Android) to access full colour control, lighting effects, and brightness adjustment. The PMX-RGB controller is sold separately. The subwoofer can also be used without the controller at a fixed default colour setting straight out of the box.Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
