Rockford Fosgate T1S2-12 Power 12" T1 Slim Single 2-Ohm Subwoofer T1 Performance, Shallow Depth Product Overview The Rockford Fosgate T1S2-12 is a 12" slimline single 2-ohm subwoofer from the flagship Power T1 series, rated at 600W RMS and 1200W peak. Engineered specifically for installations where traditional-depth subwoofers will not fit, the T1S2-12 is not a generic shallow driver it is a purpose-designed slimline subwoofer built to deliver near-identical performance characteristics to the full-depth Power T1 range, through a suite of patent-pending and proprietary technologies that are unique to the T1 slimline platform. At the heart of the T1S2-12 is a proprietary slotted voice coil assembly with interior and exterior windings that enables exceptional long-excursion travel from a reduced mounting depth addressing the fundamental challenge of shallow subwoofer design where limited cone excursion typically constrains bass output. A high-energy neodymium motor structure, proprietary split yoke pass-through motor technology, encapsulating voice coil-to-former coupling, integrated copper cap heat-sinking shorting ring (IDHS), dual Nomex progressive spiders with integrated lead wires, and a carbon fibre/PMI/glass fibre composite cone combine to produce a slimline driver engineered with the same rigour as the full-depth T1 range. Optimised for sealed enclosures. Detachable die-cast aluminium trim ring included; optional grille insert available separately. Key Specifications Driver size: 12" slimline Voice coil configuration: Single 2-ohm Power handling: 600W RMS / 1200W peak Motor structure: High-temp high-energy neodymium Voice coil: Dual wound 2.5" with interior and exterior windings (slotted assembly) Cone: Carbon fibre / PMI / glass fibre composite with aluminium dust cap Surround: Injection-moulded foam with VAST technology Spiders: Dual Nomex progressive with integrated lead wires Basket: Aluminium die-cast with integrated heat sink fins Shorting ring: Integrated copper cap heat-sinking (IDHS) Input terminals: Custom insulated push spring 10 AWG Pole piece: Vented Trim ring: Detachable die-cast aluminium (included) Grille: Optional grille insert (sold separately) Optimised for: Sealed enclosures Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits Proprietary slotted voice coil assembly with interior/exterior windings (patent pending): The engineering core of the T1S2-12. The slotted assembly with dual winding configuration allows the voice coil to travel significantly further than a conventional shallow driver voice coil, generating the long excursion needed for deep, high-output bass from a reduced mounting depth. This is the key technology that separates the T1S2-12 from generic shallow subwoofers. Proprietary split yoke pass-through motor technology (patent pending): The split yoke design allows the motor structure to be configured in a way that enables greater excursion travel within a slimmer overall assembly depth. A fundamental motor architecture innovation that contributes directly to the T1S2-12's ability to match full-depth T1 performance characteristics. High-temp high-energy neodymium motor structure: Neodymium magnets produce a stronger magnetic field per unit mass than conventional ferrite magnets, enabling higher motor force (BL) in a more compact and lighter motor assembly critical for achieving T1-level sensitivity and power handling in a slimline format where magnet volume is constrained. Encapsulating voice coil-to-former coupling technology (patent pending): The voice coil is coupled to the former through an encapsulating process that increases the bonding surface area and strength, preventing delamination at the high excursion levels and sustained power inputs the T1S2-12 is designed to handle. Integrated copper cap heat-sinking shorting ring (IDHS): The copper shorting ring reduces inductance variation across the excursion range (improving linearity and reducing distortion) while simultaneously acting as a heat sink to draw thermal energy away from the voice coil gap directly contributing to sustained power handling reliability. Carbon fibre/PMI/glass fibre composite cone with aluminium dust cap: A multi-material composite cone significantly stiffer and lighter than conventional paper or polypropylene cones, maintaining pistonic accuracy at the high excursion levels the slotted voice coil assembly enables. PMI (polymethacrylimide) foam core adds internal damping to suppress cone resonances. Injection-moulded foam surround with VAST technology: VAST (Vertical Attach Surround Technique) reclaims cone surface area at the surround attachment, and the injection-moulded foam surround provides consistent, repeatable excursion compliance across the full travel range more precise than rubber or cloth surrounds at high excursion levels. Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the extended excursion range the slotted voice coil enables. Integrated lead wires eliminate the traditional separate tinsel lead removing a common failure point in high-excursion slimline drivers. Aluminium die-cast basket with integrated heat sink fins: The basket fins actively dissipate heat from the motor assembly during sustained high-power use a thermal management feature particularly important in compact, sealed enclosure environments where heat accumulates more rapidly than in larger enclosure volumes. Single 2-ohm voice coil simplified wiring: Single voice coil eliminates dual-coil wiring complexity, presenting a direct 2-ohm load to the amplifier. Straightforward pairing with any 2-ohm stable mono amplifier without impedance configuration decisions. Vented pole piece: Air channels through the pole piece reduce thermal compression and back-pressure behind the cone at high excursion levels, improving linearity and power handling consistency. Custom insulated push spring 10 AWG terminals: Appropriate for the current demands of a 600W RMS, 2-ohm system. Push-spring design allows fast, clean wiring without tools. Optimised for sealed enclosures: Rockford Fosgate has specifically tuned the T1S2-12 for sealed enclosure use, ensuring the driver's compliance and Qts parameters produce the intended bass response in a sealed alignment confirm recommended enclosure volume with Rockford Fosgate documentation before building. Detachable die-cast aluminium trim ring included: Provides a clean, finished appearance at the installation cutout. The detachable design allows removal for bare-driver installation where a trim ring is not required. Optional grille insert available separately: Grille protection is available for installations where driver exposure is a concern confirm compatible part number with your supplier. Technical Specs Specification Detail SKU T1S2-12 Brand Rockford Fosgate Driver Size 12" slimline Voice Coil Configuration Single 2-ohm Power Handling 600W RMS / 1200W peak Motor Structure High-temp high-energy neodymium Voice Coil Dual wound 2.5"; interior and exterior windings (slotted assembly) Voice Coil Coupling Encapsulating voice coil-to-former technology (patent pending) Motor Technology Proprietary split yoke pass-through (patent pending) Cone Carbon fibre / PMI / glass fibre composite Dust Cap Aluminium Surround Injection-moulded foam with VAST technology Spiders Dual Nomex progressive with integrated lead wires Basket Aluminium die-cast with integrated heat sink fins Shorting Ring Integrated copper cap heat-sinking (IDHS) Pole Piece Vented Input Terminals Custom insulated push spring 10 AWG Trim Ring Detachable die-cast aluminium (included) Grille Optional insert (sold separately) Enclosure Optimisation Sealed Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With Mono amplifiers stable at 2 ohms, rated at or near 600W RMS Rockford Fosgate Power T1 and T2 series mono amplifiers Custom sealed enclosures designed for the T1S2-12 confirm recommended enclosure volume with Rockford Fosgate documentation before building Vehicles where traditional-depth subwoofers will not fit: behind-seat ute and truck installations, shallow boot floor vehicles, and custom fabrication builds with depth constraints Rockford Fosgate T1S-1X12 slim sealed loaded enclosure (purpose-built enclosure for the T1 slim driver range) Rockford Fosgate 10 AWG and heavy-gauge wiring kits for 2-ohm mono amplifier installation Rockford Fosgate RCA cables and signal processors Frequently Asked Questions How does the T1S2-12 achieve T1-level performance in a slimline format? The T1S2-12 uses a proprietary slotted voice coil assembly with interior and exterior windings (patent pending) that enables long excursion travel from a reduced mounting depth the key constraint of conventional shallow drivers. Combined with the split yoke pass-through motor technology (patent pending), neodymium motor structure, and encapsulating voice coil coupling, the T1S2-12 is engineered to deliver near-identical performance to traditional-depth T1 subwoofers from a significantly shallower installation profile. What impedance does the T1S2-12 present to the amplifier? The T1S2-12 is a single 2-ohm voice coil driver, presenting a direct 2-ohm load to the amplifier. No wiring configuration is required connect a 2-ohm stable mono amplifier rated at or near 600W RMS and go. Is the T1S2-12 suitable for the Rockford Fosgate T1S-1X12 loaded enclosure? The T1S-1X12 is a purpose-built slim sealed loaded enclosure from Rockford Fosgate that houses a T1 slim driver. Confirm with your supplier whether the T1S2-12 is the specific driver variant installed in the T1S-1X12 or whether it is compatible as a replacement driver before purchasing. What enclosure type is the T1S2-12 optimised for? The T1S2-12 is specifically optimised for sealed enclosures. Rockford Fosgate has tuned the driver's parameters for sealed alignment confirm recommended enclosure volume with official Rockford Fosgate documentation or a qualified installer before designing or building an enclosure. Is a grille included with the T1S2-12? No. The T1S2-12 ships with a detachable die-cast aluminium trim ring only. An optional grille insert is available separately confirm the compatible part number with your supplier before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T1S1-12 Power 12" T1 Slim Single 1-Ohm Subwoofer T1 Performance, Shallow Depth, 1-Ohm Ready Product Overview The Rockford Fosgate T1S1-12 is a 12" slimline single 1-ohm subwoofer from the flagship Power T1 series, rated at 600W RMS and 1200W peak. The 1-ohm stable counterpart to the T1S2-12, it carries the complete T1 slimline technology stack in a single 1-ohm voice coil configuration presenting a direct 1-ohm load to the amplifier for maximum power extraction from 1-ohm stable mono amplifiers without any wiring configuration required. Like the T1S2-12, the T1S1-12 is purpose-engineered to deliver near-identical performance characteristics to the full-depth Power T1 range from a significantly shallower mounting depth, through the same suite of proprietary and patent-pending technologies: the slotted voice coil assembly with interior and exterior windings enabling long excursion travel, the split yoke pass-through motor technology, high-energy neodymium motor structure, encapsulating voice coil-to-former coupling, integrated copper cap heat-sinking shorting ring (IDHS), dual Nomex progressive spiders with integrated lead wires, and carbon fibre/PMI/glass fibre composite cone. Optimised for sealed enclosures. Detachable die-cast aluminium trim ring included; optional grille insert available separately. Key Specifications Driver size: 12" slimline Voice coil configuration: Single 1-ohm Power handling: 600W RMS / 1200W peak Motor structure: High-temp high-energy neodymium Voice coil: Dual wound 2.5"; interior and exterior windings (slotted assembly) Cone: Carbon fibre / PMI / glass fibre composite with aluminium dust cap Surround: Injection-moulded foam with VAST technology Spiders: Dual Nomex progressive with integrated lead wires Basket: Aluminium die-cast with integrated heat sink fins Shorting ring: Integrated copper cap heat-sinking (IDHS) Input terminals: Custom insulated push spring 10 AWG Pole piece: Vented Trim ring: Detachable die-cast aluminium (included) Grille: Optional insert (sold separately) Optimised for: Sealed enclosures Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits Single 1-ohm voice coil direct 1-ohm load, zero wiring complexity: The defining differentiator from the T1S2-12. A single 1-ohm voice coil presents a direct 1-ohm load to any 1-ohm stable mono amplifier no parallel or series wiring decisions, no configuration required. The most direct path to maximum power output from a 1-ohm stable amplifier in a slimline 12" T1 driver. Proprietary slotted voice coil assembly with interior/exterior windings (patent pending): Enables long excursion travel from a reduced mounting depth the fundamental engineering challenge of slimline subwoofer design. The slotted assembly with dual winding configuration allows the voice coil to travel significantly further than a conventional shallow driver, generating the displacement needed for deep, high-output bass from a slim installation profile. Proprietary split yoke pass-through motor technology (patent pending): A motor architecture innovation that enables greater excursion travel within a slimmer overall assembly depth, working in combination with the slotted voice coil to produce T1-level bass performance from a shallow driver. High-temp high-energy neodymium motor structure: Neodymium magnets produce significantly stronger magnetic fields per unit mass than conventional ferrite magnets, enabling high motor force (BL) in the compact, lightweight motor assembly required for a slimline design delivering the sensitivity and power handling of a T1 driver from a reduced physical footprint. Encapsulating voice coil-to-former coupling technology (patent pending): Increases bonding surface area and strength between the voice coil and former, preventing delamination at the high excursion levels and sustained 600W RMS input the T1S1-12 is designed for. Integrated copper cap heat-sinking shorting ring (IDHS): Simultaneously reduces inductance variation across the excursion range (improving linearity and reducing distortion) and draws thermal energy away from the voice coil gap essential for sustained 600W RMS reliability in compact, sealed enclosure environments where heat accumulates rapidly. Carbon fibre/PMI/glass fibre composite cone with aluminium dust cap: A stiff, lightweight multi-material composite significantly stiffer than paper or polypropylene cones, maintaining pistonic accuracy across the extended excursion range the slotted assembly enables. PMI foam core adds internal damping to suppress cone resonances. Injection-moulded foam surround with VAST technology: VAST reclaims cone surface area at the surround attachment, maximising effective piston area in the 12" slimline format. The injection-moulded foam surround provides consistent, repeatable compliance across the full travel range. Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the extended excursion range. Integrated lead wires eliminate the traditional separate tinsel lead removing a common high-excursion failure point that is particularly critical in a slimline driver designed for long voice coil travel. Aluminium die-cast basket with integrated heat sink fins: The basket fins actively dissipate heat from the motor assembly during sustained high-power use a thermal management feature particularly important in compact sealed enclosure installations where back-panel heat accumulation is a reliability concern. Vented pole piece: Air channels through the pole piece reduce thermal compression and back-pressure behind the cone at high excursion levels, improving linearity and power handling consistency in sealed enclosure use. Custom insulated push spring 10 AWG terminals: Appropriate for the high current demands of a 600W RMS, 1-ohm system. Push-spring design allows fast, clean wiring without tools. Optimised for sealed enclosures: The T1S1-12 is specifically tuned for sealed enclosure use. Confirm recommended enclosure volume with Rockford Fosgate documentation before building to ensure the intended bass response is achieved. Detachable die-cast aluminium trim ring included: Provides a clean, finished installation appearance at the cutout. Detachable for bare-driver installations where a trim ring is not required. Optional grille insert available separately: Confirm compatible part number with your supplier for installations where driver protection is required. Technical Specs Specification Detail SKU T1S1-12 Brand Rockford Fosgate Driver Size 12" slimline Voice Coil Configuration Single 1-ohm Power Handling 600W RMS / 1200W peak Motor Structure High-temp high-energy neodymium Voice Coil Dual wound 2.5"; interior and exterior windings (slotted assembly) Voice Coil Coupling Encapsulating voice coil-to-former technology (patent pending) Motor Technology Proprietary split yoke pass-through (patent pending) Cone Carbon fibre / PMI / glass fibre composite Dust Cap Aluminium Surround Injection-moulded foam with VAST technology Spiders Dual Nomex progressive with integrated lead wires Basket Aluminium die-cast with integrated heat sink fins Shorting Ring Integrated copper cap heat-sinking (IDHS) Pole Piece Vented Input Terminals Custom insulated push spring 10 AWG Trim Ring Detachable die-cast aluminium (included) Grille Optional insert (sold separately) Enclosure Optimisation Sealed Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With Mono amplifiers stable at 1 ohm, rated at or near 600W RMS Rockford Fosgate Power T1 and T2 series mono amplifiers (1-ohm stable) Custom sealed enclosures designed for the T1S1-12 confirm recommended sealed enclosure volume with Rockford Fosgate documentation before building Vehicles where traditional-depth subwoofers will not fit: behind-seat ute and truck installations, shallow boot floor vehicles, and custom fabrication builds with depth constraints Rockford Fosgate T1S-1X12 slim sealed loaded enclosure (purpose-built slim sealed enclosure in the T1 slimline range) Rockford Fosgate 10 AWG and heavy-gauge wiring kits for 1-ohm mono amplifier installation Rockford Fosgate RCA cables and signal processors Frequently Asked Questions What is the difference between the T1S1-12 and T1S2-12? Both are 12" T1 slimline subwoofers with identical 600W RMS power handling and the same complete T1 slimline technology stack. The T1S1-12 has a single 1-ohm voice coil presenting a direct 1-ohm load, while the T1S2-12 has a single 2-ohm voice coil presenting a direct 2-ohm load. Choose the T1S1-12 when your amplifier is 1-ohm stable and 1-ohm wiring is the system target; choose the T1S2-12 for 2-ohm stable amplifier pairings. What impedance does the T1S1-12 present to the amplifier? The T1S1-12 is a single 1-ohm voice coil driver, presenting a direct 1-ohm load. No wiring configuration is required connect a 1-ohm stable mono amplifier rated at or near 600W RMS directly to the 10 AWG push spring terminals. How does the T1S1-12 achieve T1-level bass performance in a slimline format? The T1S1-12 uses a proprietary slotted voice coil assembly with interior and exterior windings (patent pending) enabling long excursion travel from a reduced mounting depth, combined with a split yoke pass-through motor technology (patent pending) and high-energy neodymium motor structure. These technologies together allow the T1S1-12 to deliver near-identical performance characteristics to a traditional-depth Power T1 subwoofer from a significantly shallower installation profile. What enclosure type is the T1S1-12 optimised for? The T1S1-12 is specifically optimised for sealed enclosures. Confirm recommended sealed enclosure volume with official Rockford Fosgate documentation or a qualified installer before designing or building an enclosure to ensure the intended bass response is achieved. Is a grille included with the T1S1-12? No. The T1S1-12 ships with a detachable die-cast aluminium trim ring only. An optional grille insert is available separately confirm the compatible part number with your supplier before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T1S-1X12 Power 12" T1 Slim Sealed Loaded Enclosure Big Thump, Slim Footprint Product Overview The Rockford Fosgate T1S-1X12 is a factory-loaded sealed enclosure housing a single 12" Power T1 slim subwoofer with a 600 Watt RMS power handling capacity. Designed specifically for under-seat and behind-seat truck installations where depth is restricted but output expectations are anything but, the T1S-1X12 delivers the deep, solid thump characteristic of a sealed enclosure without demanding the space of a traditional subwoofer box. Pre-wired to 1 ohm straight from the factory, the T1S-1X12 is ready to be pushed hard by a compatible mono amplifier no internal wiring, no driver installation, and no enclosure building required. The slim-line wedge profile is constructed from 5/8" MDF with a premium black carpet finish and stitched Rockford Fosgate logo, and ships complete with a grille for immediate, professional-looking installation in utes, SUVs, and cab-style vehicles across Australia. Key Specifications Subwoofer: Single 12" Rockford Fosgate Power T1 slim Power handling: 600W RMS Pre-wired impedance: 1 ohm Enclosure type: Sealed Enclosure design: Slim-line wedge (truck/under-seat style) Construction: 5/8" MDF Finish: Black carpet with black stitching and Rockford Fosgate logo Input terminals: 12 AWG spring-loaded quick-release Grille: Included Features & Benefits 600W RMS power handling: The T1S-1X12 is built to take serious power. Paired with a compatible 600W mono amplifier, it delivers the kind of authoritative bass output that belies its slim profile ideal for Australian ute and SUV builds where space is tight but bass expectations are high. Pre-wired to 1 ohm: Factory pre-wired to a 1-ohm load, the T1S-1X12 is ready to maximise output from a compatible mono amplifier straight out of the box. No internal wiring configuration required connect your amplifier and go. Sealed enclosure for deep, tight bass: The sealed design produces the deep, solid thump preferred by enthusiasts who want accurate, controlled bass response rather than the louder but less precise output of a ported enclosure. Ideal for rock, hip-hop, and bass-heavy Australian country and electronic music genres. Slim-line wedge profile: Purpose-designed for behind-seat and under-seat installation in utes, trucks, and cab-style vehicles. The wedge shape maximises internal enclosure volume within a minimal height footprint, fitting where standard subwoofer boxes simply cannot. 5/8" MDF construction: Medium-density fibreboard walls provide the rigidity and resonance control needed for accurate bass reproduction, minimising enclosure flex and unwanted panel vibration at high output levels. Premium black carpet with stitched Rockford Fosgate logo: A factory-finished appearance that looks purpose-built rather than aftermarket. The black carpet and black stitching integrate cleanly into the interiors of most Australian utes and SUVs. 12 AWG spring-loaded quick-release input terminals: Tool-free wiring connection and disconnection. Practical for installs where the enclosure may need to be temporarily removed common in ute tray and cab configurations. Grille included: Ships with a protective grille fitted, ready for immediate installation without sourcing additional accessories. Complete loaded enclosure: Subwoofer, enclosure, wiring, and grille are all included. No separate driver purchase, no box building, and no guesswork on enclosure tuning a complete plug-and-play subwoofer solution. Technical Specs Specification Detail SKU T1S-1X12 Brand Rockford Fosgate Subwoofer Driver 12" Rockford Fosgate Power T1 Slim Power Handling 600W RMS Pre-Wired Impedance 1 ohm Enclosure Type Sealed Enclosure Style Slim-line wedge (truck/under-seat) Construction Material 5/8" MDF Finish Black carpet; black stitching Logo Stitched Rockford Fosgate logo Input Terminals 12 AWG spring-loaded quick-release Grille Included Dimensions Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With Rockford Fosgate Power and Punch series mono amplifiers rated at 600W RMS into 1 ohm Utes, trucks, and dual-cab vehicles with behind-seat or under-seat storage space SUVs and wagons with underfloor or rear cargo area installations Vehicles requiring a slim subwoofer solution where standard enclosure depth is not available Rockford Fosgate wiring kits and RCA cables for amplifier integration Frequently Asked Questions What amplifier do I need for the T1S-1X12? The T1S-1X12 is pre-wired to 1 ohm and handles 600W RMS. A mono amplifier stable at 1 ohm and rated at or near 600W RMS is recommended for optimal performance such as a compatible Rockford Fosgate Power or Punch mono amplifier. Will the T1S-1X12 fit behind the seat of my ute or dual-cab? The T1S-1X12 is specifically designed for behind-seat and under-seat truck and ute installations using a slim-line wedge profile. Confirm the exact enclosure dimensions with your supplier and measure your available space before purchase, as dimensions vary between vehicle models. Is the T1S-1X12 a ported or sealed enclosure? It is a sealed enclosure. Sealed designs deliver deep, tight, and accurate bass with a solid thump character preferred for music genres and listeners who prioritise bass quality and control over maximum volume output. Does the T1S-1X12 come with a subwoofer already installed? Yes. The T1S-1X12 is a fully loaded enclosure the 12" Power T1 slim subwoofer is factory-installed, pre-wired to 1 ohm, and ships with a grille included. Connect your amplifier to the spring-loaded input terminals and it is ready to use. Can I rewire the T1S-1X12 to a different impedance? The T1S-1X12 ships pre-wired to 1 ohm. Rewiring to a different impedance depends on the voice coil configuration of the installed T1 slim driver. Confirm the driver's voice coil specification with your supplier or installer before attempting any rewiring. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T1S-1X10P Power 10" 500 Watt Slim Vented Loaded Enclosure Built for truck installs that demand serious output without sacrificing cabin space, the T1S-1X10P pairs a Power T1 slim 10" subwoofer with a precision-tuned vented wedge enclosure rated at 500 watts RMS and configured for maximum current at 1 ohm. Product Overview The T1S-1X10P is Rockford Fosgate's loaded slim vented enclosure from the Power Series, housing the T1S1-10 Power T1 slim 10" subwoofer in a wedge-profile MDF box designed specifically for behind-seat truck installations where depth is limited. Despite the slim-line footprint, the enclosure is vented through a high-flow, low-noise slotted port that is tuned to enhance hard-hitting, boomy bass frequencies rather than the tighter, more controlled output of a sealed design. The 1-ohm nominal impedance configuration allows the T1S1-10 driver to be pushed with serious amplifier power, with 500 watts RMS and 1000 watts peak power handling supported from within a compact wedge profile. The enclosure is constructed from 5/8" MDF and finished in black carpet with black stitched Rockford Fosgate logo detailing. Spring-loaded 12 AWG input terminals provide quick-release connectivity, and a grille is included for driver protection. Klippel verified and CEA-2031 compliant, with a 1-year warranty. Features & Benefits Power T1 Slim Subwoofer with 500W RMS Power Handling: The T1S1-10 Power T1 slim driver is rated at 500 watts RMS and 1000 watts peak, delivering Power Series output capacity from a subwoofer specifically designed for minimum-depth enclosures. Klippel verification confirms the driver's performance parameters have been measured and optimised for accuracy at high excursion levels. Vented Wedge Enclosure Tuned for Hard-Hitting Bass: The slotted port is tuned specifically to enhance hard-hitting, boomy bass frequencies, making the T1S-1X10P the preferred choice for listeners who want maximum impact and low-frequency punch rather than tight, sealed-box accuracy. High-Flow, Low-Noise Slotted Vent: The slotted port design maximises airflow through the enclosure at resonance while minimising port noise and chuffing at high output levels, maintaining clean bass output as amplifier power increases. 1-Ohm Nominal Impedance: The 1-ohm configuration allows the T1S-1X10P to be driven directly from a monoblock amplifier at its lowest stable impedance, maximising available output power from compatible amplifiers and delivering the kind of output associated with a much larger system. Slim-Line Wedge Profile for Truck Behind-Seat Installation: The wedge dimensions of 4.2" x 6.3" depth and 14.5" height allow the T1S-1X10P to fit behind the seats of most trucks without consuming the cab's usable passenger or storage space. 5/8" MDF Construction: The enclosure is constructed from 5/8" Medium Density Fiberboard, providing structural rigidity and acoustic mass suited to vented subwoofer enclosure requirements. 12 AWG Spring-Loaded Input Terminals: The spring-loaded terminal design accepts wire up to 12 AWG and provides a quick-release connection for easy installation or removal without tools. Black Carpet Finish with Stitched Logo: The premium black carpet finish with black-stitched Rockford Fosgate logo detailing provides a clean, finished appearance suited to in-cabin truck installations. Grille Included: A grille is included in the box for full driver protection after installation. CEA-2031 Compliant: Woofer power handling conforms to CEA-2031 industry standards, confirming the 500W RMS rating is a real, tested figure. Technical Specs Specification Detail SKU T1S-1X10P Series Power Woofer Size 10" Woofer Quantity 1 Woofer Series Power T1S (T1S1-10) Power Handling (RMS) 500W Power Handling (Peak) 1000W Nominal Impedance 1 Ohm Frequency Response 20 Hz - 200 Hz Enclosure Type Vented (Shallow Wedge) Enclosure Material 5/8" MDF Enclosure Finish Black Carpet with Black Stitching Speaker Connector Spring-loaded, up to 12 AWG Grille Included Dimensions (H x W x D1 x D2) 14.5" x 31.5" x 4.2" x 6.3" (37.0 cm x 80.0 cm x 10.7 cm x 15.9 cm) Shipping Weight 36 lbs (16.3 kg) Compliance CEA-2031, Klippel Verified Warranty 1 Year Goes Well With The T1S-1X10P operates at 1 ohm and handles 500 watts RMS, requiring a monoblock amplifier that is stable at 1 ohm with sufficient output to drive it effectively. Rockford Fosgate's R2-1200X1 is a well-matched amplifier option, delivering substantial power at 1 ohm from within the Prime Series range. A 4-gauge amplifier wiring kit is required for the power and ground run, and a quality RCA interconnect from the head unit's subwoofer pre-out is the recommended signal source connection. For truck installations requiring front and rear speaker amplification alongside the T1S-1X10P, a separate 4-channel amplifier such as the R2-300X4 or R2-200X2 connected via the monoblock's RCA pass-through is the recommended approach. Frequently Asked Questions Is the T1S-1X10P a sealed or vented enclosure, and how does that affect the bass character? The T1S-1X10P is a vented enclosure, using a high-flow slotted port tuned to enhance hard-hitting, boomy low-frequency output. This makes it the preferred choice for listeners who want maximum impact and low-frequency punch. For tighter, more controlled bass with greater transient accuracy, a sealed enclosure would be the alternative. Rockford Fosgate's P300-10T is an example of a sealed powered truck enclosure if a different bass character is preferred. What amplifier is required, and what impedance does the T1S-1X10P present? The T1S-1X10P is configured at 1-ohm nominal impedance, requiring a monoblock amplifier that is rated stable at 1 ohm. Confirm the amplifier's 1-ohm stability rating before purchase, as not all monoblock amplifiers support 1-ohm operation. At 500 watts RMS power handling, the amplifier should be capable of delivering at least 500 watts at 1 ohm for the driver to reach its rated output. Does the T1S-1X10P include a grille and all hardware needed for installation? Yes. The T1S-1X10P includes a grille for driver protection and spring-loaded 12 AWG input terminals are built into the enclosure. An amplifier, amplifier wiring kit, and RCA interconnect are required separately for a complete installation. Will the T1S-1X10P fit behind the seat of my truck? The T1S-1X10P measures 14.5" high, 31.5" wide, and has a wedge depth ranging from 4.2" to 6.3". These dimensions are designed for common truck behind-seat applications, but clearance varies by vehicle. Measure the available space behind the seat in your specific truck before purchase to confirm the enclosure will fit without obstructing the seat's range of movement. What does Klippel verification mean for the T1S1-10 driver? Klippel is an independent speaker measurement and certification programme that identifies and corrects non-linear distortion parameters in speaker drivers, including suspension non-linearities and motor force variation across the cone's travel range. Klippel verification on the T1S1-10 driver confirms that its performance parameters have been accurately measured and optimised, ensuring the driver delivers clean, low-distortion output at the high excursion levels produced at 500 watts RMS. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T1D412 Power 12" T1 Dual 4-Ohm Subwoofer 800 Watts, VAST Technology, T1 Performance in 12" Product Overview The Rockford Fosgate T1D412 is a 12" dual 4-ohm voice coil subwoofer from the flagship Power T1 series, rated at 800 Watts RMS and 1600 Watts peak. Bringing the full suite of Power T1 technologies to the 12" format, the T1D412 delivers the same patented VAST cone technology, FlexFit die-cast aluminium basket, Kevlar fibre reinforced paper cone, Nomex-reinforced high-temp voice coil, and anodized aluminium construction as the T1 15" range in the more universally applicable 12" driver size suited to a wider range of enclosures and Australian vehicle builds. Patented VAST (Vertical Attach Surround Technique) technology increases the effective cone surface area by up to 25% over a conventional surround attachment, allowing the T1D412 to move more air and produce more bass output per watt than a standard 12" driver performing, in Rockford Fosgate's own terms, like a much larger woofer. The dual 4-ohm configuration wires in parallel to a 2-ohm load for maximum power delivery from a compatible high-output mono amplifier, or in series for an 8-ohm load for specific system configurations. Grille and integral trim ring included. Key Specifications Driver size: 12" Voice coil configuration: Dual 4-ohm (DVC) Wiring options: 2 ohm (parallel) / 8 ohm (series) Power handling: 800W RMS / 1600W peak Technology: Patented VAST up to 25% increased cone surface area Basket: FlexFit rigid die-cast aluminium Cone: Kevlar fibre reinforced paper Voice coil former: Anodized aluminium with copper-clad aluminium wire Voice coil reinforcement: Spun-laced Nomex collar (high-temp) Dust cap: Anodized aluminium heat-sinking Input terminals: Proprietary 8 AWG insulated all-metal spring terminals Spiders: Symmetrical dual progressive roll tear-resistant poly-cotton Tinsel leads: Periodic-stitched fatigue-resistant Grille: Included with integral trim ring Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits Patented VAST technology up to 25% more cone surface area: VAST (Vertical Attach Surround Technique) repositions the surround attachment point to reclaim up to 25% of the cone area traditionally covered by the surround, delivering more effective piston area than a conventional 12" driver moving more air and producing more bass output per watt from the same basket diameter. FlexFit rigid die-cast aluminium basket: Precision-cast for structural rigidity with installation geometry flexibility for custom fabrication and extreme builds where standard basket angles create clearance issues with the enclosure or vehicle structure. Purpose-built for serious Australian car and truck audio installations. 800W RMS / 1600W peak power handling: The T1D412 handles 200W RMS less than the T1 15" models, reflecting the smaller cone area, while remaining firmly in high-output territory suited to the most powerful 12"-oriented mono amplifiers in the Rockford Fosgate Power series. Dual 4-ohm voice coils 2-ohm parallel or 8-ohm series wiring: Wired in parallel, the T1D412 presents a 2-ohm load for maximum power delivery from a 2-ohm stable mono amplifier. Wired in series, it presents an 8-ohm load for specific bridged or multi-driver configurations. Choose the T1D412 when a 2-ohm stable amplifier pairing is the system target. High-temp voice coil with spun-laced Nomex reinforcement collar: Nomex reinforcement at the critical former-to-cone junction prevents delamination and separation under sustained high-power, high-excursion use at 800W RMS continuous input a key reliability differentiator from lesser 12" drivers at this power level. Anodized aluminium voice coil former with copper-clad aluminium wire: Superior heat dissipation versus paper or plastic formers, extending voice coil life under sustained high-power use in the high-temperature boot environments common in Australian vehicles during summer. Copper-clad aluminium winding reduces moving mass while maintaining conductivity, improving transient response and efficiency. Kevlar fibre reinforced paper cone: Kevlar adds stiffness and break-up resistance without excessive weight, maintaining accurate pistonic motion across the full excursion range at 800W RMS where an unreinforced paper cone would begin to flex and distort. Anodized aluminium heat-sinking dust cap: Acts as an active heat sink during sustained high-power use, drawing thermal energy away from the pole piece and voice coil gap directly contributing to long-term reliability at the power levels the T1D412 is rated to handle. Optimised pole piece and spider venting: Internal air channels reduce compression behind the cone at high excursion levels, improving linearity and bass accuracy at the displacement levels an 800W RMS 12" driver routinely operates at. Proprietary 8 AWG insulated all-metal spring input terminals: Heavy-gauge terminals appropriate for the high current demands of an 800W RMS, 2-ohm system. All-metal construction ensures reliable, corrosion-resistant connections over the long term. Symmetrical dual progressive roll poly-cotton spiders: Dual spider configuration provides linear restoring force symmetry across the full excursion range, reducing harmonic distortion and maintaining voice coil alignment at high displacement levels. Periodic-stitched fatigue-resistant tinsel leads: Periodic stitching distributes flex stress along a longer lead length, significantly extending tinsel lead fatigue life at the sustained high-excursion levels the T1D412 is designed to operate at. Grille and integral trim ring included: Ships complete with protective grille and trim ring for a finished, professional installation appearance without requiring a separately purchased grille. Technical Specs Specification Detail SKU T1D412 Brand Rockford Fosgate Driver Size 12" Voice Coil Configuration Dual 4-ohm (DVC) Wiring Options 2 ohm (parallel) / 8 ohm (series) Power Handling 800W RMS / 1600W peak Technology Patented VAST up to 25% increased cone surface area Basket FlexFit rigid die-cast aluminium Cone Kevlar fibre reinforced paper Dust Cap Anodized aluminium heat-sinking Voice Coil Former Anodized aluminium Voice Coil Wire Copper-clad aluminium Voice Coil Reinforcement Spun-laced Nomex collar (high-temp) Spiders Symmetrical dual progressive roll tear-resistant poly-cotton Tinsel Leads Periodic-stitched fatigue-resistant Input Terminals Proprietary 8 AWG insulated all-metal spring terminals Grille Included with integral trim ring Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With High-output mono amplifiers stable at 2 ohms (parallel wiring) rated at or near 800W RMS Mono amplifiers stable at 8 ohms (series wiring) for specific system configurations Rockford Fosgate Power T1 and T2 series mono amplifiers Custom ported and sealed enclosures designed for the T1D412 confirm recommended enclosure specifications with Rockford Fosgate documentation before building Rockford Fosgate 8 AWG and heavy-gauge wiring kits for high-current 2-ohm installations Rockford Fosgate RCA cables and signal processors for high-output system integration Competition and show car audio builds requiring a flagship 12" 2-ohm stable driver Australian vehicles where 12" driver diameter fits available enclosure space more practically than 15" Frequently Asked Questions What is the difference between the T1D412 and the T1 15" models? The T1D412 shares the same VAST technology, FlexFit basket, Kevlar cone, Nomex voice coil, and construction standard as the T1D415 and T1D215. The key differences are driver size (12" vs 15") and power handling (800W RMS vs 1000W RMS). The T1D412 suits builds where a 12" format is preferred for enclosure size, vehicle fitment, or system balance reasons. What is the difference between the T1D412 and T1D212? Both are 12" Power T1 subwoofers with identical 800W RMS power handling, VAST technology, FlexFit basket, and construction. The T1D412 has dual 4-ohm coils (2-ohm parallel / 8-ohm series), while the T1D212 has dual 2-ohm coils (1-ohm parallel / 4-ohm series). Choose the T1D412 for 2-ohm stable amplifier pairings; choose the T1D212 for 1-ohm stable amplifier pairings. What impedance does the T1D412 present to the amplifier? The T1D412 has dual 4-ohm voice coils. Wired in parallel, it presents a 2-ohm load the standard configuration for maximising power from a 2-ohm stable high-output mono amplifier. Wired in series, it presents an 8-ohm load. Confirm your amplifier's stable impedance rating before wiring. What enclosure does the T1D412 require? The T1D412 requires a custom or aftermarket enclosure. Rockford Fosgate publishes recommended sealed and ported enclosure specifications for the T1D412 confirm these with official documentation or a qualified installer before designing or building an enclosure. Does the T1D412 include a grille? Yes. The T1D412 ships with a grille and integral trim ring included, providing a finished, professional installation appearance without requiring a separately purchased grille. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T1D410 Power 10" T1 Dual 4-Ohm Subwoofer 600 Watts, VAST Technology, T1 Performance in 10" Product Overview The Rockford Fosgate T1D410 is a 10" dual 4-ohm voice coil subwoofer from the flagship Power T1 series, rated at 600 Watts RMS and 1200 Watts peak. Carrying the full Power T1 technology stack into the 10" format, the T1D410 delivers the same patented VAST cone technology, FlexFit die-cast aluminium basket, Kevlar fibre reinforced paper cone, Nomex-reinforced high-temp voice coil, and anodized aluminium construction as the T1 12" and 15" models in the most compact T1 driver size available, suited to enclosure and vehicle builds where 12" or 15" diameter is impractical. Patented VAST (Vertical Attach Surround Technique) technology increases effective cone surface area by up to 25% over a conventional surround attachment, allowing the T1D410 to deliver more bass output per watt than a standard 10" driver punching well above its physical size. The dual 4-ohm configuration wires in parallel to a 2-ohm load for maximum power delivery from a compatible high-output mono amplifier, or in series for an 8-ohm load for specific system configurations. Grille and integral trim ring included. Key Specifications Driver size: 10" Voice coil configuration: Dual 4-ohm (DVC) Wiring options: 2 ohm (parallel) / 8 ohm (series) Power handling: 600W RMS / 1200W peak Technology: Patented VAST up to 25% increased cone surface area Basket: FlexFit rigid die-cast aluminium Cone: Kevlar fibre reinforced paper Voice coil former: Anodized aluminium with copper-clad aluminium wire Voice coil reinforcement: Spun-laced Nomex collar (high-temp) Dust cap: Anodized aluminium heat-sinking Input terminals: Proprietary 8 AWG insulated all-metal spring terminals Spiders: Symmetrical dual progressive roll tear-resistant poly-cotton Tinsel leads: Periodic-stitched fatigue-resistant Grille: Included with integral trim ring Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits Patented VAST technology up to 25% more cone surface area: VAST (Vertical Attach Surround Technique) repositions the surround attachment point to reclaim up to 25% of the cone area traditionally covered by the surround. In a 10" driver where every square centimetre of piston area counts, this technology delivers meaningfully more output per watt than a conventional 10" design performing like a larger woofer from the same basket diameter. FlexFit rigid die-cast aluminium basket: Precision-cast for structural rigidity with installation geometry flexibility for custom fabrication and extreme builds where standard basket angles create clearance issues. The most practical basket design in the T1 range for compact enclosures and tight vehicle installations common in Australian hatchbacks, sedans, and utes. 600W RMS / 1200W peak power handling: High-output power handling in a 10" format. Suited to high-performance builds where 10" driver diameter is preferred for enclosure efficiency, vehicle fitment, or SPL output characteristics in smaller sealed or ported enclosures. Dual 4-ohm voice coils 2-ohm parallel or 8-ohm series wiring: Wired in parallel, the T1D410 presents a 2-ohm load for maximum power delivery from a 2-ohm stable mono amplifier. Wired in series, it presents an 8-ohm load for specific bridged or multi-driver configurations. Choose the T1D410 when a 2-ohm stable amplifier pairing is the system target. High-temp voice coil with spun-laced Nomex reinforcement collar: Nomex reinforcement at the critical former-to-cone junction prevents delamination under sustained 600W RMS, high-excursion use maintaining structural integrity at the power levels a T1 10" is designed to handle continuously. Anodized aluminium voice coil former with copper-clad aluminium wire: Superior heat dissipation compared to paper or plastic formers. Copper-clad aluminium winding reduces moving mass while maintaining conductivity, improving transient response and efficiency particularly beneficial in a 10" driver where cone mass directly affects high-frequency bass extension and punch. Kevlar fibre reinforced paper cone: Stiffness and break-up resistance without excessive weight. Maintains accurate pistonic motion at the high excursion levels a 600W RMS 10" driver operates at, where an unreinforced cone would distort and lose accuracy. Anodized aluminium heat-sinking dust cap: Active heat sink during sustained high-power use, drawing thermal energy away from the pole piece and voice coil gap contributing directly to long-term reliability in compact, sealed enclosure environments where heat buildup is accelerated. Optimised pole piece and spider venting: Internal air channels reduce compression behind the cone at high excursion levels, improving linearity and bass accuracy particularly important in compact sealed enclosures where back-pressure management is critical. Proprietary 8 AWG insulated all-metal spring input terminals: Heavy-gauge terminals appropriate for the current demands of a 600W RMS, 2-ohm system. Consistent with the terminal standard across the entire Power T1 subwoofer range. Symmetrical dual progressive roll poly-cotton spiders: Dual spider configuration provides linear restoring force symmetry across the full excursion range, reducing harmonic distortion and maintaining voice coil alignment at high displacement levels. Periodic-stitched fatigue-resistant tinsel leads: Periodic stitching distributes flex stress along a longer lead length, extending tinsel lead fatigue life at the sustained high-excursion levels the T1D410 is designed for. Grille and integral trim ring included: Ships complete with protective grille and trim ring for a finished, professional installation appearance. Technical Specs Specification Detail SKU T1D410 Brand Rockford Fosgate Driver Size 10" Voice Coil Configuration Dual 4-ohm (DVC) Wiring Options 2 ohm (parallel) / 8 ohm (series) Power Handling 600W RMS / 1200W peak Technology Patented VAST up to 25% increased cone surface area Basket FlexFit rigid die-cast aluminium Cone Kevlar fibre reinforced paper Dust Cap Anodized aluminium heat-sinking Voice Coil Former Anodized aluminium Voice Coil Wire Copper-clad aluminium Voice Coil Reinforcement Spun-laced Nomex collar (high-temp) Spiders Symmetrical dual progressive roll tear-resistant poly-cotton Tinsel Leads Periodic-stitched fatigue-resistant Input Terminals Proprietary 8 AWG insulated all-metal spring terminals Grille Included with integral trim ring Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With High-output mono amplifiers stable at 2 ohms (parallel wiring) rated at or near 600W RMS Mono amplifiers stable at 8 ohms (series wiring) for specific system configurations Rockford Fosgate Power T1 and T2 series mono amplifiers Compact sealed and ported enclosures designed for the T1D410 confirm recommended enclosure specifications with Rockford Fosgate documentation before building Rockford Fosgate 8 AWG and heavy-gauge wiring kits for high-current 2-ohm installations Rockford Fosgate RCA cables and signal processors for high-output system integration Australian vehicles where 10" driver diameter is preferred for compact enclosure fitment: sedans, hatchbacks, SUVs, and utes with limited boot depth Frequently Asked Questions What is the difference between the T1D410 and the T1 12" and 15" models? The T1D410 shares the same VAST technology, FlexFit basket, Kevlar cone, Nomex voice coil, and construction standard as the T1D412, T1D415, and T1D215. The key differences are driver size and power handling 10" at 600W RMS versus 12" at 800W RMS and 15" at 1000W RMS. Choose the T1D410 when a 10" format suits your enclosure design or vehicle fitment requirements. What is the difference between the T1D410 and T1D210? Both are 10" Power T1 subwoofers with identical 600W RMS power handling, VAST technology, FlexFit basket, and construction. The T1D410 has dual 4-ohm coils (2-ohm parallel / 8-ohm series), while the T1D210 has dual 2-ohm coils (1-ohm parallel / 4-ohm series). Choose the T1D410 for 2-ohm stable amplifier pairings; choose the T1D210 for 1-ohm stable amplifier pairings. What impedance does the T1D410 present to the amplifier? The T1D410 has dual 4-ohm voice coils. Wired in parallel, it presents a 2-ohm load the standard configuration for maximising power from a 2-ohm stable high-output mono amplifier. Wired in series, it presents an 8-ohm load. Confirm your amplifier's stable impedance rating before wiring. What enclosure does the T1D410 require? The T1D410 requires a custom or aftermarket enclosure. Rockford Fosgate publishes recommended sealed and ported enclosure specifications for the T1D410 confirm these with official documentation or a qualified installer before designing or building an enclosure. Does the T1D410 include a grille? Yes. The T1D410 ships with a grille and integral trim ring included, providing a finished, professional installation appearance without requiring a separately purchased grille. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less
