Designed for a Subwoofer System That Requires Little Space The Punch PBR300X1 is a 300 Watt mono amplifier designed for compact subwoofer systems. This efficient amp packs a Punch in motorcycles, ATVs and hybrid-electric vehicles without sucking a lot of juice from your electrical system. The PBR300X1 is a mono amplifier designed for a subwoofer system that requires little space. The BRT (Boosted Rail Technology) is an ultra efficient design that doesn't even use a switching power supply to generate its 300 Watts of power! The BRT also has a variable hi-level DC offset turn-on circuit for easy installation into any OEM system. Great for motorcycles and recreational vehicles. Features: MOSFET output stage 12dB/octave Butterworth crossover High level inputs Ultra compact chassis Variable 4-6 volt hi level DC offset voltage input turn-on control Specifications: CEA-2006 Compliant Number of Channels 1 Total Power (Sum of Rated Power) 300 Watts Rated Power (RMS Continuous Power) 75 Watts x 1 @ 4-Ohm, 150 Watts x 1 @ 2-Ohm, 300 Watts x 1 @ 1-Ohm Dynamic Power (PVC/PowerCube¬Æ) 96 Watts x 1 @ 4-Ohm, 189 Watts x 1 @ 2-Ohm, 326 Watts x 1 @ 1-Ohm Bridgeable No Frequency Response 20Hz - 250Hz +/-3dB Input Sensitivity Low-Level: 150 mV - 4 V, High-Level: 400 mV - 11 V, Circuit Topology ClassClass BR Efficiency (average) 75% @ 4-Ohm, 75% @ 2-Ohm, 75% @ 1-Ohm Total Harmonic Distortion (THD+Noise) 4-Ohm: <1.0%, 2-Ohm: <1.0% Signal Input High/Low Input Switch, High/Low Level Input: 4-Pin harness, Hi-Level Sensitivity: Variable DC offset sensitivity Tone Controls External via Optional Punch EQ Crossover Controls Low-Pass: 35Hz - 250Hz @ 12dB/Octave Butterworth Remote Controls Optional PEQ provides 0dB to +18dB @ 45Hz Visual Indicators Power/Protect, BRT (Boost) Power Wire Gauge 10 AWG Power Input Connector Detachable Compression Terminal Speaker Wire Gauge 16 AWG Speaker Output Connector 4-Pin Harness, Wiring Convenience: 2 Negative Terminals (-), 2 Positive Terminals (+) Cooling Convection Operating Voltage 9 - 16 VDC Recommended Fuse (not included) 30 A Average Current Draw (13.8V Music) 15 A Max. Current Draw (13.8V Sinewave) 30 A Suggested Alternator 75 A Dimensions (H x W x D) 1.53 x 4.25 x 6.75 (in.) 3.90 x 10.8 x 17.2 (cm) Shipping Weight 2.76 lbs. (1.25 Kg.) Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Rockford Fosgate Punch 600 Watt 4-Channel Amplifier: Versatile to Power Any Audio System Configuration The Rockford Fosgate Punch P600X4 is a 4-channel amplifier producing 150 Watts into all four channels at 2-Ohm. The P600X4 is perfect for a 4-way full-range system or a 3-way system having a front stage with subwoofers on the rear channels. The Punch P600X4 multi-channel amplifier is versatile to power any audio system configuration. In addition to 4-channel stereo mode, you can bridge both channels to create a high power 2-channel amp, or run stereo speakers on the front with subwoofers on the rear in 3-channel mode. The variable HP/LP crossover and built-in Punch EQ allows for precise tuning of Bass frequencies and the Pass-Thru RCA jacks provide flexibility as your system grows and keeping Y-adapters to a minimum. Rockford Fosgate P600X4 Features: High level input capable with Auto Turn-On circuit RCA pass-thru outputs Features C.L.E.A.N. Set-up Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator) 12dB/octave Butterworth crossover On-board Punch EQ with +18dB boost @ 45Hz Muted turn on Stealth top mounted control panel Cast aluminum heatsink Short circuit protection Over current protection   Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Rockford Fosgate Punch 500 Watt Class-bd Mono Amplifier: With Its Super-Efficient Class-bd Circuit Topology, the P500X1bd Will Drop Some Serious Bass! The Punch P500X1bd is a mono amplifier capable of 500 Watts into a 1-Ohm load. The Class-BD technology produces bass more efficiently over traditional amps, and its frequency response allows it to be optimized for subwoofers. With its super efficient Class-bd circuit topology, the P500X1bd will drop some serious BASS! Due to its dedicated low frequency response, this amplifier is optimized for mid-bass speakers or subwoofers only. No need to worry because its 1-ohm capability will drive a pair of 4-ohm DVC subwoofers or quad-configuration of 2-ohm DVC subwoofers with ease. Rockford Fosgate P500X1BD Features: High level input capable with Auto Turn-On circuit Features C.L.E.A.N. Set-up Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator) RCA pass-thru outputs 12dB/octave Butterworth crossover On-board Punch EQ with +18dB boost @ 45Hz Muted turn on Stealth top mounted control panel Cast aluminum heatsink Short circuit protection Over current protection Infrasonic filter Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

"All-in-One" Solution for Adding Serious Bass to Hatchbacks, Sedans, and SUVs The Punch P500-12P is an "all in one" solution for adding serious bass to Hatchbacks, Sedans, and SUVs. This model features a 12" high output woofer with a 500-watt internal amplifier and a high output vented enclosure that's great for sedan and hatchback applications. The enclosure features quick-release input and power connectors for easy removal when extra space is required. The Punch 500-12P is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 12" high output subwoofer is impedance optimized for the built in 500-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. You can change the amount of bass on the fly with the included remote level control. The slot port provides powerful output at lower frequencies for enhanced bass reproduction. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-of/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks. The enclosure also features a quick-release connectors for easy removal when you need extra cargo space. Features: Optimized 12" Low Impedance Woofer 500 Watt Class-D Amplifier with Optimized "Closed Loop" Design Adjustable 12db/Octave low pass crossover On Board Phase Switch Intelligent auto turn on/off function Robust Power/Ground connections Quick Input Connections for Easy Removal On Board Adjustable Bass EQ Remote bass level control included Separate low level and speaker level inputs Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish Thermal and over/under voltage protection Designed For Hatchback, Sedan, and SUV Applications Specifications: CEA-2031 Compliant Frequency Response 20 Hz to 200 Hz Woofer Quantity 1 Woofer Size 12" Woofer Series Proprietary Power Handling (Watts RMS) 500 Watts RMS Enclosure Type Ported Enclosure Material 5/8" MDF (Medium Density Fiberboard) CEA-2006 Compliant Integrated Amplifier 500 Watts RMS Crossover Controls Variable 50 Hz to 200 Hz, 12dB/Octave Butterworth Tone Controls Bass Boost 0 dB to +12 dB Phase Control 0¬∞ to 180¬∞ Remote Control Punch Level Control (Included) / Replacement Part: 1510-57864-01 Auto Turn-On Selector Remote Trigger, DC Offset Sense, Audio Sense Input Switch High-Level (Speaker Line), Low-Level (RCA) Signal Input Low/High-Level: 1 RCA Pair (L/R Summed) / Replacement Part: 1560-57865-01 Input Sensitivity Low-Level: 150 mV to 6 V, High-Level: 300 mV to 12 V Input Impedance 20k Ohms Power Input Connector Quick Disconnect / Replacement Part: 1040-57860-01 Power Wire Gauge B+/GND: 8 AWG, REM: 18 AWG Heatsink Type Extruded Aluminum Circuit Topology Class Class-D Cooling Convection Visual Indicators Power/Protect LED Fuses 30 Amp (2 x 15 Amp ATO Fuse) Dimensions: Box H x W x D 15.00‚Äù x 24.76‚Äù x 10.91 x 7.71‚Äù Wedge H x W x D1 x D2 (38.1 cm x 62.9 cm x 27.7 cm x 18.92 cm) Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Rockford Fosgate 10" Shallow Stamped Mesh Grille Insert: Protect Your Subwoofers from the Brutal Environment of Your Trunk Stamped steel grille insert for select Rockford Fosgate 10" Punch shallow P3 subwoofers. Requires trim ring originally included with subwoofer to hold grille in place. Made from stamped metal, this black grille will protect your 10" P3S shallow subwoofers from the brutal environment of your trunk. Keeps your golf clubs, softball bats, hockey sticks or even baby strollers away from your prized Rockford Fosgate subwoofers. Simply remove the existing trim ring from your woofer, insert the mesh grille, and re-secure the trim ring. Compatible with select models. Rockford Fosgate P3SG-10 Features: Inserts snugly into Gen-2 P3S trim rings Protects against surround and cone damage Sized to fit Gen-2 P3S woofers Stamped mesh grille insert   Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Delivers ‚ÄúPunch‚Äù Even When Depth Is Limited Rockford Fosgate P3S 8" shallow mount subwoofer delivers ‚ÄúPunch‚Äù even when depth is limited. The P3SD4-8 features Dual 4-Ohm voice coils for wiring flexibility and 150 Watts RMS power handling. The Rockford Fosgate P3S 8" shallow mount subwoofer delivers Punch, even in depth limited situations. Rockford Fosgate understands all vehicles are not the same, because some cannot accommodate deep subwoofers. In the past, that meant no Bass. Not anymore! Now even depth-challenged vehicles can have REAL Bass and the Dual Voice Coil allows configurations for every application. Shallow woofers are specifically designed for spaces where a traditional woofer cannot be used. Features: M-Roll Santoprene™ surround StampCast basket with integrated spider venting Anodized aluminum cone and dust cap Dual linear spider with embedded 16 AWG tinsel leads Diamond cut cast aluminum trim ring with optional grille Shallow Motor Assembly Optimized for both sealed and vented enclosures Specifications: Nominal Impedance Dual 4-Ohm Power Handling (Watts RMS)150 Watts RMS, 300 Watts Max Magnet Weight (oz) 37.5 oz. (1.06 Kg) Voice Coil Diameter 2" (51.6 mm) SPL (dB @ 1w/1m) 82 CEA-2031 Compliant Qes 1.05 Vas (Liters) 15.8 Cutout Diameter 7.13 in. (181.0 mm) Size 8" Speaker Connector Dual 10 AWG Compression Mounting Depth 2.66 in. (67.5 mm) Shipping Weight 8.8 lbs. (3.99 Kg.) Fs (Hz) 39 Qts 0.87 Qms 5 Xmax (mm) 8.5 Woofer Displacement 0.040 cu. ft. (1.13 Liters) Re (Ohms) 6.0 Le (mH) 1.46 Sd (cm2) 220 Subwoofer Type Shallow Voice Coil Type Dual Voice Coil Sealed Box Volume (Vb) 0.25 cu. ft. (7.0 Liters) Vented Box Volume (Vb) 0.75 cu. ft. (21.2 Liters)   Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Highlights: Highlights: FEATURES: M-ROLL SANTOPRENE™ SURROUND STAMPCAST BASKET WITH INTEGRATED SPIDER VENTING ANODIZED ALUMINUM CONE AND DUSTCAP DUAL LINEAR SPIDER WITH EMBEDDED 16 AWG TINSEL LEADS DIAMOND CUT CAST ALUMINUM TRIM RING WITH OPTIONAL GRILLE SHALLOW MOTOR ASSEMBLY OPTIMIZED FOR BOTH SEALED AND VENTED ENCLOSURES Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!

Read more less

Rockford Fosgate Punch 10" P3S Shallow 4-Ohm DVC Subwoofer: Delivers “Punch” Even When Depth Is Limited Rockford Fosgate P3S 10" shallow mount subwoofer delivers “Punch” even when depth is limited. The P3SD4-10 features Dual 4-Ohm voice coils for wiring flexibility and 300 Watts RMS power handling. The Rockford Fosgate P3S 10" shallow mount subwoofer delivers Punch, even in depth limited situations. Rockford Fosgate understands all vehicles are not the same, because some cannot accommodate deep subwoofers. In the past, that meant no Bass. Not anymore! Now even depth challenged vehicles can have REAL Bass and the Dual Voice Coil allow configurations for every application. Shallow woofers are specifically designed for spaces where a traditional woofer cannot be used. Rockford Fosgate P3SD4-10 Features: M-Roll Santoprene™ surround StampCast basket with integrated spider venting Anodized aluminum cone and dustcap Dual linear spider with embedded 16 AWG tinsel leads Diamond cut cast aluminum trim ring with optional grille Shallow Motor Assembly Optimized for both sealed and vented enclosures Rockford Fosgate P3SD4-10 Specifications: Magnet Weight (kg) NOT USED 1.32 oz. (47 kg.) Nominal Impedance Dual 4-Ohm Magnet Weight (oz) 47 oz. (1.32 Kg) Voice Coil Diameter 2.5" (65.5 mm) SPL (dB @ 1w/1m) 83 Fs (Hz) 42 Qms 6.00 Vas (Liters) 14.3 Cutout Diameter 9.06 in. (230.0 mm) Woofer Displacement 0.074 cu. ft. (2.1 Liters) Sd (cm2) 333 Size 10" Speaker Connector Dual 10 AWG Compression Mounting Depth 3.50 in. (89.0 mm) Shipping Weight 11.9 lbs. (5.39 kg.) Qts 0.78 Qes 0.90 Xmax (mm) 8.1 CEA-2031 Compliant Power Handling (Watts RMS) 300 Watts RMS, 600 Watts Max Re (Ohms) 6.80 Le (mH) 4.3 Subwoofer Type Shallow Voice Coil Type Dual Voice Coil Sealed Box Volume (Vb) 0.5 cu. ft. (14.1 Liters) Vented Box Volume (Vb) 1.0 cu. ft. (28.3 Liters) Legendary Products & Support From Authorized Dealers When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized Rockford Fosgate dealer today!
